Hanwha Vision HV-ARN-810S 8CH 8MP H.265 AI NVR with PoE Switch

Hanwha Vision HV-ARN-810S 8CH 8MP H.265 NVR with PoE Switch

$526.70

FREE DELIVERYWARRANTY GUARANTEED

✔ Dedicated 5★ Customer Care Team ✔ Fast & Responsive Tech Support

Hanwha Vision HV-ARN-810S | 8-Channel 8MP H.265 NVR | 8-Port PoE Switch

The Hanwha Vision HV-ARN-810S delivers an 8-channel NVR solution designed for small to medium surveillance installations. Featuring H.265, H.264, and MJPEG codec support with 60Mbps network camera recording, it offers efficient and flexible storage performance. Equipped with 8 PoE+ ports and a 65W budget, the unit supports plug-and-play camera connectivity without additional switching hardware. It also includes 4K HDMI output, dual track recording, and P2P remote access via Wisenet Viewer and Wisenet Mobile for convenient monitoring from anywhere.

Key Features

8-Channel 8MP Recording: Supports up to 8 cameras at resolutions up to 8 megapixels.
H.265 Compression: Reduces storage and bandwidth requirements compared to older codecs.
8-Port PoE+ Switch: Built-in PoE+ ports with a 65W budget enable plug-and-play camera installation.
4K HDMI Output: Dual track recording with 4K HDMI local monitor output for high-resolution display.
HDD Support: Accommodates up to 1 HDD with a maximum capacity of 6TB for local storage.
P2P Remote Access: QR code connection via Wisenet Viewer and Wisenet Mobile for easy remote viewing.

Additional Information

Data Sheet ARN-810S

$526.70 inc GST +3 Year Warranty & Support

Description

Product SKU: HV-ARN-810S

Product Overview

Built for installers and system owners running up to 8 Wisenet IP cameras, the HV-ARN-810S is an 8-channel NVR with an integrated 8-port PoE+ switch that removes the need for a separate network switch at the install site. Equipped with H.265 compression and support for up to 8MP resolution per channel, it handles high-definition recordings across all 8 feeds at a combined 60Mbps throughput. The 65W PoE+ budget powers connected cameras directly over Cat cable, keeping rack or wall installations tidy and straightforward. Featuring a 4K HDMI output, the local monitor feed is sharp and detailed for on-site review. It also includes P2P QR code connectivity for quick remote access via Wisenet Mobile on smartphones or Wisenet Viewer on PC and Mac. With a single HDD bay accepting drives up to 6TB and dual track recording support, the HV-ARN-810S suits small to medium fixed-camera deployments where simplicity of setup is a priority.

Key Capabilities

Integrated 8-Port PoE+ Switch

With 8 PoE+ ports and a 65W shared budget built directly into the unit, there is no need for a separate PoE switch. Cameras receive both data and power over a single Cat cable run, simplifying wiring at the NVR end and reducing hardware costs on smaller installs.

Up to 8MP Recording Across 8 Channels

All 8 channels support resolutions up to 8MP, meaning cameras installed at entrances, car parks, or internal areas can record at full resolution without the NVR downscaling the feed. Combined 60Mbps throughput sustains high-resolution streams across all connected cameras simultaneously.

H.265 Compression

H.265 encoding reduces file sizes compared to H.264 while maintaining the same visual detail, which extends the usable recording period on a given HDD. For a single-bay NVR with a 6TB ceiling, this compression efficiency is important for maximising continuous recording retention.

4K HDMI Local Monitor Output

The 4K HDMI output drives a connected display at full ultra-high-definition resolution, giving on-site operators or security staff a detailed live view across all camera positions. This is useful in reception areas, control rooms, or back offices where local monitoring is part of the daily workflow.

P2P Remote Access via QR Code

Setup for remote viewing requires only a QR code scan in the Wisenet Mobile app on iOS or Android, or Wisenet Viewer on a PC or Mac. This eliminates the need for manual port forwarding on most networks, making commissioning faster for installers and more accessible for end users checking footage off site.

Best For

Small Commercial Installations: The 8-channel capacity and integrated PoE+ switch make this a self-contained recording unit for retail shops, offices, or small warehouses running up to 8 IP cameras without additional networking hardware.
Wisenet Camera Deployments: Designed within the Hanwha Vision Wisenet ecosystem, the HV-ARN-810S is best matched with Wisenet-compatible IP cameras where plug-and-play PoE detection and app integration can be fully utilised.
Sites Requiring Remote Monitoring: The P2P QR code connection and Wisenet Mobile app support make this suited to owner-operated businesses or managed installations where the end user needs off-site access without a complex network configuration.
High-Resolution Fixed-Camera Systems: Sites where cameras are positioned at fixed points, such as entrances, counters, or storage areas, benefit from the 8MP per channel capability and 60Mbps total bandwidth for sustained detail-rich recording across all positions.

Why Choose the HV-ARN-810S

The HV-ARN-810S addresses a common installer challenge: running 8 PoE cameras without sourcing and cabling a separate PoE switch. By combining the NVR and PoE switching into one unit with 8 dedicated ports and a 65W budget, the installation footprint stays compact and the cable count at the head end is reduced. The 8MP per channel ceiling and H.265 support give this recorder real longevity, handling current Wisenet camera generations at full resolution rather than bottlenecking on the recorder side. The 4K HDMI output and P2P remote access via Wisenet Mobile add practical value for both on-site staff and off-site monitoring. With the installation wizard and dual track recording also included, this NVR is suited to time-sensitive commercial installs where configuration speed matters. Available at Security Wholesalers, the HV-ARN-810S is backed by the Hanwha Vision Wisenet platform and a current firmware update bringing it to v5.05.12.

Buyer Decision Tips

Storage Planning: The HV-ARN-810S accepts a single HDD with a maximum capacity of 6TB. With 8 cameras recording at high resolution using H.265, storage consumption will vary by motion activity and frame rate settings. Calculate your retention requirement before purchase and consider selecting a surveillance-grade drive (WD Purple or Seagate Skyhawk) at the highest supported capacity if continuous multi-day recording is needed. If your retention requirements exceed what a single 6TB drive can hold, consider an NVR with multiple HDD bays.

PoE Budget per Camera: The 8 PoE+ ports share a total 65W power budget. Dividing this across 8 cameras leaves approximately 8W per camera on average. Standard IP dome and turret cameras typically draw 5-12W, so most Wisenet cameras will operate within this budget. However, if you intend to connect cameras with active deterrence LEDs, heaters, or motorised lenses that draw closer to 15-25W, check each camera’s PoE draw before committing to an 8-camera layout on this NVR.

Key Features & Technical Specifications

Model	HV-ARN-810S
Channel Count	8 channels
Maximum Camera Resolution	Up to 8MP per channel
Video Compression	H.265, H.264, MJPEG
Recording Throughput	60Mbps incoming network camera recording
PoE Ports	8 x PoE+ ports
PoE Power Budget	65W total
HDD Bays	1 bay
Maximum HDD Capacity	Up to 6TB
Monitor Output	4K HDMI
Recording Mode	Dual track recording
Remote Access	P2P via QR code, Wisenet Mobile (iOS/Android), Wisenet Viewer (PC/Mac)
Current Firmware	v5.05.12 (update available)
Ecosystem	Hanwha Vision Wisenet

Ideal Use Cases

Retail Shopfronts and Store Interiors

Up to 8 cameras covering entry points, point-of-sale areas, and stockrooms can be connected and powered directly from the HV-ARN-810S without a separate switch, making it practical for retail tenancies with limited comms rack space.

Small Office Buildings

Offices covering reception, corridors, car parks, and entry doors fit comfortably within an 8-channel layout. H.265 compression maximises the usable recording time on the single 6TB HDD, and the 4K HDMI output supports a connected monitor at reception or in a server room.

Owner-Operated Business Remote Monitoring

The P2P QR code setup and Wisenet Mobile app allow business owners to check live footage from a smartphone without configuring port forwarding, which is a practical advantage for single-site operators who want straightforward off-site access.

Light Industrial and Warehouse Monitoring

Small warehouses and light industrial sites with loading areas, roller doors, and internal storage zones can be covered across 8 camera positions at up to 8MP resolution per feed, giving sufficient detail for footage review after an incident.

Multi-Tenancy Residential Common Areas

Stairwells, car parks, lobby areas, and building entries in apartment blocks or townhouse complexes can be managed through 8 dedicated PoE camera positions from a single compact NVR, simplifying both installation and ongoing access for body corporate managers.

Choosing the Right Model

Choose this model if: You are installing up to 8 Wisenet IP cameras and want a self-contained unit that handles both PoE switching and recording without a separate network switch. The 8MP per channel ceiling and H.265 support make it compatible with current-generation high-resolution cameras, and P2P remote access via Wisenet Mobile suits sites where end-user app access is expected.
Choose a different model if: Your system exceeds 8 cameras, or if you need more than 6TB of local storage. A single-bay NVR is a constraint on larger deployments where multi-day retention at high resolution is required. Similarly, if individual cameras in your layout draw above the shared 65W PoE budget when combined, a NVR paired with a dedicated high-wattage PoE switch may be more appropriate.

FAQs

Does the HV-ARN-810S require a separate PoE switch to power cameras?
No. The HV-ARN-810S includes 8 built-in PoE+ ports with a shared 65W budget. Cameras connect directly to the NVR via Cat cable and receive both power and data from the unit itself. For most standard Wisenet IP cameras drawing under 8W each, the 65W budget is sufficient across all 8 ports simultaneously.
What is the maximum storage this NVR supports?
The HV-ARN-810S has a single HDD bay and supports drives up to 6TB. A surveillance-grade drive such as a WD Purple or Seagate Skyhawk is recommended. If you require more than 6TB of local storage, this NVR’s single-bay design is a hard ceiling and a different recorder with multiple bays should be considered.
How does the P2P remote access work on this NVR?
The HV-ARN-810S supports P2P connection via QR code. During setup, the NVR displays a QR code that you scan using the Wisenet Mobile app on iOS or Android, or connect through Wisenet Viewer on a PC or Mac. This method typically avoids the need for manual port forwarding on a standard router, simplifying remote access setup for both installers and end users.
What does dual track recording mean on the HV-ARN-810S?
Dual track recording allows the NVR to store 2 separate video streams per camera simultaneously. This is typically a main stream at high resolution for detailed playback and a sub-stream at lower resolution for efficient remote viewing or bandwidth-sensitive access. Both tracks are stored concurrently on the HDD.
Is there a firmware update available for the HV-ARN-810S?
Yes. Firmware version v5.05.12 is available for the HV-ARN-810S. Keeping the NVR firmware current is important for system stability, compatibility with newer Wisenet cameras, and maintaining any security patches in the Wisenet platform. The update process can be performed via the NVR’s setup interface.
Which cameras are compatible with the HV-ARN-810S?
The HV-ARN-810S is designed for use with Hanwha Vision Wisenet IP cameras that connect over standard Ethernet. It supports ONVIF-compliant cameras as well, though full feature integration is best achieved with cameras within the Wisenet ecosystem. Confirm camera compatibility and PoE draw per unit before finalising a camera selection, particularly if cameras with high-power features are planned. The HV-ARN-810S is available through Security Wholesalers alongside a broad range of compatible Wisenet cameras.
Can the HV-ARN-810S output to a 4K television or monitor?
Yes. The NVR includes a 4K HDMI output, allowing connection to any 4K-capable HDMI display. This makes the local live view and playback interface sharp and detailed when viewed on a compatible monitor or television, which is useful for reception desks, control rooms, or back-of-house monitoring setups where an on-site display is part of the installation.
