Product SKU: TP-Link InSight S455
Product Overview
The TP-Link InSight S455 is a state-of-the-art 5MP full-colour turret network camera engineered for dependable, high-performance surveillance. Delivering crystal-clear, high-definition video day and night, it offers 24/7 full-colour capability for vivid, detailed footage even in low-light conditions. This model features advanced People & Vehicle Analytics and Human & Vehicle Classification, ensuring more accurate event detection while reducing false alarms. Two-way audio allows for real-time communication, enhancing both monitoring and deterrence capabilities. Built to withstand harsh environments, the InSight S455 boasts an IP67 weatherproof rating and utilises H.265+ compression technology for efficient storage and bandwidth usage. Part of TP-Link’s VIGI series, it supports smart detection modes such as intrusion and loitering detection, making it a reliable choice for commercial, industrial, and residential security.
Key Capabilities
24/7 Full-Colour Surveillance
Capture rich, detailed video around the clock with full-colour capability, ensuring vital visual information is retained even in challenging low-light environments.
Advanced Human & Vehicle Classification
Accurately distinguish between people, vehicles, and irrelevant motion to reduce false alarms and focus only on important events.
Two-Way Audio
Communicate instantly via the built-in microphone and speaker, enabling real-time interaction and deterrence in monitored areas.
Weatherproof IP67 Design
Operates reliably in rain, dust, and extreme temperatures, making it suitable for both indoor and outdoor installations.
Smart Event Detection
Includes intrusion detection, loitering detection, and object removal alerts, providing customisable and precise monitoring to match specific security needs.
Key Features
- 5MP high-resolution turret camera with full-colour night vision
- Human & vehicle classification for accurate event alerts
- Two-way audio with built-in microphone and speaker
- Smart detection modes including intrusion and loitering detection
- IP67 weatherproof housing for reliable outdoor use
- H.265+ compression for efficient storage and bandwidth usage
- Wide field of view with 2.8mm or 4mm fixed lens options
Specifications Summary
- Lens Type: Fixed
- Focal Length and FOV: 2.8mm (H: 111.4°, V: 58.8°, D: 134°) / 4mm (H: 88°, V: 46°, D: 105.4°)
- DORI Distance: 2.8mm – Detect: 64m, Recognise: 13m / 4mm – Detect: 80m, Recognise: 16m
- Audio Type: Two-way audio with built-in mic and speaker
- Night Vision Range (IR/White Light): Up to 30m
Technical Specifications
- Image Sensor: 1/2.7″ Progressive Scan CMOS
- Resolution: 2880 × 1620
- Minimum Illumination: 0.005 Lux; 0 Lux with IR/White light
- Lens Options: 2.8mm or 4.0mm fixed lens
- Shutter Speed: 1/3 to 1/10,000s
- Audio: Built-in microphone and speaker
- Day/Night Mode: IR Cut Filter
- Ingress Protection: IP67
- Video Compression: H.265+, H.265, H.264+, H.264
Choosing Between the 2.8mm and 4mm Lens
The TP-Link InSight S455 is available in two fixed lens options—2.8mm and 4mm—allowing you to tailor the field of view to your application:
| Lens |
Field of View |
Best For |
Notes |
| 2.8mm |
Horizontal: 111.4°, Vertical: 58.8°, Diagonal: 134° |
Wider coverage |
Ideal for open areas like yards or shop floors |
| 4.0mm |
Horizontal: 88°, Vertical: 46°, Diagonal: 105.4° |
More focused coverage |
Best for entrances, corridors, or targeted areas |
Tip:
Choose 2.8mm for wide, close-range coverage.
Choose 4mm for capturing detail at longer distances.
Add Hard Drive
IN THE BOX
Additional Information
Product Video Samples
Full Specifications Table
| Image Sensor |
1/2.7” Progressive Scan CMOS |
| Resolution |
2880 × 1620 |
| Minimum Illumination |
0.005 Lux; 0 Lux with IR/White light |
| Lens |
2.8mm or 4mm Fixed Lens |
| FOV |
2.8mm: H: 111.4°, V: 58.8°, D: 134° / 4mm: H: 88°, V: 46°, D: 105.4° |
| Night Vision |
Up to 30m (IR & White Light) |
| Audio |
Two-way audio, built-in mic & speaker |
| Ingress Protection |
IP67 |
| Video Compression |
H.265+, H.265, H.264+, H.264 |
TP-Link Warranty
TP-Link 3-Year Manufacturer Warranty
All TP-Link IP cameras and recording devices (NVRs/DVRs) are covered by a 3-year back-to-base manufacturer warranty.
Note: Disk drives are limited to a 3-year warranty.
