Product SKU: DS-PDP15P-EG2-WB-B
Product Overview
The Hikvision DS-PDP15P-EG2-WB(B) is a white AX PRO indoor wireless passive infrared detector designed to provide reliable motion detection while reducing unwanted alarms caused by household pets. It delivers a detection range of up to 15 metres with a 90° detection angle and 84 detection zones, while selectable Auto, High and Pet sensitivity modes allow performance to be matched to the protected room. Pet immunity supports animals up to 30 kg when the detector is correctly installed and configured. Hikvision Tri-X two-way RF communication operates at 433 MHz with encrypted transmission, frequency hopping and a free-space range of up to 1.2 km. Digital temperature compensation, sealed optics, creep-zone protection, front and rear tamper detection and up to five years of battery life make it a practical indoor motion detector for compatible AX PRO homes and commercial alarm systems.
Key Capabilities
15 m PIR Motion Detection
The passive infrared sensor monitors movement across an indoor area up to 15 metres, with a current specified detection angle of 90° and 84 detection zones. This makes it suitable for living areas, offices, hallways, retail spaces and other general indoor rooms.
Up to 30 kg Pet Immunity
Dedicated Pet sensitivity mode is designed to reduce alarms caused by suitable household animals weighing up to 30 kg while continuing to identify human movement. Correct mounting height and room layout remain important for dependable pet-immune operation.
Smart Environmental Control
SEC processing combines advanced digital signal processing and 3D optics with digital temperature compensation, sealed optics and creep-zone protection to help maintain useful detection performance across changing indoor conditions.
Tri-X Two-Way Wireless
Hikvision Tri-X provides two-way 433 MHz wireless communication with frequency hopping and encrypted transmission. The Australian 433 MHz model provides a published free-space wireless range of up to 1.2 km.
Front & Rear Tamper Protection
Front and rear tamper protection helps the AX PRO system detect attempts to open the detector or remove it from its installed mounting position, adding supervision against physical interference.
Up to 5 Years Battery Life
A single replaceable CR123A 3 V battery powers the detector, with Hikvision specifying standard standby operation of up to five years. Low-battery supervision helps support planned maintenance through the compatible AX PRO system.
Best For
- Homes with pets: Up to 30 kg pet immunity can reduce unwanted PIR alarms when the detector is correctly positioned and configured.
- Living areas and hallways: The 15 metre detection range provides broad indoor coverage from a single wall-mounted detector.
- Offices and retail spaces: Wireless installation makes it suitable for protecting rooms where running new alarm cable would be inconvenient.
- Retrofit alarm upgrades: Long-range Tri-X communication and battery operation simplify adding motion detection to finished buildings.
- AX PRO expansions: Remote configuration and multiple enrolment methods support efficient deployment across compatible Hikvision alarm systems.
Why Choose the DS-PDP15P-EG2-WB(B)
The DS-PDP15P-EG2-WB(B) combines broad 15 metre indoor motion coverage with pet-aware detection and AX PRO wireless convenience. Auto, High and Pet sensitivity settings let the detector be adjusted around the real room and occupancy requirements, while Smart Environmental Control processing, digital temperature compensation, sealed optics and creep-zone protection help maintain dependable detection performance. Tri-X two-way communication, frequency hopping and signal-strength indication simplify professional wireless deployment, and front and rear tamper monitoring add device supervision. Supplied by Security Wholesalers, this standard white version is particularly useful for homes and small commercial premises where reliable indoor PIR detection, long battery life and pet immunity are required without installing new alarm cabling.
Buyer Decision Tips
Buyer Tip: Pet immunity depends on correct installation as well as animal weight. Mount the detector at the recommended 1.8 to 2.4 metre height and avoid positioning furniture, shelving or other objects where pets can climb into higher and more sensitive detection zones.
Key Features & Technical Specifications
| Product |
AX PRO indoor wireless passive infrared motion detector with pet immunity. |
| Model |
DS-PDP15P-EG2-WB(B). |
| Colour |
White or Black. |
| Detection Method |
Passive infrared. |
| Detection Range |
Up to 15 m. |
| Detection Angle |
90°. |
| Detection Zones |
84. |
| Detectable Speed |
0.3 to 2 m/s. |
| Sensitivity Modes |
Auto, High and Pet. |
| Pet Immunity |
Up to 30 kg. |
| White Light Filter |
6,500 lux. |
| Digital Temperature Compensation |
Supported. |
| Creep Zone Protection |
Supported. |
| Digital Processing |
Supported. |
| Sealed Optics |
Supported. |
| Tamper Protection |
Front and rear. |
| Environment Temperature Indicator |
Supported. |
| Signal Strength Indicator |
Supported. |
| LED Indicator |
Blue alarm indicator. |
| Wireless Technology |
Hikvision Tri-X Wireless. |
| Transmission Method |
Two-way RF wireless. |
| Transmission Frequency |
433 MHz for the Australian WB version. |
| Transmission Security |
Encrypted wireless transmission. |
| Frequency Hopping |
Supported. |
| Wireless Range |
Up to 1.2 km in free space. |
| Enrolment Methods |
Power-up, Remote ID and QR code. |
| Remote Configuration |
Supported through the compatible AX PRO app environment. |
| Power Supply |
Battery powered. |
| Battery |
1 × CR123A, 3 V. |
| Standard Battery Life |
Up to 5 years standby. |
| Operating Temperature |
-10°C to 55°C. |
| Storage Temperature |
-20°C to 60°C. |
| Operating Humidity |
10% to 90%. |
| Recommended Mounting Height |
1.8 to 2.4 m. |
| Mounting Method |
Wall mount; optional wall and ceiling mounting accessory supported. |
| Application Environment |
Indoor. |
| Dimensions |
65.5 × 103 × 48.5 mm. |
| Weight |
Approximately 128 g. |
Ideal Use Cases
Homes with Pets
Use Pet sensitivity mode to reduce unwanted alarms from suitable household animals weighing up to 30 kg.
Living Areas
The 15 metre PIR range and broad detection pattern provide practical coverage across larger indoor rooms.
Offices
Add supervised motion detection to workspaces, meeting areas and internal circulation zones without installing new alarm wiring.
Retail Spaces
Protect shop floors, storerooms and other suitable indoor areas as part of an AX PRO intrusion-detection system.
Retrofit Alarm Systems
Battery operation and long-range Tri-X communication make it easier to add PIR coverage to existing finished buildings.
Choosing the Right Model
- Choose the DS-PDP15P-EG2-WB(B) if: You need a white indoor AX PRO PIR with 15 metre detection, up to 30 kg pet immunity, Tri-X wireless and front/rear tamper protection.
- Choose the black variant if: The protected room uses dark walls, ceilings or fixtures and a black PIR will provide a less visible installation.
- Choose a PIRCAM detector if: The system also needs captured images for visual alarm verification when motion is detected.
- Choose an outdoor PIR if: The detector will be exposed to rain, weather or other external environmental conditions.
FAQs
- What detection range does the Hikvision DS-PDP15P-EG2-WB(B) provide?
The Hikvision DS-PDP15P-EG2-WB(B) is an indoor passive infrared detector with a specified detection range of 15 metres. Hikvision’s current specification lists a 90° detection angle with 84 detection zones. The detector is intended for wall mounting at approximately 1.8 to 2.4 metres, and final coverage should be confirmed on site because furniture, partitions, mounting angle and room layout can affect practical detection performance.
- How much pet immunity does the DS-PDP15P-EG2-WB(B) provide?
Hikvision specifies pet immunity up to 30 kg. The detector includes a dedicated Pet sensitivity mode designed to reduce alarms caused by suitable household animals while continuing to detect human movement. Pet immunity still depends on correct mounting height, detector angle, room layout and animal behaviour, so the installation should avoid furniture or structures that allow pets to enter the detector’s more sensitive zones at height.
- What sensitivity settings are available on the DS-PDP15P-EG2-WB(B)?
The detector provides Auto, High and Pet sensitivity settings. This allows the installer to tune operation for the protected room rather than relying on one fixed response level. Hikvision also includes digital temperature compensation, Smart Environmental Control processing, sealed optics and creep-zone protection to help maintain useful detection performance across normal indoor environmental changes.
- How far can the DS-PDP15P-EG2-WB(B) communicate wirelessly?
The Australian 433 MHz DS-PDP15P-EG2-WB(B) specification lists a Tri-X wireless transmission range of up to 1.2 km in free space. Communication is two-way and uses frequency hopping with encrypted transmission. Real indoor range can be lower because walls, reinforced concrete, metal structures and RF interference affect performance, so the built-in signal-strength indication should be checked at the intended mounting position.
- Does the DS-PDP15P-EG2-WB(B) have tamper protection?
Yes. Hikvision specifies both front and rear tamper protection. This allows the AX PRO system to detect attempts to open the detector housing or remove the unit from its installed position when tamper monitoring is correctly enabled. The detector is also fully supervised by the compatible alarm system, including low-battery and wireless supervision functions.
- What battery does the DS-PDP15P-EG2-WB(B) use?
The detector uses one CR123A 3 V battery, and Hikvision specifies standard standby battery life of up to five years. Actual service life can vary with wireless conditions, alarm activity, temperature and battery quality. The battery is replaceable, and low-battery status can be supervised through the compatible AX PRO system so maintenance can be scheduled before the detector becomes unavailable.
- Is the DS-PDP15P-EG2-WB(B) suitable for outdoor use?
No. Hikvision lists the DS-PDP15P-EG2-WB(B) as an indoor detector. Its specified operating range is -10°C to 55°C with 10% to 90% operating humidity, but no outdoor IP weather-protection rating is listed. When planning the detector through Security Wholesalers, use it only in suitable indoor locations and choose an appropriately rated detector for exposed outdoor areas.
