Product SKU: NVR-216MH-C/16P
Product Overview
For installers putting together a 16-camera IP surveillance system without a separate PoE switch, the NVR-216MH-C/16P delivers a straightforward centralised recording solution in a compact 1U chassis. Built around 16 independent PoE ports rated to IEEE 802.3 af/at, this recorder powers compatible IP cameras directly over the network cable, simplifying both cabling and infrastructure. Featuring 160Mbps incoming bandwidth and support for H.265+, H.265, H.264+ and H.264 compression, the NVR-216MH-C/16P handles multi-camera recording efficiently across a range of IP camera resolutions up to 8MP. It includes 2 SATA bays supporting up to 8TB per drive, 4K HDMI output, VGA output, and simultaneous 16-channel synchronous playback. The unit ships without a hard drive, allowing buyers to size storage to their specific retention and resolution requirements. It is well suited to small-to-medium commercial sites, residential properties, and light-duty business premises where a dedicated PoE NVR removes the need for additional networking hardware.
Key Capabilities
16 Built-In PoE Ports
All 16 camera ports deliver PoE power compliant with IEEE 802.3 af/at, with a combined PoE budget of up to 150W. This removes the need for a separate PoE switch in most 16-camera deployments, reducing rack space and installation cost.
H.265+ Compression Support
Support for H.265+, H.265, H.264+ and H.264 means the NVR can work with a wide range of compatible IP cameras while the most efficient formats significantly reduce storage consumption and bandwidth use across all 16 channels.
Dual SATA HDD Bays
Two SATA interfaces each support drives up to 8TB, providing a maximum raw storage capacity of 16TB. This gives installers flexibility to match retention time to camera count, resolution, and recording schedule without being locked into a fixed storage size.
4K HDMI and VGA Display Outputs
The HDMI output supports 4K (3840 x 2160) at 30Hz alongside standard HD resolutions, while VGA provides compatibility with existing monitors up to 1080p. Both outputs are available simultaneously for multi-screen control room setups.
160Mbps Incoming Bandwidth
With 160Mbps incoming and 80Mbps outgoing bandwidth, the NVR-216MH-C/16P sustains continuous recording across all 16 channels at practical IP camera bitrates, preventing dropped frames or recording gaps in multi-camera configurations.
Best For
- Plug-and-Play IP Camera Installations: The 16 onboard PoE ports allow direct camera connection over a single Cat5e/Cat6 cable per camera, removing the need for an external PoE switch and simplifying the network architecture of the surveillance system.
- Small-to-Medium Commercial Sites: Retail stores, offices, childcare centres, and light industrial premises needing up to 16 IP cameras and centralised local recording are a natural fit for this 1U recorder.
- Residential Multi-Camera Systems: Homes requiring more than 8 cameras and wanting a single recorder to manage all channels, store footage locally, and support remote viewing via Hik-Connect benefit from the NVR-216MH-C/16P’s channel capacity and PoE simplicity.
- Upgraders Replacing Analogue DVR Systems: Sites moving from analogue CCTV to IP cameras can centralise the new network cameras on the NVR-216MH-C/16P while reusing existing structured cabling where suitable.
Why Choose the NVR-216MH-C/16P
The NVR-216MH-C/16P offers a practical value point for 16-channel IP recording without sacrificing the built-in PoE infrastructure that defines a properly integrated system. Unlike a basic NVR requiring a separate managed PoE switch, this unit integrates all 16 PoE connections internally, keeping installation tidy and reducing the number of powered devices in the rack. The 2 SATA bays accommodate drives up to 8TB each, giving a meaningful storage ceiling for sites recording continuously at 4MP or 8MP. Synchronous playback across all 16 channels at once makes incident review straightforward at the monitor rather than requiring a separate workstation. Remote access is supported through Hik-Connect, and the Gigabit network interface handles external streaming alongside local recording without congestion. Available through Security Wholesalers, the NVR-216MH-C/16P is suited to installers and integrators who need a dependable 16-channel PoE recorder at a competitive price point without unnecessary feature overhead.
Buyer Decision Tips
PoE Power Budget: The total PoE output of the NVR-216MH-C/16P is capped at 150W across all 16 ports. If you are installing cameras with built-in IR illuminators, heaters, or active deterrence features drawing 15W or more per unit, calculate your total camera power draw before committing to a full 16-camera deployment. High-power cameras at full load across all 16 ports may exceed the 150W budget and require an external supplementary PoE switch for some channels.
Storage Planning Before Purchase: This NVR ships without a hard drive. Storage requirements depend on camera count, resolution, compression format, and recording schedule. As a practical guide, 16 cameras recording continuously at 1080p with H.265+ will typically consume between 1TB and 2TB per week. For 8MP cameras or longer retention periods, size up to the maximum dual-drive configuration early rather than retrofitting drives once the system is live.
Key Features & Technical Specifications
| IP Video Inputs |
16 channels |
| PoE Ports |
16 x IEEE 802.3 af/at, up to 150W total PoE budget |
| Incoming Bandwidth |
160 Mbps |
| Outgoing Bandwidth |
80 Mbps |
| Decoding Format |
H.265+, H.265, H.264+, H.264 |
| Decoding Capability |
4-ch at 1080p |
| Recording Resolution |
8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Synchronous Playback |
16 channels |
| HDMI Output |
1 x 4K (3840 x 2160) at 30Hz, also supports 1080p/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
| VGA Output |
1 x 1920 x 1080p/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
| Audio Output |
1 x RCA (Linear, 1 KΩ) |
| HDD Bays |
2 x SATA, up to 8TB per drive |
| USB Interfaces |
2 x USB 2.0 |
| Network Interface |
1 x RJ-45, 10/100/1000 Mbps self-adaptive Ethernet |
| Network Protocols |
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS |
| Power Supply |
100 to 240 VAC, 50 to 60 Hz |
| Power Consumption (NVR only) |
Up to 15W (excluding PoE load) |
| Operating Temperature |
-10 to +55 degrees C |
| Chassis / Dimensions |
1U chassis, 385 x 315 x 52 mm |
| Weight |
Up to 2.6 kg |
Ideal Use Cases
Retail and Shopfront Surveillance
A retail store deploying cameras at entrances, checkouts, stock rooms, and car park areas can connect all cameras directly to the NVR-216MH-C/16P’s 16 PoE ports without needing a separate network switch, reducing equipment cost and cabinet clutter.
Office and Commercial Premises
Multi-floor offices needing coverage of reception areas, corridors, server rooms, and perimeter access points can centralise all 16 channels on this single 1U recorder, supporting remote viewing via Hik-Connect for after-hours monitoring.
Residential Estates and Large Homes
Properties requiring more than 8 cameras across driveways, gates, pool areas, and building perimeters benefit from the NVR-216MH-C/16P’s 16-channel capacity and the ability to record at up to 8MP resolution for detail-critical coverage zones.
Schools and Childcare Facilities
Educational facilities covering classrooms, entry points, playgrounds, and car parks across a single site can run all cameras back to one NVR-216MH-C/16P, with 16-channel synchronous playback supporting fast incident review by staff or management.
Small Warehouses and Light Industrial Sites
A warehouse or workshop needing cameras across loading docks, internal bays, and staff entry points can utilise all 16 PoE ports without additional switching infrastructure, with H.265+ compression keeping storage consumption manageable across continuous 24/7 recording.
Choosing the Right Model
- Choose this model if: You need a 16-channel PoE NVR with integrated camera power delivery, H.265+ recording support, dual HDD bays, and 4K HDMI output, and do not require AI analytics or advanced event-based search capabilities beyond standard motion recording.
- Choose a different model if: Your installation requires built-in AI analytics such as perimeter detection, line crossing, or smart search functions. An AI-capable NVR in the same HiLook range would provide those features without requiring a separate analytics device or camera-side processing only.
- Choose a different model if: You need more than 16 camera inputs. A 32-channel PoE NVR would cover larger sites where future camera expansion beyond 16 channels is planned at the time of installation.
- Choose a different model if: Your camera fleet includes high-power units that push total PoE draw above 150W. In that case, a higher-wattage NVR or a combination of this NVR with a supplementary PoE switch would be more appropriate.
FAQs
- Does the NVR-216MH-C/16P come with a hard drive included?
No. This unit is sold without a hard drive. It has 2 SATA bays, each supporting drives up to 8TB, giving a maximum local storage capacity of 16TB. You will need to purchase compatible surveillance-grade hard drives separately before the recorder can store footage.
- How many cameras can be connected, and do they all receive PoE power?
The NVR-216MH-C/16P supports up to 16 IP cameras via its 16 onboard PoE ports. All 16 ports are powered and comply with IEEE 802.3 af/at, so compatible cameras receive both data and power over a single Cat5e or Cat6 cable. No separate PoE switch is required for a standard deployment.
- What is the total PoE power budget and how does it affect camera selection?
The combined PoE output is limited to 150W across all 16 ports. Most standard IP cameras draw between 5W and 13W, which keeps a full 16-camera system well within budget. However, cameras with built-in heaters, powerful IR arrays, or active deterrence speakers can draw 15W or more, so calculating total draw before finalising camera models is recommended.
- What is the maximum recording resolution supported?
The NVR-216MH-C/16P records at resolutions up to 8MP across its 16 channels. Supported resolutions include 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 720p, and lower legacy formats. The unit also supports 4K HDMI monitor output for live view and playback.
- Can I access live view and playback remotely on my phone?
Yes. The NVR-216MH-C/16P supports Hik-Connect, which allows remote live viewing and playback via a smartphone app. The unit also supports standard network protocols including DDNS and HTTPS for flexible remote access configuration across different network environments.
- Can this NVR be installed in a rack, and what are its physical dimensions?
Yes. The NVR-216MH-C/16P is a 1U chassis unit measuring 385 x 315 x 52 mm and weighing up to 2.6 kg, making it suitable for standard 19-inch rack mounting with an appropriate rack tray or shelf. It can also be placed on a shelf or in a security cabinet in non-rack installations.
- Where can I find documentation and support for this unit?
The quick start guide, full datasheet, and user manual for the NVR-216MH-C/16P are linked in the Additional Information section below this description. The product is part of the Security Wholesalers range and technical support is available through the store for installation and configuration queries.
