Product SKU: DS-2CD2T66G2H-4I
Product Overview
The Hikvision DS-2CD2T66G2H-4I is a professional 6 MP bullet-style hybrid camera combining advanced ColorVu warm-light illumination with powerful infrared (IR) capability for 24/7 full-colour imaging. Replacing the older DS-2CD2T66G2 model, this upgraded version provides superior brightness, extended IR range up to 80 m, and AcuSense technology for intelligent human and vehicle detection. It’s ideal for outdoor installations requiring dependable surveillance and precise colour reproduction at long distances.
Why Choose the DS-2CD2T66G2H-4I
The DS-2CD2T66G2H-4I is built for accuracy, flexibility, and resilience. Its hybrid ColorVu + IR system ensures vivid colour footage in low light while automatically switching to IR in complete darkness. With up to 80 m IR range, 6 MP resolution, and 120 dB True WDR, it delivers detailed imaging in all conditions. H.265+ compression reduces storage costs, and the robust IP67-rated housing ensures long-term reliability in harsh Australian weather.
Key Capabilities
Hybrid ColorVu + IR Lighting
Combines warm light and infrared illumination to deliver full-colour images in near-darkness and smooth transition to IR when ambient light is insufficient.
6 MP High-Resolution Imaging
The 3200 × 1800 resolution CMOS sensor captures sharp detail for accurate recognition of faces, vehicles, and movements even at distance.
AcuSense Deep Learning Analytics
Accurately identifies humans and vehicles using advanced algorithms, filtering out false triggers from animals, shadows, or foliage.
Extended IR Range
Provides up to 80 m of IR illumination for large perimeters or open spaces, ensuring consistent coverage and visibility in complete darkness.
Reliable Outdoor Design
IP67-rated metal housing resists dust, rain, and extreme temperatures from −30 °C to +60 °C, perfect for Australian outdoor environments.
Key Features
-
6 MP Progressive Scan CMOS: Captures 3200 × 1800 resolution video with enhanced sharpness and clarity for professional-grade monitoring.
-
Hybrid Illumination (ColorVu + IR): Automatically adjusts between warm and infrared light for superior 24-hour colour performance.
-
120 dB True WDR: Handles high-contrast lighting scenes for evenly balanced image exposure.
-
Smart Detection: Powered by AcuSense technology to distinguish humans and vehicles from environmental motion, improving accuracy and alerts.
-
Weatherproof Durability: IP67-rated aluminium housing provides dust and water resistance for consistent operation outdoors.
Specifications Summary
| Feature |
Specification |
| Image Sensor |
6 MP Progressive Scan CMOS |
| Resolution |
3200 × 1800 |
| Lens Options |
2.8 mm (2I) or 4 mm (4I) fixed lens |
| IR Range |
Up to 80 m (4I model) |
| WDR |
120 dB |
| Video Compression |
H.265+, H.265, H.264+, H.264 |
| Ingress Protection |
IP67 weatherproof |
| Operating Conditions |
−30 °C to +60 °C, humidity ≤ 95% |
| Storage |
microSD up to 512 GB, NAS supported |
Ideal Use Cases
- Perimeter and Site Surveillance
Ideal for large outdoor areas such as warehouses, construction zones, and car parks. The 4 mm lens provides long-range clarity, with detection up to 77 m and recognition up to 15 m in IR mode.
- 24/7 Perimeter Security in Low Light
Hybrid ColorVu illumination provides bright colour imaging under near-darkness and automatically transitions to IR for long-range detection at night.
- Access Point Monitoring
Perfect for gates, driveways, and entryways. AcuSense analytics ensures that only relevant events — humans or vehicles — trigger alerts, reducing false notifications.
- Urban and Municipal Installations
The rugged IP67 housing and wide temperature range make it suitable for public infrastructure, street corners, and industrial facilities requiring all-weather reliability.
- Retail Back-of-House and Parking
Enhances security for delivery areas and staff parking, with high-resolution footage and bandwidth efficiency through H.265+ compression.
Choosing Between the 2.8 mm and 4 mm Lens
The DS-2CD2T66G2H series offers two fixed lens variants — the “2I” (2.8 mm) and “4I” (4 mm) — allowing you to tailor your field of view and IR coverage to your site needs:
| Lens |
Field of View |
Best For |
Notes |
| 2.8 mm (2I) |
~114° horizontal |
Wide coverage |
Ideal for general surveillance of open areas such as courtyards or driveways; offers IR range up to ~60 m. |
| 4.0 mm (4I) |
~94° horizontal |
Longer distance |
Provides greater subject detail and extended IR up to ~80 m for perimeters, fences, or car park coverage. |
Tip:
Choose 2.8 mm (2I) for wider coverage.
Choose 4 mm (4I) for focused, longer-range monitoring.
FAQs
- Does this model replace the DS-2CD2T66G2?
Yes, the DS-2CD2T66G2H series replaces the older IR-only model, adding ColorVu hybrid lighting for full-colour night vision.
- Which lens and IR range does the “4I” version have?
The DS-2CD2T66G2H-4I includes a 4 mm fixed lens with IR range up to 80 m, suitable for long-distance perimeter monitoring.
- Is it available in both black and white?
Yes, this camera comes in either black or white finishes to suit different environments or aesthetic preferences.
- How does it differ from the “2I” variant?
The 2I uses a wider 2.8 mm lens with IR up to 60 m, while the 4I has a narrower 4 mm lens with 80 m IR for longer coverage distances.
- What analytics does AcuSense provide?
On-board deep learning detects humans and vehicles while filtering out motion from weather, trees, or animals to reduce false alerts.
- Is it outdoor-rated?
Yes, it’s IP67-certified and operates from −30 °C to +60 °C, built for dependable outdoor performance.
Additional Information
DS-2CD2T66G2H-2I_4I Datasheet (2024-05-13)
Product Video Samples
Hikvision Warranty
3-Year Manufacturer Warranty
