Hanwha Wisenet QND-8010R NEW-Q 5MP Indoor Dome Camera, H.265, 120dB WDR, 20m IR, 2.8mm

$460.00

FREE DELIVERYWARRANTY GUARANTEED

✔ Dedicated 5★ Customer Care Team ✔ Fast & Responsive Tech Support

Hanwha Wisenet QND-8010R | 5MP Indoor Dome Camera | 2.8mm Fixed Lens | H.265

The Hanwha Wisenet QND-8010R delivers 5MP resolution in a compact indoor dome format, designed for small to medium-sized applications such as retail, banking and office environments. Equipped with a 2.8mm fixed lens and 20m IR night vision, it provides clear, detailed footage in both day and night conditions. Featuring WiseStream II and H.265 compression, it can reduce bandwidth consumption by up to 75% compared to H.264, lowering storage and network costs. This model also supports hallway view mode, 120dB WDR, and defocus detection for improved reliability and image integrity.

Key Features

5MP Resolution: Captures sharp, detailed images at up to 5 megapixels at 30fps.
120dB Wide Dynamic Range: Handles high-contrast scenes with balanced exposure across the frame.
H.265 with WiseStream II: Reduces bandwidth by up to 75% compared to H.264 for efficient storage and streaming.
20m IR Night Vision: Provides reliable monochrome imaging in complete darkness up to 20 metres.
Defocus Detection: Automatically detects when the image goes out of focus and raises an alert.
Hallway View Mode: Supports 9:16 rotated orientation, ideal for corridors and narrow spaces.

Additional Information

QND-8010R Datasheet

$460.00 inc GST +3 Year Warranty & Support

Description
Specifications

Product SKU: QND-8010R

Product Overview

For retail stores, banking branches, and offices needing dependable indoor coverage without a complex setup, the Hanwha Wisenet QND-8010R is a ceiling-mount dome camera that delivers 5MP resolution in a compact, discreet form factor. Featuring a 2.8mm fixed lens and 120dB Wide Dynamic Range, it handles challenging lighting conditions common in retail and banking environments where bright windows and artificial lighting create high contrast scenes. WiseStream II compression works alongside H.265 to reduce bandwidth consumption by up to 75% compared to H.264, making this camera well suited to sites with limited network capacity or where storage efficiency is a priority. Built-in 20m IR enables clear monochrome imaging in complete darkness, while the hallway view mode supports narrow corridor and aisle layouts. A micro SD card slot accepts up to 128GB for local backup storage, and PoE simplifies cabling during installation. This makes it a practical choice for small to medium-sized indoor deployments where image quality and network efficiency both matter.

Key Capabilities

5MP Resolution at 30fps

At 2592 x 1944 pixels and a maximum of 30fps, the QND-8010R captures enough detail to identify faces and read signage across a retail floor or banking counter, without sacrificing frame rate during busy periods.

120dB Wide Dynamic Range

A 120dB WDR rating allows the camera to render usable detail in both bright and shadowed areas within the same frame. This is particularly valuable in offices with large windows or retail spaces combining natural and fluorescent lighting.

WiseStream II with H.265

WiseStream II dynamically adjusts compression based on scene complexity. Combined with H.265, it can reduce bandwidth by up to 75% compared to H.264, cutting storage and network costs significantly across multi-camera installations.

Hallway View Mode

Hallway view rotates the image orientation to a vertical 9:16 aspect ratio, maximising coverage in narrow corridors, aisles, and passageways. This avoids wasted pixels on ceiling and floor areas that contribute nothing to surveillance value.

Defocus Detection

The camera actively monitors its own image sharpness and triggers an alert if the lens becomes obscured or goes out of focus. This reduces the risk of a camera appearing operational while producing unusable footage due to tampering or accidental obstruction.

Best For

Retail Stores: The 5MP resolution and 120dB WDR handle the mixed lighting of a retail floor, providing enough detail to support incident review at checkout counters and entry points.
Banking and Financial Premises: The discreet dome form factor suits professional environments, while WDR manages the bright lighting typically used in banking interiors without blowing out faces or signage.
Office Corridors and Reception Areas: Hallway view mode makes this camera well suited to narrow indoor passages where standard widescreen orientation wastes significant image area on floor and ceiling.
Multi-Camera Indoor Systems with Limited Bandwidth: WiseStream II compression reduces per-camera bandwidth demand, making it easier to scale up camera counts without upgrading network infrastructure.

Why Choose the QND-8010R

The QND-8010R brings together 5MP imaging, 120dB WDR, and WiseStream II compression in an indoor dome that is straightforward to install and configure. Where a basic 2MP or lower-resolution dome would struggle to provide usable face detail across a 4-6 metre retail aisle, the 5MP sensor retains enough pixel density to support incident review and identification. The 120dB WDR is a meaningful specification in environments like banks and offices where window light and overhead fluorescents create contrast that cheaper cameras handle poorly. WiseStream II keeps storage and bandwidth requirements in check as camera counts grow. Defocus detection and tampering alerts add an extra layer of operational assurance without requiring additional analytics hardware. The QND-8010R is available through Security Wholesalers as part of the Hanwha Q Series range, which is positioned at the standard tier for small to medium commercial applications where proven performance and installation efficiency are the priority.

Buyer Decision Tips

Fixed Lens Framing: The QND-8010R uses a fixed 2.8mm lens, which provides a wide angle of view suited to close-range indoor coverage such as a counter, aisle, or lobby entry. If your installation requires coverage of a longer run such as a deep open-plan office or a carpark lane, a varifocal lens model will give you the framing adjustment needed to fill the sensor with the relevant area. Confirm your mounting height and the width of the scene you need to cover before committing to the 2.8mm fixed option.

Key Features & Technical Specifications

Model	Hanwha Wisenet QND-8010R
Resolution	5MP (2592 x 1944)
Lens	2.8mm fixed
Frame Rate	Max. 30fps at 5MP (H.265 / H.264)
Minimum Illumination	0.15 Lux (Colour), 0 Lux (B/W with IR LED on)
IR Range	20m
Wide Dynamic Range	120dB
Day / Night	Yes (mechanical IR cut filter)
Video Compression	H.265, H.264, MJPEG
Compression Technology	WiseStream II
Streaming	Multiple streaming supported
Video Analytics	Motion detection, tampering, defocus detection
Hallway View	Yes
Local Storage	Micro SD / SDHC / SDXC, up to 128GB
Power	PoE (IEEE 802.3af)
Camera Type	Indoor dome
Series	Hanwha Wisenet Q Series

Ideal Use Cases

Retail Checkout and Aisle Monitoring

The 5MP sensor captures enough detail for post-incident review at checkout counters and product aisles. Hallway view mode stretches coverage efficiently down narrow aisles without wasting resolution on ceiling and floor areas.

Banking Branches and Teller Areas

120dB WDR manages the demanding lighting mix in banking interiors. The discreet dome form factor suits professional client-facing spaces where a visible external camera would be inappropriate.

Office Reception and Entry Lobbies

Ceiling-mounted dome installation suits open lobby areas. The 2.8mm lens covers the width of a standard reception area from a ceiling height of 2.5-3.5 metres, and IR allows monitoring after business hours without additional lighting.

Indoor Corridors and Lift Lobbies

Hallway view orientation converts the camera’s field of view to a vertical 9:16 layout, which maps precisely onto narrow indoor passages, stairwells, and lift lobby approaches where a standard widescreen frame is poorly matched.

Choosing the Right Model

Choose this model if: You need a discreet 5MP indoor dome with strong WDR for mixed-lighting environments, efficient H.265 and WiseStream II compression to manage storage across multiple cameras, and a straightforward PoE installation for retail, office, or banking applications.
Choose a different model if: Your scene requires coverage beyond 8-10 metres with fine facial detail, in which case a varifocal lens dome will allow you to narrow the field of view and fill the sensor with the relevant portion of the scene. If the installation is outdoors or in a wet area, you will need a camera with an appropriate weatherproof IP rating, as the QND-8010R is rated for indoor use only.

FAQs

Can the QND-8010R be used outdoors?
No. The QND-8010R is designed for indoor ceiling installation only. It does not carry a weatherproof IP rating and should not be exposed to rain, humidity, or direct outdoor conditions. For outdoor applications, a dome or turret camera with an IP66 or IP67 rating would be required.
What does WiseStream II actually do for storage and bandwidth?
WiseStream II is Hanwha’s dynamic compression technology that analyses each scene in real time and adjusts the encoding bitrate based on complexity. Static scenes such as an empty corridor use less bandwidth, while busy scenes receive higher bitrate allocation. When combined with H.265, total bandwidth and storage consumption can be reduced by up to 75% compared to standard H.264, which directly reduces NVR storage requirements and network load across multi-camera deployments.
What does defocus detection do and why does it matter for a retail or office installation?
Defocus detection monitors the sharpness of the live image and triggers an alert if the lens loses focus, such as when a dome cover is deliberately smeared or the camera is knocked out of position. In staffed environments like offices or retail stores, this alert prompts a maintenance response before an extended period of unusable footage goes unnoticed.
How does hallway view mode work on the QND-8010R?
Hallway view rotates the camera’s output to a vertical 9:16 orientation using in-camera processing. When the camera is mounted in a corridor or aisle, this matches the physical shape of the scene, using the full 5MP sensor area on the relevant coverage zone rather than capturing floor and ceiling at either side of a standard widescreen frame.
Does the QND-8010R support local recording without a separate NVR?
Yes. The camera includes a micro SD card slot that supports SD, SDHC, and SDXC cards up to a maximum of 128GB. This allows local edge recording as a backup or as a standalone recording option in low-camera-count installations where a dedicated NVR is not required.
Is PoE the only power option, and what standard does it use?
The QND-8010R is powered via PoE, which supplies both power and data over a single Ethernet cable. This simplifies indoor installation considerably as no separate power cabling run is needed to each camera position. The camera is compatible with IEEE 802.3af PoE switches and NVRs with built-in PoE ports. For purchasing and compatibility queries, Security Wholesalers can assist with matching the camera to a suitable Hanwha NVR or PoE switch.
