Product SKU: DHI-NVR5832-AI/ANZ
Product Overview
The Dahua DHI-NVR5832-AI/ANZ is a 32-channel, 2U WizSense network video recorder designed for commercial sites that need substantial recording storage, structured network connectivity and AI-assisted event review. Eight SATA bays provide more storage flexibility than common two-bay or four-bay recorders, while RAID 0, 1, 5, 6 and 10 support different capacity, performance and redundancy priorities. This model has no built-in PoE ports, so cameras connect through suitable external PoE switches or other supported power arrangements. The recorder accepts compatible IP cameras up to 32MP and provides up to 384Mbps incoming, recording and outgoing bandwidth when recorder-side AI is disabled. Face analysis, perimeter protection and SMD Plus support focused investigations, while dual Gigabit network ports, 4K display outputs, eSATA and extensive alarm connections suit professional warehouses, retail sites, schools, healthcare facilities and multi-building properties.
Key Capabilities
Eight-Bay Recording Storage
Eight internal SATA bays support compatible surveillance hard drives up to 16TB per disk under the stated conditions. This gives larger camera systems considerably more room for retention planning than smaller desktop recorders with only two or four drive bays.
RAID Storage Protection
RAID 0, 1, 5, 6 and 10 allow storage to be configured around capacity, performance or disk-failure resilience. This is particularly useful for commercial sites where recording availability matters more than maximising raw drive capacity alone.
Thirty-Two Camera Channels
The recorder supports up to 32 IP camera channels, providing capacity for larger surveillance layouts across several buildings, floors or operational zones. Cameras connect through the site network because the recorder does not include an integrated PoE camera switch.
Recorder-Side WizSense Analytics
Face detection, face recognition, perimeter protection and SMD Plus can be processed by the recorder within the confirmed channel limits. Human and motor-vehicle filtering helps operators focus on relevant activity rather than reviewing every conventional motion alarm.
Dual Gigabit Network Interfaces
Two Gigabit Ethernet ports support multi-address mode, load balancing, fault tolerance and other network-binding configurations. This provides more design flexibility where camera traffic, remote clients and network resilience require separate planning.
Multi-Monitor and Alarm Integration
Two HDMI and two VGA outputs support separate local camera layouts and 4K display. Sixteen alarm inputs, eight alarm outputs, audio connections, serial interfaces and eSATA provide broader integration options than a basic desktop NVR.
Best For
- Warehouses and Distribution Centres: Supports loading docks, vehicle entrances, internal aisles, stock areas and external boundaries through one recorder.
- Multi-Building Properties: External PoE switches can be distributed between buildings while all cameras record to a central storage platform.
- Retail and Commercial Sites: Provides capacity for shopfronts, sales floors, offices, storerooms, loading areas and car parks.
- Schools and Healthcare Facilities: Human and vehicle filtering can assist authorised event review across entrances, paths and shared areas.
- Storage-Focused CCTV Systems: Eight drive bays and RAID support suit installations where retention and disk-failure resilience are major considerations.
Why Choose the DHI-NVR5832-AI/ANZ
The DHI-NVR5832-AI/ANZ is better suited to storage-intensive commercial systems than a smaller four-bay recorder. Its eight SATA bays and multiple RAID options allow buyers to balance usable capacity with disk-failure protection, while dual Gigabit network ports support more structured camera and client traffic management. The non-PoE design also suits distributed sites where camera switches are positioned closer to separate buildings or floors instead of routing every cable back to the recorder. Recorder-side SMD Plus, perimeter protection and face functions provide practical event filtering, while extensive alarm and display connections support control-room use. Available through Security Wholesalers, this model is a strong choice when storage capacity, network flexibility and system integration are more important than a compact chassis.
Buyer Decision Tips
RAID Planning Tip: RAID improves storage resilience but reduces usable capacity. Select the RAID level, number of drives and drive capacities according to the required retention period, tolerance for disk failure and restoration expectations.
PoE Planning Tip: This recorder does not power cameras. Select suitable PoE switches or injectors separately and confirm their combined power budget, uplink bandwidth, network location and redundancy requirements before installation.
Key Features & Technical Specifications
| Recorder Type |
32-channel, 2U, eight-HDD WizSense network video recorder. |
| Channel Count |
Supports 32 IP camera channels. |
| Built-In PoE |
No built-in PoE ports; external camera power and network switching are required. |
| Camera Resolution |
Supports compatible IP cameras up to 32MP. |
| Network Bandwidth |
AI disabled: 384Mbps incoming, recording and outgoing; AI enabled: 200Mbps for each. |
| Decoding Capacity |
AI disabled: up to 16 × 4MP or 32 × 1080p at 30fps; AI enabled: up to 12 × 4MP or 24 × 1080p at 30fps. |
| Recorder-Side AI |
Face detection, face recognition, perimeter protection and SMD Plus. |
| AI Channel Capacity |
2-channel face detection and recognition, 4-channel perimeter protection and 8-channel SMD Plus. |
| Camera-Side Analytics |
Supports compatible face functions, metadata, perimeter protection, SMD Plus, ANPR, stereo analysis, heat maps and people counting. |
| Video Compression |
Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG. |
| Video Outputs |
2 HDMI and 2 VGA outputs with separate HDMI video-source support and 4K display capability. |
| Display Layouts |
Main screen supports up to 36 windows; secondary screen supports up to 16 windows. |
| Playback |
Up to 16-channel simultaneous playback with instant, general, event, tag and smart playback modes. |
| HDD Bays |
8 SATA bays supporting compatible hard drives up to 16TB per bay, subject to operating temperature. |
| RAID Support |
RAID 0, RAID 1, RAID 5, RAID 6 and RAID 10. |
| External Storage |
1 eSATA interface and disk-group support. |
| Network Interfaces |
2 × 10/100/1000Mbps Gigabit Ethernet ports. |
| Audio and Alarm Interfaces |
1 RCA audio input, 2 RCA audio outputs, 16 alarm inputs and 8 alarm outputs. |
| Additional Interfaces |
1 RS-232, 2 RS-485 and 4 USB ports, including 2 front USB 2.0 and 2 rear USB 3.0 ports. |
| Power, Size and Environment |
100–240V AC; up to 13W without HDDs; 439.9 × 457.9 × 89.0mm; 6.4kg; -10°C to +55°C. |
Ideal Use Cases
Warehouse CCTV Systems
Record loading docks, vehicle entrances, internal aisles, storage areas and perimeter cameras across a larger site.
Multi-Building Sites
Position external PoE switches closer to each building while managing all 32 camera channels through one recorder.
Retail and Shopping Sites
Centralise footage from shopfronts, sales areas, offices, storerooms, loading zones and car parks.
Schools and Healthcare Facilities
Human and vehicle filtering supports authorised review across entrances, pathways, reception areas and shared spaces.
Long-Retention Installations
Eight SATA bays, RAID and eSATA suit projects where recording capacity and disk-failure resilience are major considerations.
Choosing the Right Model
- Choose this model if: You need up to 32 IP camera channels, eight HDD bays, RAID, dual Gigabit network ports and externally managed PoE switching.
- Choose a PoE NVR if: Cameras must connect and receive power directly from the recorder without separate switches.
- Choose a four-bay recorder if: The required retention and redundancy can be achieved without the larger eight-bay chassis.
- Choose an AcuPick-capable recorder if: Rapid person or vehicle target searching is an essential system requirement.
- Plan RAID before ordering drives: Different RAID levels change usable capacity, disk-failure tolerance and the number of drives required.
FAQs
- How many cameras can connect to the DHI-NVR5832-AI/ANZ, and does it provide PoE?
The DHI-NVR5832-AI/ANZ supports 32 IP camera channels but does not include built-in PoE camera ports. Cameras must receive power through suitable external PoE switches, injectors or supported local power arrangements. This design suits structured networks where switching is distributed across several cabinets, floors or buildings, but the PoE budget and uplink capacity must be selected separately from the recorder.
- What is the advantage of eight HDD bays in this Dahua NVR?
Eight SATA bays provide substantially more storage flexibility than a four-bay or two-bay recorder. Each compatible hard drive supports up to 16TB under the stated operating conditions, and the recorder supports RAID 0, 1, 5, 6 and 10. Actual retention depends on camera count, resolution, frame rate, bitrate, compression and recording schedule, so drive capacity and RAID level should be planned together.
- Does the DHI-NVR5832-AI/ANZ include hard drives?
The product information confirms eight SATA bays but does not confirm pre-installed hard drives. Buyers purchasing through Security Wholesalers should check the selected sales configuration and choose surveillance-grade storage based on the required retention period and RAID plan. Recording capacity should be calculated from camera count, resolution, frame rate, bitrate, compression and whether recording will be continuous, event-based or scheduled.
- What AI functions can the recorder perform itself?
AI by Recorder supports face detection and face recognition on up to two channels, perimeter protection on up to four channels and SMD Plus on up to eight channels. SMD Plus applies secondary filtering for people and motor vehicles to reduce less relevant alarms caused by leaves, rain and lighting changes. These functions share processing resources, so the intended combination should be planned before commissioning.
- Does the DHI-NVR5832-AI/ANZ support AcuPick?
AcuPick is not listed among the confirmed functions for the DHI-NVR5832-AI/ANZ. Its recorder-side intelligence covers face detection, face recognition, perimeter protection and SMD Plus, while compatible cameras can provide metadata, ANPR, stereo analysis, heat maps and people counting. Choose a recorder with explicitly confirmed AcuPick support when rapid person or vehicle target searching is essential to the project.
- What camera resolution and bandwidth does this NVR support?
The DHI-NVR5832-AI/ANZ accepts compatible IP cameras with resolutions up to 32MP. With recorder-side AI disabled, it provides up to 384Mbps incoming, recording and outgoing bandwidth. With AI enabled, each limit reduces to 200Mbps. The final camera mix should be planned around resolution, frame rate, bitrate, live-view layouts and playback requirements because multiple high-resolution streams can consume decoding and network capacity quickly.
- What display, playback and network options are available?
The recorder provides two HDMI outputs and two VGA outputs, supports separate HDMI video sources and offers 4K local display. Main-screen layouts extend to 36 windows, while simultaneous playback supports up to 16 channels. Two Gigabit Ethernet ports support multi-address mode, load balancing, fault tolerance and other binding modes, giving installers more flexibility for camera traffic, client access and network resilience.
- Is the DHI-NVR5832-AI/ANZ suitable for commercial CCTV systems?
Yes. The DHI-NVR5832-AI/ANZ suits warehouses, retail sites, schools, offices, healthcare facilities and multi-building properties requiring up to 32 IP camera channels, eight HDD bays and AI-assisted event review. Its RAID support, dual Gigabit ports, 384Mbps bandwidth, dual HDMI and VGA outputs, extensive alarm interfaces and eSATA connection provide more storage, network and integration flexibility than a smaller desktop recorder.
Additional Information
Dahua DHI-NVR5832-AIANZ Datasheet
