Product SKU: DH-IPC-HFW3667T-ZAS-IL-ANZ
Product Overview
The Dahua DH-IPC-HFW3667T-ZAS-IL-ANZ is a 6MP Smart Dual Light vari-focal bullet network camera designed for detailed perimeter, entrance and outdoor property surveillance. Its 2.7–13.5mm motorised lens adjusts from a wide 114° horizontal overview to a tighter 32° view, allowing the scene to be refined after installation. The camera records at up to 3288 × 1850 at 25 or 30 fps and combines 120dB WDR, AI Scene Self-adaptation, electronic image stabilisation and low-light sensitivity for challenging environments. Four multi-core illuminators provide up to 60 metres of infrared and warm-light coverage, with Smart Dual Light enabling colour event recording when a classified target appears. SMD 4.0, tripwire and intrusion detection classify humans and vehicles, while a built-in microphone, external audio and alarm connections, microSD storage up to 512GB, PoE, 12V DC and IP67 protection support flexible residential and commercial installations.
Key Capabilities
6MP High-Definition Video
The 1/2.7-inch CMOS sensor records at up to 3288 × 1850 at 25 or 30 fps, providing detailed video for entrances, driveways, yards and commercial perimeter areas.
Motorised Vari-Focal Lens
The 2.7–13.5mm lens adjusts from a wide 114° horizontal view to a focused 32° view, allowing installers to refine the required coverage after the camera is mounted.
60-Metre Smart Dual Light
Four multi-core illuminators provide up to 60 metres of infrared and warm-light coverage, supporting discreet monitoring and colour event recording within the same camera.
Human and Vehicle Classification
SMD 4.0, tripwire and intrusion rules classify people and vehicles, helping reduce alerts caused by animals and other non-target movement.
Flexible Audio and Alarm Integration
A built-in microphone supports local audio recording, while separate RCA audio input and output connections and one alarm input and output support additional compatible devices.
PoE, Local Storage and IP67
The camera supports IEEE 802.3af PoE or 12V DC power, microSD storage up to 512GB and an IP67-rated metal enclosure for correctly installed outdoor surveillance.
Best For
- Driveways and Entry Gates: The adjustable lens can provide a broad approach view or tighter coverage of a defined vehicle or pedestrian entry point.
- Warehouses and Loading Areas: Long-range dual illumination and human or vehicle classification suit large operational areas with changing light.
- Building Perimeters: The visible bullet housing, IP67 construction and intrusion rules support exposed boundary and access-route monitoring.
- Retail and Commercial Sites: Supports detailed video, event-based colour recording, audio capture and alarm integration around external entrances.
- Variable-Distance Scenes: The motorised lens suits locations where the final viewing width or target distance cannot be confirmed before installation.
Why Choose the DH-IPC-HFW3667T-ZAS-IL-ANZ
The DH-IPC-HFW3667T-ZAS-IL-ANZ combines flexible optical adjustment, intelligent target classification and two night-viewing methods in one outdoor bullet camera. Its motorised lens can be refined after mounting, making it more adaptable than a fixed-lens camera where coverage requirements may change. Smart Dual Light normally uses infrared but can activate warm light for colour recording when a relevant target enters the configured area. SMD 4.0, perimeter protection, AcuPick and AI Scene Self-adaptation add practical search and image-management capabilities. Available through Security Wholesalers, this model is best selected after confirming the required viewing distance, compatible recorder, illumination behaviour, alarm wiring, audio equipment and storage arrangement.
Buyer Decision Tips
Lens and Illumination Tip: The 60-metre figures describe the maximum infrared and warm-light illumination ranges rather than guaranteed identification distances. Select the lens position and mounting height according to the required target detail.
Audio and Power Tip: A microphone is built in, but a built-in speaker is not specified. Two-way audio requires compatible external audio equipment. The camera accepts PoE or 12V DC, and both may be connected for power continuity.
Key Features & Technical Specifications
| Model | DH-IPC-HFW3667T-ZAS-IL-ANZ |
| Product Type | 6MP Smart Dual Light motorised vari-focal bullet WizSense network camera |
| Image Sensor | 1/2.7-inch progressive-scan CMOS |
| Maximum Resolution | 3288 × 1850 |
| Maximum Frame Rate | Up to 25 or 30 fps at 3288 × 1850 |
| Lens | 2.7–13.5mm motorised vari-focal lens with F1.4 maximum aperture |
| Field of View | Horizontal 114°–32°, vertical 58°–17° and diagonal 138°–36° |
| Close Focus Distance | 0.1m |
| Minimum Illumination | 0.007 lux in colour, 0.0007 lux in black and white, and 0 lux with the illuminator operating |
| Smart Dual Light | Four multi-core infrared and warm-light illuminators |
| Illumination Distance | Up to 60m infrared and up to 60m warm light |
| Perimeter Protection | Tripwire and intrusion detection with human and vehicle classification |
| Smart Motion Detection | SMD 4.0 |
| Additional Intelligence | AcuPick, AI Scene Self-adaptation and refined intelligent search with compatible back-end devices |
| Wide Dynamic Range | 120dB WDR |
| Image Functions | BLC, HLC, 3D noise reduction, EIS, defog, ROI, mirror, rotation and eight privacy areas |
| Video Compression | H.265, H.264, H.264H, H.264B and sub-stream MJPEG |
| Smart and AI Coding | Smart H.265+, Smart H.264+, AI H.265 and AI H.264 |
| Stream Capability | Three video streams |
| Built-In Audio | Built-in microphone |
| External Audio | One RCA audio input and one RCA audio output |
| Alarm Interfaces | One wet-contact alarm input and one wet-contact alarm output |
| Network Interface | One RJ45 10/100 Base-T Ethernet port |
| Interoperability | ONVIF Profiles S, G, T and M, plus CGI |
| Storage | MicroSD card up to 512GB, FTP, SFTP and NAS |
| Management Software | SmartPSS Lite, DSS and DMSS |
| Power Supply | 12V DC or IEEE 802.3af PoE |
| Dual Power Continuity | Continues operating when one connected power source is removed while both 12V DC and PoE are available |
| Power Consumption | Up to 9.9W using 12V DC or 12.5W using PoE |
| Protection and Construction | IP67-rated metal enclosure |
| Operating Conditions | −30°C to +60°C at up to 95% non-condensing relative humidity |
| Dimensions and Weight | 238.5 × 90.7 × 90.7mm; net weight 835g |
Ideal Use Cases
Driveways
Use the wide lens setting for an overall vehicle approach or zoom in for more focused coverage of a gate or lane.
Warehouse Yards
Human and vehicle classification, long-range illumination and vari-focal adjustment suit loading and access areas.
Building Perimeters
Tripwire and intrusion rules can monitor defined boundaries while filtering movement that does not match a person or vehicle.
Retail and Commercial Entrances
Provides detailed video, audio capture and event-based colour recording around external doors and delivery points.
Farms and Rural Properties
The adjustable lens and 60-metre dual illumination suit sheds, gates and access routes with limited ambient lighting.
Audio and Alarm-Integrated Sites
External audio and alarm interfaces support installations requiring additional speakers, microphones, sensors or relay-controlled equipment.
Choosing the Right Model
- Choose this camera if: You need 6MP video, a motorised 2.7–13.5mm lens, 60-metre Smart Dual Light and human or vehicle classification.
- Choose a fixed-lens camera if: The required viewing angle is already known and optical adjustment after installation is unnecessary.
- Choose a built-in-speaker model if: Two-way audio is required without adding an external speaker to the camera’s RCA audio output.
- Choose an 8MP camera if: The project requires true 3840 × 2160 4K UHD rather than the 3288 × 1850 resolution of this 6MP model.
| Image | Name | Price | Buy | hf:att:pa_ai-technology | hf:att:pa_audio-features | hf:att:pa_camera-count | hf:att:pa_camera-style | hf:att:pa_detection-features | hf:att:pa_deterrence-features | hf:att:pa_environmental-features | hf:att:pa_focal-length | hf:att:pa_hdd-bays | hf:att:pa_hdd-included | hf:att:pa_ik-rating | hf:att:pa_included-storage | hf:att:pa_installation-level | hf:att:pa_ip-rating | hf:att:pa_kit-camera-style | hf:att:pa_lens-type | hf:att:pa_low-light-technology | hf:att:pa_max-recording-resolution | hf:att:pa_mounting-position | hf:att:pa_night-vision-range | hf:att:pa_night-vision-type | hf:att:pa_optical-zoom | hf:att:pa_poe-ports | hf:att:pa_power-connectivity | hf:att:pa_protocol-compatibility | hf:att:pa_recorder-channels | hf:att:pa_remote-viewing | hf:att:pa_resolution | hf:att:pa_specialist-features | hf:att:pa_system-format | hf:att:pa_white-light-range | hf:att:pa_zoom-type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Dahua DH-PFA130-E Dahua Water proof Junction Box | $21.00 | ||||||||||||||||||||||||||||||||||
| Dahua PFA152-E Pole Mount Bracket | $22.00 inc GST +3 Year Warranty & Support |
FAQs
- What resolution and frame rate does the Dahua DH-IPC-HFW3667T-ZAS-IL-ANZ support?
The camera records at up to 3288 × 1850, providing 6MP video at up to 25 fps or 30 fps according to the configured video standard. It supports three streams and additional resolutions including 5MP, 4MP, 3MP, 1080p and 720p. The available combined frame rates depend on the total encoding capacity when several streams are enabled simultaneously. - How does Smart Dual Light work on this camera?
Smart Dual Light normally uses infrared illumination at night. When a classified target enters the configured monitoring area, the warm light can switch on so the event is recorded in colour. After the target leaves, the camera can return to infrared operation. Both the infrared and warm-light systems have a maximum specified illumination distance of 60 metres. - What viewing range does the 2.7–13.5mm motorised lens provide?
The motorised vari-focal lens adjusts from a wide 114° horizontal view at 2.7mm to a tighter 32° view at 13.5mm. The wide setting suits yards, entrances and broad perimeter areas, while the telephoto setting provides more focused coverage of distant gates or lanes. The final framing can be adjusted after mounting through compatible management equipment. - Can the camera distinguish between people and vehicles?
Yes. SMD 4.0 and the tripwire and intrusion functions support human and vehicle classification, helping reduce alarms caused by animals and other non-target movement. The camera also supports AcuPick and refined intelligent search when used with compatible back-end devices. Detection performance still depends on mounting height, target size, angle, scene conditions and correct rule configuration. - Does the DH-IPC-HFW3667T-ZAS-IL-ANZ support audio recording and two-way audio?
The camera has a built-in microphone for local audio capture, plus one RCA audio input and one RCA audio output for compatible external audio equipment. A built-in speaker is not specified, so two-way audio requires an appropriate external speaker connected to the audio output. The installation must also comply with applicable privacy and audio-recording requirements. - Can the camera record without an NVR?
Yes. The camera supports a microSD card with a capacity of up to 512GB, along with FTP, SFTP and NAS storage. It can also record to a compatible NVR. A memory card is not listed as a standard inclusion. Recording duration varies with resolution, frame rate, codec, bit rate, scene activity and the selected recording schedule. - Is this camera suitable for outdoor installation?
Yes. The camera has a metal enclosure with an IP67 protection rating and operates from −30°C to +60°C at up to 95% non-condensing humidity. Correct mounting and weatherproof cable termination remain essential. Its warm light may also affect neighbours or traffic, so the illumination direction, activation rules and mounting position should be planned carefully. - What should be checked before ordering this 6MP WizSense camera?
Confirm the required 2.7–13.5mm viewing range, 60-metre infrared and warm-light coverage, compatible PoE or 12V DC power, NVR support, microSD storage, alarm wiring and audio requirements before ordering. The camera measures 238.5 × 90.7 × 90.7mm and weighs 835g. Security Wholesalers can help confirm the camera, recorder and mounting combination.
