Hikvision DS-6904UDI 4 Channel Output 4K Decoder, 4x 12MP, 8x 8MP, 12x 5MP, 20x 3MP, 32x 2MP


Designed for the high-definition video monitoring system, the Hikvision HIK-6904UDI Decoder is developed on the basis of embedded hardware platform, ensuring high reliability and stability of system running. The HIK-6904UDI Decoder is capable of 4-ch@12MP, 8-ch@8MP, 12- ch@5MP, 20-ch@3MP and 32-ch@2MP simultaneous decoding, and outputting decoded video via BNC, VGA, or HDMI interfaces, and it also supports multiple video stream formats like H.265, H.264+, H.264 and MPEG4. The decoded video can be displayed on a video wall or large screen.

$1,842.00 $2,465.00 inc GST +3 Year Warranty & Support

Download Specification Sheet
Download User Manual

Designed for the high-definition video monitoring system, the Hikvision HIK-6904UDI Decoder is developed on the basis of embedded hardware platform, ensuring high reliability and stability of system running. The HIK-6904UDI Decoder is capable of 4-ch@12MP, 8-ch@8MP, 12- ch@5MP, 20-ch@3MP and 32-ch@2MP simultaneous decoding, and outputting decoded video via BNC, VGA, or HDMI interfaces, and it also supports multiple video stream formats like H.265, H.264+, H.264 and MPEG4. The decoded video can be displayed on a video wall or large screen.

  • Powerful decoding capability up to 128-ch 1080p
  • Multiple output interfaces: HDMI, VGA, BNC
  • Various video viewing functions: window splicing, cross-window, window division, window roaming
  • H.265+/H.265, H.264+/H.264, Hik264, MPEG4 and MJPEG video compression
  • DS-6901UDI provides HDMI,VGA,and BNC output interfaces.
  • DS-6904UDI,DS-6908UDI,DS-6910UDI,DS-6912UDI,DS-6916UDI provide HDMI(adaptable to DVI-D) and BNC output interfaces.
  • Up to 4K (3840×2160@30Hz) via HDMI output interfaces(only for even interface).
  • Up to 16-ch decoding at 12 MP resolution (DS-6916UDI).
  • H.265+/H.265,H.264+/H.264,Hik264,MPEG4 and MJPEG video compression.
  • PS,RTP,TS,ES,HIK encapsulation formats.
  • Three encoding levels:baseline,main,and high-profile.
  • G.722,G711A,G726,G711U,MPEG2-L2,and AAC audio compression.
  • Two decoding modes:active decoding and passive decoding.
  • Remote video files` decoding output.
  • Supports window opening and window roaming.
  • Supports two-way audio via client software.
  • Supports multi-screen control with PC installed with RSC server.
  • Supports Wi-Fi module access to display the signal from IOS/Android mobile phone or pad on video all/
  • Wi-Fi can be enabled via the Web browser or client software.You can get stream and decode the video on the video wall when Wi-Fi is enabled if no wired network can be accessed.
  • Gets stream and decodes via URL and RTSP from encoding devices.
  • Displays the decoded video stream on the video wallby directly linking cameras or by stream media forwarding.
  • You can configure what the video wall shows when decoding ends and streaming fails via the Web browser and client software.
  • Configurable LED width and height parameters when the LED is connected.
  • Regular and irregular virtual screen configurable to display multiple signal sources and get rid of the restriction of physical screen.
  • Accessible by 2.4 MP DeepinView camera.
  • Accessible by thermal network camera and you can view the temperature measurement,dynamic fire source detection,ship detection and VCA information in live view and playback.
  • You can enable or disable the smart information for the thermal network camera.
  • Remote PTZ control via transparent channel.
  • Two-way audio.
  • Port aggregation technology(Ethernet Channel).
