| Image Sensor: |
| |
1/1.8″ Progressive Scan CMOS |
|
|
|
| Min. Illumination: |
| |
Color: 0.02 Lux @ (F1.2, AGC ON)
B/W: 0.001 Lux @ (F1.2, AGC ON) |
|
|
|
| Shutter time: |
| |
1 s to 1/100,000 s |
|
|
|
| Slow shutter: |
| |
Support |
|
|
|
| Lens: |
| |
2.8-12mm @ F1.4 |
|
|
|
| Auto Iris: |
| |
DC drive |
|
|
|
| Adjustment Range: |
| |
Pan:0° – 355°, Tilt: 0° – 75°, Rotation: 0° – 355° |
|
|
|
| Day& Night: |
| |
IR cut filter with auto switch |
|
|
|
| Wide Dynamic Range: |
| |
Support |
|
|
|
| Digital noise reduction: |
| |
3D DNR |
| Compression Standard |
|
|
|
| Video Compression: |
| |
H.264/MJPEG |
|
|
|
| H.264 code profile: |
| |
Baseline Profile / Main Profile / High Profile |
|
|
|
| Video bit rate: |
| |
32Kbps~16Mbps |
|
|
|
| Audio Compression: |
| |
G.711/G.722.1/G.726/MP2L2 |
|
|
|
| Audio bit rate: |
| |
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Image |
|
|
|
| Max. Image Resolution: |
| |
3072 x 2048 |
|
|
|
| Main Stream: |
| |
50Hz: 25fps (3072×2048,3072×1728,2560×2048,2560×1920,2048×1536,1920×1080,1280×720)
60Hz: 25fps (3072×2048),30fps(3072×1728,2560×2048,2560×1920,2048×1536,1920×1080,1280×72
0) |
|
|
|
| Third Stream: |
| |
Independent with Main Stream and Sub Stream, up to
50Hz: 25fps(1280 × 720)
60Hz: 30fps (1280 × 720) |
|
|
|
| Image Settings: |
| |
Saturation, brightness, contrast adjustable through client software or web browser |
|
|
|
| BLC: |
| |
Support |
|
|
|
| Smart Defog: |
| |
Support |
|
|
|
| ROI: |
| |
Support |
|
|
|
| Day/Night Switch: |
| |
Auto/Schedule/Triggered by Alarm In |
| Network |
|
|
|
| Network Storage: |
| |
NAS (Support NFS,SMB/CIFS) |
|
|
|
| Alarm Trigger: |
| |
Intrusion detection, Defocus detection, Motion detection, Face detection, line crossing detection,
Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
|
|
|
| Protocols: |
| |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
|
|
|
| Security: |
| |
User Authentication, Watermark, IP address filtering, Anonymous access |
|
|
|
| System Compatibility: |
| |
ONVIF, PSIA, CGI, ISAPI |
| Interface |
|
|
|
| Audio Input: |
| |
1-ch 3.5 mm audio interface, Mic in/Line in. 1 built-in Microphone |
|
|
|
| Audio Output: |
| |
1-ch 3.5mm audio interface |
|
|
|
| Communication Interface: |
| |
1 RJ45 10M/100M Ethernet port, 1 RS-485 interface and 1 RS-232 interface |
|
|
|
| Alarm Input: |
| |
1 |
|
|
|
| Alarm Output: |
| |
1 |
|
|
|
| Video Output: |
| |
1Vp-p Composite Output (75 Ω, BNC) |
|
|
|
| On-board storage: |
| |
Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
|
|
|
| Reset Button: |
| |
Yes |
| General |
|
|
| Protection Level |
|
IP66 |
| Operating conditions |
|
-30 °C – 60 °C Humidity 95% or less (non-condensing) -H: -40 °C – 60 °C |
| Power Supply |
|
DC12V/AC24V/PoE(802.3af) , -H: DC12V/AC24V/PoE(802.3at) |
| IR Distance |
|
Up to 30m (8-32mm to 50m) |
| Power Consumption |
|
Max: 12W -H: 17W |
| Dimensions |
|
Φ 164.9 × 127 mm(Φ 6.49” ×5”) |
| Weight |
|
2100g (4.62lbs) |
