Product SKU: QND-8080R
Product Overview
For retailers, banking facilities, and office environments needing discreet ceiling-mounted coverage with genuine image detail, the QND-8080R is a 5MP indoor dome camera from Hanwha’s Q Series that balances solid performance with practical installation. Equipped with a 3.2-10mm motorized varifocal lens, the camera allows installers to adjust the field of view remotely without physically repositioning the unit, which simplifies deployment in ceilings where access is limited. Featuring WDR at 120dB, it handles scenes where bright windows or lighting contrasts would otherwise wash out key details. Built with WiseStream II compression, it reduces bandwidth consumption by up to 50 percent, and when combined with H.265 encoding, bandwidth efficiency can improve by up to 75 percent compared to H.264. It also integrates hallway view mode, defocus detection, and local MicroSD storage up to 128GB, making it a complete indoor monitoring solution for small to medium-sized commercial applications.
Key Capabilities
Motorized Varifocal Lens
The 3.2-10mm motorized varifocal lens gives installers remote zoom and focus adjustment, removing the need to reposition the dome housing after installation. This is particularly useful in suspended ceilings or high-mounted positions where physical access is awkward once the camera is fitted.
120dB Wide Dynamic Range
With WDR at 120dB, the QND-8080R captures balanced footage in environments with mixed lighting, such as retail spaces with large front windows or banking counters positioned near overhead lighting. Both bright and shadowed areas remain visible in the same frame.
WiseStream II Compression
WiseStream II dynamically adjusts the bitrate based on scene complexity, reducing bandwidth by up to 50 percent. Combined with H.265 encoding, overall bandwidth consumption can improve by up to 75 percent compared to H.264, directly lowering NVR storage costs and network load across multi-camera installations.
Hallway View Mode
Hallway view rotates the image orientation to a portrait aspect ratio, making it well suited to corridor monitoring in offices, banking floors, or retail aisles. This eliminates wasted frame area on either side and focuses the full resolution on the length of the corridor or aisle being monitored.
Defocus Detection
The camera automatically detects when its image becomes out of focus, whether from deliberate tampering, vibration, or lens drift over time. An alert is triggered so operators or installers can respond promptly, maintaining consistent image quality across the monitored area.
Best For
- Retail Ceiling Monitoring: The motorized varifocal lens and 5MP resolution allow installers to frame specific checkout zones, product aisles, or entrance areas with precision from the ceiling mount.
- Banking and Financial Premises: 120dB WDR handles the challenging mixed lighting typical of banking counters, teller areas, and front-of-house zones where window glare is common.
- Office and Corporate Environments: The discreet indoor dome profile suits corporate reception areas, meeting rooms, and open-plan offices where a low-profile camera form factor is expected.
- Corridor and Aisle Coverage: Hallway view mode optimises the 5MP sensor for long, narrow indoor spaces such as corridors, stairwells, and retail aisles where a standard landscape frame would waste significant resolution.
Why Choose the QND-8080R
The QND-8080R stands apart from basic fixed-lens indoor domes through its combination of motorized varifocal adjustment, high-grade WDR, and intelligent compression in a single ceiling-mount housing. A fixed-lens dome at the same price point would require physical repositioning and refocusing if the monitored scene changes, whereas the QND-8080R allows remote lens adjustment through the camera interface. The 120dB WDR rating is notably higher than entry-level alternatives, which is meaningful in retail and banking environments where bright windows and artificial lighting coexist in the same scene. WiseStream II compression actively reduces storage and bandwidth demands, which has a direct impact on infrastructure costs in multi-camera deployments. The inclusion of MicroSD storage up to 128GB also provides a local backup option independent of the NVR. The QND-8080R is available at Security Wholesalers as part of the Hanwha Q Series indoor camera range.
Buyer Tip: The QND-8080R uses a motorized varifocal lens, which means the field of view can be adjusted remotely after installation. Before mounting, consider the ceiling height and the area you need to cover. A higher ceiling position paired with a narrower zoom setting will give you more reach, while a lower mount with a wider setting suits broader open-plan coverage. Confirm your NVR supports H.265 to take full advantage of the WiseStream II bandwidth savings.
Key Features & Technical Specifications
| Resolution |
5MP (2592 x 1944) |
| Lens Type |
3.2-10mm motorized varifocal (3.1x) |
| Minimum Illumination |
0.15 Lux (Colour), 0 Lux (B/W with IR on) |
| Frame Rate |
Max 30fps at 5MP |
| Video Compression |
H.265, H.264, MJPEG with multiple streaming |
| Wide Dynamic Range |
120dB |
| IR Range |
Up to 20m |
| Day/Night |
Auto (mechanical IR cut filter) |
| Video Analytics |
Tampering detection, Motion detection, Defocus detection |
| Local Storage |
MicroSD / SDHC / SDXC up to 128GB |
| Hallway View |
Supported |
| Compression Technology |
WiseStream II |
| Power |
PoE (IEEE 802.3af) |
| Housing Type |
Indoor dome |
| Camera Series |
Hanwha Wisenet Q Series |
Ideal Use Cases
Retail Stores
The 5MP resolution and motorized varifocal lens allow precise framing of checkout counters, entrances, and product display areas from ceiling positions, with 120dB WDR managing the contrast between lit displays and window glare.
Banking and Financial Branches
Teller counters and front-of-house areas benefit from the 120dB WDR and 5MP detail, capturing transaction-level footage clearly even in environments with mixed overhead lighting and natural light from shopfronts.
Office and Corporate Premises
The compact indoor dome profile blends into office ceiling grids and suspended ceilings. WiseStream II compression reduces network load across multi-camera office deployments without compromising recorded image quality.
Corridors and Internal Walkways
Hallway view mode repositions the image to a portrait orientation, using the full 5MP sensor resolution across the length of a corridor, stairwell, or internal aisle rather than wasting frame area on either side.
Small to Medium Commercial Sites
WiseStream II combined with H.265 reduces storage requirements by up to 75 percent compared to H.264, making the QND-8080R cost-effective to deploy across multiple rooms or floors without scaling up NVR storage capacity.
Choosing the Right Model
- Choose this model if: You need a ceiling-mounted indoor dome with motorized varifocal lens flexibility, strong WDR for mixed-lighting commercial environments, and efficient H.265 compression for managing storage across multiple cameras.
- Choose a different model if: Your installation is outdoors or in an area exposed to dust, moisture, or physical interference. The QND-8080R is an indoor-rated dome and is not designed for external mounting. If you require outdoor coverage, a weatherproof turret or bullet camera with an IP66 or IP67 rating would be more appropriate.
- Choose a different model if: Your scene requires coverage beyond 20m in low-light conditions. For longer IR range indoors or outdoors, consider a camera with an extended IR specification confirmed in the product data.
FAQs
- Can the QND-8080R lens be adjusted after the camera is installed on the ceiling?
Yes. The 3.2-10mm motorized varifocal lens can be adjusted remotely via the camera’s web interface or compatible VMS software without physically accessing the dome housing. This is particularly useful for ceiling-mounted installations where repositioning after the initial fit would otherwise require a ladder and significant rework.
- What does WiseStream II actually do, and does it affect image quality?
WiseStream II is Hanwha’s dynamic bitrate technology that increases compression during low-activity scenes and reduces it when motion or detail increases. The result is up to 50 percent bandwidth savings overall. When combined with H.265, total savings can reach up to 75 percent compared to H.264 without a visible reduction in image quality during recorded events.
- Is the QND-8080R suitable for installation above a checkout counter or teller window?
Yes. The 5MP sensor paired with 120dB WDR makes it well suited to counter-level monitoring where overhead lighting and natural light from windows create contrast challenges. The motorized varifocal lens also allows the field of view to be narrowed to focus precisely on the counter area from a ceiling position.
- What is defocus detection and when would it trigger?
Defocus detection monitors the sharpness of the live image continuously. If the lens goes out of focus, whether from vibration, tampering, or gradual drift, the camera generates an alert. This allows operators or monitoring staff to identify image quality problems without relying on a manual review of recorded footage.
- Does the QND-8080R support local storage if the NVR is unavailable?
Yes. The camera includes a MicroSD, SDHC, or SDXC memory card slot supporting up to 128GB. This allows continuous or event-based local recording directly on the camera, providing a backup recording path if network connectivity to the NVR is interrupted.
- Where can I source the QND-8080R in Australia?
The QND-8080R is part of the Hanwha Wisenet Q Series range available through Security Wholesalers. A datasheet is also available to download for specification verification before purchase. It is recommended to confirm NVR compatibility, available PoE switch capacity, and MicroSD card class rating before deploying at scale across a multi-camera site.
