Dahua TIOC Advanced 2.0 DH-IPC-HFW3849T1P-AS-PV-0280B-S3 8MP AI Active Deterrence Full color Starlight IP Bullet Fixed 2.8mm
$359.00
FREE DELIVERYWARRANTY GUARANTEED
✔ Dedicated 5★ Customer Care Team ✔ Fast & Responsive Tech Support
Dahua TIOC 2.0 | 8MP Full-Colour AI Bullet Camera | 2.8mm Fixed Lens | Active Deterrence | IP67
The Dahua TIOC 2.0 IPC-HFW3849T1-AS-PV-S3 delivers 8MP full-colour imaging in a compact AI bullet camera designed for residential and commercial security applications. Featuring a 2.8mm fixed lens, hybrid IR and warm white LEDs provide full-colour illumination up to 30 metres, maintaining vivid detail in complete darkness. Equipped with active deterrence, the camera combines red and blue strobe lights with a built-in siren to warn and deter intruders in real time. It also includes SMD 3.0 for accurate human and vehicle classification, a built-in microphone and speaker for two-way audio, and AI H.265+ compression with local MicroSD storage up to 256GB.
Key Features
8MP Ultra HD Sensor: 1/2.8″ CMOS delivers 3840×2160 resolution at 30fps, including in challenging low-light conditions.
Full-Colour Night Vision: Hybrid IR and warm white LEDs provide up to 30m full-colour illumination in complete darkness.
Active Deterrence: Red and blue strobe lights combined with a built-in siren actively warn and deter intruders in real time.
Two-Way Audio: Built-in microphone and speaker enable live voice communication and remote audio monitoring.
Smart Motion Detection Plus: SMD 3.0 accurately classifies human and vehicle targets to significantly reduce false alarms.
AI H.265+ Compression: Reduces bandwidth and storage requirements while supporting local MicroSD recording up to 256GB.
Combining active deterrence with full-colour 24/7 night imaging, the Dahua TiOC 2.0 IPC-HFW3849T1-AS-PV-S3 is an 8MP IP bullet camera built for perimeter and outdoor installations where passive recording alone is not enough. The 1/2.8″ CMOS sensor delivers 3840×2160 resolution at 30fps, while dual illumination – warm light LEDs and IR – provides full-colour footage up to 30 metres in complete darkness, capturing clothing colours, facial detail, and vehicle characteristics that greyscale IR cameras cannot. The fixed 2.8mm lens produces an approximately 102° horizontal field of view, suited to entry points, driveways, shopfronts, and construction site perimeters. When SMD 3.0 detects a confirmed human or vehicle target, the camera responds with red and blue strobe warning lights and a built-in siren, turning detection into an immediate, visible deterrent. Two-way audio via the built-in microphone and speaker extends that response capability remotely. IP67-rated housing ensures suitability for exposed Australian outdoor environments.
Key Capabilities
8MP Full-Colour 24/7 Imaging
The 1/2.8″ CMOS sensor captures 3840×2160 at 30fps with a minimum illumination of 0.005 Lux. Warm light LEDs produce full-colour footage around the clock, providing the detail needed to identify individuals and vehicles even in zero ambient light conditions.
Dual Illumination with Smart Switching
IR and warm white LEDs operate together or independently, with the camera switching automatically based on scene conditions. Fixed illumination modes are also available, allowing installers to match the lighting approach to site requirements without ongoing manual adjustment.
Active Deterrence: Strobe and Siren
Red and blue strobe lights combined with a built-in siren activate upon confirmed target detection, creating an immediate visible and audible warning on site. This response occurs without requiring an operator to be present or monitoring, making it effective for unmanned locations outside business hours.
SMD 3.0 AI Target Classification
Smart Motion Detection Plus accurately separates human and vehicle targets from environmental noise such as foliage movement, animals, and weather. This reduces nuisance alerts significantly and ensures that deterrence actions and operator notifications are triggered only by genuine events.
Two-Way Audio
The built-in microphone and speaker support real-time voice communication in both directions. Property owners or security personnel can speak directly to individuals on site via the Dahua mobile app, enabling remote verbal warnings or visitor management without a physical presence.
Flexible Local Storage and Compression
AI H.265+ and H.264+ compression reduces bitrate and storage requirements during low-activity periods without meaningful quality loss. MicroSD support up to 256GB enables standalone recording, useful for sites with limited or no NVR infrastructure.
Best For
Construction and Industrial Perimeters: After-hours monitoring with automatic strobe and siren deterrence enables remote response to unauthorised access without requiring overnight security staff on site.
Retail Shopfronts and Commercial Entrances: Full-colour 8MP imaging captures usable detail of faces, clothing, and vehicles at close to medium range, while active deterrence manages after-hours loitering and access attempts.
Warehouse and Storage Facility Perimeters: SMD 3.0 keeps false alarm rates low in busy outdoor environments, ensuring that deterrence actions and mobile alerts occur only for genuine human or vehicle detections.
Residential Driveways and Gate Entries: The 102° field of view covers wide entry points, and two-way audio allows homeowners to communicate with or warn individuals at the property boundary directly from a smartphone.
Sites with No Monitoring Centre: One-tap arming via the Dahua mobile app and autonomous deterrence triggering make this camera functional as a standalone active security layer without requiring 24/7 monitoring staff.
Why Choose the IPC-HFW3849T1-AS-PV-S3
Where most bullet cameras capture an incident after it begins, the IPC-HFW3849T1-AS-PV-S3 is engineered to interrupt it before it escalates. The TiOC 2.0 platform brings together three capabilities that are typically found only in separate systems: full-colour 8MP imaging via a 1/2.8″ CMOS sensor, SMD 3.0 AI classification to keep alerts meaningful, and active deterrence through red and blue strobe lights and a built-in siren. Unlike standard IR bullet cameras that produce greyscale night footage, this model delivers colour video at 0.005 Lux, meaning individuals remain identifiable in low light. The fixed 2.8mm lens provides a wide 102° horizontal field of view suited to entrances and open approaches. MicroSD support up to 256GB and AI H.265+ compression reduce ongoing infrastructure costs. Available through Security Wholesalers as part of the Dahua TiOC 2.0 range, this model suits any site where deterrence and image quality carry equal weight.
Buyer Decision Tips
Buyer Tip: The 2.8mm fixed lens on this model provides a wide 102° horizontal field of view, making it most effective at close to medium range for entries, gates, and building faces. If your target area is a narrow corridor, long driveway requiring tighter framing, or a scene demanding adjustable focal length after installation, a motorised varifocal bullet in the same TiOC 2.0 family would give you more installation flexibility. Confirm your scene width and mounting distance before selecting focal length.
Key Features & Technical Specifications
Image Sensor
1/2.8″ Progressive Scan CMOS
Resolution
3840 x 2160 (8MP / 4K)
Frame Rate
Up to 30fps at 3840 x 2160
Minimum Illumination
0.005 Lux @ F1.0 (Colour)
Lens Type
Fixed
Focal Length
2.8mm
Horizontal Field of View
~102°
Vertical Field of View
~54°
DORI Distance – Detect
88.0m
DORI Distance – Recognise
35.2m
Illumination Range
Up to 30m (IR and warm light LEDs)
Day/Night Mode
Full-colour with smart illumination switching
Shutter Speed
1/3s – 1/100,000s
Video Compression
H.265, H.264, Smart Codec AI H.265+, AI H.264+
Audio
1 in / 1 out; built-in microphone and speaker; two-way audio
Active Deterrence
Red and blue strobe warning lights; built-in siren/speaker
After-hours detection via SMD 3.0 triggers automatic strobe and siren deterrence without requiring staff on site. Mobile app alerts with one-tap arming allow site managers to monitor and respond from any location.
Retail Shopfronts
Full-colour 8MP footage captures usable facial and clothing detail at entrance points. The strobe and speaker system provides an immediate visible response to loitering or after-hours break-in attempts without relying on third-party monitoring.
Residential Driveways and Entries
The 102° field of view covers gates and driveway approaches, while two-way audio lets homeowners speak with or warn individuals at the boundary directly from a smartphone, day or night.
Warehouse and Storage Perimeters
SMD 3.0 filters out false triggers from vehicle movement and environmental interference, ensuring that deterrence actions and notifications correspond to confirmed human or vehicle intrusions rather than background activity.
Car Parks and Open Approaches
The DORI detect range of 88 metres and a recognise range of 35.2 metres supports monitoring of open areas and vehicle approaches, with full-colour night imaging aiding identification at distances where greyscale IR cameras produce limited usable detail.
School Grounds and Community Facilities
Autonomous deterrence operation after hours protects community assets without ongoing monitoring costs. MicroSD recording up to 256GB with AI H.265+ compression keeps storage infrastructure minimal for budget-sensitive sites.
Choosing the Right Model
Choose this model if: You need 8MP full-colour 24/7 imaging with active deterrence (red/blue strobe, built-in siren, two-way audio) and SMD 3.0 AI classification in a bullet camera housing with a wide 2.8mm fixed lens for entrances, driveways, shopfronts, or perimeter walls.
Choose a different model if: You require a longer focal length or motorised varifocal lens to cover a narrow scene or adjust framing after installation, need a turret or dome form factor for ceiling or soffit mounting, or only need passive recording without active deterrence features.
FAQs
What does TiOC 2.0 mean and how does it affect how this camera behaves? TiOC stands for Three-in-One Camera, referring to the integration of full-colour imaging, dual illumination, and active deterrence in a single unit. In the IPC-HFW3849T1-AS-PV-S3, the TiOC 2.0 platform means these three functions are coordinated: when SMD 3.0 classifies a human or vehicle target, the camera can simultaneously trigger the strobe lights, sound the siren, and push a notification to the mobile app without requiring a separate controller or NVR action.
Does the active deterrence trigger automatically, or does someone need to activate it manually? Both options are available. The camera can be configured to trigger the red and blue strobe lights and built-in siren automatically upon a confirmed SMD 3.0 human or vehicle detection. It also supports manual one-tap arming and deterrence activation via the Dahua mobile app, giving operators the choice of autonomous or operator-initiated response depending on the site’s requirements.
What is the difference between the IR and warm light illumination on this camera, and when does each activate? IR LEDs produce infrared light invisible to the human eye, used for discreet night monitoring. Warm light LEDs produce visible white light that illuminates the scene in colour. In the default smart switching mode, the camera uses IR for ambient monitoring and automatically activates warm light when a target is detected, producing colour footage at the moment it matters most. Both can also be set to operate continuously or independently via configuration.
Can this camera record independently without an NVR? Yes. The IPC-HFW3849T1-AS-PV-S3 supports MicroSD cards up to 256GB for local recording, allowing it to operate as a standalone unit without a connected NVR. For centralised management, extended storage, and full access to TiOC 2.0 event-based recording features, pairing with a compatible Dahua NVR is recommended.
Is the 2.8mm fixed lens appropriate for a long driveway or narrow approach? The 2.8mm lens provides an approximately 102° horizontal field of view, which is wide and well suited to covering broad entry points, building facades, and open approaches at close to medium range. For a narrow or long driveway where you need tighter framing at distance, a longer focal length lens would be more appropriate. Confirm mounting distance and scene width before specifying this model for corridor-style coverage.
What compression formats does the IPC-HFW3849T1-AS-PV-S3 support, and how do they affect storage? The camera supports H.265, H.264, Smart Codec AI H.265+, and AI H.264+. The AI smart codec options reduce bitrate dynamically during periods of low scene activity, lowering storage consumption and network bandwidth requirements without impacting image quality during active periods. This is particularly useful for sites using MicroSD local storage or connections with limited upload speeds.
What third-party systems is this camera compatible with? The IPC-HFW3849T1-AS-PV-S3 supports ONVIF and RTSP protocols, enabling basic integration with many third-party video management systems. For access to the full TiOC 2.0 feature set including coordinated active deterrence triggers, event-based recording, and SMD 3.0 alert management, pairing with a Dahua WizSense NVR is recommended. Contact Security Wholesalers for guidance on compatible recorder models and system configurations.
What ingress protection rating does this camera carry, and is it suitable for exposed outdoor Australian conditions? The camera is rated IP67, meaning it is fully dustproof and protected against temporary water immersion. This makes it suitable for exposed outdoor mounting in locations subject to rain, humidity, and dust, including coastal and high-rainfall environments. The IP67 rating does not cover sustained submersion, but for standard outdoor wall and eave mounting it provides a sufficient protection level for Australian conditions.
All Dahua IP cameras and recording devices (NVRs/DVRs) are covered by a
3-year back-to-base manufacturer warranty.
Note: Disk drives are limited to a 3-year warranty.
Our warranty is limited to the replacement of faulty items or parts
and does not include damage caused by incorrect fitting of parts or accessories.
(a) Australian Consumer Law (ACL)
Certain legislation, including the Australian Consumer Law (ACL) in the Competition and Consumer Act 2010 (Cth), and similar consumer protection
laws and regulations may confer you with rights, warranties, guarantees, and remedies
relating to the provision of goods or services to you by us via the Site which cannot
be excluded, restricted, or modified. Our liability is governed solely by the ACL and
these Terms.
(b) Goods
If you are a consumer as defined in the ACL, the following notice applies to you:
“Our goods come with warranties and guarantees that cannot be excluded under the
Australian Consumer Law (Consumer Guarantees). You are entitled to a replacement or
a refund for a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major
failure.”
(c) Our Warranties
To the extent permitted by law, we exclude all express and implied warranties,
and all material and work is provided to you without warranties of any kind,
either express or implied. We expressly disclaim all warranties including but
not limited to implied warranties of merchantability and fitness for a particular
purpose.
(d) Manufacturer Warranties
Certain products, including particular models of IP security cameras and DVR/NVR
equipment, may come with a manufacturer’s warranty. The manufacturer’s warranty is
in addition to but may overlap with any rights and remedies you may have under
applicable law, including any Consumer Guarantees. If you are not considered a
“consumer” within the meaning of the ACL, the manufacturer’s warranty may be your
sole remedy. Many manufacturers’ warranties do not apply in a business or commercial
setting. Please contact the manufacturer if you would like to make a claim under
the manufacturer’s warranty.
(e) Repair, Replacement, or a Refund
If you wish to seek repair, replacement, or a refund for a product, please
contact us and we will explain the requirements to you. This may include you
providing evidence of the faulty product to us.
(f) Refund
You are not entitled to a refund for change of mind. If you are entitled to a
refund, we will only provide it once evidence of the faulty product is received
by us, or once we have received the product at our warehouse and inspected it
to assess whether it is eligible for a refund under these Terms. Any refund we
make will be by the same payment method used to purchase the product.
(g) Installed Products
Subject to this clause, we will not accept for return any product that has been
used, connected, installed, attempted to be connected or installed, or if your
product is custom-made or is a special buy product.
(h) Packaging
You must adequately package any product you are returning for our collection
to ensure that it is not damaged during return delivery to our warehouse. You
are also responsible for arranging the return delivery and the costs involved.
(i) Duty of Care
You have a duty of care for the product while it is in your possession. If
you damage products and then subsequently return them, you may be liable to pay
to repair the product to its original condition. In these circumstances, where
a repair is not economically viable, no refund will be made.
Everything you need to choose the right Dahua TiOC camera for your needs.
1. What is Dahua TiOC?
Dahua’s TiOC (Three-in-One Camera) series combines full-colour imaging, active deterrence, and advanced AI analytics. This all-in-one solution delivers 24/7 colour monitoring, proactive security through strobe lights and sirens, and intelligent detection of humans and vehicles, significantly reducing false alarms.
2. Key Benefits of Dahua TiOC
Full-Colour Imaging: Captures vivid colour footage around the clock, even in low-light environments without relying solely on infrared.
Active Deterrence: Built-in strobe lights and sirens help deter intruders in real time.
AI-Powered Analytics: Detects and differentiates between people and vehicles, improving detection accuracy and reducing false alerts.
Integrated Design: Combines multiple capabilities into a single camera, making installation and monitoring more efficient.
3. Recommended Use Cases
Residential driveways and front doors
Retail shops and entryways
Warehouse loading docks
Commercial office corridors
Public parks, carparks and shared spaces
4. Types of Dahua TiOC Cameras
Turret: Compact and flexible; ideal for both indoor and outdoor settings.
Dome: Vandal-resistant and discreet; great for public-facing areas.
Bullet: Offers extended range for perimeter and driveway surveillance.
PTZ: Remote-controlled panning, tilting, and zooming for wide-area coverage.
Mini Cameras: Suitable for discreet indoor coverage in narrow spaces.
Also available: AcuSense, Live Guard, 4K resolution, dual-lens panoramic, and more.
5. Choose by Resolution
2MP (1080p): Suitable for basic surveillance and general observation.
4MP (2K): Enhanced clarity ideal for recognising faces and vehicles.
6MP: Balanced resolution for larger areas without excessive bandwidth usage.
8MP (4K): High-detail imaging for premium security coverage.
6. Choose by Smart Features
Built-in Microphone: Records audio alongside video for better context.
Built-in Speaker: Enables two-way communication and verbal warnings.
Strobe Light + Siren: Alerts intruders with both visual and audio deterrents.
Smart Motion Detection: Detects people and vehicles intelligently using AI.
AI / Deep Learning: Reduces false alarms and improves detection accuracy using advanced analytics.
7. Choosing by Environment
Location
Recommended Camera Type
Reason
Front Door
Turret with Mic
Compact with audio for clear visitor recording
Driveway
Bullet 4MP or 8MP
Long-range view for vehicles and movement
Retail Store
Dome 2MP or 4MP
Discreet and vandal-resistant in busy areas
Warehouse Loading Dock
Bullet with AI
Wide coverage with accurate motion detection
Office Corridor
Mini or Turret
Ideal for hallway visibility and minimal intrusion
8. Installation Tips
Use PoE (Power over Ethernet) to simplify wiring and minimise setup time.
Position cameras away from reflective surfaces to avoid glare or false triggers.
Mount at eye level or slightly above for optimal angle and image quality.
Adjust the camera’s field of view to ensure full coverage of entry points.
Engage a licensed installer to ensure proper setup and compliance with Australian regulations.
