Dahua 64CH WizSense DHI-NVR5464-AI/ANZ Network Video Recorder with 4 HDD Bays, 384Mbps Bandwidth, AI Analytics

Product SKU: DHI-NVR5464-AI/ANZ

Product Overview

The Dahua DHI-NVR5464-AI/ANZ 64CH WizSense Network Video Recorder with 4 HDD Bays, 384Mbps Bandwidth and AI Analytics is a professional 1.5U recorder designed for large IP CCTV systems that need high channel capacity, intelligent event handling and flexible local storage. It supports up to 64 IP camera channels, Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding, with up to 384Mbps incoming, recording and outgoing bandwidth when AI is disabled. Its 4 SATA HDD bays support up to 16TB per drive, while dual HDMI, dual VGA, 16 alarm inputs, 6 alarm outputs, 2 Gigabit network ports, eSATA, RS-232, RS-485 and 4K display support make it suitable for larger commercial and security control room installations. With AI by recorder and AI by camera, including face detection, face recognition, perimeter protection, SMD Plus, metadata, ANPR, people counting and heat map support, the DHI-NVR5464-AI/ANZ is suited to retail, warehouses, education, office buildings, logistics, car parks and multi-area surveillance projects.

Key Capabilities

Best For

• Large Commercial CCTV Systems: Suitable for sites needing up to 64 IP camera channels with strong bandwidth and multi-monitor output.
• Retail and Shopping Precincts: Face recognition, SMD Plus, metadata, people counting and heat map support efficient security and investigation workflows.
• Warehouses and Logistics Sites: High channel count, 16 alarm inputs, 6 alarm outputs and smart analytics suit loading docks, stock zones and vehicle movement areas.
• Education and Office Buildings: 64-channel recording and 4K display output support corridors, foyers, car parks, entry points and shared spaces across larger premises.
• AI-Assisted Surveillance Projects: AI by recorder and AI by camera support smarter alerts, faster search and more useful event review when configured with compatible cameras.

Why Choose the DHI-NVR5464-AI/ANZ

Choose the Dahua DHI-NVR5464-AI/ANZ when the installation needs a 64-channel WizSense recorder with strong bandwidth, advanced analytics and professional local display options. It supports up to 32MP recording, 4 SATA HDD bays, 2 HDMI outputs, 2 VGA outputs, 2 Gigabit network ports, eSATA, 16 alarm inputs and 6 alarm outputs for demanding CCTV projects. AI by recorder supports face detection and recognition, perimeter protection and SMD Plus, while AI by compatible cameras can add metadata, ANPR, stereo analysis, people counting, vehicle density and heat map functions. This model, supplied by Security Wholesalers, is a strong Dahua recorder for larger commercial systems needing high channel capacity, AI-assisted monitoring and practical 4-HDD storage capacity.

Buyer Decision Tips

Key Features & Technical Specifications

Ideal Use Cases

Choosing the Right Model

• Choose this model if: You need a 64-channel Dahua WizSense NVR with 4 HDD bays, 384Mbps bandwidth, AI analytics, 4K display output and professional alarm I/O.
• Choose a PoE NVR if: You want built-in camera power ports directly on the recorder instead of using separate PoE switches.
• Choose an 8-HDD model if: The site needs longer recording retention, more local storage capacity or larger storage planning headroom.
• Check AI bandwidth: AI-enabled bandwidth is lower than AI-disabled bandwidth, so confirm analytics workload, camera bitrate and recording settings before finalising the system.
• Check storage requirements: Confirm HDD capacity, recording schedule, resolution, bitrate, retention period and whether external eSATA storage is required.

FAQs

1. How many cameras does the Dahua DHI-NVR5464-AI/ANZ support?
   The Dahua DHI-NVR5464-AI/ANZ supports up to 64 IP camera channels. It is suitable for larger CCTV systems across commercial, retail, warehouse, education, office and industrial environments.
2. Does this NVR include PoE ports?
   No. The DHI-NVR5464-AI/ANZ does not include built-in PoE camera ports. Cameras should be powered using suitable PoE switches, PoE injectors or compatible external power supplies depending on the system design.
3. How many hard drives can it take?
   This NVR includes 4 SATA ports and supports up to 16TB per HDD, with maximum HDD capacity varying based on environmental temperature and drive compatibility. HDDs are not included unless supplied as part of a separate kit.
4. What bandwidth does the recorder support?
   The recorder supports up to 384Mbps incoming, recording and outgoing bandwidth when AI is disabled. When AI is enabled, it supports up to 200Mbps incoming, 200Mbps recording and 200Mbps outgoing bandwidth.
5. What AI features does this recorder support?
   The NVR supports AI by recorder including face detection, face recognition, perimeter protection and SMD Plus. It also supports compatible camera-side AI including metadata, ANPR, stereo analysis, crowd distribution, people counting, vehicle density and heat map functions.
6. Does this recorder support 4K display output?
   Yes. The recorder supports 4K display output and includes 2 HDMI plus 2 VGA outputs. It supports heterogeneous HDMI output and simultaneous VGA/HDMI output combinations for practical multi-monitor setups.
7. Is this suitable for high-resolution cameras?
   Yes. The recorder supports recording resolutions up to 32MP, along with 24MP, 16MP, 12MP, 8MP and lower resolutions. Decoding capability depends on whether AI is enabled and the selected stream settings.
8. What should I check before buying the DHI-NVR5464-AI/ANZ?
   Before buying, confirm camera count, camera bitrate, AI workload, recording resolution, HDD capacity, retention target, PoE switch design, alarm I/O needs, monitor outputs and compatible camera analytics. Security Wholesalers can supply this Dahua NVR for compatible commercial CCTV systems.

Additional Information

Dahua NVR5464-AIANZ Datasheet
