Product SKU: 02536-006
Product Overview
For integrators designing a validated Axis Camera Station Pro system at commercial scale, the AXIS S1232 Tower is a purpose-built 32TB tower recording server supplied with 32 AXIS Camera Station Pro Core Device NVR licenses included in the box. Rather than sourcing a server, storage, operating system and software separately, this unit arrives with enterprise-class hard drives preinstalled, RAID storage preconfigured to RAID 5 at the factory, and AXIS Camera Station Pro software preloaded on Microsoft Windows 11 IoT Enterprise LTSC 2024. The server is validated for up to 64 video channels and a recording bitrate of up to 500 Mbit/s, making it a capable recording platform for medium to large commercial sites including warehouses, schools, office buildings, retail groups, logistics facilities and medical centres. Part number 02536-006 carries a 5-year Axis warranty and is designed for deployment within a properly structured Axis network video system.
Key Capabilities
32 AXIS Camera Station Pro Licenses Included
The server includes 32 AXIS Camera Station Pro Core Device NVR licenses tied to the hardware, making it ready for a 32-device Axis VMS deployment without any additional software purchase. Additional licenses can be acquired separately if the project scope expands beyond the included count.
32TB Enterprise-Class Storage
Four 8TB enterprise-class hard drives are installed at the factory, giving 32TB raw capacity. In the default RAID 5 configuration, approximately 24TB is available for recording, balancing usable storage with single-drive failure protection for continuous commercial operation.
Flexible RAID Configuration
RAID 0, 1, 5, 6 and 10 are all supported. RAID 5 ships as the default, RAID 6 adds stronger redundancy for critical footage retention requirements, and RAID 10 suits environments where both performance and redundancy are prioritised over raw usable capacity.
Validated High-Bitrate Recording
The server platform is validated for up to 64 video channels and a recording bitrate of up to 500 Mbit/s. The included 32 licenses cover initial deployment, and the server has the processing headroom to support larger configurations when additional licensing and correct network design are applied.
Expandable 8-Bay Tower Chassis
With 8 total HDD bays and 4 free bays available after the factory drives are installed, there is room to expand storage capacity as site retention requirements grow. The tower form factor also suits installations where rack cabinet space is not available.
Secure and Resilient Hardware Platform
A Trusted Platform Module certified to FIPS 140-2 level 2, encrypted storage support, redundant 600W hot-plug power supplies and an Intel Xeon E processor combine to deliver the hardware stability and cybersecurity baseline expected of a professional surveillance server environment.
Best For
- Axis Camera Station Pro Commercial Deployments: Designed for sites that need a validated Axis VMS recording server rather than a generic Windows machine with separately sourced storage and software.
- 32-Device Systems Ready from Day One: The 32 included AXIS Camera Station Pro Core Device NVR licenses cover cameras, intercoms, audio devices and access control devices within the Axis ecosystem without additional licensing outlay at initial setup.
- Sites Anticipating Storage Growth: The 4 free HDD bays allow on-site storage expansion as retention requirements increase, reducing the need to replace the recorder when the system grows.
- High-Resolution Multi-Camera Environments: Validated for 500 Mbit/s recording throughput, the server handles high-resolution Axis cameras recording across large commercial sites without performance compromise.
- Installations Without Rack Cabinet Space: The tower form factor suits server rooms, secure storage areas or comms spaces that do not have a 19-inch rack cabinet, making it accessible for a wider range of commercial site configurations.
Why Choose the AXIS S1232 Tower
What separates the AXIS S1232 Tower from a generic recording server is that every component has been selected and validated by Axis as a complete system. The Intel Xeon E processor, 32GB RAM, NVIDIA T Series graphics card, enterprise-class drives and AXIS Camera Station Pro software are tested together at the 32TB configuration to deliver confirmed performance up to 64 video channels and 500 Mbit/s. The 32 included Core Device NVR licenses reduce project cost compared to purchasing a bare server and software separately, and the AXIS Audio Manager Pro licenses included when installed on this server add further value for sites deploying Axis audio hardware. Redundant power supplies, FIPS 140-2 level 2 certified TPM and a 5-year Axis warranty reflect the standard expected for commercial recording infrastructure. Available through Security Wholesalers, the AXIS S1232 Tower is suited to integrators and end users who want a fully supported, purpose-built Axis recording platform without the complexity of assembling one from separate components.
Buyer Decision Tips
Buyer Tip 1 – No Built-In PoE Ports: The AXIS S1232 Tower is a network recording server, not a PoE NVR. It does not power or connect cameras directly. All cameras must be connected through external PoE switches or PoE injectors on the same network. If the project requires integrated PoE camera ports, AXIS S30 series recorders such as the AXIS S3008 Mk II or AXIS S3016 are better suited to that requirement.
Buyer Tip 2 – Storage Planning Before Deployment: The 32TB raw capacity delivers approximately 24TB in the factory RAID 5 configuration. Actual footage retention depends on camera count, resolution, frame rate, codec, motion frequency and recording schedule. Use AXIS Site Designer or a storage calculator before confirming retention expectations with the client, particularly on sites with high-resolution cameras or extended retention requirements.
Key Features & Technical Specifications
| Model |
AXIS S1232 Tower |
| Part Number |
02536-006 |
| Form Factor |
Tower recording server |
| AXIS Camera Station Pro Licenses Included |
32 Core Device NVR licenses |
| AXIS Audio Manager Pro Licenses Included |
10 licenses when installed on the server |
| Validated Video Channels |
Up to 64 video channels |
| Validated Recording Bitrate |
Up to 500 Mbit/s |
| Processor |
Intel Xeon E processor |
| Memory |
2 x 16GB |
| Graphics Card |
NVIDIA T Series |
| Operating System |
Microsoft Windows 11 IoT Enterprise LTSC 2024 |
| Hard Drives Included |
4 x 8TB enterprise-class HDDs |
| Total HDD Bays |
8 |
| Free HDD Bays |
4 |
| Raw Storage Capacity |
32TB before RAID |
| Factory RAID Usable Storage |
Approximately 24TB after RAID 5 |
| Supported RAID Levels |
RAID 0, 1, 5, 6, 10 |
| Default RAID Level |
RAID 5 |
| PoE Ports |
No built-in PoE ports. External PoE switch required. |
| Network Interfaces |
2 x RJ45 1Gbps ports plus iDRAC dedicated Ethernet port |
| Power Supply |
2 x 600W hot-plug redundant power supplies |
| Typical Power Consumption |
159W |
| Maximum Power Consumption |
181W |
| Security |
Trusted Platform Module, FIPS 140-2 level 2 certified |
| Warranty |
5-year Axis warranty |
Ideal Use Cases
Office Buildings
Medium to large office sites using Axis cameras across entry points, reception areas, corridors, lifts and car parks can use the AXIS S1232 Tower as the central AXIS Camera Station Pro recording server, with the 32 included licenses covering many common commercial camera layouts.
Schools and Education Campuses
Schools and campuses can deploy the server as the core Axis recording platform for cameras monitoring gates, administration buildings, playground perimeters, walkways, shared facilities and car parks, with the validated 64-channel capacity providing room for phased camera rollouts.
Warehouses and Logistics Facilities
The 500 Mbit/s validated recording throughput and enterprise-class storage make this server suited to warehouses and logistics depots running high-resolution Axis cameras across loading docks, dispatch areas, internal aisles and external yards where retention and bitrate demands are high.
Retail Groups
Retail sites can run the AXIS S1232 Tower as a local recording server for cameras covering entrances, POS counters, aisles, stockrooms and loading areas. AXIS Camera Station Pro provides investigators with centralised playback, search and evidence export tools without requiring a cloud dependency.
Medical Centres and Professional Suites
The FIPS 140-2 level 2 certified TPM, encrypted storage support, redundant power supplies and 5-year Axis warranty make the AXIS S1232 Tower a strong fit for professional environments where data handling, hardware reliability and vendor accountability are key considerations.
Multi-Site Business Standardisation
Businesses operating across multiple locations can standardise on the AXIS S1232 Tower and AXIS Camera Station Pro for consistent software, storage architecture and remote management across branches, reducing training overhead and simplifying ongoing system support.
Choosing the Right Model
- Choose this model if: You are deploying a professional Axis Camera Station Pro system, need 32 device licenses included from the outset, want 32TB raw storage with RAID protection, and require a tower form factor for a location without rack cabinet space.
- Choose this model if: The project requires a factory-validated Axis recording server with enterprise-class drives, preloaded software and a 5-year Axis warranty rather than a self-built Windows recording machine.
- Choose a different model if: The recorder needs to sit in a 19-inch server rack or comms cabinet alongside other rack-mounted network equipment. A rack-mounted Axis recording server would be better suited to that installation environment.
- Choose a different model if: Built-in PoE camera ports are required. This server connects to cameras through the network only and does not power devices directly. Axis S30 series recorders with integrated PoE ports are designed for that type of deployment.
- Choose a different model if: The project is a small home or single-premises system with a handful of cameras. The AXIS S1232 Tower is a commercial-grade recording server intended for properly designed network video systems at commercial scale.
FAQs
- Does the AXIS S1232 Tower include AXIS Camera Station Pro licenses?
Yes. The AXIS S1232 Tower includes 32 AXIS Camera Station Pro Core Device NVR licenses tied to the hardware. These licenses cover cameras, intercoms, audio devices and access control devices within the Axis ecosystem. Additional licenses can be purchased separately if the system grows beyond the included count.
- How many cameras can this server support?
The recorder is validated for up to 64 video channels and a recording bitrate of up to 500 Mbit/s when correctly licensed and configured. The included 32 licenses cover the initial device count. Expanding beyond 32 devices requires additional AXIS Camera Station Pro licenses. Actual throughput depends on camera resolution, frame rate, codec settings and analytics load across the system.
- Does the AXIS S1232 Tower have built-in PoE ports to power cameras?
No. The AXIS S1232 Tower is a network recording server and does not include integrated PoE camera ports. All cameras and Axis devices must be powered and connected through external PoE switches or PoE injectors on the local network. This differs from Axis S30 series recorders such as the AXIS S3016, which include integrated PoE ports for direct camera connection.
- How much usable storage is available in the factory configuration?
The unit ships with 4 x 8TB enterprise-class hard drives providing 32TB of raw capacity. In the factory RAID 5 default, approximately 24TB is available for footage recording. Actual retention will vary based on camera count, resolution, frame rate, codec, scene activity and the recording schedule configured in AXIS Camera Station Pro.
- Can I add more storage to the AXIS S1232 Tower later?
Yes. The tower chassis has 8 total HDD bays, with 4 drives installed at the factory and 4 bays remaining free. Compatible enterprise hard drives can be added to expand raw capacity as the site’s retention requirements grow. Any storage expansion should be planned alongside a review of the RAID configuration to maintain the desired level of redundancy.
- Which RAID level should I configure for a commercial surveillance site?
RAID 5 is the factory default and suits most commercial recording environments, providing protection against a single drive failure while maximising usable capacity from the 4 installed drives. RAID 6 is worth considering on sites where footage retention is critical and a second simultaneous drive failure must be tolerated. RAID 0 provides maximum capacity but no redundancy and is not recommended where continuous footage retention is required.
- What is included in the AXIS Audio Manager Pro license bundle on this server?
When AXIS Camera Station Pro is installed on the AXIS S1232 Tower, 10 AXIS Audio Manager Pro licenses are also included. These licenses apply to Axis audio devices managed through the server, making the platform suitable for sites that combine video surveillance with Axis network audio without requiring a separate software purchase for audio management.
- Where can I purchase the AXIS S1232 Tower in Australia?
The AXIS S1232 Tower recording server (part number 02536-006) is part of the Security Wholesalers range. It is supplied with the 32 AXIS Camera Station Pro Core Device NVR licenses, factory RAID 5 configuration and 5-year Axis warranty as described. Contact Security Wholesalers directly to confirm availability and to discuss project-specific requirements before ordering.
Cabling Considerations
- Network Cable Type: Cat5e minimum for camera network connections. Cat6 or Cat6A is recommended for new installations, particularly where higher-resolution cameras or long cable runs are involved.
- Maximum Cable Run to PoE Switch: Up to 100 metres per standard Ethernet segment between a camera and its PoE switch. This limit applies to the network infrastructure connecting cameras to the switch, not to the server itself.
- PoE Switch Requirement: The AXIS S1232 Tower does not include PoE ports. A managed PoE switch with sufficient ports and power budget for all connected Axis cameras and devices must be included in the system design. Axis recommends matching switch capacity to the total PoE draw of the connected device set.
- Server Network Connection: The AXIS S1232 Tower includes 2 x RJ45 1Gbps network ports and a dedicated iDRAC Ethernet port. For recording systems with high camera counts or high bitrate streams, connecting both network interfaces to the switch and configuring link aggregation or separating management and recording traffic can improve throughput stability.
Additional Information
