Product SKU: QNV-8020R
Product Overview
Mounted on exterior ceilings, soffits, and wall brackets across retail stores, banking branches, and office buildings, the Hanwha Wisenet QNV-8020R is a 5MP outdoor vandal dome camera built to deliver consistent image quality in demanding day-to-day environments. Featuring a 4mm fixed lens and a maximum resolution of 2592 x 1944, it captures detailed coverage of entry points, corridors, car park overhangs, and building perimeters. Equipped with a 120dB Wide Dynamic Range, it handles strong backlight conditions such as glass facades and bright external light sources without washing out the scene. WiseStream II compression works alongside H.265 to reduce bandwidth and storage demands without sacrificing image quality. The QNV-8020R also carries an IP66 weatherproof rating and IK10 vandal-resistant housing, making it suitable for publicly accessible outdoor locations where the camera may be exposed to tampering or harsh weather conditions.
Key Capabilities
5MP Resolution at 30fps
Delivering up to 2592 x 1944 resolution at a full 30 frames per second, the QNV-8020R captures sharp detail on faces, signage, and licence plates within the 4mm field of view, supporting evidential review in retail and commercial settings.
120dB Wide Dynamic Range
The 120dB WDR rating allows the camera to balance bright and shadowed areas simultaneously, keeping detail visible near doorways, loading bays, or glazed building fronts where lighting conditions vary significantly throughout the day.
IK10 Vandal-Resistant Housing
Rated IK10, the dome housing withstands deliberate impact attempts, making the QNV-8020R appropriate for publicly accessible locations such as building entrances, stairwells, and external corridors where camera interference is a risk.
WiseStream II with H.265
WiseStream II dynamically adjusts the bitrate based on scene complexity. Combined with H.265 encoding, this can reduce bandwidth consumption by up to 75 percent compared to standard H.264, lowering storage costs across multi-camera installations.
20m IR Night Vision
The built-in IR LEDs provide usable night-time coverage to 20 metres in zero-lux conditions, supporting continuous monitoring of building perimeters, car park entry points, and access paths after dark without additional lighting infrastructure.
Best For
- Retail Storefronts and Banking Branches: The 4mm fixed lens and 5MP resolution suit ceiling-mounted positions above entry points and teller areas, where capturing clear facial detail at a standard counter distance is the primary requirement.
- Office Building Perimeters and Car Parks: IP66 weatherproofing and IK10 impact resistance allow the QNV-8020R to handle outdoor installation on soffits, building eaves, and external wall brackets without protective enclosures.
- Multi-Camera Commercial Installations: WiseStream II and H.265 support keep bandwidth and storage requirements manageable when deploying multiple cameras across a single site, reducing infrastructure costs.
- Locations With Variable Lighting: The 120dB WDR rating makes the QNV-8020R a practical choice for scenes that include direct sunlight, skylights, or bright artificial lighting alongside darker interior or shaded areas within the same frame.
Why Choose the QNV-8020R
The QNV-8020R occupies a practical position within Hanwha’s Q series, offering a confirmed combination of 5MP resolution, 120dB WDR, IK10 vandal resistance, and IP66 outdoor rating in a compact dome form factor. The 4mm fixed lens provides a field of view suited to corridor-width coverage and standard ceiling heights in commercial environments. Where a basic 2MP or non-vandal dome would leave gaps in image quality or housing durability, the QNV-8020R closes those gaps at a cost point appropriate for small-to-medium site deployments. The onboard microSD slot supports up to 128GB of local storage, providing a backup recording path independent of the NVR. WiseStream II compression reduces the per-camera load on network and storage infrastructure, which matters when scaling to 8 or more channels. The QNV-8020R is available through Security Wholesalers as part of the broader Hanwha Wisenet Q series range.
Buyer Decision Tips
Lens Angle and Ceiling Height: The QNV-8020R uses a fixed 4mm lens. At a typical ceiling height of 2.7 to 3.5 metres, this provides a focused view suitable for monitoring a counter, corridor, or entry zone up to roughly 6 to 8 metres in depth. If you need broader scene coverage from a high ceiling or need to cover a wide open area like a warehouse floor from a single mounting point, consider a camera with a wider fixed lens or a varifocal lens option instead.
Key Features & Technical Specifications
| Model |
QNV-8020R |
| Resolution |
5MP (2592 x 1944) |
| Lens Type |
Fixed |
| Focal Length |
4mm |
| Frame Rate |
Max. 30fps at 5MP |
| Video Compression |
H.265, H.264, MJPEG |
| Bandwidth Optimisation |
WiseStream II |
| Wide Dynamic Range |
120dB |
| Day/Night |
True Day/Night (ICR) |
| Minimum Illumination |
0.15 Lux (Colour), 0 Lux (B/W with IR) |
| IR Distance |
20m |
| Weatherproof Rating |
IP66 |
| Vandal Resistance |
IK10 |
| Power Input |
PoE (IEEE 802.3af) |
| Local Storage |
Micro SD/SDHC/SDXC up to 128GB |
| Analytics |
Motion detection, tampering, defocus detection |
| Special Modes |
Hallway view |
| Multiple Streaming |
Supported |
Ideal Use Cases
Retail Store Entry and POS Areas
Ceiling-mounted above doorways or service counters, the 4mm lens and 5MP resolution produce images detailed enough for transaction monitoring and post-incident review of customer and staff interactions.
Bank Branch and Financial Premises
The 120dB WDR handles the mixed lighting conditions typical in banking environments, including window glare and overhead fluorescents, keeping teller area footage usable throughout the day.
Office Building Entrances and External Corridors
IP66 and IK10 ratings allow installation at building access points without a protective enclosure. The 20m IR range maintains usable footage across external corridors and covered walkways at night.
Car Park Entry Overhangs and Boom Gate Areas
Mounted beneath a car park entry canopy, the dome profile limits wind load and the IK10 rating handles minor impacts. Night-time coverage to 20m suits standard single-lane car park approaches.
Multi-Site Commercial Rollouts
WiseStream II and H.265 reduce per-camera bandwidth by up to 75 percent versus H.264, making the QNV-8020R a cost-effective choice when deploying standardised camera specifications across multiple branch locations.
Choosing the Right Model
- Choose this model if: You need a compact outdoor vandal dome with 5MP resolution, confirmed IK10 impact resistance, and a 4mm lens suited to ceiling-mounted positions at standard commercial ceiling heights, with efficient H.265 and WiseStream II compression for network-managed sites.
- Choose a different model if: Your installation requires a longer IR range beyond 20 metres for monitoring deep driveways or large open yards, in which case a bullet-style camera with extended IR output would be better suited to those sightlines. Similarly, if the mounting position varies across sites and lens angle flexibility is needed, a varifocal dome would offer greater adjustment without physical re-positioning.
FAQs
- Is the QNV-8020R suitable for outdoor installation without additional weatherproofing?
Yes. The QNV-8020R carries an IP66 rating, which confirms protection against dust ingress and sustained water jets. It is designed for direct outdoor mounting on soffits, eaves, and external walls without a separate protective housing or enclosure.
- What does the IK10 rating mean in practice for a ceiling-mounted dome?
IK10 is the highest standard impact protection rating under IEC 62262, indicating the housing can withstand impacts up to 20 joules. For a publicly accessible dome camera mounted above a doorway or in a corridor, this means the unit is resistant to deliberate interference attempts such as hitting or striking the dome.
- How does WiseStream II affect recording storage requirements?
WiseStream II dynamically lowers the bitrate during low-activity periods and increases it when motion or scene complexity rises. Combined with H.265 encoding, total storage consumption can be reduced by up to 75 percent compared to standard H.264. On an 8-camera system, this can significantly extend the recording retention period on the same storage capacity.
- Can the QNV-8020R record locally without an NVR?
Yes. The camera includes a microSD/SDHC/SDXC card slot supporting up to 128GB. This allows the camera to record footage locally, functioning as a standalone unit or as a fallback recording path if the network connection to the NVR is interrupted.
- What is the hallway view mode and when is it useful?
Hallway view rotates the sensor output to a 9:16 portrait orientation rather than the standard 16:9 landscape view. This is useful when the camera is installed to monitor a narrow corridor, stairwell, or aisle where the height of the scene is more important than the width, reducing wasted field of view on either side.
- What power supply does the QNV-8020R require?
The QNV-8020R is powered via PoE (Power over Ethernet), drawing power directly through the Cat5e or Cat6 cable connected to a PoE-capable switch or NVR. No separate power cable or adaptor is required at the camera end, simplifying installation runs and reducing the number of cables needed at each mounting point. The QNV-8020R is available through Security Wholesalers as part of the Hanwha Wisenet Q series lineup.
