Product SKU: XNO-C7083R
Product Overview
For perimeter security installations where flexible framing and intelligent object detection are both required, the XNO-C7083R delivers a purpose-built solution. Built on the Wisenet7 platform, this 4MP outdoor bullet camera combines a 2.8-10mm motorised varifocal lens with AI-powered analytics, giving installers remote control over zoom and focus while providing accurate classification of people, vehicles, faces and licence plates. It records at up to 60fps and uses H.265 compression with WiseStreamIII to manage bandwidth efficiently without sacrificing detail. WiseIR provides up to 40m of infrared night vision with balanced illumination, while extremeWDR at 120dB handles high-contrast lighting at entrances and outdoor approaches. The housing is rated IP66, IP67, IK10 and NEMA4X, making it suited to exposed wall and pole mounting in industrial, commercial and government applications where the camera must perform consistently regardless of weather conditions.
Key Capabilities
Motorised Varifocal Lens (2.8-10mm)
The 3.6x motorised varifocal lens enables remote zoom and focus adjustment after mounting, so installers can dial in the exact field of view for a specific entry point, fence line or outdoor approach without physically repositioning the camera body.
AI Object Detection and Behavioural Analytics
The Wisenet7 AI engine classifies people, vehicles, faces and licence plates, and triggers event-based alerts for intrusion, loitering and line crossing. This moves monitoring from passive recording to active event detection, with far fewer false triggers than standard motion detection.
4MP Resolution at Up to 60fps
At 2592 x 1520 resolution and frame rates up to 60fps, the XNO-C7083R captures smooth, detailed footage that supports confident identification of individuals and vehicles during fast-moving incidents at monitored locations.
WiseIR Night Vision to 40m
Integrated WiseIR automatically adjusts infrared intensity to prevent overexposure as subjects move closer, delivering balanced illumination across the full 40m range in complete darkness, which is critical for unlit car parks, loading docks and perimeter paths.
extremeWDR at 120dB
A 120dB wide dynamic range ensures the camera retains usable detail when facing direct sunlight, vehicle headlights or strongly backlit entry points, avoiding the washed-out or silhouetted images that affect cameras with lower WDR ratings.
IP66/IP67, IK10 and NEMA4X Rated Housing
The XNO-C7083R is built for exposed outdoor deployment. Its dual IP weather rating, IK10 impact resistance and NEMA4X certification make it suitable for harsh industrial environments, coastal sites and locations where the camera may be subject to deliberate interference.
Best For
- Perimeter and Fence Line Monitoring: The motorised varifocal lens allows precise framing of long outdoor approaches and boundary lines, while WiseIR provides reliable 40m coverage in the low-light conditions typical of perimeter locations.
- Car Parks and Vehicle Entry Points: AI-based vehicle detection and licence plate recognition support accurate incident logging and event-triggered alerts at entry and exit lanes or open-air parking areas.
- Industrial and Warehouse Sites: The IP66/IP67, IK10 and NEMA4X ratings allow reliable deployment in dusty, wet or physically demanding environments including loading docks, external walkways and plant areas.
- Commercial Building Exteriors: The bullet form factor provides visible directional coverage on external walls and soffits, and the AI behavioural analytics support intrusion and loitering detection for after-hours monitoring of commercial premises.
Why Choose the XNO-C7083R
The XNO-C7083R stands apart from standard 4MP bullet cameras through its combination of Wisenet7 AI processing, motorised varifocal framing and a protection rating set that covers IP66, IP67, IK10 and NEMA4X simultaneously. A camera without AI classification can record events but cannot distinguish a person from a passing animal or blowing debris. The XNO-C7083R classifies people, vehicles, faces and licence plates, and fires targeted alerts for intrusion, loitering and line crossing. The 2.8-10mm motorised lens removes the guesswork of fixed-lens installations, allowing post-mount zoom adjustment to cover exactly the right zone. WiseStreamIII compression reduces storage and bandwidth demand without degrading image quality, which matters for large multi-camera deployments. The XNO-C7083R is available through Security Wholesalers, and its combination of Wisenet7 analytics with a rugged, dual-rated housing makes it a technically strong choice for professional outdoor installations.
Buyer Decision Tips
Motorised Varifocal vs Fixed Lens: The 2.8-10mm motorised varifocal lens is genuinely useful when the exact coverage zone cannot be confirmed before installation, or when the camera position is fixed by structural constraints such as a wall bracket or conduit run. If your site layout is already confirmed and the camera can be freely positioned, a fixed wide-angle lens may be a simpler option. Where precise reach matters, such as a gate entrance or a defined corridor approach, the motorised varifocal pays for itself by removing the need for repositioning after cabling.
AI Analytics and VMS Compatibility: The XNO-C7083R runs its AI object detection and behavioural analytics on-camera, so basic event classification does not depend on the recorder or VMS. However, to fully utilise licence plate and face detection outputs, confirm that your NVR or VMS supports Hanwha Wisenet7 metadata and event handling. Not all third-party VMS platforms expose all AI event types, so check compatibility before specifying this camera for an AI-driven workflow.
Key Features & Technical Specifications
| Resolution |
4MP (2592 x 1520) |
| Image Sensor |
1/2.8″ CMOS |
| Lens Type |
2.8-10mm motorised varifocal (3.6x optical zoom) |
| Frame Rate |
Up to 60fps |
| IR Night Vision Range |
Up to 40m (WiseIR) |
| Wide Dynamic Range |
120dB (extremeWDR) |
| Video Compression |
H.265, H.264, MJPEG (WiseStreamIII) |
| AI Analytics |
People, vehicle, face and licence plate detection; intrusion, loitering, line crossing |
| Noise Reduction |
WiseNRII |
| Platform |
Wisenet7 |
| Power Supply |
PoE (IEEE 802.3af) |
| Weather Rating |
IP66, IP67 |
| Impact Rating |
IK10 |
| NEMA Rating |
NEMA4X |
| Camera Type |
Outdoor bullet |
Ideal Use Cases
Building Perimeter and Fence Lines
The bullet housing mounts directly to walls, poles and eave soffits for directed outdoor coverage. The 40m WiseIR range reaches across wide perimeter zones, and the motorised lens can be narrowed to focus on a specific gap or access point in a fence line.
Car Parks and Vehicle Access Lanes
The AI engine detects and classifies vehicles and supports licence plate detection, making the XNO-C7083R a practical choice for entry and exit lanes, open car parks and boom gate approaches where vehicle identification matters.
Loading Docks and Logistics Areas
The IP66/IP67 and NEMA4X ratings allow installation in exposed docking bays subject to rain, dust and wash-down activity. Loitering and intrusion detection help manage after-hours access to goods areas without requiring constant operator attention.
Industrial Sites and Yards
The IK10 vandal resistance and dual weather rating make this camera suitable for construction sites, manufacturing yards and utility facilities where cameras are exposed to both environmental and physical risks. AI classification reduces false alerts from machinery movement and environmental triggers.
Commercial Building Entry Points
At entrances facing strong backlight or direct sun, the 120dB extremeWDR maintains detail across both shaded and bright areas of the frame. People detection and face classification add useful metadata to footage captured at high-traffic entry points.
Choosing the Right Model
- Choose this model if: You need a 4MP outdoor bullet camera with AI-based object detection, licence plate and face classification, a motorised varifocal lens for post-mount framing flexibility, and a protection rating set that covers IP66, IP67, IK10 and NEMA4X for demanding outdoor deployment.
- Choose a different model if: Your application requires pan, tilt and optical zoom coverage across a wide open area, in which case a PTZ camera is better suited. If your site is fully indoors and a discreet ceiling-mount profile is needed, a dome or turret camera will be a better physical fit than the bullet housing.
FAQs
- What types of objects can the XNO-C7083R detect and classify?
The Wisenet7 AI engine on the XNO-C7083R classifies people, vehicles, faces and licence plates. It also supports behavioural analytics including intrusion detection, loitering detection and line crossing, allowing the system to generate targeted alerts rather than treating all motion equally.
- Does the motorised varifocal lens adjust remotely, or does it need to be tuned physically at the camera?
The 2.8-10mm motorised varifocal lens supports remote zoom and focus adjustment through a compatible NVR or VMS interface. This allows an installer to mount the camera first and fine-tune the field of view from a workstation, removing the need for a second person at height or repeated physical access to the camera.
- How does WiseIR prevent overexposure at close range?
WiseIR automatically adjusts the intensity of the infrared LEDs based on the distance of the subject in the frame. When a person or vehicle moves close to the camera, the IR output dims to avoid a washed-out image. This maintains readable detail across the full 40m range rather than only at a fixed distance.
- What does the 120dB extremeWDR rating mean for outdoor installation?
A 120dB wide dynamic range allows the XNO-C7083R to handle scenes where very bright and very dark areas appear in the same frame simultaneously. This is particularly relevant at building entries facing the sun, lit car park exits at night and any location where vehicle headlights or artificial lighting creates strong contrast against a darker background.
- Is the XNO-C7083R suitable for coastal or chemically exposed environments?
The NEMA4X rating covers protection against corrosion and chemical wash-down in addition to the standard IP weather sealing. This makes the XNO-C7083R appropriate for coastal sites, food processing facilities and industrial environments where salt air or cleaning agents are a factor in long-term camera durability.
- Does this camera require a special NVR to record AI events?
The AI processing runs on-camera using the Wisenet7 platform, so basic object classification occurs independently of the recorder. To fully utilise AI event outputs such as licence plate data and face detection metadata, the connected NVR or VMS should support Hanwha Wisenet7 event integration. Check recorder compatibility before specifying the camera for a fully AI-driven workflow. The XNO-C7083R is available through Security Wholesalers, where the team can assist with compatibility questions.
- What does IK10 mean, and does it matter for a bullet camera in an outdoor location?
IK10 is the highest impact protection rating in the IEC 62262 standard, indicating the housing can withstand 20 joules of impact force. For an exposed outdoor bullet camera mounted at accessible heights on a fence line, loading dock or car park entrance, IK10 provides meaningful physical robustness against tampering or accidental impact from equipment and vehicles.
