Product Overview
For sites where mains power and fixed internet are simply not available, the DS-2XS6A46G1/P-IZS/C36S80 delivers a genuinely self-contained outdoor surveillance solution. This solar-powered ANPR bullet camera pairs an 80W photovoltaic panel and a 360Wh rechargeable lithium battery with built-in 4G connectivity, so it operates entirely off-grid without compromising on capability. Featuring a 4MP sensor with a 2.8-12mm motorised varifocal lens, it can be precisely aimed at a lane, gate, or road approach to capture vehicle number plates using onboard Automatic Number Plate Recognition. Built with a 1/1.8″ progressive scan CMOS sensor and 120 dB Wide Dynamic Range, it handles backlit entrances and high-contrast outdoor scenes. Deep learning-based human and vehicle classification adds accurate event detection, while local edge storage via MicroSD (up to 256GB) and 8GB eMMC ensures footage is retained even during network interruptions. It is well suited to remote property entrances, farm gates, construction site access, and private roads where traditional security infrastructure is not practical.
Key Capabilities
Solar-Powered Off-Grid Operation
The 80W photovoltaic panel charges a 360Wh lithium battery, providing continuous 24/7 operation at remote sites. Intelligent battery management includes temperature protection, charge-discharge protection, low-battery sleep mode, and remote wakeup, extending service life in variable conditions.
Built-In ANPR
Onboard Automatic Number Plate Recognition reads and captures vehicle licence plates directly on the camera, enabling automated access logging, vehicle tracking, and integration with third-party access control systems without requiring a separate ANPR server or recorder.
4G Cellular Connectivity
An integrated LTE module supports LTE-TDD, LTE-FDD, WCDMA, and GSM networks via a Micro SIM card. This removes any dependency on fixed internet infrastructure, making real-time remote access and event notifications practical at locations far from any cabled network.
Motorised Varifocal Lens
The 2.8-12mm motorised varifocal lens provides 4.3x optical zoom with autofocus, allowing precise framing of a driveway, gate lane, or road approach from the installation point. Wide-angle mode covers general area monitoring while the zoomed position delivers the tight framing ANPR capture requires.
AI Human and Vehicle Classification
Deep learning algorithms classify motion events as human or vehicle targets, filtering out environmental triggers such as moving vegetation or animals. This keeps event logs and alert notifications relevant, which is particularly important when remote monitoring response time matters.
Dual-Layer Edge Storage
A MicroSD slot supports cards up to 256GB for extended local recording, backed by 8GB of built-in eMMC storage. Both layers keep footage accessible locally during 4G outages, reducing the risk of recording gaps at sites where network reliability cannot be guaranteed.
Best For
- Remote Site Entry Monitoring: The solar panel and 4G module together eliminate the need for any external power or network cable, making this practical at farm gates, private roads, and rural property entrances where running infrastructure would be cost-prohibitive.
- Unmanned Vehicle Access Points: Built-in ANPR reads number plates and logs vehicle movements automatically, supporting access control workflows at gated communities, private driveways, and parking areas without on-site staff.
- Construction Site Security: The IP66-rated bullet housing and solar independence suit temporary deployments where power is unavailable and the camera may need to be relocated as site conditions change.
- Agricultural and Farm Perimeters: Monitors equipment sheds, livestock paddock entrances, and farm access tracks with event-based recording triggered by vehicle or human movement classification.
- Highway and Border Approaches: The 4G link and ANPR capability support vehicle tracking and real-time plate capture on remote roads where fixed network infrastructure does not exist.
Why Choose the DS-2XS6A46G1/P-IZS/C36S80
Most bullet cameras require both a power source and a network connection, limiting deployment to locations with existing infrastructure. The DS-2XS6A46G1/P-IZS/C36S80 removes both constraints simultaneously. The 80W solar panel and 360Wh battery provide autonomous power with intelligent management that prevents over-discharge in low-sun periods, while the integrated 4G LTE module delivers live remote access via Hik-Connect and HikCentral from anywhere on the cellular network. Combining this with onboard ANPR, a motorised varifocal lens for precise lane framing, and dual-layer edge storage means the camera captures, reads, and retains plate data locally even when connectivity drops. A standard ANPR bullet camera without these built-in features would require a nearby recorder, a network switch, and mains power to deliver the same result. Available at Security Wholesalers, this model is the practical choice when the installation site simply cannot support conventional cabling.
Buyer Decision Tips
SIM Card and Data Plan: The 4G module requires a Micro SIM card with a suitable data plan, which is not included. Before ordering, confirm the mobile network coverage at the installation site and select a data plan that suits the expected event frequency and remote viewing requirements. In areas with weak LTE signal, footage will still be stored locally on the MicroSD or eMMC, but live remote access will be unreliable until signal improves.
Solar Panel Positioning: The 80W panel must be oriented to receive maximum direct sunlight throughout the day. In southern Australia, a north-facing tilt is typical. Installations in heavily shaded locations, under tree canopy, or in regions with extended overcast periods should account for reduced charging hours, as the 360Wh battery capacity and low-battery sleep mode are designed to manage short-term shortfalls but not prolonged shading over multiple days. Note that a lead time applies to this product, so confirm availability before committing to a project schedule.
Key Features & Technical Specifications
| Model |
DS-2XS6A46G1/P-IZS/C36S80 |
| Resolution |
4MP (2560 x 1440) |
| Image Sensor |
1/1.8″ progressive scan CMOS |
| Lens Type |
Motorised varifocal, 2.8-12mm, 4.3x optical zoom, autofocus |
| Wide Dynamic Range |
120 dB true WDR |
| Video Compression |
H.265+ |
| ANPR |
Built-in Automatic Number Plate Recognition |
| Smart Detection |
Deep learning human and vehicle target classification |
| 4G Connectivity |
LTE-TDD / LTE-FDD / WCDMA / GSM, Micro SIM card |
| Solar Panel |
80W photovoltaic panel (included) |
| Battery |
360Wh rechargeable lithium battery |
| Battery Management |
High-low temperature protection, charge-discharge protection, low-battery sleep, remote wakeup |
| Local Storage |
MicroSD up to 256GB, built-in 8GB eMMC |
| Weather Rating |
IP66 |
| Remote Management |
Hik-Connect, HikCentral |
| Housing |
Outdoor bullet |
Ideal Use Cases
Farm Gate and Rural Property Entry
Solar power and 4G connectivity allow deployment at remote farm gates with no nearby power poles or internet. ANPR logs every vehicle entering or exiting, and the 2.8-12mm motorised lens frames the lane precisely from the mounting position.
Construction Site Access Control
The IP66-rated bullet housing handles dust and rain on active construction sites. Solar independence means the camera can be repositioned as the site layout changes, without re-running power cables, while edge storage on MicroSD retains footage between 4G sessions.
Gated Community and Private Road Monitoring
Built-in ANPR captures and records plate data at entry and exit points, supporting integration with access control systems for automated vehicle permitting without manual operator involvement or a local server on site.
Remote Highway and Road Approaches
4G LTE transmission enables real-time vehicle monitoring on regional roads and highway approaches where fixed network infrastructure is absent. Deep learning vehicle classification triggers event recording accurately, reducing storage consumption on the onboard MicroSD.
Temporary Event and Pop-Up Site Security
Solar power and cellular connectivity make this camera practical for temporary deployments at events, markets, or short-term leased sites where neither mains power nor fixed networking is available and rapid setup is required.
Agricultural Equipment and Storage Monitoring
Human and vehicle classification via deep learning keeps alerts relevant at machinery sheds and equipment storage areas where livestock, birds, or blowing vegetation would otherwise generate constant false motion events.
Choosing the Right Model
- Choose this model if: Your site has no mains power and no fixed internet connection, and you need onboard ANPR to log vehicle plates at a gate, lane, or road approach. The combination of the 80W solar panel, 360Wh battery, 4G LTE module, and built-in ANPR in a single bullet unit is the defining reason to specify this model.
- Choose a different model if: Mains power and a wired network are already available at the installation point. In that case, a standard PoE ANPR bullet camera will deliver the same imaging and plate capture capability at a lower cost, without the solar and cellular components you would not need.
- Choose a different model if: The installation site receives very limited direct sunlight for extended periods. The solar system is designed for outdoor environments with reasonable sun exposure, and a fully off-grid wired alternative would be more reliable in permanently shaded or indoor locations.
- Choose a different model if: You need PTZ capability or wide-area panoramic coverage across a large open space. The fixed bullet form factor with a varifocal lens is optimised for directed lane or road coverage rather than wide sweeping or pan-tilt-zoom surveillance.
FAQs
- Does the DS-2XS6A46G1/P-IZS/C36S80 include a SIM card?
No. The camera accepts a Micro SIM card but one is not supplied. You will need to source a Micro SIM from a mobile carrier with a data plan that suits your monitoring requirements. Before purchasing, confirm that the installation location has 4G LTE, WCDMA, or GSM coverage from your chosen carrier, as the camera depends entirely on cellular connectivity for remote access and event transmission.
- How does the solar system handle extended cloudy periods?
The 360Wh lithium battery is designed to sustain operation through short periods of low solar input. The intelligent battery management system includes a low-battery sleep mode that powers down non-essential functions and a remote wakeup feature so the camera can resume operation automatically when charge levels recover. Extended periods of heavy shading or overcast weather will reduce available runtime, so panel placement in a location with maximum daily sun exposure is important for consistent performance.
- How accurate is the built-in ANPR on this camera?
The onboard ANPR uses deep learning algorithms to detect, capture, and read vehicle number plates. Accuracy is influenced by the lens framing, vehicle approach angle, vehicle speed, and lighting conditions. The 2.8-12mm motorised varifocal lens allows precise adjustment of the capture zone, and the 120 dB Wide Dynamic Range sensor helps maintain plate legibility in high-contrast lighting such as headlights against a dark background. For best results, the camera should be mounted at an appropriate height and angle to capture plates as vehicles approach in a single lane.
- What happens to recorded footage if the 4G connection drops?
The camera stores footage locally on the MicroSD card (up to 256GB) and the built-in 8GB eMMC. Both storage layers operate independently of network connectivity, so recording continues without interruption during cellular outages. Once the 4G connection is restored, the camera can resume remote access and event notifications through Hik-Connect or HikCentral.
- Can this camera be mounted on a pole or post at a remote gate?
Yes. The bullet housing is designed for directional outdoor mounting on poles, walls, or dedicated camera mounts. The motorised varifocal lens allows fine adjustment of the field of view after mounting, so the capture zone can be precisely set to cover a gate lane or road approach without physically repositioning the camera body. The 80W solar panel is mounted separately and connected to the camera unit, and should be oriented for maximum sun exposure relative to the mounting location.
- Is the DS-2XS6A46G1/P-IZS/C36S80 compatible with Hikvision NVRs?
The camera is designed for standalone solar and 4G operation and connects via the cellular network rather than a traditional PoE or wired LAN connection. Remote management is handled through Hik-Connect and HikCentral software platforms. If integration with a Hikvision NVR is required, confirm compatibility with your specific NVR model before purchasing, as the 4G-based connection differs from standard IP camera network integration. Security Wholesalers can assist with compatibility queries prior to ordering.
- What weather conditions can this camera withstand?
The DS-2XS6A46G1/P-IZS/C36S80 carries an IP66 weatherproof rating, providing full protection against dust ingress and against powerful water jets from any direction. The battery management system also includes high and low temperature protection, allowing operation across the temperature extremes typical of Australian outdoor environments including coastal, desert, and high-altitude locations.
Additional Information
No additional downloads available for this product.
