Product SKU: DS-2CD37167G3T-LIZSUY
Product Overview
The Hikvision DS-2CD37167G3T-LIZSUY is a 16MP Ultra Series Smart Hybrid Light dome network camera designed for high-detail outdoor surveillance, advanced analytics and challenging lighting environments. Its 1/1.8-inch Progressive Scan CMOS sensor delivers up to 4608 × 3456 resolution, while HIK AI-ISP, scene-adaptive 130 dB WDR and ultra-low-light imaging help maintain clear footage across changing conditions. A motorised 2.7–13.5 mm F1.2 varifocal lens allows the viewing angle to be adjusted from a broad 99° horizontal scene to a tighter 43° view. Smart Hybrid Light integrates infrared and white illumination with a range up to 40 metres. Deep-learning human and vehicle classification, face capture, people counting and arrayed dual microphones add intelligent surveillance capability, while the Y anti-corrosion version combines IP67, IK10 and NEMA 4X protection for demanding outdoor installations.
Key Capabilities
16MP Ultra-High-Definition Imaging
The 1/1.8-inch sensor produces up to 4608 × 3456 resolution, providing very high pixel density for large scenes and detailed post-event review. This is particularly useful where operators may need to digitally inspect smaller objects or activity within recorded footage.
HIK AI-ISP Low-Light Imaging
HIK AI-ISP provides advanced image processing and noise reduction to improve clarity in demanding lighting. Combined with the large 1/1.8-inch sensor, F1.2 aperture and scene-adaptive WDR, it helps retain usable colour, contrast and detail as lighting changes.
2.7–13.5 mm Motorised Varifocal Lens
The motorised lens adjusts from approximately 99° to 43° horizontal field of view. Installers can remotely refine zoom and focus to balance wide scene coverage against greater target detail without manually readjusting the lens at the camera.
40 m Smart Hybrid Light
Integrated infrared and white supplemental lighting provide a range up to 40 metres. Smart Hybrid Light supports three supplemental-light modes, allowing the camera to operate with discreet IR, visible white light or an intelligent lighting strategy according to the configured scene.
Human & Vehicle Deep Learning
Perimeter protection supports line crossing, intrusion, region entrance and region exiting detection with alarms filtered by human and vehicle target types. This helps reduce unwanted event notifications from irrelevant movement within busy outdoor scenes.
Dual Microphones & Audio Interfaces
An arrayed dual microphone provides built-in audio capture, while separate line-level audio input and output interfaces support external audio equipment. The camera does not include an integrated speaker, so an external speaker is required where live talk-back is needed.
Best For
- Commercial perimeters: High-resolution imaging and human/vehicle filtering suit boundaries, driveways and restricted outdoor areas.
- Warehouses and logistics facilities: The motorised lens and 40 metre supplemental lighting provide flexible coverage around loading and storage areas.
- Building entrances: The varifocal lens can concentrate more detail on doorways, gates and controlled pedestrian approaches.
- Evidence-focused surveillance: 16MP resolution provides additional image detail for reviewing large scenes and smaller recorded targets.
- Demanding outdoor locations: IP67, IK10 and NEMA 4X protection on the Y version suit environments requiring additional corrosion resistance.
Why Choose the DS-2CD37167G3T-LIZSUY
The DS-2CD37167G3T-LIZSUY combines very high 16MP image detail with a flexible motorised varifocal lens and sophisticated low-light processing in a robust dome enclosure. HIK AI-ISP and 130 dB WDR help maintain image quality across difficult lighting, while Smart Hybrid Light provides infrared and white illumination up to 40 metres. Deep-learning human and vehicle classification makes perimeter events more targeted, and additional functions such as face capture, people counting, dual microphones and alarm interfaces broaden its use beyond basic recording. Available through Security Wholesalers, the Y anti-corrosion version is particularly suitable where high image quality, intelligent analytics and stronger environmental protection are all required in one professional outdoor camera.
Buyer Decision Tips
Buyer Tip: Maximum 4608 × 3456 resolution operates at up to 12.5 fps in a 50 Hz system. If smoother motion is more important than maximum pixel count, the camera supports up to 25 fps at resolutions including 3840 × 2160 and below.
Buyer Tip: This model has built-in dual microphones but no integrated speaker. If the project requires two-way talk, connect a compatible external speaker through the line-level audio output or select an appropriate model with a built-in speaker.
Key Features & Technical Specifications
| Product |
16MP Smart Hybrid Light motorised varifocal dome network camera. |
| Model |
DS-2CD37167G3T-LIZSUY. |
| Image Sensor |
1/1.8-inch Progressive Scan CMOS. |
| Maximum Resolution |
4608 × 3456, approximately 16MP. |
| Minimum Illumination |
Colour: 0.001 Lux at F1.2 with AGC on; 0 Lux with supplemental light. |
| Shutter Speed |
1 second to 1/100,000 second. |
| Day & Night |
IR cut filter. |
| Lens |
Motorised 2.7–13.5 mm varifocal lens, maximum F1.2 aperture. |
| Field of View |
Horizontal 99°–43°, vertical 72°–33°, diagonal 136°–54°. |
| Focus |
Auto, semi-auto and manual. |
| DORI – Wide |
Detect 113.0 m, Observe 44.9 m, Recognise 22.6 m, Identify 11.3 m. |
| DORI – Tele |
Detect 240.8 m, Observe 95.5 m, Recognise 48.2 m, Identify 24.1 m. |
| Supplemental Lighting |
IR and white light with Smart Hybrid Light, up to 40 m. |
| IR Wavelength |
850 nm. |
| Wide Dynamic Range |
130 dB WDR. |
| Image Enhancement |
HIK AI-ISP, BLC, HLC, 3D DNR, distortion correction and defog. |
| Video Compression |
H.265, H.265+, H.264, H.264+ and MJPEG depending on stream. |
| Analytics |
Human and vehicle classification, line crossing, intrusion, region entrance, region exiting, face capture and people counting. |
| Built-In Microphone |
Arrayed dual microphone. |
| Built-In Speaker |
No. |
| Audio Interfaces |
1 line input and 1 line output. |
| Alarm Interfaces |
2 alarm inputs and 2 alarm outputs, maximum 24 V AC/DC at 1 A. |
| Power Output |
12 V DC, maximum 100 mA. |
| Onboard Storage |
microSD, microSDHC and microSDXC up to 512 GB. |
| Network Interface |
1 × RJ45 10/100 Mbps Ethernet port. |
| Power |
12 V DC ±25%, maximum 16.2 W; PoE IEEE 802.3at Class 4, maximum 18 W. |
| Protection |
IP67, IK10 and NEMA 4X anti-corrosion protection on the Y version. |
| Anti-Corrosion Level |
Hikvision moderate anti-corrosion protection classification. |
| Operating Conditions |
-30°C to 60°C; humidity 95% or less, non-condensing. |
| Material |
Metal. |
| Dimensions |
Ø141 mm × 112 mm. |
| Weight |
Approximately 850 g. |
Ideal Use Cases
Commercial Perimeters
Use 16MP imaging and human/vehicle perimeter rules around boundaries, driveways and restricted external areas.
Warehouses & Loading Areas
The motorised lens provides flexibility when covering loading docks, storage zones, gates and vehicle approaches.
Building Entrances
Zoom toward doorways and access points where higher pixel density is more useful than the widest available field of view.
Large Indoor Spaces
High resolution and people-counting capability can support monitoring in suitable foyers, commercial areas and larger internal spaces.
Moderately Corrosive Outdoor Areas
The Y version adds NEMA 4X anti-corrosion protection for sites where a standard outdoor camera enclosure may not provide the preferred level of environmental resistance.
Choosing the Right Model
- Choose the DS-2CD37167G3T-LIZSUY if: You need 16MP resolution, HIK AI-ISP, a motorised 2.7–13.5 mm lens, 40 metre Smart Hybrid Light, deep-learning analytics and the Y anti-corrosion enclosure.
- Choose an /SL active-deterrence model if: The site also requires a built-in strobe light, onboard speaker and audible warning capability.
- Choose a lower-resolution camera if: Reduced recording bandwidth and storage consumption are more important than maximum image detail.
- Choose a fixed-lens model if: The target scene and field of view are already known and motorised zoom adjustment is unnecessary.
FAQs
- Is the Hikvision DS-2CD37167G3T-LIZSUY a 16MP camera?
Yes. The DS-2CD37167G3T-LIZSUY uses a 1/1.8-inch Progressive Scan CMOS sensor and provides a maximum resolution of 4608 × 3456, which is approximately 16MP. In a 50 Hz system, full 4608 × 3456 recording operates at up to 12.5 fps, while lower resolutions support higher frame rates. This makes the camera especially useful where very high scene detail is more important than maximum full-resolution motion smoothness.
- What lens does the DS-2CD37167G3T-LIZSUY use?
The camera uses a motorised 2.7–13.5 mm varifocal lens with a maximum F1.2 aperture. Its horizontal field of view adjusts from approximately 99° to 43°, allowing installers to balance broad scene coverage against higher pixel density on a narrower target area. Focus can operate in auto, semi-auto or manual mode, making commissioning easier than with a manually adjusted conventional varifocal lens.
- How far do the IR and white lights reach?
The DS-2CD37167G3T-LIZSUY integrates infrared and white supplemental lighting with a specified range of up to 40 metres. Smart Hybrid Light provides three supplemental-light modes, allowing the camera to use IR, white light or an intelligent lighting strategy depending on configuration. The 40 metre figure is an illumination range rather than a guaranteed identification distance, so usable detail still depends on lens position, subject size and scene conditions.
- Does the DS-2CD37167G3T-LIZSUY have a built-in microphone?
Yes. The camera includes an arrayed dual microphone for built-in audio capture and also provides one line-level audio input and one line-level audio output. A built-in speaker is not specified for this model, so the camera should not be described as providing standalone two-way audio. If live talk-back is required, the installation needs a compatible external speaker connected through the audio output or another suitable audio arrangement.
- What smart analytics are built into this Hikvision camera?
The camera supports deep-learning human and vehicle classification for perimeter protection. Available rules include line crossing, intrusion, region entrance and region exiting, with alarms that can be filtered by target type. It also supports face capture, people counting, scene change detection, audio exception detection, defocus detection and motion detection with human and vehicle filtering, giving installers a broad set of event options for professional surveillance projects.
- How much onboard storage does the DS-2CD37167G3T-LIZSUY support?
The camera includes a built-in memory-card slot supporting microSD, microSDHC and microSDXC cards up to 512 GB. Local storage can be used for recording and event capture and can complement supported network-storage functions such as NAS and Auto Network Replenishment. When planning the camera through Security Wholesalers, match the card endurance and capacity to the actual recording workload rather than choosing storage by capacity alone.
- Is the DS-2CD37167G3T-LIZSUY suitable for harsh outdoor installations?
Yes. The camera is rated IP67 for dust and water resistance and IK10 for impact resistance. The Y anti-corrosion version also carries NEMA 4X protection and is classified by Hikvision for moderate anti-corrosion applications. Its specified operating range is -30°C to 60°C with humidity up to 95% non-condensing. Correct mounting, sealing and cabling are still required to maintain the performance of the complete outdoor installation.
- What is the difference between this model and an active-deterrence /SL version?
The DS-2CD37167G3T-LIZSUY provides 16MP imaging, Smart Hybrid Light, deep-learning analytics, built-in dual microphones and audio/alarm interfaces, but it does not include the integrated strobe light and built-in speaker associated with Hikvision /SL active-deterrence variants. Choose this model when high-resolution imaging and analytics are the priority, and choose an appropriate /SL model when onboard visual and audible warning functions are also required.
Additional Information
Hikvision DS-2CD37167G3T-LIZSUY_Datasheet
