Ruijie Reyee RG-POE-AF15 Gigabit PoE Injector with 15.6W Output, 52V Power Supply, Compact Wall-Mount Design‍‌​​‌​​​‌‌​‌‌‌‌‌​‌‌‍

$22.18
WARRANTY GUARANTEED
✔ Dedicated 5★ Customer Care Team   ✔ Fast & Responsive Tech Support

Ruijie Reyee Passive PoE Injector | 1-Port Gigabit Ethernet | 52V Output | 15.6W Power | High Surge Protection | Compact Wall-Mount Design

‍‌​​‌​​​‌‌​‌‌‌‌‌​‌‌‍

The RG-POE-AF15 delivers a compact passive PoE injector solution designed for powering compatible Reyee access points in homes, offices, retail spaces and small network environments. Featuring 1000Base-T Gigabit connectivity, 52V DC output and 15.6W power delivery, it provides stable power and data over a single Ethernet connection.

It also includes high surge protection and 2-pair powering, making it a practical accessory supplied by Security Wholesalers for clean AP installations where a nearby power point is not ideal. Designed with a compact 92 x 46.5 x 29.5mm body and a -10°C to +45°C operating temperature range, it suits reliable indoor network deployments.

Key Features

  • 15.6W Passive PoE: Delivers 52V DC output at 0.3A for compatible passive PoE network devices.
  • Gigabit Data Support: Includes a 1000Base-T network port for standard Gigabit Ethernet connectivity.
  • Stable AP Power Supply: Designed to provide reliable power for compatible Reyee wireless access points.
  • High Surge Protection: Supports safer operation with a high surge protection rating for connected equipment.
  • Compact Wall-Mount Design: Uses a small, lightweight body that is easy to position in tight network spaces.
  • Wide Input Compatibility: Supports 100–240V AC input at 50/60Hz for flexible installation use.

Additional Information

Reyee Passive PoE Adapter Series-20260112

$22.18 inc GST +3 Year Warranty & Support

Product SKU: RG-POE-AF15

‍‌​​‌​​​‌‌​‌‌‌‌‌​‌‌‍

Product Overview

The Ruijie Reyee RG-POE-AF15 is a compact Gigabit passive PoE injector designed to provide both data and power to one compatible network device through a single Ethernet cable. With 1000Base-T data support, 52V DC output and 15.6W passive PoE power, it is best suited to selected low-power wireless access points and network devices that require passive PoE rather than a standards-negotiated PoE switch port. This Ruijie Reyee RG-POE-AF15 Gigabit PoE injector is useful for homes, offices, hotels and small business installations where a single compatible device needs PoE power without replacing the existing switch or router. Its compact wall-mount-friendly design, wide operating temperature range and high surge protection make it a practical accessory for simple, neat indoor network deployments.

Key Capabilities

15.6W Passive PoE Output

The RG-POE-AF15 supplies 52V DC at 0.3A, providing 15.6W passive PoE power for compatible devices. It is best used where the powered device has been confirmed to match this passive PoE requirement.

Gigabit Data Support

The 1000Base-T connection allows the injector to pass Gigabit data to a compatible device while delivering power through the same cable. This helps keep small network installations clean without limiting the link to older Fast Ethernet speeds.

Simple Single-Device Power

This injector is useful when only one compatible access point or network device needs PoE power. It avoids the need to replace an existing non-PoE switch for a small, single-device deployment.

High Surge Protection

Built-in surge protection helps add resilience to the power and data connection. This is useful in real installations where network equipment may be exposed to electrical disturbances through cabling or power supply conditions.

Compact Wall-Mount Design

The small body size makes the RG-POE-AF15 easy to position near a power point, router, switch or patch panel. It suits tidy installations where the injector needs to be kept out of the way.

Best For

  • Single Access Point Installations: Suitable for powering one compatible passive PoE access point without installing a PoE switch.
  • Homes and Small Offices: A practical choice where one network device needs power and data through one Ethernet cable.
  • Hotel and Office Wall APs: Useful for compatible wall access point deployments where a compact PoE injector is preferred.
  • Non-PoE Switch Networks: Helps add PoE power to a compatible single device while keeping the existing switch or router in place.

Why Choose the RG-POE-AF15

Choose the RG-POE-AF15 when the job calls for a simple, compact passive PoE injector rather than a multi-port PoE switch. For small installations, the main advantage is that it provides Gigabit data and 15.6W passive PoE power to one compatible device without adding unnecessary rack hardware. This makes it especially useful for wall access points, small office upgrades and single-device deployments where neat cabling matters. This model, supplied by Security Wholesalers, is a practical option when the powered device’s passive PoE voltage and wattage requirements match the injector exactly.

Buyer Decision Tips

Buyer Tip: Confirm that the device being powered supports 52V passive PoE and does not require a different voltage, wattage or standards-negotiated PoE type. Passive PoE injectors should only be used with compatible devices.

Buyer Tip: Choose this 15.6W model for lower-power compatible devices. If the device requires a higher PoE budget, select a suitably rated injector or PoE switch instead of relying on an undersized power supply.

Key Features & Technical Specifications

Product Type 1-port Gigabit passive PoE injector.
Model RG-POE-AF15.
Series Ruijie Reyee passive PoE injector accessory.
Network Port 1000Base-T Gigabit Ethernet connection.
PoE Type Passive PoE.
Output Voltage 52V DC at 0.3A.
Output Power 15.6W.
Rated Input Voltage 100–240V AC at 50/60Hz.
Input Current 0.5A maximum.
Inrush Current Less than 80A at 230V AC.
Powering Pin Assignment 2-pair powering on pins 4,5 positive and pins 7,8 negative.
Surge Protection High surge protection rating for supported installations.
Compatible Device Type Designed for compatible wall AP and passive PoE device deployments.
Operating Temperature -10°C to +45°C.
Storage Temperature -40°C to +70°C.
Dimensions 92 x 46.5 x 29.5 mm.

Ideal Use Cases

Wall Access Points

Use the RG-POE-AF15 where a compatible wall AP needs passive PoE power from a nearby power outlet and Ethernet connection.

Home Networks

A neat option for powering one compatible network device without adding a larger PoE switch to a simple home setup.

Small Offices

Suitable for office installations where a single compatible access point needs Gigabit data and passive PoE power.

Hotels and Accommodation

Useful for compatible wall AP deployments in hotel rooms, reception areas or accommodation spaces where tidy cabling is important.

Single-Device Network Additions

A practical accessory when adding one passive PoE device to an existing non-PoE network without redesigning the switch setup.

Choosing the Right Model

  • Choose this model if: You need a compact Gigabit passive PoE injector with 52V output and 15.6W power for one compatible device.
  • Choose a higher-power injector if: The connected device requires more than 15.6W or specifies a larger passive PoE power supply.
  • Choose a PoE switch instead if: You need to power multiple access points, cameras or network devices from the same location.

FAQs

  1. Is the RG-POE-AF15 suitable for all PoE devices?
    No. The RG-POE-AF15 is a passive PoE injector and should only be used with devices that support the required 52V passive PoE input. It is not a universal replacement for all PoE, PoE+ or PoE++ equipment. Always check the powered device specifications before connecting it.
  2. What devices is the RG-POE-AF15 best used with?
    The RG-POE-AF15 is best used with compatible low-power passive PoE devices, especially selected wall access points. It suits installations where one device needs both power and Gigabit data through a single Ethernet cable, and the existing network switch or router does not provide the correct PoE output.
  3. How much power does the RG-POE-AF15 provide?
    The RG-POE-AF15 provides 52V DC at 0.3A, which equals 15.6W output power. This is suitable for compatible lower-power passive PoE devices. If the connected device requires a higher power budget, a higher-rated injector or compatible PoE switch should be selected instead.
  4. Does the RG-POE-AF15 support Gigabit networking?
    Yes. The RG-POE-AF15 supports 1000Base-T Gigabit Ethernet, allowing compatible devices to receive data and passive PoE power through one cable. To achieve Gigabit performance, the connected device, cable and upstream switch or router must also support Gigabit networking.
  5. Can the RG-POE-AF15 replace a PoE switch?
    The RG-POE-AF15 can replace the need for a PoE switch only when powering one compatible passive PoE device. If you need to power multiple devices, a PoE switch is usually a cleaner and more scalable option. For a single wall AP or small network addition, the injector can be more practical.
  6. Where should the RG-POE-AF15 be installed?
    The RG-POE-AF15 is best installed indoors near a power outlet, switch, router or patch panel. Its compact size makes it suitable for home, hotel and office environments where one compatible PoE device needs a neat power source. This model is available through Security Wholesalers for suitable passive PoE deployments.
  7. What should I check before buying the RG-POE-AF15?
    Before buying the RG-POE-AF15, confirm the powered device’s PoE type, voltage, wattage and network speed requirement. A common mistake is choosing a passive PoE injector based only on connector type. The voltage and power rating must match the device to avoid unstable operation or equipment damage.

Additional Information

Reyee Passive PoE Adapter Series-20260112
