Product SKU: P5676-LE
Product Overview
For large outdoor sites where a single camera must monitor multiple zones, track moving targets, and hold usable detail at long distances, the AXIS P5676-LE PTZ Camera delivers 4MP resolution at up to 60fps with 30x optical zoom across a 4.5-135mm varifocal lens. The horizontal field of view spans from 57.1 degrees at wide angle down to 2.1 degrees at telephoto, giving control room operators a full situational overview that can be compressed into sharp zoomed detail within the same camera housing. Equipped with Lightfinder 2.0 for colour imaging down to approximately 0.1 lux, Forensic WDR up to 120 dB, and built-in IR illumination for 0 lux coverage, it maintains usable footage across a complete 24-hour cycle. AXIS Object Analytics runs on-board for real-time detection and classification of people and vehicles, with Advanced Gatekeeper and autotracking enabling autonomous responses without live operator input. Rated IP66, IK10, and NEMA 4X, and operating from -30 degrees C to 50 degrees C, the P5676-LE is engineered for demanding outdoor PTZ deployments at ports, industrial perimeters, stadiums, and critical infrastructure sites.
Key Capabilities
30x Optical Zoom at 4MP Resolution
A 4.5-135mm varifocal lens with 30x optical zoom and 12x digital zoom compresses the horizontal field of view from 57.1 degrees down to 2.1 degrees. At 4MP and up to 60fps, operators can read vehicle details and identify individuals at distances that lower-resolution PTZ cameras cannot usefully cover.
Lightfinder 2.0 and Forensic WDR
Lightfinder 2.0 holds colour imaging down to approximately 0.1 lux, keeping footage in colour through near-darkness without switching to monochrome. Forensic WDR at up to 120 dB handles simultaneous shadow and highlight detail, which is critical at floodlit loading docks, mixed-lighting venue entrances, and roadside monitoring points.
Built-in IR for Zero-Lux Operation
Built-in IR illumination extends coverage to 0 lux, enabling 24-hour monitoring at remote perimeter sites, unmanned utility yards, and infrastructure locations where installed lighting is not available. This removes a common dependency on external lighting infrastructure for night-time coverage.
On-Board Analytics, Autotracking, and Advanced Gatekeeper
AXIS Object Analytics processes detection and classification of people and vehicles entirely on the camera using the built-in ARTPEC platform, without a separate analytics server. Autotracking follows moving targets across the full PTZ range, and Advanced Gatekeeper triggers automatic zoom-ins to predefined zones when detection events occur.
256 Presets, Guard Tours, and PTZ Control Depth
With 256 configurable preset positions, guard tours, nadir flip, zoom queues, focus recall, and spot focus, the P5676-LE supports structured multi-zone patrol strategies across large sites. Operators can automate coverage circuits, define alarm-triggered repositioning, and maintain focus precision at maximum zoom.
IP66, IK10, NEMA 4X, and Electronic Image Stabilisation
Protection ratings cover dust and water ingress (IP66), impact resistance (IK10), and corrosive environments including coastal salt spray (NEMA 4X). The operating range of -30 degrees C to 50 degrees C with humidity tolerance up to 100% is matched by Electronic Image Stabilisation to compensate for vibration at pole-top and rooftop mounts.
Best For
- Large Outdoor Perimeters and Fence Lines: The 30x optical zoom and full pan/tilt range allow a single P5676-LE to monitor extended site boundaries, access roads, and gate entries that would otherwise require multiple fixed camera positions.
- Ports, Terminals, and Shipping Infrastructure: Rapid preset repositioning and 256 configured zones let operators switch between berths, container areas, and pedestrian gates on a single camera, while autotracking follows people or vehicles between monitored points.
- Critical Infrastructure and Utility Sites: NEMA 4X corrosion resistance combined with the -30 degrees C to 50 degrees C operating range makes this camera suited to substations, water treatment facilities, and remote infrastructure where environmental conditions are demanding and site access for maintenance is limited.
- Stadiums, Arenas, and Large Public Venues: Guard tours and alarm-triggered preset repositioning support automated multi-zone patrol across concourses, car parks, and event entries. Forensic WDR manages the mixed artificial and ambient lighting common to these environments.
- Remote and Unmanned Monitoring Sites: Advanced Gatekeeper and autotracking enable the camera to detect activity and respond autonomously, making it practical for sites monitored outside staffed hours or managed from a centralised control room without a dedicated operator per location.
Why Choose the AXIS P5676-LE
What separates the AXIS P5676-LE from mid-range outdoor PTZ options is the combination of 4MP resolution at 60fps, 30x optical zoom, and fully on-board analytics in a single housing built to NEMA 4X corrosion resistance standards. Many PTZ cameras at this zoom level rely on server-side analytics or offer basic motion detection only. The P5676-LE runs AXIS Object Analytics, Advanced Gatekeeper, and autotracking locally on the ARTPEC platform, reducing server load and delivering faster alarm-triggered responses at distributed or remote sites. Forensic WDR at up to 120 dB and Lightfinder 2.0 address the specific low-light and mixed-lighting challenges of ports, industrial yards, and large venues more precisely than standard WDR. Zipstream compression with H.264/H.265 and up to 20 configurable streams controls bandwidth and storage at scale, while secure boot, signed firmware, and hardware cryptographic storage meet cybersecurity requirements increasingly specified on government and commercial projects. Available at Security Wholesalers, the P5676-LE is suited to integrators specifying outdoor PTZ where image quality, edge analytics, and environmental durability all need to be confirmed at the design stage.
Buyer Decision Tips
Power Infrastructure Planning: The P5676-LE requires PoE Class 6, which is only reliably delivered under 802.3bt (PoE++). Standard 802.3af switches and most 802.3at (PoE+) switches will not provide sufficient wattage per port to power this camera. Before finalising the specification, confirm that each switch port assigned to this camera can output Class 6 power, or budget for a dedicated high-power PoE injector at each camera location. Overlooking this at the design stage is one of the most common causes of installation delays on PTZ projects of this class.
Mount Selection and EIS Limits: Electronic Image Stabilisation compensates for vibration at exposed mounts, but it works within a fixed compensation range and applies a small sensor crop to create stabilisation headroom. On pole-top or rooftop installations in high-wind environments, selecting a rigid, low-vibration mount rated for site wind loads will improve autotracking accuracy and zoom-in consistency. EIS is most effective as a supplement to a stable mount, not as a substitute for one.
Key Features & Technical Specifications
| Model |
AXIS P5676-LE PTZ Camera |
| Resolution |
4MP (2688 x 1512) |
| Frame Rate |
Up to 60fps |
| Lens |
4.5-135mm varifocal, f/1.6-4.6 |
| Optical Zoom |
30x |
| Digital Zoom |
12x |
| Horizontal Field of View |
57.1 degrees (wide) to 2.1 degrees (telephoto) |
| Minimum Illumination |
Colour: approx. 0.1 lux | Monochrome: approx. 0.03 lux | With IR: 0 lux |
| IR Illumination |
Yes, built-in |
| Wide Dynamic Range |
Forensic WDR, up to 120 dB |
| Low-Light Technology |
Lightfinder 2.0 |
| Analytics |
AXIS Object Analytics (on-board), Advanced Gatekeeper, Autotracking |
| PTZ Features |
256 preset positions, guard tours, nadir flip, zoom queues, focus recall, spot focus, orientation aids |
| Image Stabilisation |
Electronic Image Stabilisation (EIS) |
| Video Compression |
H.264, H.265, MJPEG with Zipstream |
| Video Streams |
Up to 20 configurable streams |
| Local Storage |
microSD edge storage |
| Audio |
Audio input/output |
| Weather/Impact Rating |
IP66, IK10, NEMA 4X |
| Operating Temperature |
-30 degrees C to 50 degrees C |
| Humidity |
Up to 100% |
| Power |
PoE Class 6 |
| Cybersecurity |
Secure boot, signed firmware, hardware cryptographic storage |
Ideal Use Cases
Ports and Shipping Terminals
The 30x optical zoom and 256 configurable preset positions allow a single P5676-LE to cover vessel berths, container yards, and vehicle gates across large terminal footprints. Autotracking follows personnel or vehicles between zones without requiring a dedicated operator per shift.
Industrial Perimeter and Site Boundaries
NEMA 4X, IP66, and IK10 ratings combined with the -30 degrees C to 50 degrees C operating range suit exposed industrial fence lines and site perimeters. On-board AXIS Object Analytics classifies intrusion events without server-side processing, which is practical for distributed industrial sites with limited local IT infrastructure.
Stadiums and Large Public Venues
Guard tours and alarm-triggered preset repositioning automate multi-zone patrol across concourses, car parks, and event spaces. Lightfinder 2.0 and Forensic WDR handle the combination of artificial and ambient lighting at these venues that creates exposure problems for standard cameras.
Traffic and Vehicle Monitoring
At 4MP and 60fps, the P5676-LE captures vehicle detail at extended range using 30x optical zoom. AXIS Object Analytics classifies vehicle events in real time, and Advanced Gatekeeper triggers automatic zoom-ins to entry and exit points on detection, reducing the need for constant manual camera control.
Remote Utility and Infrastructure Sites
Built-in IR illumination supports 0 lux coverage at sites without external lighting. Autotracking and Advanced Gatekeeper allow autonomous responses to detected activity at substations, water infrastructure, and unmanned sites monitored from a central location. Secure boot and signed firmware satisfy cybersecurity specifications for government and utility operators.
Choosing the Right Model
- Choose this model if: Your project requires a single outdoor PTZ camera to monitor large distances with 30x optical zoom, on-board object detection and autotracking, and full environmental protection to IP66, IK10, and NEMA 4X across a wide temperature range.
- Choose a different model if: Your coverage requirement is a fixed defined zone rather than a wide-area scan-and-track scenario. A fixed or motorised varifocal turret or bullet camera will deliver comparable or higher resolution for a defined area at lower cost and with a simpler PoE power requirement.
- Choose a different model if: Your existing PoE switch infrastructure runs 802.3at (PoE+) only and you cannot add dedicated Class 6 injectors. A PTZ camera with lower power draw may be more practical without requiring switch upgrades at each camera location.
- Choose a different model if: Your primary need is simultaneous wide-angle overview of an entire area rather than zoom and tracking. A panoramic or multi-sensor camera may deliver broader simultaneous coverage from a single mounting point with a simpler configuration and lower power consumption.
FAQs
- What PoE class does the AXIS P5676-LE require and which switches support it?
The P5676-LE requires PoE Class 6, which is delivered under the 802.3bt (PoE++) standard. Standard 802.3af switches and most 802.3at (PoE+) switches do not deliver sufficient wattage per port to power this camera. Before specifying this model, confirm that each assigned switch port supports Class 6 output, or plan for a dedicated high-power PoE injector at each camera location.
- How does the 30x optical zoom perform at maximum reach in terms of image usability?
The 30x optical zoom covers a focal range of 4.5mm to 135mm, narrowing the horizontal field of view to 2.1 degrees at telephoto. At this zoom level the 4MP sensor and autofocus system maintain usable detail for vehicle observation and person identification at extended distances. The additional 12x digital zoom extends reach further, though pixel density decreases beyond what the optical zoom alone delivers.
- Does the P5676-LE operate in complete darkness without any external lighting at the site?
Yes. Built-in IR illumination enables monitoring down to 0 lux, meaning the camera operates in total darkness without any installed external lighting. Lightfinder 2.0 maintains colour imaging down to approximately 0.1 lux before transitioning to monochrome at approximately 0.03 lux, with IR illumination activating automatically below that threshold.
- Is AXIS Object Analytics processed on the camera itself or does it require a separate server?
AXIS Object Analytics runs entirely on the camera using the built-in ARTPEC processor. No external analytics server or additional software licence is required for person and vehicle detection, classification, autotracking, or Advanced Gatekeeper triggering. This is a key practical advantage for remote or multi-site deployments where server infrastructure at each location is not available. The P5676-LE is offered through Security Wholesalers for integrators specifying edge-processing PTZ cameras on commercial and government projects.
- What is Advanced Gatekeeper and how does it differ from standard autotracking?
Autotracking follows a detected moving target across the full PTZ range continuously once it is in frame. Advanced Gatekeeper adds a zone-based trigger layer: when a person or vehicle enters a predefined zone, the camera automatically zooms in to that area regardless of whether tracking is already active. This is useful for gate entries, perimeter breach points, or access corridors where you want automatic close-up capture on zone activation rather than just continuous target following.
- What does the NEMA 4X rating cover beyond standard IP66 weatherproofing?
IP66 certifies protection against dust ingress and powerful water jets from any direction. NEMA 4X adds resistance to corrosion from external agents including salt spray, chemical splatter, and similar environmental contaminants. This makes the P5676-LE appropriate for coastal industrial sites, marine terminal infrastructure, and chemical processing environments where standard IP-rated housings may degrade over time.
- How does Electronic Image Stabilisation affect image quality and autotracking performance on exposed mounts?
EIS compensates for physical movement caused by wind, vibration, or mechanical disturbance at the mounting point by applying a crop to the sensor frame to create stabilisation headroom. This reduces rolling or shaking in footage at exposed pole-top or rooftop installations. The trade-off is a small reduction in the effective field of view. For sites with persistent high vibration, pairing EIS with a rigid, low-movement mount rated for the site wind load improves autotracking consistency at higher zoom levels.
