Product SKU: WRN-810S
Product Overview
Built around Hanwha Vision’s Wisenet WAVE video management platform, the WRN-810S is an 8-channel PoE+ NVR designed for professional IP surveillance installations where a more capable VMS-style interface is preferred over a basic standalone recorder. Unlike conventional plug-and-play NVRs, this unit ships preloaded with Ubuntu Linux 18.04 LTS and the Wisenet WAVE client and server software, giving installers and end users access to a scalable platform for live view, recording, playback and multi-site remote access from the moment it is commissioned. Equipped with 8 built-in PoE/PoE+ camera ports and a 100W PoE budget, it simplifies camera cabling by eliminating the need for a separate PoE switch. With 2 x Gigabit uplink ports, dual HDMI and VGA local outputs, 4 alarm inputs, and a compact 1U rack-mountable chassis, the WRN-810S is suited to small to medium commercial installations where professional presentation and VMS flexibility are both required. Note: Hanwha has released a replacement model for this unit. Please check the Additional Information section below for the current successor product.
Key Capabilities
Wisenet WAVE VMS Platform
The WRN-810S ships with Wisenet WAVE client and server software preloaded on a dedicated 32GB eMMC OS drive. This separates the operating system from recording storage and provides a structured VMS environment for camera management, event handling and remote access, rather than the limited interface of a basic NVR.
8 x Built-In PoE/PoE+ Ports
All 8 camera channels are powered directly from the recorder via PoE/PoE+ RJ45 ports, with a shared 100W budget. This removes the need for a dedicated PoE switch in smaller installations and keeps the comms cabinet tidy, provided the total camera power draw stays within budget.
Dual Gigabit Uplink Ports
Two independent Gigabit WAN RJ45 ports allow the recorder to connect to a wider network, router or surveillance backbone without bandwidth bottlenecks. This is particularly useful where the NVR must serve remote access and local recording simultaneously on a commercial network.
Up to 12TB Internal Storage
Two SATA data drive bays support up to 12TB of internal recording storage, keeping the OS and recording drives fully separated. With 80Mbps recording throughput, storage capacity should be sized against the resolution, frame rate and compression settings planned for each camera channel.
1U Rack-Mountable Chassis with Alarm I/O
The compact 1U form factor fits standard comms racks and equipment cabinets with rack mount brackets included. The addition of 4 alarm inputs and 2 alarm outputs supports integration with door contacts, PIR sensors or output devices, making it more than a basic recording unit for professionally designed systems.
Best For
- Professional Installers Requiring WAVE VMS: Sites that need a structured video management interface with remote access, mobile app support and WAVE Cloud Sync rather than a basic standalone recorder.
- Rack-Mounted Comms Cabinet Installations: The 1U chassis and included rack mount brackets make the WRN-810S a natural fit for commercial comms rooms and equipment racks where a clean, professional layout is required.
- 8-Camera Commercial Systems Using Hanwha IP Cameras: Installations built around Hanwha Vision IP cameras benefit from native WAVE compatibility, with ONVIF support extending flexibility to third-party cameras where needed.
- Sites Needing Integrated PoE Without a Separate Switch: Smaller commercial deployments where keeping the equipment count low matters, as all 8 camera ports deliver PoE/PoE+ directly from the recorder.
Why Choose the WRN-810S
What separates the WRN-810S from a standard 8-channel NVR is the Wisenet WAVE platform embedded into the hardware itself. Rather than relying on basic proprietary firmware, this recorder runs Ubuntu Linux 18.04 LTS with a dedicated 32GB eMMC OS drive, leaving the 2 SATA data bays entirely for recording. The dual Gigabit WAN ports, 4 alarm inputs, 2 alarm outputs and ONVIF compliance add professional-grade flexibility that simpler recorders lack. The 100W PoE budget across 8 ports and the 80Mbps recording throughput make this a well-rounded unit for carefully designed 8-camera IP systems. Buyers who need VMS-style video management, rack-mount form factor and integrated PoE in a single unit will find the WRN-810S addresses all three. Available through Security Wholesalers, this unit suits professional installers who want WAVE functionality without the cost of a separate server-based WAVE deployment.
Buyer Decision Tips
Check PoE Budget Against Your Camera Selection: The WRN-810S provides 100W across all 8 PoE/PoE+ ports. If your planned cameras are power-hungry models such as PTZ units or cameras with heaters, calculate the total draw before purchasing. For lower-power fixed cameras, the 100W budget is generally adequate across all 8 channels.
Confirm WAVE Licence Inclusion for Australian Stock: Wisenet WAVE licensing requirements vary by region and package. Hanwha’s North American documentation references a bundled licence count, but Australian stock specifications may differ. Confirm WAVE licence inclusions with your supplier before purchase to avoid unexpected software costs at commissioning.
Key Features & Technical Specifications
| Model |
WRN-810S |
| Channels |
8 channels |
| Recording Bandwidth |
Up to 80Mbps |
| PoE Ports |
8 x RJ45 PoE/PoE+ (10/100Mbps) |
| Total PoE Budget |
100W |
| Network Uplink Ports |
2 x RJ45 Gigabit WAN (1Gbps) |
| Internal Storage |
Up to 12TB |
| Drive Bays |
2 x SATA data drive bays |
| OS Drive |
32GB eMMC (dedicated, separate from recording storage) |
| Operating System |
Ubuntu Linux 18.04 LTS |
| Video Outputs |
1 x HDMI, 1 x VGA |
| USB Ports |
3 total (1 x front, 2 x rear) |
| Alarm I/O |
4 inputs / 2 outputs |
| ONVIF Compliance |
Yes |
| Power Input |
100-240V AC |
| Power Consumption |
37W (excluding PoE output) |
| Dimensions |
370mm x 50.7mm x 320mm |
| Weight |
2.78kg |
| Operating Temperature |
0°C to 40°C |
| Form Factor |
1U rack-mountable |
| Included Accessories |
USB mouse, rack mount brackets |
Ideal Use Cases
Commercial Retail and Office Sites
Small retail shops and office environments with up to 8 cameras benefit from the WRN-810S’s integrated PoE ports, WAVE VMS management and local HDMI display output, reducing the hardware required to stand up a tidy, professionally managed system.
Warehouses and Light Industrial Sites
Sites requiring alarm input integration alongside IP camera recording will find the 4 alarm inputs and 2 alarm outputs useful for connecting door contacts or motion-triggered devices to a centralised WAVE-managed recording environment.
Comms Cabinet and Rack Installations
The 1U rack-mountable chassis and included rack brackets make this recorder appropriate for installations where equipment is centralised into a cabinet. The compact 370mm depth keeps it compatible with standard shallow-depth racks.
Hanwha Vision IP Camera Systems
Installers deploying Hanwha Vision IP cameras get the most from the WRN-810S through native Wisenet WAVE compatibility, including WAVE client, mobile app access and Cloud Sync support for scalable multi-site management.
Mixed-Brand IP Camera Deployments
ONVIF compliance means the WRN-810S is not limited to Hanwha cameras. Sites that have existing third-party ONVIF-conformant cameras can integrate them into the WAVE platform alongside any Hanwha cameras in the same system.
Choosing the Right Model
- Choose this model if: You need an 8-channel WAVE VMS-based NVR with integrated PoE, rack-mount form factor, dual Gigabit uplinks and alarm I/O for a professionally installed commercial system, and you have confirmed availability of this unit with your supplier.
- Choose a different model if: You require more than 8 channels, a higher PoE budget for power-hungry cameras, or you are planning a new installation and want a current-generation WAVE NVR. Hanwha has released a successor to this unit, which is linked in the Additional Information section below and may better suit new system designs.
- Choose a different model if: Your site does not need WAVE VMS features and a simpler plug-and-play NVR would meet your recording requirements at a lower cost. The WAVE platform adds value for multi-site management and AI camera integration, but introduces licensing considerations that may not be necessary for basic recording-only deployments.
FAQs
- Is the WRN-810S a standard NVR or a Wisenet WAVE recorder?
The WRN-810S is specifically designed as a Wisenet WAVE PoE+ NVR. It ships preloaded with Ubuntu Linux 18.04 LTS and the Wisenet WAVE client and server software, making it a VMS-based recorder rather than a conventional standalone NVR. This distinction affects how cameras are managed, how playback works and how the system scales across sites.
- How many cameras can the WRN-810S support?
The WRN-810S supports up to 8 IP camera channels. All 8 channels have corresponding PoE/PoE+ ports on the recorder itself, so no separate PoE switch is required for a full 8-camera installation, provided the total camera power draw remains within the 100W PoE budget.
- What is the total PoE power budget and how does it affect camera selection?
The total PoE budget is 100W shared across all 8 ports. Standard fixed IP cameras typically draw between 6W and 15W each, so most 8-camera configurations will fit comfortably within this budget. However, PTZ cameras or cameras with active heating elements can draw significantly more power and may require a separate PoE switch or injector for those specific channels.
- How much internal storage does the WRN-810S support, and how is it organised?
The WRN-810S supports up to 12TB of recording storage across 2 SATA data drive bays. A separate dedicated 32GB eMMC drive handles the operating system, so the full capacity of the SATA drives is available for camera footage. HDDs should be selected from Hanwha’s compatibility list to ensure stable operation.
- Does the WRN-810S work with non-Hanwha cameras?
Yes. The WRN-810S is listed as ONVIF camera compliant, allowing compatible third-party IP cameras to be added alongside Hanwha Vision cameras. However, advanced WAVE features such as AI metadata search and smarter event workflows are typically more fully supported when using compatible Hanwha AI cameras.
- Do I need to purchase WAVE licences separately?
The WRN-810S ships with the Wisenet WAVE software preloaded for quick deployment. However, WAVE licence inclusions vary by region and package. Licence requirements for Australian stock should be confirmed with your supplier before commissioning to avoid unexpected costs. Security Wholesalers can assist with clarifying what is included for the Australian market.
- Is the WRN-810S still a current product?
Hanwha has released a replacement model for the WRN-810S. The successor unit is linked in the Additional Information section below. Buyers planning a new installation should review both options to confirm which model is currently available and best matched to their system requirements. Stock availability of the WRN-810S should be confirmed with your supplier prior to ordering.
