Product SKU: ITC413-PW4D-IZ1
Product Overview
Built for controlled vehicle entry and exit points, the Dahua ITC413-PW4D-IZ1 is a purpose-designed 4MP ANPR camera that combines deep-learning license plate recognition with direct barrier and gate control integration. Featuring a motorized 2.7-12mm vari-focal lens, the camera can be precisely aimed and zoomed to suit the capture zone at a specific lane without physical remounting. Equipped with a 1/1.8-inch CMOS sensor, 140 dB wide dynamic range, and 850 nm IR illumination optimised for plate capture within a 10 m range, it maintains read accuracy across changing light conditions from midday sun through to complete darkness. It supports allowlists and blocklists of up to 110,000 entries each, with relay outputs to trigger barriers, boom gates, or sirens automatically. With IP67 weather sealing and IK10 impact resistance, the ITC413-PW4D-IZ1 is built to remain operational in exposed outdoor installations at gated entrances, parking facilities, and logistics sites.
Key Capabilities
Deep-Learning ANPR Engine
The onboard deep-learning algorithm reads license plate numbers and also identifies vehicle brand, colour, and type. Capture accuracy reaches 99% and recognition accuracy reaches 96-98% for standard reflective plates, covering vehicles travelling at speeds up to 80 km/h within a 3-8 m capture zone.
Motorized 2.7-12mm Vari-focal Lens
The motorized varifocal lens allows installers to dial in the exact framing and focal length required for the specific capture distance at each lane. This removes the need to physically reposition the camera head after mounting, keeping setup practical at entry and exit points where precise plate framing is critical.
140 dB Wide Dynamic Range
A 140 dB WDR rating with Scene Self-Adaptation (SSA) exposure control prevents plate washout when vehicles pull in from bright sunlight into a shaded entry lane. This is the most common imaging failure point for ANPR cameras installed at parking barriers, making WDR performance a practical requirement rather than a marketing spec.
Relay Outputs and Wiegand Interface
Two relay outputs allow the ITC413-PW4D-IZ1 to directly trigger barriers, electronic locks, lights, or sirens based on plate recognition results. A Wiegand interface and 2 RS-485 channels support integration with access control panels, intercoms, and third-party gate controllers, enabling automated vehicle access without a separate controller.
Large Allowlist and Blocklist Capacity
Both the allowlist and blocklist support up to 110,000 entries each, making this suitable for multi-tenanted buildings, hospital campuses, universities, or logistics hubs where a large registered vehicle fleet needs to be managed locally without relying on continuous server connectivity for access decisions.
IP67, IK10 and Local Storage
The aluminium alloy body with anti-corrosion coating carries IP67 dust and water ingress protection and IK10 impact resistance, suitable for unsupervised outdoor mounting. A microSD card slot supports up to 256 GB of local storage for plate capture images and event logs, providing a self-contained evidence record independent of NVR connectivity.
Best For
- Parking Barrier Automation: Relay outputs and onboard access logic trigger boom gates automatically when a recognised plate is detected, removing the need for a separate controller at single-lane entry and exit points.
- Gated Residential Communities: The 110,000-entry allowlist stores resident and visitor plates locally, enabling autonomous gate operation even during network outages.
- Logistics and Fleet Access: Vehicle type, brand, and colour recognition alongside plate reading supports audit logging of truck and fleet movements at loading docks and industrial yards.
- Commercial Building Entry Points: Wiegand and RS-485 interfaces connect the camera to existing access control panels, adding vehicle credentials to a building’s existing security infrastructure.
- Campus and Institutional Access: High-capacity lists and Dahua DSS Pro compatibility make this suited to hospitals, universities, and airports managing large registered vehicle populations across managed entry zones.
Why Choose the ITC413-PW4D-IZ1
The ITC413-PW4D-IZ1 is not a general-purpose surveillance camera adapted for plate reading. It is a dedicated ANPR device with a deep-learning recognition engine that reads plates, identifies vehicle attributes, and acts on that data through onboard relay logic – all without requiring a separate server to process each event. The 140 dB WDR with SSA handles the transition from bright outdoor lighting into covered entry lanes, which is where simpler cameras lose plate detail. The motorized 2.7-12mm lens allows precise framing for the specific capture distance at each installation rather than accepting a compromise. With 99% capture accuracy and recognition accuracy up to 98% for reflective plates at speeds up to 80 km/h, it delivers consistent results in real traffic conditions. Available through Security Wholesalers, the ITC413-PW4D-IZ1 is supported by Dahua’s DSS Pro and Smart PSS platforms for multi-site management and event monitoring.
Buyer Decision Tips
Installation Geometry Matters: The ITC413-PW4D-IZ1 is designed for single-lane entry points with a capture zone of 3-8 m and a lane width of 3-4 m. Before mounting, confirm the camera can be positioned to face oncoming traffic at the correct angle and distance. Mounting too high, too far back, or at a sharp side angle will reduce recognition accuracy regardless of lens setting. The motorized zoom helps once the camera is in the right position, but it does not compensate for a poor mounting location.
Integration Planning: The relay outputs can directly drive many barrier and gate controllers, but confirm the trigger voltage and current requirements of your specific hardware before wiring. The Wiegand output is suited to access control panels that accept Wiegand credential input. For Dahua DSS-based deployments, the ITSAPI integration provides structured plate event data for management software, which is distinct from the standard ONVIF video stream.
Key Features & Technical Specifications
| Model |
ITC413-PW4D-IZ1 |
| Resolution |
4MP (2688 x 1520) at 30 fps |
| Sensor |
1/1.8-inch CMOS |
| Lens |
Motorized vari-focal 2.7-12mm |
| Aperture |
F/1.4 |
| Wide Dynamic Range |
140 dB with Scene Self-Adaptation (SSA) |
| IR Illumination |
850 nm IR, up to 30 m range; 10 m optimised for plate capture |
| ANPR Capture Distance |
3 m to 8 m |
| Lane Width |
3 m to 4 m |
| Vehicle Speed |
Up to 80 km/h |
| Capture Accuracy |
99% or greater |
| Recognition Accuracy |
96% typical; 98% for standard reflective plates |
| Allowlist / Blocklist Capacity |
Up to 110,000 entries each |
| Relay Outputs / Alarm Inputs |
2 x relay outputs; 2 x alarm inputs |
| Interfaces |
2 x RS-485; 1 x Wiegand |
| Audio |
Built-in microphone (3 m pickup); built-in 2 W speaker |
| Local Storage |
MicroSD card slot, up to 256 GB |
| Power |
PoE (IEEE 802.3at) or 12 V DC; less than 12 W with IR active |
| Protection Rating |
IP67 / IK10 |
| Operating Temperature |
-30 degrees C to +65 degrees C |
| Housing |
Aluminium alloy with anti-corrosion coating |
| Dimensions / Weight |
395 x 121 x 128 mm; 2.3 kg |
| Protocols |
H.264, H.265, MJPEG; ONVIF Profile S/T; CGI; ITSAPI; Dahua SDK |
| Compatible Software |
Dahua DSS Pro, DSS Express, Smart PSS |
Ideal Use Cases
Parking Station Entry and Exit
The relay output integration with barrier controllers and the 110,000-entry allowlist allow fully automated ticketless parking access for registered vehicles. Plate captures are stored locally on microSD card for audit and dispute resolution.
Gated Estate and Residential Complex
Resident vehicles stored in the allowlist pass automatically, while unrecognised plates trigger the blocklist response or alert. The 140 dB WDR handles varied lighting at gate entrances, including vehicle headlights after dark.
Logistics and Distribution Centre
Fleet and delivery trucks moving at up to 80 km/h are captured accurately at the site entry. Vehicle brand, type, and colour data alongside the plate number supports delivery verification, driver audit logs, and access scheduling via DSS Pro.
Hospital or University Campus
Large registered vehicle populations are handled by the 110,000-entry lists. The Wiegand interface allows the ITC413-PW4D-IZ1 to feed plate-based credentials into an existing campus access control panel without replacing the head-end system.
Commercial Building Basement and Undercover Car Park
The F/1.4 aperture and IR illumination optimised for plate capture at 10 m maintain reliable recognition in low-light basement entry ramps. The aluminium IK10-rated housing withstands incidental knocks from passing vehicles or trolleys near the entry point.
Choosing the Right Model
- Choose this model if: You need a self-contained ANPR camera that can read plates, manage access lists, and trigger a barrier or gate relay output directly from onboard logic at a single-lane entry point, with no external server required for basic access decisions.
- Choose a different model if: Your site requires multi-lane wide-area plate monitoring across an open car park or roadway rather than a single controlled entry point. A PTZ or multi-sensor camera with a server-side ANPR licence may be more appropriate for uncontrolled approach environments where vehicles are not funnelled through a defined 3-4 m lane.
- Choose a different model if: Your primary requirement is general outdoor video surveillance without a plate recognition function. A standard bullet camera at a lower price point will cover that role, while the ITC413-PW4D-IZ1 is optimised specifically for plate capture geometry and access control output logic.
FAQs
- What is the maximum vehicle speed the ITC413-PW4D-IZ1 can capture accurately?
The camera captures plate images for vehicles travelling at speeds up to 80 km/h. This covers typical approach speeds at parking barriers, gated entries, and controlled access lanes. For fast-moving traffic on open roads above this speed, a different camera class would be required.
- Can this camera directly open a boom gate without a separate access controller?
Yes. The 2 relay outputs allow the ITC413-PW4D-IZ1 to send a trigger signal directly to a compatible barrier or gate motor when a plate on the allowlist is recognised. Basic automated entry and exit can be achieved without an external access control panel, provided the gate hardware accepts a dry contact or relay trigger input.
- How does the motorized vari-focal lens help during installation?
The 2.7-12mm motorized zoom allows the installer to adjust the framing and focal length after the camera is physically mounted. This is important because plate capture accuracy depends on the plate filling the right proportion of the frame at the intended capture distance. Being able to tune the zoom without remounting the camera simplifies setup at awkward entry structures.
- Does it recognise plates at night without additional lighting?
Yes. The 850 nm IR illumination is optimised for plate capture within 10 m, and the F/1.4 aperture provides high light sensitivity. The WDR system also handles situations where vehicle headlights would otherwise cause overexposure of the plate image. No external lighting is required for standard overnight operation.
- How many vehicles can be stored in the onboard access lists?
The allowlist and blocklist each support up to 110,000 entries stored on the camera. This is sufficient for large facilities including multi-tenanted commercial buildings, university campuses, and hospitals. Access decisions based on these lists are made locally on the device without needing a network connection to a server.
- What is the recognition accuracy under normal conditions?
The ITC413-PW4D-IZ1 achieves a capture accuracy of 99% or greater and a recognition accuracy of 96% or greater under typical conditions. For standard reflective license plates, recognition accuracy reaches 98% or greater. These figures apply within the designed capture zone of 3-8 m and lane width of 3-4 m.
- What software platforms is this camera compatible with?
The ITC413-PW4D-IZ1 integrates with Dahua DSS Pro, DSS Express, and Smart PSS via ITSAPI, which provides structured plate event data rather than just a video stream. It also supports ONVIF Profile S and T for integration with third-party VMS platforms. The Dahua SDK is available for custom integrations. This camera is part of the Security Wholesalers range, and the team can advise on DSS platform sizing for multi-site deployments.
