Product SKU: Ruijie Reyee RG-NBS3300-16MG4XS-HP
© Security Wholesalers Australia. All rights reserved. https://www.securitywholesalers.com.au/product/ruijie-reyee-rg-nbs3300-16mg4xs-hp-20-port-multi-gigabit-layer-2-managed-poe-switch-with-4-poe-ports-12-poe-ports-4-x-10g-sfp-uplinks/
Product Overview
The Ruijie Reyee RG-NBS3300-16MG4XS-HP 20-Port Multi-Gigabit Layer 2 Managed PoE Switch is designed for high-performance business, Wi-Fi, CCTV, education, retail and commercial network deployments requiring faster access ports, advanced PoE output and 10G uplink capability. It features 4 PoE++ ports, 12 PoE+ ports and 4 x 10G SFP+ uplinks, making it suitable for compatible Wi-Fi access points, IP cameras, intercoms, VoIP phones, uplink switches and higher-bandwidth network devices. The multi-gigabit Layer 2 managed design provides stronger access performance and network control than standard Gigabit-only switch models. This model is best selected where a managed PoE switch is required for modern high-speed devices, Wi-Fi deployments and 10G backbone connectivity.
Key Capabilities
20-Port Multi-Gigabit Design
The RG-NBS3300-16MG4XS-HP provides a high-performance switching platform for modern business networks requiring faster-than-standard access connectivity.
4 PoE++ Ports
Four PoE++ ports support compatible higher-power devices that require more power than standard PoE+ ports can provide.
12 PoE+ Ports
Twelve PoE+ ports allow compatible cameras, access points, intercoms and VoIP phones to receive power and data through Ethernet cabling.
4 x 10G SFP+ Uplinks
Four 10G SFP+ uplinks provide high-speed backbone flexibility for compatible fibre modules, distribution switches, core switches or network cabinets.
Layer 2 Managed Switching
Layer 2 managed operation provides network control and structure for supported deployments requiring more administration than unmanaged switches provide.
Best For
- Wi-Fi Access Point Deployments: Suitable for powering compatible high-performance wireless access points across offices, schools and commercial environments.
- Multi-Gigabit Business Networks: Practical for modern networks where higher-speed access ports are preferred over standard Gigabit-only switching.
- High-Power PoE Devices: Useful for compatible devices requiring PoE++ support, alongside standard PoE+ devices on the same switch.
- 10G Backbone Connectivity: A good option where 10G SFP+ uplinks are needed for faster connections to core switches, network cabinets or fibre backbones.
- Managed Commercial Networks: Best where administrators need Layer 2 management, PoE control and structured network deployment.
Why Choose the RG-NBS3300-16MG4XS-HP
The RG-NBS3300-16MG4XS-HP is a strong choice when a commercial network needs multi-gigabit access switching, PoE++ support and 10G uplink capacity in one managed switch. Its mix of 4 PoE++ ports and 12 PoE+ ports makes it suitable for powering compatible high-demand access points, cameras, intercoms and other network devices, while the 4 x 10G SFP+ uplinks help support faster backbone connectivity. The Layer 2 managed design also supports more structured control for business networks. For systems supplied through Security Wholesalers, this switch should be selected after confirming device count, PoE power requirements, multi-gigabit access needs, 10G uplink design, SFP+ module compatibility, VLAN requirements and management workflow.
Buyer Decision Tips
Buyer Tip: Choose the RG-NBS3300-16MG4XS-HP when you need a 20-port multi-gigabit Layer 2 managed PoE switch with 4 PoE++ ports, 12 PoE+ ports and 4 x 10G SFP+ uplinks.
Installation Tip: Confirm PoE++ device requirements, total PoE demand, access port speed needs, SFP+ module compatibility, 10G uplink layout, cable quality, VLAN design and rack or cabinet space before deployment.
Key Features & Technical Specifications
| Model |
RG-NBS3300-16MG4XS-HP |
| Brand |
Ruijie Reyee |
| Product Type |
Multi-gigabit Layer 2 managed PoE switch |
| Switch Series |
Reyee managed switch |
| Port Count |
20 ports |
| Access Port Type |
Multi-gigabit PoE access ports |
| PoE++ Ports |
4 × PoE++ ports |
| PoE+ Ports |
12 × PoE+ ports |
| SFP+ Uplinks |
4 × 10G SFP+ uplinks |
| Management |
Layer 2 managed |
| Primary Use |
Managed multi-gigabit PoE switching for compatible powered devices, Wi-Fi access points, CCTV systems and business networks |
| Typical Applications |
Wi-Fi access points, IP cameras, intercoms, VoIP phones, offices, schools, retail sites, warehouses, commercial networks, 10G uplinks and high-speed access switching |
| Installation Type |
Network cabinet, rack, shelf or business network area installation with suitable power, cabling and 10G uplink planning |
| Best Use |
Multi-gigabit Wi-Fi deployments, high-power PoE devices, Layer 2 managed switching, 10G SFP+ uplinks and commercial network expansion |
| Deployment Consideration |
Confirm connected device count, PoE++ and PoE+ power requirements, access port speed needs, cable quality, Layer 2 requirements, SFP+ module compatibility, uplink bandwidth and management setup before installation |
Ideal Use Cases
High-Performance Wi-Fi Networks
Use the switch to power and connect compatible access points that benefit from multi-gigabit switching and PoE support.
PoE++ Device Deployments
Suitable for compatible higher-power devices that require PoE++ instead of standard PoE+ output.
10G Backbone Networks
Practical for connecting to compatible core switches, fibre backbones, distribution switches or network cabinets using 10G SFP+ uplinks.
Commercial Security Systems
A good option for mixed networks with compatible cameras, intercoms, access points and other powered security devices.
Managed Business Networks
Useful where administrators need Layer 2 managed control across higher-speed access devices and PoE-powered endpoints.
Choosing the Right Model
- Choose this model if: You need a Ruijie Reyee 20-port multi-gigabit Layer 2 managed PoE switch with 4 PoE++ ports, 12 PoE+ ports and 4 x 10G SFP+ uplinks.
- Choose a different switch if: The site needs only standard Gigabit ports, more access ports, a lower-cost unmanaged switch, a non-PoE model, fewer 10G uplinks or a different enterprise switching feature set.
- Check before ordering: Confirm access point requirements, camera count, device wattage, PoE++ and PoE+ needs, cable standard, total power demand, SFP+ module type, uplink speed, VLAN requirements, rack space and management workflow.
FAQs
- What is the Ruijie Reyee RG-NBS3300-16MG4XS-HP used for?
The RG-NBS3300-16MG4XS-HP is used as a multi-gigabit Layer 2 managed PoE switch for business, Wi-Fi, CCTV, retail, education and commercial networks. It is suitable for compatible access points, IP cameras, intercoms, VoIP phones and other powered network devices.
- How many PoE ports does this switch have?
This model includes 4 PoE++ ports and 12 PoE+ ports. Before installation, confirm which connected devices require PoE++ power and which can operate from PoE+ ports.
- What are the 4 x 10G SFP+ uplinks used for?
The 10G SFP+ uplinks can be used with compatible SFP+ modules for high-speed fibre or backbone connectivity to a core switch, distribution switch, network cabinet or wider business network.
- Why choose a multi-gigabit switch instead of a standard Gigabit switch?
A multi-gigabit switch is better suited for compatible high-performance devices, especially modern wireless access points or network equipment that can benefit from faster access speeds than standard Gigabit switching.
- What does Layer 2 managed mean?
Layer 2 managed means the switch supports managed network control for supported deployments. This can help administrators structure the network, manage traffic and monitor connected devices more effectively than with an unmanaged switch.
- Can this switch power high-performance access points?
Yes, it can power compatible access points through its PoE++ and PoE+ ports, provided the connected devices match the available port power and the total power requirements are suitable. For systems supplied through Security Wholesalers, access point power needs, cable quality and uplink design should be checked before installation.
- When should I choose a larger switch?
Choose a larger switch when the site needs more access ports, more PoE endpoints, additional uplink flexibility or greater future expansion capacity. This model is well suited to compact high-performance networks where multi-gigabit access and 10G uplinks are priorities.
- What should be checked before installation?
Before installation, confirm connected device count, PoE++ and PoE+ requirements, cable quality, access speed requirements, uplink bandwidth, SFP+ module compatibility, VLAN or Layer 2 needs, rack or cabinet space, power access and management setup.
Additional Information
RG-NBS3300-16MG4XS-HP_Datasheet_Official_2025-12-09
