Product SKU: QNO-C9083R
Product Overview
For commercial and industrial sites needing flexible zoom coverage with AI-filtered event detection, the Hanwha Vision QNO-C9083R delivers 8MP resolution in a robust outdoor bullet housing. The 3.2-10.2mm motorized varifocal lens allows installers to dial in the exact field of view for each position, covering everything from wider yard approaches to tighter entry point framing, without physically repositioning the camera. Featuring a built-in AI engine, the QNO-C9083R classifies people and vehicles, including cars, trucks, buses, bicycles, and motorcycles, helping reduce nuisance alert volumes and sharpen the accuracy of event-driven monitoring. It also integrates virtual line crossing, loitering, intrusion, and enter and exit analytics for structured scene rules. With 30m infrared illumination, 120dB WDR, WiseNR II, WiseStream III, and IP66 and IK10 protection, this bullet camera is well suited to perimeter lines, loading docks, car parks, and building exteriors where outdoor durability and monitoring precision both matter.
Key Capabilities
Motorized Varifocal Lens
The 3.2-10.2mm motorized varifocal lens gives installers precise remote control over the field of view. Whether covering a wide loading dock or narrowing in on a gate entry, the zoom can be adjusted without touching or repositioning the mounted camera.
AI Object Detection and Classification
The built-in AI engine identifies people and vehicles, distinguishing cars, trucks, buses, bicycles, and motorcycles from general scene movement. This classification layer reduces irrelevant alerts and makes event review more focused for operators managing busy outdoor sites.
Advanced Scene Analytics
Beyond object detection, the QNO-C9083R supports virtual line crossing with direction detection, plus virtual area rules for loitering, intrusion, enter, and exit events. These tools allow structured monitoring rules to be applied to perimeters, access paths, and restricted zones.
120dB Wide Dynamic Range
Handling high-contrast scenes is critical for outdoor bullet cameras covering entries, driveways, and vehicle approaches. The 120dB WDR balances bright and shadowed areas simultaneously, preserving detail in both zones rather than losing one to overexposure or darkness.
WiseNR II and WiseStream III
WiseNR II uses the AI engine to reduce visual noise in low-light and challenging conditions, while WiseStream III applies intelligent compression to reduce bandwidth and storage demands. Together they help maintain practical surveillance quality without inflating infrastructure costs.
IP66 and IK10 Outdoor Bullet Housing
The bullet housing is rated IP66 for full weather resistance and IK10 for impact protection. This combination makes the QNO-C9083R suitable for exposed walls, fence posts, and industrial yard positions where both weather and physical interference are ongoing concerns.
Best For
- Commercial Perimeters and Fence Lines: The motorized varifocal lens and AI-based virtual line crossing detection make this camera well suited to monitoring perimeter boundaries where precise framing and structured alert rules both matter.
- Loading Docks and Yard Approaches: Vehicle classification across car, truck, and bus categories combined with 120dB WDR helps manage the mixed traffic and high-contrast lighting typical of loading and despatch areas.
- Car Parks and Driveways: Adjustable zoom coverage and AI-driven vehicle and person detection support focused monitoring of vehicle movement and pedestrian activity without excessive false alerts from general motion.
- Industrial Building Exteriors: IP66 and IK10 protection combined with 30m IR and 8MP resolution gives this camera practical durability for exposed wall and eave installations in demanding operational environments.
Why Choose the QNO-C9083R
The QNO-C9083R stands apart from fixed-lens outdoor bullet cameras through its combination of motorized varifocal flexibility and an onboard AI engine that classifies both people and specific vehicle types. A simpler 8MP bullet at a similar price point will capture footage, but it cannot apply line crossing rules, loitering detection, or classify a motorcycle from a truck at the event level. The motorized varifocal also removes the need to reposition or swap cameras when coverage requirements change, which reduces labour costs on multi-point installations. WiseStream III and WiseNR II further improve the storage and bandwidth profile of the system without sacrificing monitoring clarity. The QNO-C9083R is available through Security Wholesalers for commercial, industrial, and public-facing projects where AI-driven accuracy and adaptable outdoor bullet coverage are both required.
Buyer Decision Tips
Motorized Varifocal vs Fixed Lens: The 3.2-10.2mm motorized varifocal lens is most valuable when coverage requirements are uncertain at installation time or when the same camera model needs to serve different site positions. If all your installation points are confirmed and fixed at a single field of view, a fixed-lens camera at lower cost may suffice. However, for mixed-use sites, varied mounting heights, or positions that may need reframing over time, the motorized varifocal provides meaningful long-term value and avoids repeat call-outs.
IR Range Consideration: The QNO-C9083R provides 30m infrared illumination. For most perimeter positions, building entries, driveways, and car parks this is a practical working range. If your site has long unlit approaches, open paddocks, or large outdoor storage yards where subjects need to be identified at distances beyond 30m, review whether a longer IR range bullet camera better suits those specific positions before finalising your specification.
Key Features & Technical Specifications
| Resolution |
8MP |
| Lens Type |
Motorized varifocal |
| Focal Length |
3.2-10.2mm |
| Maximum Frame Rate |
30fps at 8MP |
| Minimum Illumination (Colour) |
0.06 Lux |
| Minimum Illumination (B/W) |
0.006 Lux |
| Wide Dynamic Range |
120dB |
| IR Range |
30m |
| Day/Night |
ICR day and night switching |
| Video Compression |
H.265, H.264, MJPEG |
| Smart Compression |
WiseStream III |
| Noise Reduction |
WiseNR II |
| AI Object Detection |
People and vehicles (car, truck, bus, bicycle, motorcycle) |
| Event Analytics |
Virtual line crossing (with direction detection), loitering, intrusion, enter, exit |
| Protection Rating |
IP66, IK10 |
| Power |
PoE, max 12W |
Ideal Use Cases
Warehouse and Industrial Yard Perimeters
The combination of AI vehicle and person classification with adjustable varifocal zoom makes the QNO-C9083R practical for industrial yards where traffic types are mixed and coverage distances vary between positions.
Loading Dock and Despatch Areas
120dB WDR manages the sharp contrast between overhead artificial lighting and open sky at loading areas, while truck and vehicle classification supports structured monitoring of incoming and outgoing vehicle activity.
Car Parks and Vehicle Access Points
Motorized zoom allows each camera to be framed precisely for lane or bay coverage, while AI vehicle detection and virtual line crossing help capture meaningful entry and exit events rather than broad undifferentiated motion.
Building Exterior Walls and Entry Points
IP66 and IK10 protection supports reliable operation on exposed exterior walls. The motorized varifocal lens lets installers adapt framing to suit entry doors, stairwells, and pathway approaches without repositioning the mounted housing.
Commercial Fence Lines and Restricted Zone Boundaries
Virtual line crossing with direction detection and intrusion detection analytics allow rule-based monitoring to be applied along fence lines and boundary paths, generating alerts when movement crosses defined thresholds rather than triggering on all general motion.
Choosing the Right Model
- Choose this model if: Your site needs a combination of flexible zoom framing via motorized varifocal, AI-based person and vehicle classification, structured analytics such as line crossing and loitering, and rugged IP66 and IK10 outdoor bullet protection in a single 8MP unit.
- Choose a different model if: Your coverage distances consistently exceed 30m in unlit outdoor areas, as a bullet camera with a longer IR range would better serve those positions. Alternatively, if all mounting positions are fixed and the field of view will not change, a fixed-lens bullet camera at the same resolution may provide similar performance at a lower cost point.
FAQs
- How does the motorized varifocal lens work on the QNO-C9083R and why does it matter for installation?
The 3.2-10.2mm motorized varifocal lens allows the viewing angle to be adjusted remotely through the camera’s software interface or a connected recorder, without physically touching or repositioning the camera. For installers working across varied mounting heights, building geometries, or outdoor positions with different coverage requirements, this significantly reduces the time needed to fine-tune framing on site.
- What vehicle types can the AI engine on the QNO-C9083R classify?
The built-in AI engine classifies vehicles as cars, trucks, buses, bicycles, and motorcycles, as well as detecting people as a separate object class. This level of classification allows event rules to target specific vehicle types rather than all motion, which is particularly useful for loading areas, car parks, and gated entry points where different vehicle categories carry different operational significance.
- What analytics rules can be configured on this camera?
The QNO-C9083R supports virtual line crossing with direction detection, meaning alerts can be configured for movement crossing a defined line in one or both directions. Virtual area analytics include loitering, intrusion, enter, and exit events. These tools allow structured monitoring zones to be applied to specific parts of the scene rather than relying solely on general motion detection across the full frame.
- Is the 30m IR range sufficient for commercial outdoor applications?
For most commercial perimeter positions including building entries, pedestrian paths, car park lanes, and loading dock approaches, 30m infrared range provides adequate night-time coverage. However, for open sites where subjects need to be identified at greater distances, such as large outdoor storage areas or long unlit driveways, a camera with extended IR range should be assessed for those specific positions.
- How does 120dB WDR improve performance in outdoor bullet camera positions?
Outdoor bullet cameras frequently face scenes with strong contrast between bright sky, reflected sunlight, and shaded surfaces. Without adequate WDR, cameras either overexpose the bright areas or lose detail in shadows. The 120dB WDR on the QNO-C9083R processes both simultaneously, which is particularly useful for entry points, driveways, and loading areas where both people approaching and vehicle plates need to remain visible within the same frame.
- What does WiseStream III do for storage and bandwidth on the QNO-C9083R?
WiseStream III is Hanwha’s intelligent compression technology that analyses video content and applies more aggressive compression to low-activity areas of the frame while preserving detail in motion-heavy zones. On an 8MP camera running continuously, this can meaningfully reduce the storage footprint and network bandwidth demand compared to standard H.265 encoding alone, without visibly degrading the monitoring quality of active scene areas.
- What is the power requirement and how is the QNO-C9083R connected?
The QNO-C9083R is powered via PoE with a maximum draw of 12W, meaning a single Cat5e or Cat6 cable carries both network data and power to the camera. This simplifies installation by removing the need for a separate power run to each camera position, which is particularly practical for wall-mounted bullet installations on building exteriors and perimeter positions.
