Product SKU: QRN-1620S
Product Overview
Managing 16 cameras across a small to medium business installation demands a recorder that can handle high-resolution footage without bottlenecks or complicated setup. The Hanwha Wisenet QRN-1620S is a second-generation NEW-Q 16-channel NVR built to meet that need, with 16 built-in PoE ports delivering true plug-and-play camera connection and a total network recording bandwidth of 128Mbps. Supporting up to 8-megapixel recording and 4K HDMI output at 3840×2160, this NVR is built for installers and site managers who need sharp, detailed footage across every connected camera. H.265 compression reduces storage consumption by up to 50 percent compared to H.264, helping stretch the included 3TB HDD further. With 2 SATA bays supporting up to 12TB of storage, an enhanced graphical interface, dual track recording, dual monitoring, and compatibility with the Wisenet V2.0 mobile app, the QRN-1620S is a well-rounded recorder for commercial and light-industrial deployments.
Key Capabilities
16-Channel 4K Recording
The QRN-1620S supports recording from up to 16 cameras at resolutions reaching 8 megapixels. This ensures even larger sites with high-traffic zones, entry points, and loading areas are captured in full 4K detail across every channel simultaneously.
16 Built-in PoE Ports at 128Mbps
With 16 onboard PoE ports, cameras connect directly to the NVR over a single network cable per camera, supplying both power and data. The 128Mbps total bandwidth ensures the recorder keeps up with a full complement of high-resolution cameras without dropping frames.
H.265 Compression
H.265 encoding reduces file sizes by up to 50 percent compared to H.264, stretching the capacity of installed storage significantly. For a 16-camera system running around the clock, this compression translates directly into longer retention periods without adding extra drives.
4K HDMI Display Output
The QRN-1620S outputs to a monitor at up to 3840×2160 resolution, allowing security staff or reception teams to view the full camera grid in sharp detail on a compatible 4K display, with no image quality lost between camera and screen.
Dual Track Recording and Dual Monitoring
Second-generation NEW-Q NVRs introduce dual track recording for simultaneous high- and low-resolution streams, and dual monitoring for driving two separate display outputs. This gives operators and installers more flexibility in how footage is reviewed and displayed on site.
Best For
- Small to Medium Business Installations: The 16-channel capacity covers a full perimeter, internal zones, and entry points for a typical commercial or office site, with room to grow up to the full 16-camera limit.
- Plug-and-Play PoE Deployments: The 16 built-in PoE ports eliminate the need for a separate PoE switch, simplifying installation and reducing rack space requirements for the installer.
- Storage-Conscious Operators: H.265 compression and a 2-bay SATA configuration scaling to 12TB lets site managers balance footage retention against storage costs without investing in a larger NVR chassis.
- Remote Monitoring via Mobile: Compatibility with the Wisenet V2.0 mobile app gives business owners or security managers the ability to view live and recorded footage from any location on a smartphone or tablet.
Why Choose the QRN-1620S
The QRN-1620S sits in a practical position for commercial installations that need genuine 4K recording across 16 channels without the cost or complexity of enterprise-grade infrastructure. Its 16 built-in PoE ports remove the need for an external managed switch, and the 128Mbps recording bandwidth ensures no compromise on frame rate or resolution when all channels are active. The H.265 engine reduces storage overhead significantly, making the included 3TB HDD last longer before expansion is needed. The enhanced NEW-Q graphical interface lowers the training curve for end users, while dual track recording and dual monitoring features give installers tools that a basic entry-level 16-channel recorder simply does not offer. Available through Security Wholesalers, the QRN-1620S is supported by Hanwha’s local product ecosystem and the Wisenet V2.0 app for straightforward remote access.
Buyer Decision Tips
Storage Planning: The QRN-1620S ships with 3TB pre-installed and supports up to 12TB across 2 SATA bays. For a full 16-camera deployment at 4K resolution using continuous recording, calculate your required retention period before purchasing additional drives. H.265 compression reduces file sizes by up to 50 percent, but 16 high-resolution cameras running 24/7 will still consume storage quickly. Factor in motion-based recording schedules to extend retention on the installed drive before expansion.
Camera Compatibility: While the QRN-1620S is optimised for Hanwha Wisenet cameras and supports ONVIF protocols, performance features such as dual track recording and enhanced GUI integration are fully realised when paired with compatible Hanwha Wisenet cameras. Confirm camera compatibility with the QRN-1620S before specifying third-party cameras on the same system if advanced features are required.
Key Features & Technical Specifications
| Model |
QRN-1620S |
| Generation |
NEW-Q (Second Generation) |
| Video Channels |
16 |
| Maximum Recording Resolution |
8MP (4K) |
| HDMI Output Resolution |
Up to 3840×2160 (4K UHD) |
| Built-in PoE Ports |
16 |
| Total Network Recording Bandwidth |
128Mbps |
| Video Compression |
H.265, H.264 |
| Storage Compression Saving |
Up to 50% vs H.264 |
| Included HDD |
3TB |
| SATA Bays |
2 |
| Maximum Storage Capacity |
12TB (2 x SATA drives) |
| Recording Modes |
Dual track recording |
| Monitoring |
Dual monitoring |
| Mobile App |
Wisenet V2.0 |
| GUI |
Enhanced NEW-Q Graphical User Interface |
| Replaces |
QRN-1610S |
Ideal Use Cases
Retail Stores and Shopping Centres
16 channels cover checkouts, stockrooms, entry points, and car park camera feeds from a single recorder. The 4K HDMI output supports a wall-mounted monitoring display visible to staff and deterrent to shoplifters.
Commercial Office Buildings
Multi-floor office layouts with lift lobbies, stairwells, reception areas, and perimeter entrances suit the 16-channel layout. H.265 compression extends footage retention across continuous recording schedules without requiring oversized hard drives.
Warehouses and Light Industrial Sites
Wide-area facilities with loading docks, storage bays, and perimeter fencing require high-resolution coverage across multiple zones. The 128Mbps recording bandwidth supports a full 16-camera layout without frame-rate compromise.
Schools and Childcare Facilities
Campus environments with classrooms, playgrounds, car drop-off zones, and administration buildings can distribute 16 cameras effectively. The Wisenet V2.0 mobile app gives facility managers remote viewing access from anywhere.
Multi-Tenancy Residential Buildings
Apartment complexes, strata buildings, and mixed-use developments with shared car parks, lift lobbies, and common areas benefit from a centralised 16-channel NVR managed by a body corporate or building manager.
Choosing the Right Model
- Choose this model if: You need a 16-channel NVR with built-in PoE ports, 4K recording and display output, H.265 storage efficiency, and a pre-installed 3TB HDD, and your site connects 10 to 16 cameras across a small to medium commercial installation.
- Choose a different model if: Your site requires more than 16 cameras, as you will need a higher-channel NVR with additional PoE capacity. Alternatively, if your installation only requires 8 or fewer cameras, an 8-channel NVR with a smaller footprint and lower cost will better suit the deployment without unused channel overhead.
- Choose a different model if: Your storage retention requirement exceeds what 12TB of local HDD storage can provide. In that case, consider a NVR with additional SATA bays or network-attached storage integration to meet your long-term recording needs.
FAQs
- Does the QRN-1620S come with a hard drive already installed?
Yes. The QRN-1620S is supplied with a 3TB HDD pre-installed. The unit is ready to record immediately out of the box without needing to purchase or install a separate drive. If your site requires more retention capacity, a second SATA drive can be added up to the 12TB maximum across both bays.
- How many PoE cameras can the QRN-1620S power directly?
The QRN-1620S has 16 built-in PoE ports, meaning it can power and connect up to 16 PoE-compatible IP cameras directly via Cat5e or Cat6 cable with no separate PoE switch required. This simplifies installation considerably, particularly in commercial environments where rack space or additional switching infrastructure is limited.
- What is the maximum recording bandwidth of the QRN-1620S?
The total network camera recording bandwidth is 128Mbps. This supports a full 16-camera deployment at high resolutions without frame-rate reduction, provided the cameras connected are within the supported resolution and bitrate range of the NVR.
- What does dual track recording mean on the QRN-1620S?
Dual track recording allows the NVR to simultaneously capture two separate video streams from compatible cameras, typically a high-resolution stream for archiving and a lower-resolution stream for efficient remote viewing or live monitoring. This means remote access via the Wisenet V2.0 app remains smooth without consuming the full bandwidth of the primary recording stream.
- Can I monitor the QRN-1620S remotely from a smartphone?
Yes. The QRN-1620S is compatible with the Wisenet V2.0 mobile application, which supports live viewing and playback of recorded footage from a smartphone or tablet. This is particularly useful for business owners or managers who need to check in on their site remotely without accessing a desktop client.
- Is the QRN-1620S a direct replacement for the QRN-1610S?
Yes. The QRN-1620S is the confirmed successor to the QRN-1610S, forming part of the second-generation NEW-Q NVR range from Hanwha Wisenet. Improvements over the previous generation include an enhanced graphical interface, increased PoE budget, dual track recording, and dual monitoring. The QRN-1620S is part of the Security Wholesalers range and is available now. Installers upgrading from a QRN-1610S-based specification should update their bills of materials accordingly.
