Product SKU: DH-IPC-WL46A
Product Overview
The Dahua DH-IPC-WL46A is a 4MP Wi-Fi floodlight network camera designed to combine outdoor surveillance, area lighting, two-way communication and active deterrence in one wall-mounted device. Its 2.8mm fixed lens captures a 98° horizontal view at up to 2560 × 1440 resolution, while integrated warm and cool floodlights deliver 1500–2400 lumens with a maximum specified illumination distance of 30 metres. The camera also includes 10-metre infrared illumination, a 270° PIR sensor, smart detection for humans, vehicles and animals, and a built-in 110dB siren. Dual-band 2.4GHz and 5GHz Wi-Fi supports flexible wireless networking, while the microphone and speaker enable two-way audio through compatible software. Local microSD storage up to 256GB, NVR recording and IP65 protection make it suitable for homes, driveways, entrances, small businesses and other outdoor areas supplied with 100–240VAC power.
Key Capabilities
4MP Video Surveillance
The 1/3-inch CMOS sensor records at up to 2560 × 1440, providing detailed coverage of entrances, driveways and outdoor activity at up to 25 fps or 30 fps according to the ordering variant.
Dual Adjustable Floodlights
Two floodlights provide 1500–2400 lumens and a maximum specified range of 30 metres. Lighting can switch between approximately 3000K warm white and 6000K cool white.
Human, Vehicle and Animal Detection
Smart motion detection distinguishes between people, vehicles and animals to help reduce alerts caused by less relevant movement within the monitored area.
Two-Way Audio
A built-in microphone and speaker allow real-time communication through compatible management software or the DMSS mobile application when the network connection is configured correctly.
Active Light and Siren Deterrence
Motion or PIR events can activate the floodlights, while the integrated 110dB siren provides an audible warning for configured security events.
Dual-Band Wi-Fi and Local Storage
IEEE 802.11a/b/g/n/ac supports 2.4GHz and 5GHz wireless networks, while a microSD card up to 256GB can provide local recording without requiring an NVR.
Best For
- Driveways and Garages: Combines 4MP video, bright adjustable lighting and vehicle detection around parking and vehicle-access areas.
- Home Entrances: Supports visitor communication, person detection and motion-activated lighting near front doors and side entrances.
- Backyards and Outdoor Areas: Provides wireless monitoring, PIR detection and configurable warm or cool floodlighting.
- Small Retail and Offices: Adds recorded video, two-way audio and active siren deterrence around external doors and delivery areas.
- Locations Without Network Cabling: Dual-band Wi-Fi can reduce the need to install Ethernet where reliable wireless coverage is already available.
Why Choose the DH-IPC-WL46A
The DH-IPC-WL46A combines several outdoor security functions that would otherwise require separate lighting, camera, speaker and alarm devices. Its 4MP sensor and wide 2.8mm lens provide useful coverage of entrances and open areas, while the adjustable 30-metre floodlights can deliver warm or cool illumination according to the property. Smart detection for humans, vehicles and animals, together with the wide-angle PIR sensor, helps focus alerts on meaningful movement. Two-way audio and the 110dB siren add communication and deterrence options, while local microSD recording reduces reliance on an NVR. Available through Security Wholesalers, this model is best chosen where stable Wi-Fi and a suitable 100–240VAC supply are available at the mounting point.
Buyer Decision Tips
Power and Network Tip: The camera uses a 100–240VAC power supply and supports Wi-Fi networking. PoE and a wired Ethernet interface are not listed, so confirm the mains connection and wireless signal strength at the final mounting position.
Detection and Lighting Tip: The 30-metre figure is the maximum floodlight illumination distance. PIR and infrared detection are specified to 10 metres, so camera placement should be based on the required alert distance as well as the illuminated area.
Key Features & Technical Specifications
| Model | DH-IPC-WL46A |
| Ordering Variants | DH-IPC-WL46AP-0280B for PAL and DH-IPC-WL46AN-0280B for NTSC |
| Product Type | 4MP fixed-focal Wi-Fi floodlight network camera |
| Image Sensor | 1/3-inch CMOS |
| Maximum Resolution | 2560 × 1440 |
| Maximum Frame Rate | Up to 25 fps for PAL or 30 fps for NTSC at 4MP |
| Lens | 2.8mm fixed-focal M12 lens with F1.6 maximum aperture |
| Field of View | 98° horizontal, 55° vertical and 115° diagonal |
| Minimum Illumination | 0.005 lux in colour, 0.0005 lux in black and white, and 0 lux with the illuminator operating |
| Infrared Illumination | One infrared LED with a maximum specified distance of 10m |
| Floodlights | Two adjustable floodlights with a maximum specified illumination distance of 30m |
| Floodlight Brightness | 1500–2400 lumens |
| Floodlight Colour Temperature | 3000K ±200K warm white or 6000K ±300K cool white |
| Floodlight Modes | Motion activation, manual control, scheduled operation and PIR activation |
| PIR Sensor | 10m specified distance with a 270° detection range under the stated installation conditions |
| Smart Detection | Human, vehicle and animal detection |
| Active Alarm | Built-in 110dB siren |
| Audio | Built-in microphone and speaker for two-way audio |
| Audio Compression | G.711a, G.711Mu, G.726 and PCM |
| Video Compression | H.264B, H.264, H.264H, H.265 and MJPEG with Smart H.264+ and Smart H.265+ |
| Image Functions | DWDR, BLC, HLC, 3D noise reduction, ROI, smart illumination, mirror, image rotation and privacy masking |
| Wi-Fi | IEEE 802.11a/b/g/n/ac with 2.4GHz and 5GHz support |
| Interoperability | ONVIF, CGI, P2P and RTMP |
| Storage | MicroSD card up to 256GB, FTP, SFTP, NAS and compatible NVR storage |
| Mobile Application | DMSS for compatible iOS and Android devices |
| Power Supply | 100–240VAC |
| Power Consumption | 5.2W basic consumption and up to 48.3W with the camera and illuminators operating |
| Protection and Construction | IP65 with metal and plastic casing |
| Operating Conditions | −20°C to +50°C at up to 95% relative humidity |
| Dimensions and Weight | 270.7 × 217.2 × 195.6mm; net weight 1.40kg |
Ideal Use Cases
Driveways
Combines vehicle detection, 4MP video and adjustable floodlighting around cars, garages and property approaches.
Front Entrances
Provides person detection, two-way audio and motion-activated lighting around doors and visitor approach paths.
Side Access Areas
Adds surveillance and bright illumination around side gates, pathways and less visible sections of a property.
Backyards
Uses animal, human and PIR detection to monitor outdoor activity while supporting manual or scheduled lighting.
Small Commercial Entrances
Provides lighting, recording, two-way communication and audible deterrence around external business access points.
Wireless Retrofit Locations
Suitable where mains power and reliable Wi-Fi are available but installing a new network cable would be difficult.
Choosing the Right Model
- Choose this camera if: You need 4MP wireless surveillance, 30-metre floodlighting, two-way audio, smart target detection and an integrated siren.
- Choose a PoE camera if: The installation requires wired networking and power through one Ethernet cable rather than Wi-Fi and mains power.
- Choose an infrared-only camera if: Bright visible lighting is unsuitable for neighbours, traffic or the monitored environment.
- Choose a vari-focal camera if: The required view is narrower or more distant than the fixed 98° horizontal coverage provided by the 2.8mm lens.
FAQs
- Is the Dahua DH-IPC-WL46A a 4MP camera?
The DH-IPC-WL46A uses a 1/3-inch CMOS sensor and records at up to 2560 × 1440, which is 4MP. The main stream supports up to 25 fps for PAL ordering variants and 30 fps for NTSC variants. It also supports lower recording resolutions and three video streams, allowing compatible viewing, recording and bandwidth settings to be configured for the installation. - How far do the floodlights and infrared illumination reach?
The two integrated floodlights have a maximum specified illumination distance of 30 metres, while the infrared LED is rated to 10 metres. The floodlights provide 1500–2400 lumens and can switch between approximately 3000K warm light and 6000K cool light. Actual visible detail depends on the mounting height, target reflectivity, camera angle, ambient lighting and selected illumination mode. - Does the DH-IPC-WL46A support two-way audio?
Yes. The camera has a built-in microphone and speaker for real-time two-way communication through compatible software or the DMSS mobile application. Supported audio formats include G.711a, G.711Mu, G.726 and PCM. Network quality, Wi-Fi strength, mobile permissions and device configuration can affect the call experience, so audio should be tested after the camera is installed and connected. - What types of movement can the camera distinguish?
The DH-IPC-WL46A supports smart motion detection for humans, vehicles and animals, helping reduce alerts caused by less relevant movement. It also has a PIR sensor with a specified distance of 10 metres and a 270° detection range when installed at the stated reference height and angle. Detection performance varies with placement, target direction, temperature, obstructions and configured sensitivity. - Can the floodlights and siren activate when motion is detected?
Yes. The dual floodlights support motion activation, PIR activation, manual control and scheduled operation. The camera also has a built-in active alarm siren rated at 110dB. These functions can provide visible and audible deterrence when configured correctly, but activation rules should be adjusted for the property to reduce unnecessary light or siren events caused by routine movement. - Does the DH-IPC-WL46A support both 2.4GHz and 5GHz Wi-Fi?
Yes. The camera supports dual-band 2.4GHz and 5GHz Wi-Fi using IEEE 802.11a/b/g/n/ac. A stable wireless signal is important because the camera does not require a network cable for normal Wi-Fi operation. Confirm router compatibility, signal strength at the mounting location, network security and available bandwidth before installation, especially where walls, metal structures or distance may weaken coverage. - Can the DH-IPC-WL46A record without an NVR?
Yes. The camera supports a microSD card with a capacity of up to 256GB, as well as FTP, SFTP and NAS storage. It can also record to a compatible NVR. A memory card is listed as an optional accessory rather than a standard inclusion. Recording duration depends on resolution, frame rate, compression, bit rate, activity level and selected recording schedule. - What should be checked before ordering the DH-IPC-WL46A?
Confirm the PAL or NTSC ordering variant, 100–240VAC power connection, Wi-Fi coverage, wall position, 30-metre floodlight range, 10-metre PIR and infrared ranges, microSD storage and local lighting requirements before ordering. The camera measures 270.7 × 217.2 × 195.6mm and weighs 1.40kg. Security Wholesalers can help confirm whether its floodlight, audio and wireless features suit the intended entrance or outdoor area.
