Ruijie Reyee RG-RAP72Pro-OD BE7200 Wi-Fi 7 Tri-Band Outdoor Access Point with 2.5G Ethernet PoE IP68 & Cloud Management

$411.74
FREE DELIVERYWARRANTY GUARANTEED
SW ADVANTAGE✓ Trade-Price Verified✓ Priority Tech Support✓ Dedicated After-Sales Support✓ Easy Returns & Warranty

Ruijie Reyee RG-RAP72Pro-OD BE5040 Wi-Fi 7 Outdoor Access Point | Dual-Band 2.4GHz & 5GHz | Up to 5011Mbps | 5 Spatial Streams | Multi-Link Operation (MLO) | 2.5G Ethernet | PoE/PoE+ | Reyee Mesh | IP65 Weatherproof | Cloud Management

The Ruijie Reyee RG-RAP72Pro-OD delivers a BE5040 Wi-Fi 7 dual-band indoor/outdoor wireless access point designed for cafés, hospitality venues, commercial entrances, outdoor dining areas and recreational spaces requiring reliable wireless connectivity. Featuring five spatial streams with 2×2 MU-MIMO on 2.4GHz and 3×3 MU-MIMO on 5GHz, it provides combined theoretical wireless data rates of up to 5011Mbps alongside a 2.5Gbps Ethernet connection for high-speed network access.

This model integrates Wi-Fi 7 Multi-Link Operation, Reyee Mesh connectivity and AI-assisted roaming, making it a versatile wireless networking solution available at Security Wholesalers. It also supports centralised Ruijie Cloud management and standalone portal functionality for convenient network configuration and guest access management. Built with integrated omnidirectional antennas, an IP65 weatherproof enclosure and a -30°C to +65°C operating temperature range, the access point supports flexible wall or pole mounting in suitable indoor and outdoor environments.

Key Features

  • BE5040 Wi-Fi 7 Performance: Delivers combined theoretical wireless speeds up to 5011Mbps, including 4323Mbps on 5GHz and 688Mbps on 2.4GHz.
  • Five Spatial Streams: Combines 3×3 MU-MIMO on 5GHz with 2×2 MU-MIMO on 2.4GHz for efficient wireless connectivity across multiple devices.
  • Wi-Fi 7 Multi-Link Operation: Supports MLO technology to improve connection efficiency, reduce latency and enhance wireless performance with compatible devices.
  • 2.5G Ethernet & PoE: Includes one 10/100/1000/2500Mbps Ethernet port with IEEE 802.3af/at PoE power support for simplified network installation.
  • Reyee Mesh & Cloud Management: Supports Reyee Mesh, AI-assisted roaming, standalone portal functionality and remote network administration through Ruijie Cloud.
  • IP65 Outdoor Protection: Features a weatherproof enclosure, built-in omnidirectional antennas and a -30°C to +65°C operating temperature range with wall or pole mounting options.
IP65 Weatherproof Indoor and Outdoor Access Point

Additional Information

$411.74 inc GST +3 Year Warranty & Support

Product SKU: RG-RAP72Pro-OD

Product Overview

The Ruijie Reyee RG-RAP72Pro-OD is a BE5040 Wi-Fi 7 dual-band indoor/outdoor access point designed for patios, open dining areas, retail spaces, pools, hospitality venues and other locations requiring modern wireless performance with weather-resistant construction. It combines a 2×2 MU-MIMO 2.4 GHz radio with a 3×3 MU-MIMO 5 GHz radio for five spatial streams and a maximum combined wireless data rate of 5011 Mbps. Wi-Fi 7 technologies including Multi-Link Operation and Preamble Puncturing help improve wireless efficiency and resilience, while a 2.5GbE PoE/PoE+ interface provides high-speed wired backhaul. Reyee Mesh, standalone portal functions and Ruijie Cloud management simplify deployment across centrally managed commercial wireless networks.

Key Capabilities

BE5040 Wi-Fi 7 Performance

The RG-RAP72Pro-OD delivers up to 688 Mbps on 2.4 GHz and 4323 Mbps on 5 GHz, producing a combined maximum wireless data rate of 5011 Mbps.

Five Spatial Streams

A 2×2 MU-MIMO 2.4 GHz radio and 3×3 MU-MIMO 5 GHz radio provide five spatial streams for increased capacity and improved multi-user performance.

Wi-Fi 7 Multi-Link Operation

MLO allows compatible Wi-Fi 7 clients to use multiple frequency links, helping improve connection efficiency, resilience and latency under suitable network conditions.

Preamble Puncturing

Wi-Fi 7 Preamble Puncturing can avoid interference-affected portions of a channel while continuing to use clear spectrum, improving overall channel utilisation in congested environments.

2.5GbE PoE Uplink

A single 10/100/1000/2500BASE-T Ethernet port provides up to 2.5 Gbps wired connectivity and PoE/PoE+ powering from a compatible switch or injector.

Ruijie Cloud & Reyee Mesh

Reyee Mesh, AI roaming, WIO optimisation, standalone portal functions and cloud-based administration provide flexible management for distributed commercial wireless deployments.

Best For

  • Outdoor Hospitality: Weather-resistant construction and modern Wi-Fi 7 performance suit patios, open dining areas, pools and resort spaces.
  • Retail & Commercial Areas: Reyee Mesh, portal functions and cloud management suit customer-facing wireless networks.
  • High-Bandwidth Wireless: The 2.5GbE uplink provides more wired headroom than a conventional 1GbE access point.
  • Wi-Fi 7 Client Networks: MLO and Preamble Puncturing support newer compatible wireless devices and improve spectrum efficiency.
  • Indoor/Outdoor Transitional Areas: Wall or pole mounting and a slim weather-resistant enclosure suit spaces that combine indoor and exposed outdoor coverage.

Why Choose the RG-RAP72Pro-OD

The RG-RAP72Pro-OD brings modern Wi-Fi 7 capability to outdoor and semi-outdoor commercial environments without requiring a bulky industrial-style access point. Its five-stream radio design provides significantly more wireless capacity than entry-level dual-band outdoor APs, while MLO and Preamble Puncturing introduce Wi-Fi 7 efficiency improvements for compatible clients. A 2.5GbE interface helps ensure the wired uplink is less likely to become the performance bottleneck, and Reyee Mesh provides a straightforward expansion path. Available through Security Wholesalers, the RG-RAP72Pro-OD is particularly suitable for hospitality, retail and commercial deployments that need modern wireless performance, cloud management and weather-resistant installation.

Buyer Decision Tips

Buyer Tip: The RG-RAP72Pro-OD is a dual-band Wi-Fi 7 access point using 2.4 GHz and 5 GHz. It does not provide a 6 GHz radio, so choose a tri-band Wi-Fi 7 access point if 6 GHz operation is an essential project requirement.

Buyer Tip: Ruijie’s current weather rating is IP65 rather than IP68. IP65 is designed to protect against dust ingress and water jets, but installation location, cable entry, mounting and surrounding conditions still need to be appropriate for the site.

Key Features & Technical Specifications

Product Type Indoor/outdoor versatile Wi-Fi 7 access point.
Model RG-RAP72Pro-OD.
Wireless Generation Wi-Fi 7.
Wireless Class BE5040.
Band Configuration Dual-band 2.4 GHz and 5 GHz.
6 GHz Radio No.
Radio Design Dual radio, 5 spatial streams.
2.4 GHz Radio 2 × 2 MU-MIMO.
5 GHz Radio 3 × 3 MU-MIMO.
Maximum Wireless Data Rate 5011 Mbps combined theoretical rate.
2.4 GHz Maximum Rate 688 Mbps.
5 GHz Maximum Rate 4323 Mbps.
Multi-Link Operation Supported for compatible Wi-Fi 7 clients.
Preamble Puncturing Supported.
Reyee Mesh Supported.
WIO WIO 3 intelligent wireless optimisation supported.
Standalone AP Portal Supported.
Heatmap Supported through the Ruijie management ecosystem.
AI Roaming Supported.
Antennas 2 × integrated 2.4 GHz/5 GHz built-in omnidirectional antennas plus 1 × additional 5 GHz built-in omnidirectional antenna.
Ethernet Port 1 × 10/100/1000/2500BASE-T.
Maximum Wired Rate 2.5 Gbps.
Power Supply PoE/PoE+.
Local DC Power Not supported.
Maximum Power Consumption 21 W.
Maximum Associated Clients – 2.4 GHz 64.
Maximum Associated Clients – 5 GHz 511.
Maximum Associated Clients – Dual Band 511 total.
Maximum Managed Devices 300.
IPv6 Supported.
Cloud Management Ruijie Cloud supported.
Mounting Wall or pole mounting.
IP Rating IP65.
Operating Temperature -30°C to +65°C.
Dimensions 90 × 46 × 239 mm excluding mounting bracket.
Weight ≤0.7 kg without packaging.
Colour White.

Ideal Use Cases

Open Dining Areas

Weather-resistant construction and modern Wi-Fi 7 performance suit restaurants, cafés and hospitality spaces with outdoor customer seating.

Patios & Courtyards

Wall or pole mounting and discreet integrated antennas suit semi-outdoor areas where conventional indoor access points are unsuitable.

Retail Outdoor Areas

Reyee Mesh, standalone portal functions and AI roaming support centrally managed customer and staff wireless networks.

Pools & Recreation Spaces

The IP65 enclosure and broad operating-temperature range suit appropriately installed pool surrounds and outdoor recreation areas.

High-Speed Commercial Wi-Fi

A 2.5GbE uplink and five-stream Wi-Fi 7 radio design suit businesses upgrading from conventional Wi-Fi 5 or Wi-Fi 6 outdoor access points.

Choosing the Right Model

  • Choose the RG-RAP72Pro-OD if: You need Wi-Fi 7, 2.5GbE, MLO, Preamble Puncturing and weather-resistant outdoor/indoor installation.
  • Choose a tri-band Wi-Fi 7 model if: Your deployment specifically requires 6 GHz wireless operation.
  • Choose an IP68 model if: The environment requires a higher ingress-protection level than the RG-RAP72Pro-OD’s IP65 rating.
  • Choose a Wi-Fi 6 outdoor model if: Client devices do not require Wi-Fi 7 and a lower-cost AX-class access point provides sufficient capacity.

FAQs

  1. What wireless performance does the Ruijie Reyee RG-RAP72Pro-OD provide?
    The Ruijie Reyee RG-RAP72Pro-OD is a BE5040-class Wi-Fi 7 dual-band access point with a maximum wireless data rate of 5011 Mbps. Ruijie specifies up to 688 Mbps on 2.4 GHz and 4323 Mbps on 5 GHz. It uses five spatial streams in total, with a 2 × 2 MU-MIMO 2.4 GHz radio and a 3 × 3 MU-MIMO 5 GHz radio. Actual throughput depends on client capability, interference, channel conditions and the wired uplink.
  2. Is the RG-RAP72Pro-OD a tri-band Wi-Fi 7 access point?
    No. Ruijie’s current specification lists the RG-RAP72Pro-OD as a dual-radio, dual-band Wi-Fi 7 access point using 2.4 GHz and 5 GHz. It does not provide a 6 GHz radio. The 5 GHz radio reaches up to 4323 Mbps and the 2.4 GHz radio up to 688 Mbps, producing a combined maximum wireless data rate of 5011 Mbps.
  3. Does the RG-RAP72Pro-OD have a 2.5G Ethernet port?
    Yes. The RG-RAP72Pro-OD provides one 10/100/1000/2500BASE-T Ethernet port, giving it up to 2.5 Gbps wired connectivity. This is useful for a Wi-Fi 7 access point because aggregate wireless traffic can exceed the practical capacity of a conventional Gigabit uplink. The upstream switch port and cabling must also support 2.5GbE to take advantage of the higher wired rate.
  4. How is the RG-RAP72Pro-OD powered?
    The RG-RAP72Pro-OD is powered through PoE or PoE+ and does not support a local DC power input. Ruijie specifies a maximum power consumption of 21 W. For Security Wholesalers installations, an appropriate standards-compliant PoE source should be selected with enough available power budget, particularly when multiple access points share the same PoE switch.
  5. Does the RG-RAP72Pro-OD support Wi-Fi 7 MLO and Reyee Mesh?
    Yes. Ruijie promotes Multi-Link Operation as a Wi-Fi 7 feature of the RG-RAP72Pro-OD and also lists Reyee Mesh support. MLO allows compatible clients to use multiple frequency links to improve performance and resilience, while Reyee Mesh can help extend coverage across suitable deployments. Final performance depends on client compatibility, RF conditions and how the access points are positioned.
  6. Is the RG-RAP72Pro-OD suitable for outdoor installation?
    Yes. The RG-RAP72Pro-OD is designed for wall or pole mounting and carries an IP65 weatherproof rating. Ruijie specifies an operating temperature range from -30°C to +65°C. The enclosure is intended for outdoor and indoor use, making the access point suitable for patios, open dining areas, pools, retail outdoor spaces and other locations where a weather-resistant Wi-Fi 7 access point is required.
