Camera
S/N Ratio: > 52dB
Shutter Speed: 1/1 ~ 1/30,000s
Optical Zoom: 30X
Digital Zoom: 12X
Signal System: PAL/NTSC
Focus Mode: Auto/ Semiautomatic/ Manual
Day & Night: IR Cut Filter
Image Sensor: 1/3’’ Progressive Scan CMOS
Min. Illumination: Color: 0.05 Lux @ (F1.6, AGC ON), B/W: 0.01Lux @ (F1.6, AGC ON), 0 Lux with IR
Lens
Aperture Range: F1.6 to F4.4
Movement Range (Pan): 360° endless
Focal Length: 4.5 mm to 135 mm, 30× optical
Movement Range (Tilt): From -15° to 90° (Auto-flip)
Working Distance: 10 mm to 1500 mm (wide-tele)
FOV: Horizontal field of view: 65.1° to 2.34° (wide-tele)
Zoom Speed: Approx. 4 s (optical lens, wide-tele)
White Balance: Auto1/ Auto2/ Indoor/ Outdoor/ Manual/ Daylight lamp/ Sodium lamp
Resolution: 50Hz: 25fps (1920 × 1080), 60Hz: 30fps (1920 × 1080),
50HZ: 25fps(1280×720), 60HZ: 30fps(1280×720)
Digital WDR: Support
H.264 Type: Baseline Profile/Main Profile/High Profile
Video Compression: H.265/H.264+/H.264
3D DNR: Support
Video Bitrate: 32 Kbps to 8 Mbps
H.265 Type: Main Profile
Infrared
IR Intensity: Automatically adjusted, depending on the zoom ratio
IR Distance: Up to 60m
System Integration
Blacklist: Up to 100,000 items can be saved.
Communication: Support 3G (WCDMA) (Baseline model);
Support 4G (Customization needed)
Support double 3G or 4G modular (Customization needed)
Smart Function: License Plate Recognition
External Interfaces: Alarm I/O, Serial Port, Network Interface
GPS System: Support GPS
Onboard Storage: Double Built-in SD/SDXC card slot, up to 128GB
WI-FI: 802.11a/b/g/n
Protocols: IPv4/IPv6, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP
Bluetooth: BT4.0
General
Protection Level: IP66 standard, TVS 4,000V lightning protection, surge protection and voltage transient protection
Power Consumption: Approx. 15W
Power : 8VDC to 36VDC
Working Temperature/ Humidity: From -20 °C to 60 °C (From -4 °F to 140 °F), Humidity 90% or less
Weight: Approx. 2.8kg (6.17lb) with battery
