Product Overview
For indoor spaces where a discreet, compact camera needs to deliver genuine analytical intelligence, the DS-2CD2466G2-I cube camera from Hikvision offers a compelling combination of 6MP resolution and AcuSense deep-learning classification in a form factor small enough to sit on a desktop or mount flush to a wall. Featuring a 1/2.4-inch progressive-scan CMOS sensor, it captures footage at 3200 x 1800 across a 105-degree horizontal field of view courtesy of its fixed 2.8 mm lens. Equipped with AcuSense technology, the camera distinguishes between human and vehicle targets, filtering out irrelevant motion triggers from pets, foliage, or passing vehicles seen through glass. Built with 120 dB True WDR, it handles backlit entrances and mixed-lighting retail floors without washing out foreground detail. It also includes a built-in microphone for audio recording and supports PoE power delivery, keeping cabling clean on desk-mounted or wall-mounted installations.
Key Capabilities
6MP Wide Indoor Coverage
The 3200 x 1800 sensor paired with a 2.8 mm lens delivers a 105-degree horizontal field of view, capturing a full room or open-plan workspace in a single frame without the distortion of a fisheye lens.
AcuSense Human and Vehicle Classification
Deep-learning analytics classify motion as human or vehicle targets, separating meaningful alerts from background movement. This reduces the volume of irrelevant notifications on connected NVRs and monitoring apps during business hours.
120 dB True WDR
A 120 dB wide dynamic range handles environments where bright windows sit behind a dimly lit reception counter or retail floor, maintaining readable detail across the full frame rather than sacrificing foreground for background exposure.
Low-Light Performance with IR
Colour imaging remains usable down to 0.003 lux at F1.6, and the built-in 850 nm IR illuminators extend coverage to 10 m in complete darkness, useful for server rooms, storerooms, or after-hours retail floor monitoring.
Flexible Placement: Desktop, Wall, or Ceiling
The cube form factor supports wall, ceiling, and desktop mounting without additional brackets in most configurations. This allows installation in spaces where drilling is limited or where the camera needs to be repositioned periodically.
Best For
- Retail Store Monitoring: The 105-degree FOV and 6MP resolution capture product shelving and customer movement across a small to medium-sized shop floor, with AcuSense filtering out non-human motion triggers.
- Office and Reception Areas: The compact cube profile sits unobtrusively on a reception desk or mounts to a corner wall, covering entry points and common areas without drawing attention.
- Residential Indoor Rooms: Desktop placement makes this suitable for monitoring living areas, home offices, or entry hallways in rental properties where wall mounting may not be practical.
- Storerooms and Server Rooms: The 10 m IR range and 0 lux night capability allow overnight monitoring of access-controlled spaces that are unlit after hours.
Why Choose the DS-2CD2466G2-I
Where a standard indoor IP camera would deliver motion detection based on pixel change alone, the DS-2CD2466G2-I applies AcuSense classification to separate human and vehicle events from background noise. This distinction matters in busy indoor environments where passing foot traffic, air conditioning vents, or reflections would otherwise generate continuous alert noise. The 6MP sensor at 3200 x 1800 provides enough resolution for facial recognition workflows on compatible NVR platforms, and the 120 dB True WDR handles the kind of backlit scenes common near glass-fronted counters or windowed offices. The cube form factor is genuinely distinct from dome or turret cameras: it can be placed on a shelf or desk without mounting hardware, making it one of the more installer-friendly formats for sensitive interior spaces. The DS-2CD2466G2-I is available at Security Wholesalers as part of the Hikvision AcuSense indoor range.
Buyer Decision Tips
Buyer Tip: The DS-2CD2466G2-I has a fixed 2.8 mm lens with no zoom adjustment. At a standard mounting height of around 2.4 m, the 105-degree horizontal FOV covers approximately 4 to 5 m of width at that distance. If you need to monitor a longer corridor or a space wider than a standard room, consider whether a narrower lens or a second camera unit would provide better coverage before committing to this fixed focal length.
Key Features & Technical Specifications
| Image Sensor |
1/2.4-inch Progressive Scan CMOS |
| Maximum Resolution |
3200 x 1800 (6MP) |
| Minimum Illumination |
0.003 lux @ F1.6 (AGC on); 0 lux with IR |
| Lens |
Fixed 2.8 mm; horizontal FOV approx. 105 degrees, vertical approx. 55 degrees, diagonal approx. 127 degrees |
| Aperture |
F1.6 |
| IR Range |
Up to 10 m (850 nm IR) |
| WDR |
120 dB True WDR |
| Video Compression |
H.265, H.265+, H.264, H.264+ |
| Video Streams |
Main / Sub / Third stream |
| Smart Analytics |
AcuSense human and vehicle classification |
| Audio |
Built-in microphone |
| Network Interface |
RJ-45 10/100 Mbps Ethernet |
| Power Supply |
12 V DC +/-25% or PoE (IEEE 802.3af Class 3) |
| Power Consumption |
Max. 9.5 W |
| Dimensions |
70 mm x 70 mm x 130 mm |
| Weight |
Approx. 370 g |
| Mounting Options |
Wall, ceiling, or desktop |
| Operating Conditions |
-10 degrees C to 40 degrees C, humidity 95% or below (non-condensing) |
Ideal Use Cases
Retail Shop Floors
The 105-degree FOV and 6MP resolution cover checkout areas and product aisles in a single camera position, while AcuSense filters out motion from fans or window displays to deliver relevant human-detection events only.
Office Reception Desks
Desktop placement on a reception counter gives a natural forward-facing view of arrivals and departures. The 120 dB True WDR manages glare from glass entry doors or windows directly behind visitors.
Residential Living Areas
The cube form factor can sit on a bookshelf or entertainment unit without ceiling mounting, making it practical for tenants or homeowners who want indoor coverage without permanent installation work.
Server Rooms and Storerooms
Built-in 850 nm IR illuminators provide usable footage at 10 m in complete darkness. AcuSense human classification means access to restricted areas after hours generates an alert rather than a silent recording.
Small Meeting Rooms and Childcare Spaces
Wall or ceiling mounting at a standard 2.4 m height delivers broad room coverage with the wide 2.8 mm lens. The compact cube profile avoids a conspicuous security camera appearance in client-facing or care environments.
Choosing the Right Model
- Choose this model if: You need a compact, discreet indoor camera with AcuSense analytics, 6MP resolution, and flexible mounting options including desktop placement, and your environment suits a wide 105-degree fixed 2.8 mm view.
- Choose a different model if: Your installation requires outdoor weatherproofing, as this camera carries no confirmed IP weather rating for external use. Similarly, if you need a longer focal length for corridor or entrance monitoring beyond approximately 5 m width, a fixed dome or turret camera with a narrower lens would deliver better framing at distance.
FAQs
- Can the DS-2CD2466G2-I be used outdoors?
No confirmed IP weather resistance rating is listed for this camera in the product data. It is specified for indoor use only, with an operating temperature range of -10 degrees C to 40 degrees C. Mounting it in a location exposed to rain, dust, or direct sunlight is not recommended.
- What does AcuSense actually do in practice?
AcuSense uses deep-learning processing on the camera itself to classify detected motion as either a human or a vehicle target. Events that do not match either class, such as a fan oscillating, a pet moving across a room, or light changes from a passing car outside a window, are not categorised as human detections. This reduces alert volume on connected NVRs and mobile notifications.
- Is the 2.8 mm lens the only option available?
Based on the confirmed product data, the DS-2CD2466G2-I is available in a fixed 2.8 mm lens only. This provides a horizontal FOV of approximately 105 degrees, which suits general room coverage but does not allow focal length adjustment.
- Does the camera support PoE, and what power draw should I plan for?
Yes. The DS-2CD2466G2-I supports IEEE 802.3af Class 3 PoE, which is standard on most NVRs and managed PoE switches. Maximum power consumption is 9.5 W, well within the 15.4 W Class 3 PoE budget. It also accepts 12 V DC power input as an alternative.
- How does the cube form factor differ from a standard dome camera for indoor use?
Unlike a dome camera, which requires ceiling or wall drilling with a fixed bracket, the cube format can be placed on a flat surface such as a desk, shelf, or counter without hardware. This makes it faster to deploy in commercial tenancies or residential spaces where permanent mounting is not practical, while still supporting wall and ceiling mounting when needed.
- Does this camera support two-way audio?
No. The DS-2CD2466G2-I includes a built-in microphone for audio recording, but there is no confirmed built-in speaker. Two-way voice communication is not supported by this model. If audio monitoring is a priority, note that recorded audio from the microphone can be stored and reviewed on a compatible NVR. For purchasing or specification queries, Security Wholesalers can confirm current stock and compatible NVR platforms.
