Dahua DH-IPC-HDBW2831E-S-S2 8MP Lite IR Fixed-focal Dome Network Camera


With upgraded H.265 encoding technology, Dahua Lite series network camera has efficient video encoding capacity, which saves bandwidth and storage space. This camera adopts the latest starlight technology and displays better color image in the condition of low illumination. It supports SD card storage, dust-proof function, waterproof function and vandal-proof function, complying to the standards of IP67 and IK10

DH-IPC-HDBW2831E-S-S2 Specification Sheet

> 8MP, 1/2.7″ CMOS image sensor, low illuminance, high image definition
> Outputs max. 8MP (3840 × 2160) @15 fps, and supports 2688×1520 @25/30 fps
> H.265 codec, high compression rate, ultra-low bit rate
> Built-in IR LED, max IR distance: 30 m
> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire
> Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection
> Supports max. 256 GB Micro SD card
> 12V DC/PoE power support
> IP67, IK10 protection

$274.85 $350.00 inc GST +3 Year Warranty & Support

> 8MP, 1/2.7″ CMOS image sensor, low illuminance, high image definition
> Outputs max. 8MP (3840 × 2160) @15 fps, and supports 2688×1520 @25/30 fps
> H.265 codec, high compression rate, ultra-low bit rate
> Built-in IR LED, max IR distance: 30 m
> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

Sample 8MP Videos from a similar Dahua camera

ImageNamePriceBuy
Dahua DH-PFB203W Water-Proof Wall Mount Bracket$21.00 inc GST +3 Year Warranty & Support
Dahua DH-PFA136 Water-Proof Junction Box$12.00 inc GST +3 Year Warranty & Support
Camera
Image Sensor 1/2.7” 8Megapixel progressive CMOS
Effective Pixels 3840 (H) × 2160 (V)
ROM 128 MB
RAM 256 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.009 Lux@F2.0
IR Distance 30 m (98.43 ft)
IR On/Off Control Auto/Manual
IR LEDs Number 3
Pan/Tilt/Rotation Range Pan: 0°–355°

Tilt: 0°–65°

Rotation: 0°–355°

Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 2.8 mm
3.6 mm (not available)
Max. Aperture F2.0

F2.0

Field of View 2.8 mm: Pan 105° × Tilt 56° × Diagonal 125°

3.6 mm: Pan 87° × Tilt 47° × Diagonal 104°

Iris Type Fixed
Close Focus Distance 2.8 mm: 1.0 m (3.3 ft)
3.6 mm: 1.9 m (6.2 ft)
DORI Distance Lens Detect Observe Recognize Identify
2.8mm 74.7 m
(245.1 ft)
29.9 m
(98.1 ft)
14.9 m
(48.9 ft)
7.5 m
(24.6 ft)
3.6mm 106.7 m
(350.1 ft)
42.7 m
(140.1 ft)
21.3 m
(69.6 ft)
10.7 m
(35.1 ft)
Smart Event
General IVS Analytics Tripwire; intrusion
Video
Video Compression H.265; H.264; H.264B; MJPEG
Smart Codec Yes
Video Frame Rate Main stream:

3840 × 2160 (1 fps–15 fps)

2688 × 1520 (1 fps–25/30 fps)

Sub stream:

704 × 576 (1 fps–25 fps)

704 × 480 (1 fps–30 fps)

Stream Capability 2 streams
Resolution 3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 32 Kbps–8192 Kbps

H.265: 12 Kbps–8192 Kbps

Day/Night Auto(ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
White Balance Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest(RoI) Yes (4 areas)
Smart IR Yes
Image Rotation 0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.)
Mirror Yes
Privacy Masking 4 areas
Network
Network RJ-45 (10/100 Base-T)
Protocol IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour
Interoperability ONVIF(Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host 20
Edge Storage Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
Browser IE

Chrome

Firefox

Management Software Smart PSS; DSS; DMSS
Mobile Phone IOS; Android
Certification
Certifications CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Power
Power Supply 12V DC/PoE (802.3af)
Power Consumption < 6.2W
Environment
Power Consumption –40°C to +60°C (–40°F to +140°F)/less than ≤ 95% RH
Storage Temperature –40°C to +60°C (–40°F to +140°F)
Protection Grade IP67; IK10
Structure
Casing Metal
Dimensions 81 mm × Φ109.9 mm (3.19″ × Φ4.33″)
Net Weight 0.350 kg (0.77 lb)
Gross Weight 0.491 kg (1.08 lb)
