Hikvision DS-KH6350-WTE1 Gen2 IP-Based 7 inch Indoor Intercom Station Wifi WHITE

System Parameters

• Operation SystemLinux
• ROM32 MB
• RAM128 MB
• ProcessorEmbeded high performance processor

Display Parameters

• Screen Size7-inch
• Operation MethodCapacitive touch screen
• TypeColorful TFT
• Resolution1024 × 600

Video Parameters

• Lens/
• Resolution/
• FOV/
• Wide Dynamic Range (WDR)/
• Video Compression Standard/
• Focal Length/

Audio Parameters

• Audio Input 1 built-in omnidirectional microphone
• Audio Compression StandardG.711U, G.711A
• Audio Output1 built-in loudspeaker
• Audio Compression Bitrate64 Kbps
• Audio QualityNoise suppression and echo cancellation
• Volume AdjustmentAdjustable

Capacity

• Message Capacity

  TF card inserted: 200 captured pictures, 200 alarm records

  Without TF card: 2 MB RAM for picture storage; The storage number is decided by the picture size, 200 alarm records

• Notice Capacity 200
• Linked Indoor Extensions Capacity16
• Linked Doorphone Capacity17

Network Parameters

• Network ProtocolTCP/IP, SIP, RTSP
• Wi-Fi2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
• Bluetooth/
• 3G/4G/
• Zigbee/

Device Interfaces

• Alarm Input8
• Network Interface1 RJ-45 10/100 Mbps self-adaptive
• TAMPER/
• RS-4851 RS-485 (Half duplex)
• USB/
• TF CardSupport TF card, up to 128 G
• Alarm Output2
• Lock Control2 relays, Max. 30 VDC 0.3 A

General

• Button/
• InstallationWall mounting, table mounting
• Indicator/
• Weight

  Net weight: 355 g (0.8 lb)

  Gross weight: 683 g (1.5 lb)

• Protective Level/
• Working Temperature-10 °C to 50 °C (14 °F to 122 °F)
• Working Humidity10% to 90% (no-condensing)
• Dimension (W × H × D)175 mm × 113.5 mm × 21 mm (6.9″ × 4.5″ × 0.83″)
• Battery/
• Application EnvironmentIndoor
• Power Consumption≤ 5 W
• LanguageEnglish, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese (Brazil), Spanish, Hebrew, Romanian, Turkish, Estonian, Danish, Swedish, Norwegian, Finnish, Vietnamese, Croatian, Slovenian, Serbian, Arabic, Portuguese (Portugal), Lithuanian, Uzbek, Kazakh, Mongolian, Ukrainian
