What does dual-directional mean on the DS-2CD6D82G2-IS?

The DS-2CD6D82G2-IS uses a dual-directional PanoVu design to capture two independent viewing angles from one camera housing. Rather than installing 2 separate fixed cameras at a corridor intersection or building corner, a single DS-2CD6D82G2-IS unit handles both directions from one mounting point, using one cable run and one network port.

What resolution does each direction provide?

The camera delivers 8MP imaging at a maximum resolution of 3840 x 2160. This level of detail supports footage suitable for identification and incident review across both directional views, which is important in commercial and institutional surveillance environments where visual evidence quality matters.

What lens options are available and how do they differ?

The DS-2CD6D82G2-IS is available with a 2.8mm fixed lens or a 4mm fixed lens. The 2.8mm lens provides a 108.1° horizontal field of view, making it better suited to compact corridors and lobbies. The 4mm lens narrows to 87.6° horizontal, offering more useful reach along longer corridors or approaches. The lens is fixed and must be selected at the time of ordering.

Does the DS-2CD6D82G2-IS have a built-in microphone?

Yes, the camera includes 2 built-in microphones with environment noise filtering to support audio recording alongside video. Audio surveillance is subject to Australian privacy legislation. Always confirm compliance requirements and install appropriate signage before enabling audio capture on any site.

Is the DS-2CD6D82G2-IS suitable for outdoor installation?

Yes. The camera carries an IP67 rating for full dust and water resistance and an IK10 rating for vandal resistance, making it suited to exposed outdoor positions including building corners, external corridors, covered car parks and loading dock entries when correctly mounted and sealed.

Does the DS-2CD6D82G2-IS support onboard storage?

Yes, the camera includes a built-in memory card slot supporting microSD, microSDHC and microSDXC cards up to 1024GB. This supports edge recording as a backup or standalone storage option where the system design requires it, without relying solely on an NVR or network storage device.

What is the lead time for the DS-2CD6D82G2-IS and where is it available?

This product carries a 70-day lead time, so it is important to factor procurement timing into project schedules before ordering. The DS-2CD6D82G2-IS is part of the Security Wholesalers range and is intended for professional installation projects requiring dual-directional PanoVu coverage in commercial, industrial or institutional environments.

Hikvision 8MP PanoVu DS-2CD6D82G2-IS Dual-Directional Camera with Built-in Microphone, PoE, IP67 & IK10

$780.00

FREE DELIVERYWARRANTY GUARANTEED

✔ Dedicated 5★ Customer Care Team ✔ Fast & Responsive Tech Support

Hikvision DS-2CD6D82G2-IS | 8MP Dual-Directional PanoVu Camera | Built-In Microphone | PoE | IP67 & IK10

The Hikvision DS-2CD6D82G2-IS delivers an 8MP dual-directional PanoVu camera designed for wide-area surveillance where broader field-of-view coverage and fewer camera positions are preferred. Featuring dual-channel 8MP imaging, 2-channel WDR, PoE installation, and H.265+ compression, it supports clear monitoring across complex indoor and outdoor scenes. It also includes a built-in microphone for real-time audio capture during incident review. Built with IP67 weather resistance and IK10 vandal resistance, this camera suits demanding environments such as warehouses, retail spaces, campuses, car parks, and open commercial areas.

Key Features

8MP Dual-Directional PanoVu Imaging: Captures detailed wide-area video using a dual-directional panoramic camera design.
2-Channel WDR: Helps maintain clearer imaging in scenes with strong backlight or uneven lighting conditions.
Built-In Microphone: Supports real-time audio capture for enhanced monitoring and incident review.
PoE Installation: Uses Power over Ethernet for simpler cabling and streamlined network deployment.
H.265+ Compression: Reduces bandwidth and storage usage while maintaining efficient video recording.
IP67 & IK10 Protection: Provides weather-resistant and vandal-resistant durability for demanding installations.

Additional Information

DS-2CD6D82G2-IS Datasheet
Please note: 70 days lead time applies to this product.

$780.00 inc GST +3 Year Warranty & Support

Description

Product Overview

Wide-area monitoring across corridors, corners and entrance lobbies often demands two separate camera positions, each requiring its own cable run, mounting hardware and network port. The Hikvision DS-2CD6D82G2-IS addresses this directly with a dual-directional PanoVu design that captures two independent viewing directions from a single mounting point. Featuring an 8MP 1/1.8″ progressive scan CMOS sensor, the camera delivers a maximum resolution of 3840 x 2160, with 2-channel WDR to handle challenging mixed-lighting scenes. It is available with a 2.8mm lens offering a 108.1° horizontal field of view, or a 4mm lens for an 87.6° horizontal angle. Equipped with 2 built-in microphones, IR illumination reaching up to 15m, H.265+ compression, onboard microSD storage support up to 1024GB, and both IP67 and IK10 protection, the DS-2CD6D82G2-IS is built for demanding commercial, industrial and institutional installations. Please note this product carries a 70-day lead time.

Key Capabilities

Dual-Directional PanoVu Coverage

Two independent viewing directions are captured from one camera body, reducing the number of mounting points, cable runs and network connections needed at corridor intersections, building corners and walkway junctions.

8MP Imaging at 3840 x 2160

The 1/1.8″ progressive scan CMOS sensor produces detailed 8MP video across both directional views, supporting footage quality suitable for identification and incident review in commercial and institutional environments.

2-Channel WDR

WDR across both channels helps maintain usable image detail in scenes affected by strong backlight or uneven lighting, which is common at building entrances, glass doors, roller shutters and mixed indoor-outdoor coverage areas.

Built-In Microphones and Audio Capture

Two built-in microphones with environment noise filtering support real-time audio recording, adding sound context to video footage. This is particularly useful at entrances, reception desks, loading docks and monitored public-facing zones.

IR Illumination Up to 15m

850nm IR LEDs support low-light monitoring across both directions, allowing the camera to capture usable footage in after-hours corridors, car parks, internal intersections and entry points where ambient lighting is limited.

IP67 and IK10 Durability

Full dust and water resistance combined with an IK10 vandal-resistance rating makes the DS-2CD6D82G2-IS suited to exposed outdoor positions, public-facing corridors, industrial sites and educational facilities where impact and weather resistance are required.

Best For

Corridor and Hallway Intersections: The dual-directional design monitors both sides of a junction from one mounting point, removing the need for two separate cameras at the same location.
Building Corners and Entry Points: Covers two adjacent directions simultaneously, making it practical for exterior corners, lobby entrances and pedestrian chokepoints where bidirectional visibility matters.
Warehouses and Industrial Sites: Suitable for monitoring opposing aisles, loading zones and internal dispatch areas from a single ceiling or wall position, reducing cabling and installation complexity.
Schools, Campuses and Commercial Buildings: IP67 and IK10 protection combined with dual-directional coverage make this camera a practical option for public-facing areas where vandal resistance and wide coverage are both required.

Why Choose the DS-2CD6D82G2-IS

The DS-2CD6D82G2-IS directly replaces two fixed cameras in layouts where separate mounting points would otherwise be needed for bidirectional coverage. A single PoE connection powers the unit and handles both viewing directions on the network, simplifying the cabling design considerably. The 8MP sensor at 3840 x 2160 provides detailed footage from each direction, while 2-channel WDR addresses the backlight and mixed-lighting challenges common at building entrances and corridor junctions. H.265+ compression keeps bandwidth and storage requirements practical for multi-camera systems, and onboard microSD support up to 1024GB provides an edge storage option where required. The 2 built-in microphones add audio context to recorded footage with environment noise filtering included. A simpler or lower-cost fixed camera cannot replicate the dual-directional output, network efficiency and audio capability that this model combines in one unit. The DS-2CD6D82G2-IS is available through Security Wholesalers for commercial and institutional surveillance projects.

Buyer Decision Tips

Lens Selection: The 2.8mm lens suits wider, shorter-range scenarios such as corridor intersections and compact lobbies, providing a 108.1° horizontal field of view. The 4mm lens is better for longer corridors or approaches where a narrower 87.6° horizontal angle provides more useful reach. Confirm the required coverage geometry and mounting height before selecting the lens variant, as the lens is fixed and cannot be changed after purchase.

Audio Use and Lead Time: The 2 built-in microphones support audio recording, but audio surveillance is subject to local privacy legislation in Australia. Confirm compliance requirements and appropriate signage before enabling audio capture. Also note that this product carries a 70-day lead time: factor this into project scheduling and procurement planning before ordering.

Key Features & Technical Specifications

Model	DS-2CD6D82G2-IS
Product Type	Dual-Directional PanoVu Network Camera
Resolution	8MP
Maximum Resolution	3840 x 2160
Image Sensor	1/1.8″ Progressive Scan CMOS
Available Lens Options	2.8mm and 4mm fixed lens options
2.8mm Field of View	Horizontal 108.1°, vertical 53.2°, diagonal 132.8°
4mm Field of View	Horizontal 87.6°, vertical 46°, diagonal 103.5°
Wide Dynamic Range	2-channel WDR
IR Illumination	Up to 15m at 850nm
Video Compression	H.265+, H.265, H.264+, H.264, MJPEG
Audio	2 built-in microphones with environment noise filtering
Audio Compression	G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC
Ethernet Interface	1 x RJ45 10M/100M/1000M self-adaptive Ethernet port
Power	Power over Ethernet (PoE)
Onboard Storage	microSD, microSDHC and microSDXC up to 1024GB
Smart Events	Line crossing, intrusion, region entrance, region exiting, scene change, loitering, people gathering, fast moving, parking, unattended baggage, object removal detection
Basic Events	Motion detection, video tampering, alarm input/output, exception, video quality diagnosis
Weather Protection	IP67
Vandal Resistance	IK10

Ideal Use Cases

Corridor Intersections and Hallway Junctions

The dual-directional design covers both sides of a hallway intersection from one ceiling mount, supporting bidirectional monitoring without requiring two separate camera positions, cable runs or PoE ports.

Building Corners and Exterior Approaches

Covering two adjacent exterior directions from a single mounting point, the DS-2CD6D82G2-IS suits building corners and perimeter approaches where IP67 weather resistance and IK10 vandal resistance support long-term durability.

Entrance Lobbies and Reception Areas

Captures pedestrian traffic approaching from opposite directions while the 2 built-in microphones provide audio context for incidents near reception desks, entrance gates or lobby checkpoints.

Warehouses and Loading Areas

Monitors opposing aisles, dispatch zones or loading dock approaches from a single ceiling drop. H.265+ keeps bandwidth and storage manageable across multi-camera warehouse deployments, and IR illumination reaches up to 15m in low-light areas.

Schools, Campuses and Public Buildings

IK10 vandal resistance and IP67 protection make this camera practical for high-traffic public-facing areas. Smart event detection including loitering, people gathering and region entrance supports behavioural monitoring in campus and institutional settings.

Choosing the Right Model

Choose this model if: You need to monitor two directions from one installation point and want to reduce camera count, cabling and network drops in corridors, corners or bidirectional entrance areas, while also requiring IP67 and IK10 protection for outdoor or exposed indoor use.
Choose a different model if: You need continuous 360° panoramic coverage rather than two fixed directional views, in which case a fisheye or multi-sensor panoramic camera would provide more complete spatial coverage from a single mount. Similarly, if a single forward-facing direction is sufficient and budget is the priority, a standard fixed dome or turret camera will deliver comparable image quality at lower cost.

FAQs

What does dual-directional mean on the DS-2CD6D82G2-IS?
The DS-2CD6D82G2-IS uses a dual-directional PanoVu design to capture two independent viewing angles from one camera housing. Rather than installing 2 separate fixed cameras at a corridor intersection or building corner, a single DS-2CD6D82G2-IS unit handles both directions from one mounting point, using one cable run and one network port.
What resolution does each direction provide?
The camera delivers 8MP imaging at a maximum resolution of 3840 x 2160. This level of detail supports footage suitable for identification and incident review across both directional views, which is important in commercial and institutional surveillance environments where visual evidence quality matters.
What lens options are available and how do they differ?
The DS-2CD6D82G2-IS is available with a 2.8mm fixed lens or a 4mm fixed lens. The 2.8mm lens provides a 108.1° horizontal field of view, making it better suited to compact corridors and lobbies. The 4mm lens narrows to 87.6° horizontal, offering more useful reach along longer corridors or approaches. The lens is fixed and must be selected at the time of ordering.
Does the DS-2CD6D82G2-IS have a built-in microphone?
Yes, the camera includes 2 built-in microphones with environment noise filtering to support audio recording alongside video. Audio surveillance is subject to Australian privacy legislation. Always confirm compliance requirements and install appropriate signage before enabling audio capture on any site.
Is the DS-2CD6D82G2-IS suitable for outdoor installation?
Yes. The camera carries an IP67 rating for full dust and water resistance and an IK10 rating for vandal resistance, making it suited to exposed outdoor positions including building corners, external corridors, covered car parks and loading dock entries when correctly mounted and sealed.
Does the DS-2CD6D82G2-IS support onboard storage?
Yes, the camera includes a built-in memory card slot supporting microSD, microSDHC and microSDXC cards up to 1024GB. This supports edge recording as a backup or standalone storage option where the system design requires it, without relying solely on an NVR or network storage device.
What is the lead time for the DS-2CD6D82G2-IS and where is it available?
This product carries a 70-day lead time, so it is important to factor procurement timing into project schedules before ordering. The DS-2CD6D82G2-IS is part of the Security Wholesalers range and is intended for professional installation projects requiring dual-directional PanoVu coverage in commercial, industrial or institutional environments.

Additional Information

DS-2CD6D82G2-IS Datasheet
