Product SKU: HV-ARN-410S
Product Overview
Built for small to medium installations where simplicity and image quality both matter, the HV-ARN-410S is a 4-channel AI NVR from Hanwha Vision’s Wisenet A Series that combines an integrated 4-port PoE switch with support for cameras up to 8MP resolution. With H.265 compression reducing storage and bandwidth demands, a single HDD bay accepting drives up to 6TB, and a 4K HDMI output for sharp on-site monitoring, this recorder suits retail stores, small offices, residential properties, and light commercial sites running up to 4 IP cameras. Featuring P2P connectivity via QR code, remote viewing is accessible through the Wisenet Mobile app on iOS and Android as well as Wisenet Viewer CMS on PC and Mac. Dual track recording is also supported, allowing simultaneous high and low resolution streams for flexible local and remote playback. The improved installation wizard and plug-and-play PoE setup mean the system can be operational without specialist configuration knowledge.
Key Capabilities
4-Port Integrated PoE Switch
Power and data are delivered to each camera over a single Ethernet cable, removing the need for a separate PoE switch or additional power adapters at each camera location. This significantly reduces installation time and hardware cost in 4-camera deployments.
Up to 8MP Camera Support
Each of the 4 channels supports cameras up to 8MP resolution, giving installers the flexibility to run high-resolution IP cameras across the full system without a resolution bottleneck at the recorder level.
H.265 Compression
H.265 (HEVC) encoding reduces file sizes compared to H.264 at equivalent quality levels, allowing the same 6TB drive to store significantly more footage. This directly extends on-site retention without requiring a larger or more expensive storage drive.
P2P Remote Access via QR Code
Scanning the QR code links the recorder to the Wisenet Mobile app or Wisenet Viewer CMS without requiring manual port forwarding. This lowers the technical barrier for remote access setup and speeds up commissioning for both installers and end users.
4K HDMI Output and Dual Track Recording
The 4K HDMI output supports direct connection to a 4K monitor for detailed on-screen review. Dual track recording captures high and low resolution streams simultaneously, allowing smooth remote viewing without sacrificing local playback quality.
Best For
- Small Retail and Office Installs: The 4-channel limit and plug-and-play PoE setup suit sites with a defined camera count of up to 4, where a straightforward installation and clean cabling result matter.
- Residential Multi-Camera Systems: Homeowners and property managers needing an 8MP-capable recorder with easy smartphone access via Wisenet Mobile and no complex network configuration.
- Installers Commissioning Compact Sites Quickly: The guided installation wizard and QR-based P2P setup reduce on-site configuration time, which is valuable across multiple small job deployments.
- Sites Needing Extended Local Retention: H.265 compression combined with a drive up to 6TB allows longer footage retention within a single-HDD system, making this practical for sites that review recordings days after an event.
Why Choose the HV-ARN-410S
The HV-ARN-410S stands apart from basic 4-channel recorders by combining an integrated 4-port PoE switch with true 8MP camera support and 4K HDMI output in a single compact unit. A cheaper NVR without built-in PoE requires a separate switch and power supplies, adding both hardware cost and cable complexity. The inclusion of dual track recording means the system handles remote viewing over lower bandwidth connections without compromising the locally stored full-resolution stream. P2P connectivity via QR code removes the need for static IP addresses or manual port forwarding at the router, which reduces support calls after installation. H.265 compression further extends the usable capacity of the single 6TB HDD, giving longer retention compared to H.264-only recorders at the same storage size. Available at Security Wholesalers, the HV-ARN-410S is part of the Hanwha Wisenet A Series and is backed by a current firmware update (v5.05.12) that should be applied after installation.
Buyer Decision Tips
Channel Count is Fixed at 4: The HV-ARN-410S supports exactly 4 channels with no expansion path to additional channels on the same unit. If the site may grow beyond 4 cameras within the system’s service life, an 8-channel or 16-channel model from the Wisenet A Series should be considered at the outset. Retrofitting a larger recorder later carries additional labour and configuration cost.
Plan HDD Size Before Installation: The unit accommodates a single HDD up to 6TB. Retention duration depends on the resolution and frame rate of connected cameras. Running 4 cameras at 8MP continuously will fill storage faster than lower-resolution configurations. Calculate the required retention period before selecting the drive size, and apply firmware v5.05.12 after the drive is installed.
Key Features & Technical Specifications
| Model |
HV-ARN-410S |
| Series |
Hanwha Wisenet A Series |
| Video Channels |
4 |
| Maximum Camera Resolution |
8MP per channel |
| Video Compression |
H.265, H.264, MJPEG |
| Maximum Recording Bandwidth |
40Mbps |
| PoE Ports |
4 (integrated PoE switch) |
| Storage |
1 x HDD bay, up to 6TB |
| Video Output |
4K HDMI |
| Recording Mode |
Dual track recording |
| Remote Access |
P2P (QR code), Wisenet Mobile (iOS/Android), Wisenet Viewer CMS (PC/Mac) |
| Current Firmware |
v5.05.12 (available update) |
| Installation |
Guided installation wizard included |
| Brand |
Hanwha Vision |
Ideal Use Cases
Small Retail Stores
A shop with up to 4 camera positions can be fully covered using the integrated PoE ports, removing the need for a separate switch. The 4K HDMI output connects directly to an on-site monitor for staff use at the counter or back office.
Residential Properties
Home installations benefit from the QR-based P2P setup, which allows the homeowner to connect their smartphone via Wisenet Mobile without requiring advanced networking knowledge or router reconfiguration.
Small Office Environments
Offices with a reception, car park entry, server room, and rear exit can cover all 4 critical points using a single recorder. H.265 compression keeps storage consumption manageable on the single 6TB drive.
Installer Rapid Deployment
The guided installation wizard and plug-and-play PoE reduce the time needed to bring a 4-camera system online. This is particularly useful for trade installers managing multiple small commercial or residential jobs.
Sites Requiring Dual Stream Viewing
Dual track recording allows a full-resolution stream to be stored locally while a lower-bandwidth stream is delivered for remote monitoring via Wisenet Mobile or Wisenet Viewer, reducing mobile data consumption during live viewing.
Choosing the Right Model
- Choose this model if: The site requires exactly 4 cameras, benefits from plug-and-play PoE without a separate switch, and needs 8MP-capable recording with straightforward remote access via smartphone.
- Choose a different model if: The site has or may grow beyond 4 camera positions. An 8-channel or 16-channel NVR should be selected at installation time to avoid replacing the recorder during a future expansion.
- Choose a different model if: The installation requires multiple HDD bays or RAID storage for extended continuous retention. The HV-ARN-410S supports only a single HDD up to 6TB, which may not be sufficient for high-resolution continuous recording across all 4 channels over longer retention windows.
FAQs
- How many cameras can the HV-ARN-410S support?
The HV-ARN-410S supports exactly 4 IP cameras across its 4 channels. Each channel is capable of accepting cameras up to 8MP resolution. The 4 integrated PoE ports mean each camera can be connected directly to the recorder over a single Ethernet cable without a separate switch.
- What is the maximum HDD size this NVR supports?
The recorder has a single HDD bay and supports drives up to 6TB in capacity. A hard drive is not included and must be sourced separately. The actual retention period will depend on the resolution, frame rate, and number of cameras connected, as well as whether H.265 or H.264 compression is used.
- Does the HV-ARN-410S require port forwarding for remote access?
No. The P2P service built into the HV-ARN-410S allows remote access via QR code scan without manual port forwarding at the router. The Wisenet Mobile app on iOS or Android and Wisenet Viewer CMS on PC or Mac all support this P2P connection method.
- What does dual track recording mean on this NVR?
Dual track recording means the HV-ARN-410S simultaneously records two separate video streams from each camera: a high-resolution stream for local storage and review, and a lower-resolution stream optimised for remote viewing over narrower network connections. This avoids excessive mobile data consumption when checking cameras remotely without reducing the quality of locally stored footage.
- Is there a firmware update available for the HV-ARN-410S?
Yes. Firmware version v5.05.12 is available and should be applied after installation. Keeping the firmware current ensures access to the latest performance improvements and compatibility with Hanwha Vision’s camera ecosystem. The update process can be completed through the recorder’s interface. Security Wholesalers recommends applying this update before commissioning the system.
- Can the HV-ARN-410S connect to a 4K monitor?
Yes. The recorder includes a 4K HDMI output, allowing it to be connected directly to a 4K-compatible display for on-site monitoring and playback. This is useful in retail or office environments where a large monitor is used for live viewing at a desk or front counter.
- Is the HV-ARN-410S NDAA compliant?
Hanwha Vision markets its Wisenet A Series products as NDAA compliant. For site-specific compliance verification, installers working on government or sensitive commercial projects should confirm compliance documentation with their supplier prior to deployment.
