Dahua 6MP WizMind DH-IPC-EBW5641-AS Fisheye Camera with 360° View, 1.68mm Lens, 15m IR

Product SKU: DH-IPC-EBW5641-AS

Product Overview

The Dahua DH-IPC-EBW5641-AS is a 6MP WizMind fisheye network camera designed to provide a complete 360° overview from one compact camera position. Its 1.68mm fixed fisheye lens captures a broad scene for retail floors, offices, classrooms, reception areas, warehouses and other open spaces where reducing blind areas is more important than viewing one narrow direction. The camera supports multiple fisheye dewarping modes, panoramic and regional layouts, electronic PTZ navigation, two- and four-window split views, and up to 15 metres of infrared illumination. Deep-learning functions include human-focused perimeter protection, people counting, queue management and heat-map analysis, while built-in dual microphones and a speaker support two-way audio. PoE, optional 12V DC power, microSD storage up to 1TB, IP67 weather protection and IK10 impact resistance make it flexible for professional installations. For distant identification points, pair the fisheye overview with more directional cameras.

Key Capabilities

Best For

• Retail and Customer Areas: Provides a broad overview of shop floors, checkout zones and customer movement while supporting people counting and heat-map analysis.
• Offices and Reception Spaces: Covers open-plan areas, lobbies, meeting zones and reception areas from one discreet fisheye position.
• Warehouses and Open Work Areas: Helps operators monitor overall activity and movement patterns across a wide scene without aiming the camera in only one direction.
• Schools and Public Facilities: Supports wide-area observation in libraries, common areas, indoor halls and other shared spaces where broad coverage is required.
• Overview Coverage in Multi-Camera Systems: Works well as a scene-overview camera alongside directional cameras positioned for entrances, faces or other high-detail targets.

Why Choose the DH-IPC-EBW5641-AS

The DH-IPC-EBW5641-AS is a strong choice when one camera needs to provide broad awareness across an entire room or open zone rather than concentrating on a single direction. Compared with a basic fisheye camera, it adds practical dewarping layouts, electronic PTZ navigation, intelligent people and perimeter analytics, built-in two-way audio, substantial edge-storage capacity and a protected housing. This combination allows the same device to contribute to security, occupancy analysis and day-to-day site management. Supplied by Security Wholesalers, the model suits buyers who need professional 360° coverage with PoE and recorder integration rather than a standalone consumer camera. The key trade-off is pixel density at distance: for facial detail, number plates or narrow access points, dedicated directional cameras should still be positioned where identification is critical.

Buyer Decision Tips

Key Features & Technical Specifications

Ideal Use Cases

Choosing the Right Model

• Choose this model if: You need a professional 6MP 360° overview camera with dewarping, PoE, IR, two-way audio, people analytics and weather- and impact-rated protection.
• Choose a directional camera instead if: Your main requirement is detailed identification of faces, number plates or distant subjects within a narrow field of view.
• Use a combined design if: You need both full-scene awareness and concentrated evidence at entrances, counters, lanes or other critical points.

FAQs

1. Does the Dahua DH-IPC-EBW5641-AS provide a full 360-degree view?
   Yes. The DH-IPC-EBW5641-AS uses a 1.68mm fisheye lens to capture a 360° overview, making it suitable for monitoring an entire room or open area from one carefully selected position. The camera supports front-end and back-end dewarping, so the circular fisheye image can be displayed as panoramic or regional views. Mounting position and viewing mode should be planned around the area that needs the clearest detail.
2. What image resolution does the DH-IPC-EBW5641-AS record?
   The DH-IPC-EBW5641-AS records at up to 6MP with a maximum image size of 2560 × 2560 at up to 25 or 30 frames per second. This square-format resolution is designed for fisheye coverage and dewarped viewing rather than the conventional widescreen format used by many fixed cameras. The useful identification detail still depends on subject distance, mounting height and the selected display mode.
3. How far can the infrared night vision reach?
   The built-in infrared illumination is rated for up to 15 metres. This supports black-and-white monitoring in dark indoor or outdoor areas without relying on visible white light. Because fisheye cameras spread their view across a very wide scene, the strongest practical detail is normally obtained when subjects are reasonably close to the camera rather than at the outer edge of the infrared range.
4. Does the DH-IPC-EBW5641-AS support two-way audio?
   Yes. The camera has a built-in speaker and dual built-in microphones, allowing two-way talk when the audio function is configured through a compatible system. It also provides one audio input and one audio output for supported external audio equipment. Audio performance depends on installation height, background noise, network conditions and the recorder or software used to manage the camera.
5. Which intelligent analytics are included with this fisheye camera?
   The DH-IPC-EBW5641-AS supports perimeter protection with tripwire and intrusion rules for human detection, along with people counting, queue management, people counting within an area and heat-map functions. These tools are useful for both security monitoring and operational analysis. Results depend on correct installation, scene setup and rule configuration, so the analytics should be commissioned for the actual site rather than left on generic settings.
6. Can the DH-IPC-EBW5641-AS record to a microSD card?
   Yes. The camera supports a microSD card with a capacity of up to 1TB, providing an edge-storage option for local recording. It can also work with FTP, SFTP and NAS storage methods, depending on the system design. A memory card is not stated as included, and buyers should select a suitable surveillance-rated card and configure recording, overwrite and event settings to match the required retention period.
7. Is this camera suitable for outdoor or vandal-prone locations?
   The DH-IPC-EBW5641-AS carries IP67 weather protection and IK10 impact protection, so it is designed for demanding indoor or outdoor installations. Its operating range is –30 °C to +60 °C. Even with these ratings, cable entries, junction points and the mounting surface must be properly sealed and supported. Security Wholesalers can assist buyers in checking whether the planned position and mounting method suit the installation.
8. Should I choose one fisheye camera or several conventional cameras?
   Choose the DH-IPC-EBW5641-AS when broad situational awareness, reduced blind areas and dewarped panoramic viewing are more important than concentrating pixels on one distant target. Several conventional cameras may be the better choice when separate entrances, faces, number plates or long corridors require higher directional detail. A fisheye camera is often most effective as an overview camera alongside more focused cameras in critical identification zones.

Additional Information

Dahua DH-IPC-EBW5641-AS Datasheet
