| Camera |
| Sensor |
1/3″, 4.0 megapixel, progressive scan, CMOS |
| Lens |
2.8mm@F1.6 |
| DORI Distance |
Lens |
Detect(m) |
Observe(m) |
Recognize(m) |
Identify(m) |
| 2.8mm |
63 |
25.2 |
12.6 |
6.3 |
| Angle of View(H) |
105.3° |
| Angle of View (V) |
57° |
| Angle of View (O) |
136.9° |
| Adjustmentangle |
Pan: 0°~360° |
Tilt:0°~80° |
Rotate:0°~360° |
| Shutter |
Auto/Manual, shutter time: 1~1/100000 s |
| Minimum Illumination |
Colour: 0.005 Lux (F1.6, AGC ON)
0 Lux with IR on |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Digital noise reduction |
2D/3D DNR |
| S/N |
>52 dB |
| IR Range |
Up to 30m (98 ft) IR range |
| Wavelength |
850nm |
| IR On/Off Control |
Auto/Manual |
| Defog |
Digital Defog |
| WDR |
120dB |
| Video |
| Video Compression |
Ultra 265,H.265, H.264, MJPEG |
| H.264 code profile |
Baseline profile, Main Profile, High Profile |
| Frame Rate |
Main Stream:4MP (2688*1520), Max 25fps; 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 2MP (1920*1080), Max 30fps;
Sub Stream: 720P (1280*720), Max 25fps |
| Video Bit Rate |
128 Kbps~16 Mbps |
| HLC |
Supported |
| BLC |
Supported |
| OSD |
Up to 4 OSDs |
| Privacy Mask |
Up to 4 areas |
| ROI |
Up to 4 areas |
| Motion Detection |
Up to 4 areas |
| Image |
| White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction |
2D/3D DNR |
| Smart IR |
Supported |
| Flip |
Normal/Vertical/Horizontal/180° |
| Dewarping |
Support |
| Audio |
| Audio Compression |
G.711 |
| Suppression |
Supported |
| Sampling Rate |
8 KHZ |
| Storage |
| Edge Storage |
Micro SD, up to 256 GB |
| Network Storage |
ANR |
| Network |
|
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL |
| Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API |
| Client |
EZStation ,EZView ,EZLive |
| Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
| Interface |
| Network |
10M/100M Base-TX Ethernet |
| Built-in Mic |
Supported |
| Certifications |
| Certifications |
CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15 |
| General |
| Power |
12 V DC±25%,PoE (IEEE802.3 af)
Power consumption: Max 3.0 W |
| Dimensions (L × W × H) |
Φ118 x 96mm (Φ4.6” x 3.8”) |
| Weight |
0.35kg (0.77lb) |
| Material |
Front cover：metal
Rear cover：plastic
Bracket：plastic
Bottom plate：metal |
| Working Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Strorage Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection |
2KV |
| Ingress Protection |
IP67 |
