tp-link VIGI SP6030 Intelligent Solar Power Supply System 60W / 31.2Ah/10.8V Lithium Battery


  • 60W Photovoltaic Panel and 31.2Ah/10.8V Lithium Battery
  • 3× DC Voltage Output Ports
  • Modular Design
  • 5°/15°/25°/35°/45°/55° Adjustable Angles
  • Intelligent Auxiliary Heating Technology
  • Maximum Power Point Tracking (MPPT) Charging Controller
  • IP66 Weatherproof
  • Remote Management and Simple Installation

VIGI SP6030(UN)1.0 Datasheet

VIGI App Guide

VIGI SP9030_Installation Guide

$849.00 inc GST +3 Year Warranty & Support

Recommended Camera Models

  • VIGI C540-4G × 1

Highlights

  • Working Hours on Consecutive Rainy Days: 6.4 Days
  • On-load Charge on Sunny Days: 2.7 Days
  • The data is based on TP-Link laboratory and public meteorological data obtained through model simulation. It only serves as a reference for network selection. Actual data may vary due to regional disparities, seasonal climate conditions, equipment power consumption, solar panel installation angles, and other factors. For accurate information, please refer to real-world applications and conditions.

    On-load charge days is the time it takes for the battery to charge from 0% to 100% under load.



SOLAR PANEL (PHOTOVOLTAIC PANEL)
Power 60 W
Voltage 18 V
Dimensions (L x W x H) 690×516×30 mm (27.2×20.3×1.2 in)
BATTERY
Type Lithium
Intelligent Auxiliary Heat Yes
Battery Capacity 31.2 Ah
Voltage 10.8 V
Max. Output Voltage 12.6 V
Life More than 500 cycles
Dimension 242×70×65 mm (9.5×2.8×2.6 in)
Charging Condition • 0°C~45°C
• -30°C~45°C (With intelligent auxiliary heating)
Discharging Condition • -20°C~60°C
• -30°C~60°C (With intelligent auxiliary heating)
ANGLE ADJUSTMENT (MANUAL)
Range 5°/15°/25°/35°/45°/55°
HARDWARE
Interface • 1× 10/100 Mbps RJ45
• 1× Photovoltaic Panel Connector
• 3× 5.5mm DC Power Plugs (#1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A)
Indicator LED • Quantity: 4 (1× SYS Indicator, 1× LAN Indicator, 1× PV Indicator, 1× BAT Indicator)
• Color: Blue
SOFTWARE FEATURES
Load Control Yes
High and Low Temperature Protection Yes
Overdischarge Protection Yes
Power Consumption Statistics Yes
Displays Real-time Load Status Yes
Battery Level Display Yes
Time Zone Selection Yes
Region Selection Yes
Schedule Saving Yes
Firmware Remote Update Yes
Remote Reboot Yes
Local LAN Management Yes
Smart Charging Control -30°C~5°C
Account Management Yes
Web Management Yes
Remote Reset Yes
Remote Message Push Yes
OTHERS
Certification • CB, PSE (Battery)
• CE, FCC, VCCI, IC, IP66
Package Contents • VIGI SP6030
• Quick Start Guide
• Waterproof Cable Attachments
• Mounting Accessories
Box Dimensions (W X D X H) 800×615×225 mm (31.5×24.2×8.9 in)
Weight • Product Weight: 14 kg
• Package Weight: 15.5 kg
Environment • Operating Temperature: -30°C-60°C (With intelligent auxiliary heating)
• Operating Humidity: 10%~90%RH, Non-condensing
SKU: VIGI SP6030 Categories: ,
