Product SKU: WRN-2110B1
Product Overview
Installers and integrators specifying large-scale IP camera deployments will find the Hanwha Vision WRN-2110B1 well matched to demanding recording environments. This 2U rack-mount NVR supports up to 32 IP camera channels at a sustained 250 Mbps recording throughput, making it suited to enterprise security rooms, multi-site retail operations, commercial facilities, and high-density surveillance installations where both channel count and recording speed are non-negotiable. The WRN-2110B1 arrives pre-loaded with Wisenet WAVE video management software running on Ubuntu 22.04 LTS, providing a structured, familiar interface for setup, live view, playback, and event management without requiring a separate VMS licence. Featuring 4 internal SATA HDD bays with support for up to 40 TB of onboard storage, dual Gigabit Ethernet ports, and both HDMI and DisplayPort video outputs, this recorder is built around rack-based deployments where long retention, network redundancy, and direct local display are all part of the installation brief. When paired with compatible Hanwha AI cameras, the WRN-2110B1 also enables AI metadata search across recorded footage.
Key Capabilities
32-Channel IP Camera Support
The WRN-2110B1 accommodates up to 32 IP cameras in a single recorder, making it a practical choice for large commercial sites, campuses, or multi-floor buildings where consolidating feeds into one system is a priority for operators and system designers alike.
250 Mbps Recording Throughput
A 250 Mbps sustained recording bandwidth ensures the recorder can handle simultaneous high-resolution streams from all connected cameras without frame drops or bottlenecks, even in mixed-resolution environments where some cameras are recording at full 4K or multi-megapixel rates.
40 TB Internal Storage Capacity
With 4 SATA HDD bays supporting drives up to 10 TB each, the WRN-2110B1 can hold up to 40 TB of recorded footage internally. This provides extended retention periods across 32 channels without requiring immediate external storage infrastructure.
Wisenet WAVE VMS Pre-Installed
The recorder ships with Wisenet WAVE VMS loaded on Ubuntu 22.04 LTS, removing the need for a separate software purchase or licensing step during commissioning. Wave clients, mobile apps, and cloud sync are all supported, enabling remote access from day one of installation.
AI Metadata Search
When connected to compatible Hanwha AI cameras, the WRN-2110B1 supports AI-driven search across recorded footage using attributes such as human detection, face, vehicle, and licence plate. This significantly reduces the time spent reviewing footage during incident investigations.
Dual Gigabit Network Ports
Two onboard Gigabit Ethernet ports allow for network segmentation between the camera-facing LAN and the management or corporate network, or can be used for link redundancy in installations where network uptime is critical to system continuity.
Best For
- Enterprise Security Rooms: The 2U rack-mount form factor and 32-channel capacity suit server room or comms rack installations where space is structured and camera counts are high.
- Multi-Site Commercial Deployments: Remote access via Wave clients and mobile apps allows operators to monitor and manage footage across locations from a single interface without being on-site.
- Forensic Incident Review: AI metadata search, available when paired with compatible Hanwha AI cameras, allows security teams to locate specific events quickly rather than scrubbing through hours of footage manually.
- High-Resolution Mixed Camera Systems: A 250 Mbps recording bandwidth supports large deployments mixing different camera resolutions without constraining throughput across the channel group.
Why Choose the WRN-2110B1
The WRN-2110B1 separates itself from entry-level NVRs through the combination of 32 channels, 250 Mbps sustained throughput, and a pre-installed Wisenet WAVE VMS on a stable Ubuntu 22.04 LTS platform, all in a 2U rack-mount chassis sized for structured comms room deployments. A basic 16-channel or consumer-grade recorder simply cannot match this throughput at scale, nor does it provide the AI metadata search capability the WRN-2110B1 delivers when integrated with Hanwha AI cameras. The 4-bay SATA HDD configuration, supporting up to 40 TB, means retention planning is built into the hardware rather than requiring immediate expansion hardware. Dual Gigabit Ethernet ports add network design flexibility that single-port recorders cannot provide. For integrators and end users seeking a professionally specified recorder with a clear pathway to AI-driven forensic review, the WRN-2110B1, available at Security Wholesalers, is a purpose-built fit for commercial-scale deployments.
Buyer Decision Tips
AI Search Requires Compatible Cameras: The AI metadata search features of the WRN-2110B1 are only active when connected to Hanwha AI-capable cameras that transmit metadata alongside video streams. If your camera selection includes non-Hanwha or non-AI models, standard video search and motion-based playback will still function, but attribute-based AI search will not. Confirm your camera model list supports AI metadata output before specifying the recorder for forensic search use cases.
Storage Planning Across 32 Channels: At full 32-channel occupancy with cameras recording at higher resolutions, 40 TB will provide variable retention depending on frame rate, compression settings, and motion activity. H.265 compression (supported natively) will significantly extend retention compared to H.264. Plan your HDD configuration and bitrate settings before commissioning to ensure you meet your minimum retention requirement, particularly in environments where 30-day or longer archives are needed for compliance purposes.
Key Features & Technical Specifications
| Model |
WRN-2110B1 |
| Form Factor |
2U rack-mount |
| Maximum Camera Channels |
32 IP camera channels |
| Recording Bandwidth |
250 Mbps |
| HDD Bays |
4 x SATA HDD |
| Maximum Internal Storage |
Up to 40 TB (10 TB per drive) |
| Operating System |
Ubuntu 22.04 LTS |
| VMS Software |
Wisenet WAVE (pre-installed) |
| Processor |
Quad-core |
| RAM |
8 GB DDR4 |
| System Storage |
32 GB eMMC |
| Supported Video Codecs |
H.265, H.264, MJPEG |
| Network Ports |
2 x Gigabit Ethernet |
| Video Outputs |
HDMI, DisplayPort |
| AI Search |
Supported with compatible Hanwha AI cameras (human, face, vehicle, licence plate attributes) |
| Dimensions |
440 x 89.8 x 428.4 mm |
| Weight |
Approx. 5.47 kg |
| Operating Temperature |
0°C to 40°C |
| Humidity |
20% to 85% |
Ideal Use Cases
Enterprise Security Control Rooms
The 2U rack-mount chassis integrates cleanly into structured comms rooms or security control environments. With 32 channels and HDMI/DisplayPort outputs, local operators can view and manage the full camera group directly from the recorder’s display output.
Multi-Site Retail and Commercial Chains
Wisenet WAVE’s remote access via client software and mobile apps allows centralised monitoring across multiple store or site locations. A single WRN-2110B1 per site can cover up to 32 cameras, reducing the number of recorders required across a network of premises.
Forensic Investigation Environments
When paired with compatible Hanwha AI cameras, the WRN-2110B1’s AI metadata search enables rapid forensic review using human, face, vehicle, and licence plate attributes rather than manual timeline scrubbing, which is critical in high-incident or compliance-sensitive environments.
High-Resolution Multi-Camera Installations
A 250 Mbps recording throughput ensures the WRN-2110B1 can sustain full recording across all 32 channels simultaneously, even in deployments mixing 4K and multi-megapixel cameras at standard frame rates with H.265 compression enabled.
Installations Requiring Long Video Retention
With up to 40 TB of internal SATA storage across 4 drive bays, the WRN-2110B1 is suited to sites where extended footage archives are required for legal, compliance, or operational review purposes, without needing to immediately specify external storage expansion.
Choosing the Right Model
- Choose this model if: You are specifying a rack-mount recorder for 17 to 32 IP cameras, require 250 Mbps sustained throughput, want Wisenet WAVE VMS pre-installed without a separate licence cost, and need up to 40 TB of internal storage with the option of AI metadata search when using compatible Hanwha AI cameras.
- Choose a different model if: Your camera count is 16 or fewer and the 32-channel capacity exceeds your deployment scope, a lower-channel NVR would be more cost-effective. Similarly, if your installation requires PoE ports built into the recorder itself rather than using a separate PoE switch infrastructure, a PoE NVR variant would better suit that network design.
- Choose a different model if: You need external storage expansion beyond 40 TB internally. If your retention requirements exceed what 4 internal drives can provide at your target bitrate and frame rate settings, a recorder with eSATA or NAS integration may be more appropriate for your archive strategy.
FAQs
- Does the WRN-2110B1 include the Wisenet WAVE VMS licence, or does that need to be purchased separately?
The WRN-2110B1 comes with Wisenet WAVE video management software pre-installed on the Ubuntu 22.04 LTS operating system. No separate VMS licence purchase is required to operate the recorder with up to 32 connected cameras. Remote Wave clients and mobile app access are also included within the WAVE ecosystem without additional per-camera licence costs at the recorder level.
- Does the AI metadata search work with any IP camera brand connected to the recorder?
No. The AI metadata search functionality on the WRN-2110B1 requires compatible Hanwha AI cameras that transmit AI metadata alongside video data. Cameras from other manufacturers, or Hanwha cameras that do not carry AI processing, will record video normally but will not generate the metadata required for attribute-based search using human, face, vehicle, or licence plate filters.
- What HDDs should be installed in the WRN-2110B1, and are drives included?
The WRN-2110B1 supports SATA HDDs up to 10 TB per bay across its 4 bays, giving a maximum internal capacity of 40 TB. Surveillance-rated HDDs (such as those from WD Purple or Seagate SkyHawk product lines) are generally recommended for NVR applications due to their optimisation for continuous write workloads. Drives are not included and should be specified separately based on your required retention period and bitrate.
- How should I use the dual Gigabit Ethernet ports on the WRN-2110B1?
The 2 Gigabit Ethernet ports give you the option to segment the camera-facing network from your management or corporate LAN, which is a common security architecture practice in commercial installations. Alternatively, the 2 ports can be configured for link redundancy to maintain connectivity if one network path fails. The appropriate configuration depends on your network design and any specific security or compliance requirements at the installation site.
- Is the WRN-2110B1 suitable for rack mounting, and what rack depth is required?
Yes, the WRN-2110B1 is a 2U rack-mount unit. Its physical dimensions are 440 x 89.8 x 428.4 mm, so a minimum rack depth of approximately 430 mm (plus clearance for cabling at the rear) is required. Rack-mount brackets are included with the unit. This makes it straightforward to install into a standard 19-inch equipment rack or comms cabinet.
- Can the WRN-2110B1 be accessed remotely, and what software is needed on the client side?
Remote access is supported through Wisenet WAVE client software installed on a PC or laptop, or through the Wisenet WAVE mobile app on iOS or Android devices. Cloud synchronisation is also available within the WAVE ecosystem. No third-party VMS software is required. The dual Gigabit network ports support the network infrastructure needed for both local and remote connectivity from commissioning.
- Where can I purchase the WRN-2110B1 in Australia?
The WRN-2110B1 is part of the Security Wholesalers range, supplied to installers and integrators across Australia. It is stocked as a professional-grade product suited to commercial and enterprise channel surveillance deployments. Contact Security Wholesalers directly to confirm current availability, pricing, and compatibility with your specified Hanwha camera models before placing an order.
Additional Information
No additional downloads available for this product.
