Product SKU: DS-2210ZJ-WA-140
Product Overview
The Hikvision DS-2210ZJ-WA-140 is a white pendant mounting bracket designed to suspend compatible CCTV cameras approximately 549.2 mm below a ceiling or overhead mounting surface. Its long pendant profile is useful where a camera needs additional separation from the ceiling to achieve the required installation height or viewing position. The bracket combines aluminium, stainless steel, silicone and EVA components and weighs approximately 1394 g. A Ø150 mm mounting profile and multiple published M4 camera fixing patterns provide several physical attachment options for supported camera assemblies. The supplied datasheet does not state a maximum load capacity, IP rating, environmental classification or model-by-model compatibility list, so these values should not be assumed. Camera fit, supporting structure and environmental requirements should therefore be confirmed for the complete installation.
Key Capabilities
549.2 mm Pendant Drop
The long pendant body positions a compatible CCTV camera approximately 549.2 mm below the mounting surface, providing substantially more drop than compact ceiling adaptors or short pendant brackets.
Multiple Camera Mounting Patterns
The camera-side mounting plate includes double-gang, Ø130 mm and Ø128 mm M4 fixing patterns, giving the bracket several published attachment configurations for physically compatible camera assemblies.
Mixed-Material Construction
Aluminium and stainless steel are combined with silicone and EVA components within the mounting assembly, providing the structural and supporting materials specified for this bracket.
Dedicated Overhead Mounting Plate
The ceiling-side plate uses four Ø8.5 mm mounting holes positioned on an approximately Ø121.2 mm circle, providing a defined fixing arrangement for the supporting structure.
Best For
- High Ceiling Installations: Suitable where a compatible CCTV camera needs to be lowered by approximately 549 mm from the overhead mounting surface.
- Commercial Interiors: Useful in supported retail, office and public-area camera installations where a longer pendant position is required.
- Multi-Pattern Camera Bases: The published M4 mounting configurations provide several options for physically compatible camera assemblies.
- Replacement Mounting Projects: Appropriate where an existing supported installation is already confirmed to use the DS-2210ZJ-WA-140 interface.
Why Choose the DS-2210ZJ-WA-140
The DS-2210ZJ-WA-140 is useful when a compatible camera needs considerably more separation from the ceiling than a short pendant mount can provide. Its 549.2 mm overall length creates a clearly defined camera position below the supporting structure, while the Ø150 mm mounting profile and multiple M4 camera patterns offer flexibility across supported physical interfaces. The combination of aluminium, stainless steel, silicone and EVA also matches the construction specified for the complete bracket assembly. Available through Security Wholesalers, the DS-2210ZJ-WA-140 should be chosen only after confirming the exact camera, mounting substrate and project requirements because the supplied datasheet does not publish a load capacity, IP rating or explicit indoor/outdoor classification.
Buyer Decision Tips
Buyer Tip: Confirm that a 549.2 mm pendant drop is appropriate for the installation. If the camera needs to sit closer to the ceiling, a shorter compatible Hikvision mounting accessory may provide a cleaner finished result.
Buyer Tip: Do not infer a maximum load, IP rating or outdoor suitability from the bracket materials alone. These specifications are not stated in the supplied datasheet and should be verified separately if they are critical to the installation.
Key Features & Technical Specifications
| Product Type |
Pendant mounting bracket for compatible CCTV cameras. |
| Model |
DS-2210ZJ-WA-140. |
| Mounting Type |
Pendant mount. |
| Colour |
White. |
| Materials |
Aluminium + stainless steel + silicone + EVA. |
| Dimensions |
Ø150 × 549.2 mm. |
| Pendant Length |
Approximately 549.2 mm overall. |
| Maximum Diameter |
Approximately Ø150 mm. |
| Weight |
Approximately 1394 g. |
| Camera Mounting Holes |
10 × M4 holes across the published mounting patterns. |
| Camera Mounting Pattern 1 |
Double-gang pattern with 4 × M4 holes. |
| Camera Mounting Pattern 2 |
Ø130 mm pattern with 3 × M4 holes. |
| Camera Mounting Pattern 3 |
Ø128 mm pattern with 3 × M4 holes. |
| Ceiling Mounting Holes |
4 × Ø8.5 mm. |
| Ceiling Mounting Pattern |
Approximately Ø121.2 mm circle. |
| Published Load Capacity |
Not stated in the supplied datasheet. |
| Published IP Rating |
Not stated in the supplied datasheet. |
| Published Indoor/Outdoor Classification |
Not stated in the supplied datasheet. |
Ideal Use Cases
High Commercial Ceilings
Lowers a compatible camera approximately 549 mm from the mounting surface where direct ceiling mounting would position it too high.
Retail and Public Areas
Provides a defined pendant camera position for supported installations in large open indoor spaces.
Warehouse Camera Positions
Useful where a compatible camera needs additional drop beneath a high overhead structure to achieve the intended mounting height.
Multi-Pattern Camera Installations
The several published M4 fixing patterns provide useful physical flexibility where the selected camera uses a matching interface.
Choosing the Right Model
- Choose this model if: Your compatible CCTV camera uses one of the published mounting patterns and needs an approximately 549.2 mm pendant drop.
- Choose a shorter pendant if: The camera needs to sit closer to the ceiling and the 549.2 mm overall length would position it too low.
- Confirm additional specifications if: The project requires a particular load capacity, IP rating or indoor/outdoor certification, as these are not stated in the supplied datasheet.
FAQs
- What is the Hikvision DS-2210ZJ-WA-140 used for?
The Hikvision DS-2210ZJ-WA-140 is a pendant mounting bracket for compatible CCTV camera installations. It provides a 549.2 mm drop from the mounting surface and uses a circular camera plate with several published M4 mounting patterns. The bracket should still be matched to the exact camera before installation because the supplied datasheet does not provide a model-by-model compatibility list.
- What are the dimensions and weight of the DS-2210ZJ-WA-140?
The DS-2210ZJ-WA-140 measures approximately Ø150 mm × 549.2 mm and weighs about 1394 g. These figures refer to the pendant mount itself, so additional clearance should be allowed for the attached camera, cabling and fixing hardware when planning the completed installation.
- What materials are used in the DS-2210ZJ-WA-140?
The datasheet specifies aluminium, stainless steel, silicone and EVA as the materials used in the DS-2210ZJ-WA-140. These materials are used across the structural mount and associated sealing or cushioning components. The bracket is supplied in white to coordinate with compatible CCTV camera housings.
- What camera mounting patterns are provided on the DS-2210ZJ-WA-140?
The published dimension drawing shows several camera-mounting options, including a double-gang four-hole M4 pattern, a Ø130 mm three-hole M4 pattern and a Ø128 mm three-hole M4 pattern. This gives the mounting plate flexibility across supported camera assemblies, but physical compatibility should still be confirmed against the exact camera before installation.
- What mounting-hole pattern is used at the ceiling plate of the DS-2210ZJ-WA-140?
The dimension drawing specifies four Ø8.5 mm mounting holes arranged on a Ø121.2 mm circle at the ceiling plate. Installers should select fixings appropriate for the actual supporting structure and the full camera-and-bracket assembly. For Security Wholesalers projects, the substrate and fasteners should be assessed before installation rather than selected from bracket dimensions alone.
- Does the DS-2210ZJ-WA-140 have a published load rating or IP rating?
The supplied datasheet does not state a maximum load capacity, IP rating or explicit indoor/outdoor classification for the DS-2210ZJ-WA-140. Those values should therefore not be assumed. If the installation depends on a specific structural or environmental rating, confirm those requirements against the exact camera system and current approved mounting documentation before installation.
