Hanwha Vision TNO-C8083E 5MP Outdoor AI Explosion Proof Stainless Steel Bullet Camera with IP66 IK10 3.2x Motorised Varifocal 3.2-10.2mm

Product SKU: TNO-C8083E

Product Overview

The Hanwha Vision TNO-C8083E is a compact 5MP explosion-proof AI bullet camera designed for hazardous and demanding industrial environments where conventional camera housings may not be suitable. It combines a 1/2.8-inch 5MP CMOS sensor with a 3.2–10.2 mm motorised varifocal lens, delivering up to 2592 × 1944 resolution at 30 fps with a horizontal field of view from approximately 95° to 29°. AI-based person and vehicle classification supports more targeted event detection and reduced false alarms, while 120 dB WDR helps manage scenes with strong contrast. The SUS316L stainless-steel enclosure carries IP66 and IK10 ratings and is certified for explosion-protected applications including IECEx and ATEX. PoE power and a compact 4.77 kg body make the TNO-C8083E a practical option for industrial sites requiring robust construction, flexible framing and intelligent surveillance.

Key Capabilities

Best For

• Hazardous Industrial Areas: Designed for certified installations where explosion protection is a project requirement.
• Oil, Gas and Petrochemical Sites: Stainless-steel construction and hazardous-area certification suit compatible process and plant surveillance applications.
• Manufacturing Facilities: AI object classification and flexible varifocal framing can help monitor production areas, restricted zones and vehicle movements.
• Ports and Heavy Industry: IP66, IK10 and SUS316L construction suit harsh environments exposed to weather, impact and corrosive conditions.
• High-Risk Access Points: The adjustable lens can be framed more tightly where a specific gate, doorway or process area requires focused monitoring.

Why Choose the TNO-C8083E

The TNO-C8083E is designed for projects where hazardous-area certification and physical durability are as important as image quality. Its compact explosion-proof construction makes it easier to deploy than larger traditional explosion-proof housings, while the 3.2–10.2 mm motorised lens provides useful flexibility when the final viewing angle needs to be adjusted after mounting. AI person and vehicle classification also adds more meaningful event filtering than basic motion-only detection. Available through Security Wholesalers, this model is particularly appropriate where 5MP resolution, PoE connectivity, SUS316L stainless steel and certified explosion protection need to be combined in one compact network camera.

Buyer Decision Tips

Key Features & Technical Specifications

Resolution	Up to 5MP, 2592 × 1944.
Camera Type	Compact explosion-proof AI bullet network camera.
Image Sensor	1/2.8-inch 5MP CMOS.
Maximum Frame Rate	Up to 30 fps/25 fps with H.265 or H.264.
Lens	3.2–10.2 mm motorised varifocal DC auto-iris lens.
Optical Zoom	Approximately 3.2×.
Horizontal Field of View	Approximately 95° wide to 29° tele.
Vertical Field of View	Approximately 69° wide to 21° tele.
Minimum Illumination	Colour 0.07 lux at F1.6, 1/30 sec.
Day & Night	Auto ICR.
Wide Dynamic Range	120 dB.
AI Classification	Person and vehicle classification with vehicle-type attributes.
AI Analytics	Object detection, virtual line crossing and direction, plus loitering, intrusion, enter and exit events.
Business Intelligence	People counting, vehicle counting, queue management and heatmap.
Video Compression	H.265, H.264 and MJPEG with WiseStream III.
Network Interface	10/100BASE-T Ethernet.
Power	PoE, IEEE 802.3af Class 3.
Power Consumption	Maximum 9.5 W, typical 5.3 W.
Housing & Protection	SUS316L stainless steel, IP66 and IK10.
Explosion-Proof Certification	IECEx and ATEX certified; Hanwha also lists KCs and JPEx certification.
Operating Conditions	-30°C to 55°C, 0% to 95% RH non-condensing.
Dimensions	Ø110.5 × 316.2 mm.
Weight	Approximately 4.77 kg.

Ideal Use Cases

Choosing the Right Model

• Choose this model if: You need a compact 5MP explosion-proof bullet camera with AI person and vehicle classification, a 3.2–10.2 mm motorised varifocal lens and SUS316L stainless-steel construction.
• Confirm hazardous-area classification first if: The camera will be installed in an explosive atmosphere. The certification, zone, gas or dust classification and installation method must match the actual site requirements.
• Plan external illumination if: The scene must be monitored in complete darkness, because no built-in IR range is specified for this model.
• Choose a standard industrial camera instead if: The installation does not require explosion-proof certification and the additional hazardous-area construction would provide no practical benefit.

FAQs

1. What makes the Hanwha Vision TNO-C8083E suitable for hazardous locations?
   The TNO-C8083E is a compact explosion-proof network camera with IECEx and ATEX certification, and Hanwha also lists KCs and JPEx explosion-proof certification for the model. Its SUS316L stainless-steel enclosure is designed for demanding industrial environments. The exact hazardous-area classification and installation method must still be matched to the project requirements, including the certified cable-gland arrangement and local compliance obligations.
2. What resolution and frame rate does the TNO-C8083E support?
   The TNO-C8083E provides up to 5MP resolution at 2592 × 1944 and supports up to 30 fps with H.265 or H.264. MJPEG is also supported, with a maximum of 5 fps at 5MP. This gives the camera enough resolution for detailed industrial surveillance while retaining standard network-video compression options for integration with compatible recording systems.
3. What lens does the TNO-C8083E use?
   The TNO-C8083E uses a 3.2–10.2 mm motorised varifocal lens with approximately 3.2× optical zoom. Its horizontal field of view ranges from about 95° at the wide end to 29° at the tele end. This allows the installer to choose broader scene coverage or a tighter view without replacing the lens, which is useful when commissioning fixed industrial camera positions.
4. What AI analytics are built into the TNO-C8083E?
   The TNO-C8083E can classify people and vehicles and supports AI-based object detection, virtual line crossing and direction, plus virtual-area events including loitering, intrusion, entering and exiting. It also supports people and vehicle counting, queue management and heatmaps. These functions can help reduce false alarms and make event review more efficient than relying on basic motion detection alone.
5. Does the TNO-C8083E have built-in infrared illumination?
   No. The confirmed specifications do not list built-in IR illumination for the TNO-C8083E. It is specified for colour operation down to 0.07 lux at F1.6 and uses an automatic IR-cut filter for day and night operation. If surveillance is required in complete darkness, the site design should include suitable external illumination that is appropriate for the hazardous-area installation.
6. How rugged is the TNO-C8083E?
   The TNO-C8083E uses a SUS316L stainless-steel enclosure and carries IP66 weather protection and IK10 impact resistance. Its operating range is -30°C to 55°C with 0% to 95% non-condensing humidity. These characteristics suit demanding industrial locations, although installation hardware, cable entry and environmental sealing must still comply with the applicable hazardous-area and site requirements.
7. What power and network connection does the TNO-C8083E require?
   The TNO-C8083E uses PoE to IEEE 802.3af Class 3 and has a maximum stated power consumption of 9.5 W, with typical consumption of 5.3 W. Network connectivity is through 10/100BASE-T Ethernet. For systems supplied through Security Wholesalers, the PoE switch, network capacity and hazardous-area cable-entry arrangement should all be confirmed as part of the installation design.
8. What should I check before choosing the TNO-C8083E?
   Choose the TNO-C8083E when the project needs a compact 5MP explosion-proof bullet camera with a 3.2–10.2 mm motorised lens, AI person and vehicle classification, PoE power and a SUS316L stainless-steel housing. Before purchase, confirm the required hazardous-area certification, cable-gland method, external lighting needs, field of view and local compliance requirements rather than selecting the camera on resolution alone.

Additional Information

• Hanwha TNO-C8083E 5MP Compact Explosion-proof AI Camera Datasheet
• Hanwha TNO-C8083E Quick Guide
• Hanwha TNO-C8083E User Manual
