Ruijie Reyee RG-EG310GH-E 10-Port Gigabit Cloud Managed Router with Multi-WAN VPN & Load Balancing

Product SKU: RG-EG310GH-E

Product Overview

The Ruijie Reyee RG-EG310GH-E is a 10-port high-performance cloud-managed office router designed for business networks requiring multi-WAN connectivity, VPN services, intelligent load balancing and centralised remote management. Ten Gigabit RJ45 ports include six fixed LAN ports, one fixed WAN port and three configurable LAN/WAN ports, allowing up to four WAN connections or up to nine LAN interfaces depending on the network design. Routing throughput reaches up to 1.5 Gbps, while Ruijie recommends the platform for up to 350 concurrent clients and lists a maximum of 100,000 concurrent sessions. Multi-WAN failover, application-aware bandwidth management, VPN support and Ruijie Cloud make it suitable for offices, schools, hotels, retail, CCTV networks and distributed branch environments.

Key Capabilities

Best For

• Business Offices: 1.5 Gbps routing performance, VPN and cloud management suit growing office networks with multiple departments and internet services.
• Multi-WAN Networks: Up to four WAN interfaces allow broadband, NBN, fibre or backup connections to be combined or used redundantly.
• Branch Offices: VPN, SD-WAN and remote cloud administration help connect and manage distributed locations.
• Retail, Hotels & Schools: Portal authentication, bandwidth control and user-management functions support larger shared-user environments.
• CCTV & Security Networks: Gigabit ports, static routing, VLANs and multi-WAN resilience suit surveillance sites requiring stable internet and remote connectivity.

Why Choose the RG-EG310GH-E

The RG-EG310GH-E offers substantially more flexibility than a basic small-business router by combining 10 Gigabit interfaces, multi-WAN routing, VPN, SD-WAN, application-aware traffic control and cloud management in a compact 1U platform. Up to four WAN interfaces can be used for redundancy or bandwidth aggregation, while support for IPsec, L2TP, OpenVPN, PPTP and WireGuard provides several secure connectivity options for branches and remote users. Its recommended 350-client capacity also makes it suitable for larger shared networks. Available through Security Wholesalers, the RG-EG310GH-E is a strong fit for businesses wanting centralised control and resilient internet connectivity without moving to a much larger enterprise gateway.

Buyer Decision Tips

Key Features & Technical Specifications

Product Type	10-port high-performance cloud-managed office router.
Model	RG-EG310GH-E.
Total Ethernet Ports	10 × 10/100/1000BASE-T Gigabit RJ45 ports.
Fixed LAN Ports	6.
Fixed WAN Ports	1.
Configurable LAN/WAN Ports	3.
Maximum WAN Ports	4.
Maximum LAN Ports	9.
CPU	Dual-core processor, 1.35 GHz per core.
RAM	512 MB.
Flash Memory	256 MB.
Routing Throughput	Up to 1500 Mbps.
Recommended Concurrent Clients	350.
Maximum Concurrent Sessions	100,000.
Multi-WAN	Supported.
WAN Failover	Supported.
Load Balancing	Supported by flow, source IP address and interface weight.
Bandwidth Aggregation	Supported.
Multi-WAN Link Bundling Efficiency	≥80% under Ruijie laboratory conditions.
Policy-Based Routing	Supported.
Application-Based Routing	Supported.
Dynamic Routing	BGP/BGP4/BGP4+, OSPFv2, OSPFv3, RIP and RIPng supported.
Static Routing	IPv4 and IPv6 static routing supported.
VLAN	Supported on LAN ports with VLAN priority functions.
QoS	Supported.
Application Recognition	Supported.
Behaviour Management	Supported.
Website Filtering	Custom URL filtering supported.
Traffic Audit	Supported.
NAT	Static NAT, dynamic NAT and NAT loopback supported.
Port Mapping	Up to 512 entries.
DHCP	DHCP client and DHCP server supported.
DDNS	DDNS, Ruijie DDNS, Alibaba Cloud DDNS, Cloudflare and No-IP DNS support.
IPsec VPN	Supported; up to 170 Mbps published throughput and up to 64 branch connections.
L2TP VPN	Supported; up to 540 Mbps published throughput and up to 64 branch connections.
OpenVPN	Supported; up to 100 Mbps published throughput and up to 64 branch connections.
PPTP VPN	Supported; up to 640 Mbps published throughput and up to 64 branch connections.
WireGuard	Server and client supported; up to 300 Mbps published performance and up to 64 concurrent server tunnels.
VPN Accounts	Up to 300 accounts for L2TP, PPTP and OpenVPN.
SD-WAN	Supported.
SD-WAN Performance	Up to 300 Mbps.
SD-WAN Tunnels	Up to 192.
Maximum SD-WAN Branches	64.
Ruijie Cloud Management	Supported.
Reyee App Management	Remote monitoring, restart, firmware upgrade and fault diagnosis supported.
Web Management	Supported with HTTPS login.
SNMP	SNMP v1, v2c and v3.
Portal Authentication	Cloud portal, local portal, one-click, password, SMS, voucher, account and QR-code authentication supported.
PPPoE Server	Up to 300 accounts and 128 concurrent PPPoE clients.
Managed AP/NBS Devices – Router Mode	Up to 150 AP and NBS-series devices.
Managed AP/NBS Devices – AC Mode	Up to 500 AP and NBS-series devices.
Security	ACL, stateful ACL, IP-MAC binding, malformed-packet defence, fragmentation-attack defence, teardrop, LAND, SYN flood, Smurf and IP-attack defence.
Power Supply	Fixed internal power supply.
Maximum Power Consumption	25 W.
Cooling	Natural cooling with fanless design.
Surge Protection – Service Ports	±4 kV common mode.
Surge Protection – Power Connector	±6 kV common mode and ±6 kV differential mode.
Mounting	1U rack mounting.
Operating Temperature	0°C to 40°C.
Operating Humidity	10% to 90% RH, non-condensing.
Storage Temperature	-40°C to 70°C.
Dimensions	Approximately 440 × 200 × 43.6 mm.
Weight	Approximately 2.4 kg.

Ideal Use Cases

Choosing the Right Model

• Choose the RG-EG310GH-E if: You need up to four WAN interfaces, 1.5 Gbps routing throughput, comprehensive VPN support and Ruijie Cloud management.
• Choose a PoE version if: The router also needs to power compatible access points or other PoE devices directly from its Ethernet ports.
• Choose a higher-performance gateway if: Encrypted VPN traffic, internet throughput or user count is expected to exceed the published limits of this model.
• Use multi-WAN if: The business requires internet failover, aggregated bandwidth or traffic steering across multiple service providers.

FAQs

1. What performance does the Ruijie Reyee RG-EG310GH-E provide?
   The Ruijie Reyee RG-EG310GH-E is rated for up to 1.5 Gbps throughput and is recommended for up to 350 concurrent clients. Ruijie lists a maximum of 100,000 concurrent sessions, making the router suitable for office, hotel, school, retail and CCTV networks that need higher routing capacity than entry-level small-business gateways.
2. How many WAN and LAN ports does the RG-EG310GH-E provide?
   The router has 10 Gigabit RJ45 ports in total. Ruijie specifies 6 fixed LAN ports, 1 fixed WAN port and 3 configurable LAN/WAN ports, allowing up to 4 WAN interfaces or up to 9 LAN interfaces depending on the deployment. This flexibility is useful for multi-WAN internet connections, backup links and segmented business networks.
3. Does the RG-EG310GH-E support multi-WAN and load balancing?
   Yes. The RG-EG310GH-E supports multi-WAN, WAN failover, bandwidth aggregation and intelligent load balancing. Ruijie lists load balancing by flow, source IP address and interface weight, together with route selection based on link quality. This allows multiple internet connections to be combined or used redundantly according to the network design.
4. What VPN functions does the RG-EG310GH-E support?
   The RG-EG310GH-E supports IPsec, L2TP, OpenVPN, PPTP and WireGuard. Ruijie lists up to 64 branches for IPsec, L2TP, OpenVPN and PPTP networking, plus up to 64 concurrent WireGuard tunnels. Published VPN throughput varies by protocol, including up to 170 Mbps for IPsec, 540 Mbps for L2TP, 100 Mbps for OpenVPN, 640 Mbps for PPTP and 300 Mbps for WireGuard.
5. Can the RG-EG310GH-E be managed through the cloud?
   Yes. The RG-EG310GH-E supports Ruijie Cloud management and the Ruijie Reyee App for remote monitoring, restart, firmware upgrade and fault diagnosis. It also supports web management, SNMP v1/v2c/v3 and cloud portal functions. For Security Wholesalers installations, remote management can simplify support across offices, retail sites and distributed branch networks.
6. What are the dimensions, power consumption and operating limits of the RG-EG310GH-E?
   The RG-EG310GH-E is a 1U rack-mount router measuring approximately 440 mm × 200 mm × 43.6 mm and weighing about 2.4 kg. Ruijie specifies a fixed power supply, maximum power consumption of 25 W, fanless natural cooling, operating temperature from 0°C to 40°C and operating humidity from 10% to 90% non-condensing.

Additional Information

• RG-EG310GH-E 10-Port High Performance Cloud Router Datasheet
