Beyond seeing the world, the power of AI allows devices to perceive the environment and understand the world in a better way. Together with infrared illumination and Starlight technology, the camera is the perfect solution for dark, low light applications. The series combines a day/night mechanical IR cut filter for the highest image quality in variable lighting conditions during the day and True WDR for applications with direct sunlight or glare.
Powerful 25x optical zoom
IR distance up to 150m
Deep-learning-based perimeter protection
Auto-tracking and IVS
IP67 , IK10
Automatically filtering out false alarms caused by animals, rustling leaves, bright lights, etc. Enables the system to act secondary recognition for the targets. Improving alarm accuracy.
For challenging low-light applications, Dahua’s Starlight Ultra-low Light Technology offers best-in-class light sensitivity, capturing color details in low light down to 0.001 lux. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments.
PFA technology has innovatively introduced new methods of judgment to ensure the accuracy and predictability of the direction of subject distance adjustment. The result is a set of advanced focusing algorithms.PFA ensures clarity of the image throughout the process of zooming and shortens focus time. The realization of PFA technology substantially improves user experience and increases product value.
Dahua cameras operate in extreme temperature environments, rated for use in temperatures from -40 °C to +70 °C (-40 °F to +158 °F) with 95% humidity. Subjected to rigorous dust and water immersion tests and certified to the IP67 Ingress Protection rating makes it suitable for demanding outdoor applications.
The camera allows for ±25% input voltage tolerance, suitable for the most unstable conditions for outdoor applications. Its 6KV lightning rating provides effective protection for both the camera and its structure against lightning.
The camera conforms to the ONVIF (Open Network Video Interface Forum) specifications, ensuring interoperability between network video products regardless of manufacturer.
Wide Dynamic Range
The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology. For applications with both bright and low lighting conditions that change quickly, True WDR (120 dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.
This feature controls the pan/tilt/zoom actions of the camera to automatically track an object in motion and to keep it in the scene. The tracking action can be triggered manually or automatically by defined rules. Once a rule is triggered, the camera can zoom in and track the defined target automatically.
Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces the bit rate and storage requirements by up to 70% when compared to standard H.265 video compression.
|Image Sensor||1/1.8″ CMOS|
|Effective Pixels||2560 (H)×1440 (V)|
|Electronic Shutter Speed||1/3–1/30000s|
|Scanning Mode||Progressive Scanning|
|Minimum Illumination||Color: 0.001Lux@F1.6
0Lux (IR light on)
|IR Distance||150 m (492.13 ft)|
|IR On/Off Control||Zoom Prio/Manual/Smart IR|
|IR LED Number||4|
|Field of View||H: 59.8°–2.8°; V: 33.7°–1.9°; D: 63.3°–4°|
|Close Focus Distance||0.1 m–2 m|
|1724 m||689 m||344 m||172 m|
|Pan/Tilt Range||Pan: 0°–360°; Tilt: -15°–+90°|
|Manual Control Speed||Pan: 0.1°/s–300°/s; Tilt: 0.1°/s–200°/s|
|Preset Speed||Pan: 400°/s; Tilt: 300°/s|
|Tour||8(up to 32 preset per tour)|
|Video Structuralization||Support the detection of motor vehicles, non-motor vehicles, and humans.|
|Perimeter Protection||Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.|
|Event Trigger||Motion detection, video tampering, scene changing, Network disconnection, IP address conflict, illegal access, and storage anomaly.|
|General IVS||Object Abandoned/Missing|
|Streaming Capability||3 Streams|
720P(1280×960); D1(704× 576/704×480); CIF(352×288/352×240)
|Frame Rate||Mainstream: 4M/3M(1–25/30fps), 1080P/1.3M/720P(1–25/30fps)
Substream 1: D1/CIF(1–25/30fps)
Substream 2: 1080P/1.3M/720P(1–25/30fps), D1/CIF(1–25/30fps)
|Bit Rate Control||Variable Bit Rate/Constant Bit Rate|
|Bit Rate||H.264: 32 Kbps–8192 Kbps
H.265: 32 Kbps–8192 Kbps
|White Balance||Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural/Streetlamp|
|Region of Interest (RoI)||Support|
|Electronic Image Stabilization (EIS)||Support|
|Privacy Masking||Up to 24 areas|
FCC: Part15 Subpart B,ANSI C63.4- 2014
|Audio Compression||G.711A; G.711Mu; G.726; AAC; G.722.1; G.723; G.729; PCM; MPEG2-Layer2|
|Audio In||1 (LINE IN; bare wire)|
|Audio Out||1 (LINE OUT; bare wire)|
|Alarm Port||2 alarm input port; 1 alarm output port|
|Ethernet Port||1 RJ-45 Port 10/100Base-T|
|Protocol||IPv4; IPv6; HTTP; HTTPS; 802.1x; QoS; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP|
|Interoperability||ONVIF Profile S&G; CGI|
|Max. User Access||20 (Total bandwidth 48M)|
|Edge Storage||FTP; Micro SD card (256G); P2P|
|Browser||IE7 and newer versions
Chrome 42 and older versions
Firefox 52 and older versions
|Management Software||Smart Player / Smart PSS / DSS / Easy4ip|
20W (IR light on)
|Operating Conditions||–40°C to +70°C (–40°F to +158°F)|
|Ingress Protection||IP67; IK10; TVS 6000V lightning protection; surge protection|
|Dimensions||Φ190 mm×332 mm (7.48″×13.07“)|
|Weight||Net Weight: 4.7 kg (10.36 lb);
Gross Weight: 8 kg (17.64 lb)
