DAS S3296A 116-8000 Siren Strobe Horn with Tamper 8 Ohm‍‌​​‌​​‌​​​​‌​‌‌​​​‍

Product SKU: 116-8000

Product Overview

The DAS S3296A 116-8000 Siren Strobe Horn with Tamper 8 Ohm is an external alarm siren box designed for compatible hardwired security systems. It combines a plastic external siren housing, warning light strobe, passive drive horn speaker and tamper reed switch in one alarm accessory, making it suitable for residential, retail, office, workshop, warehouse and light commercial alarm installations. The strobe operates from 12VDC with an 85–95 flashes per minute rate, while the horn speaker uses an 8Ω ±15% coil impedance with 15W maximum input power. With 12–15VDC operating voltage, white housing and compact 19.8 x 15.4 x 11cm dimensions, the S3296A is a practical choice for installers needing an external siren/strobe horn box with tamper monitoring for compatible alarm panels.

Key Capabilities

Best For

• Home Alarm Systems: Suitable for compatible residential alarm installations needing an external siren box with strobe, horn and tamper.
• Small Business Security: A practical option for shops, offices, clinics, workshops and small warehouses using hardwired alarm systems.
• Alarm Replacement Jobs: Useful when replacing an older external siren box with a compatible strobe, horn and tamper unit.
• Visible Alarm Presence: The external white siren box helps provide a clear visual indication that an alarm system is installed.
• Installer Projects: Suitable for technicians needing a hardwired siren/strobe horn assembly with tamper reed switch for compatible panels.

Why Choose the S3296A

Choose the DAS S3296A when the installation requires an external alarm siren box with strobe, horn speaker and tamper monitoring in one unit. Its 8Ω passive horn speaker is suited to compatible siren driver outputs, while the integrated strobe provides a separate visual alarm warning for external identification. The tamper reed switch adds an important security layer for outdoor alarm hardware, helping detect interference when wired into the alarm panel. This model, supplied by Security Wholesalers, is a practical choice for residential and light commercial hardwired alarm systems where a traditional external siren box style is preferred.

Buyer Decision Tips

Key Features & Technical Specifications

Ideal Use Cases

Choosing the Right Model

• Choose this model if: You need a white external siren box with 12VDC strobe, 8Ω passive horn speaker and tamper reed switch.
• Choose a self-contained siren/strobe if: The alarm panel does not provide a compatible siren driver output for an 8Ω passive horn speaker.
• Check before installation: Confirm panel output compatibility, strobe power wiring, horn driver requirements, tamper zone wiring, mounting location and cable route.

FAQs

1. What is the DAS S3296A used for?
   The DAS S3296A is used as an external siren box with strobe, horn speaker and tamper for compatible hardwired security systems. It provides a visible alarm box, visual strobe indication and horn speaker output when connected to a suitable alarm panel and siren driver circuit.
2. Is the S3296A a self-contained powered siren?
   The S3296A includes a passive drive horn speaker with 8Ω ±15% impedance and 15W maximum input power. This means the alarm system must provide a compatible siren driver output. It should not be assumed to operate like a self-contained siren without confirming panel compatibility.
3. What voltage does the strobe require?
   The warning light strobe is rated at 12VDC and the overall unit is listed for 12–15VDC operation. The strobe wiring uses red for power positive and black for power negative, and the installer should confirm the panel output can support the required current draw.
4. What is the strobe flash rate?
   The strobe flash frequency is listed as 85–95 flashes per minute. This provides visual alarm indication when the alarm system activates the strobe output, helping occupants, neighbours or responders identify that the external alarm device is operating.
5. Does the S3296A include tamper protection?
   Yes. The S3296A includes a tamper reed switch rated up to 100VDC / VAC switching voltage and 0.5A switching current. The tamper connection is non-polarised and should be wired into the alarm panel according to the site’s tamper monitoring requirements.
6. Where should this siren box be installed?
   The S3296A is typically installed on an external wall where the siren box and strobe can be noticed from outside the premises. The installer should consider cable access, wall strength, tamper operation, weather exposure, visibility, service access and local alarm installation requirements.
7. What is the housing size and colour?
   The S3296A uses a white plastic housing with dimensions listed as 19.8 x 15.4 x 11cm ±0.5mm. Its traditional external siren box appearance makes it suitable for alarm replacement jobs and new installations where a visible white siren/strobe housing is preferred.
8. What should I check before buying the S3296A?
   Before buying the S3296A, confirm your alarm panel supports the required 12–15VDC strobe wiring, 8Ω passive horn speaker output and tamper switch connection. This model is available through Security Wholesalers for compatible hardwired alarm installations needing an external siren box with strobe, horn and tamper.
