Product SKU: AXIS M3128-LVE
Product Overview
For entrances, retail floors, corridors, and covered outdoor access points that need genuine 4K detail paired with on-camera intelligence, the AXIS M3128-LVE is a turret-style dome camera built to deliver both. Featuring 3840 x 2160 resolution from a 1/2.8″ CMOS sensor and a 2.9mm fixed lens with a 110° horizontal field of view, this 8MP camera covers broad interior zones from a single compact mounting point. Equipped with a built-in deep learning processing unit and AXIS Object Analytics, the camera classifies and tracks humans and vehicles at the edge, reducing alert noise without relying on server-side processing. Built with OptimizedIR up to 20m, WDR, H.265 with Axis Zipstream, and a microSD card slot for local storage, it handles mixed lighting and after-hours monitoring without external lighting. IP66 weather protection, IK08 impact resistance, and Axis Edge Vault with FIPS 140-3 Level 3 certified secure key storage round out a camera designed for professional commercial installations where cybersecurity and physical durability both matter.
Key Capabilities
4K 8MP Image Quality
The 3840 x 2160 resolution captures scene-wide detail across retail floors, building lobbies, and long corridors. When footage needs to be reviewed after an incident, the 4K image provides the clarity needed to identify individuals and objects within a wide captured area.
110° Wide-Angle Coverage from a Compact Dome
The fixed 2.9mm lens delivers a 110° horizontal and 60° vertical field of view, making the M3128-LVE well suited to indoor ceilings and wall mounts where broad coverage from a single camera position is the priority. Its flat-faced turret-style dome also helps suppress IR reflections indoors.
Edge-Based AI Object Analytics
A built-in deep learning processing unit runs AXIS Object Analytics directly on the camera. It detects, classifies, tracks, and counts humans and vehicles without requiring a separate analytics server. This reduces irrelevant motion-based alerts and makes forensic search in recorded footage faster and more precise.
OptimizedIR Night Coverage
Built-in OptimizedIR supports surveillance in complete darkness up to 20m or more depending on the scene. Entrances, storerooms, covered walkways, and service corridors can be monitored through the night without requiring dedicated lighting infrastructure.
Axis Edge Vault Cybersecurity
Axis Edge Vault provides hardware-based protection with FIPS 140-3 Level 3 certified cryptographic key storage, secure boot, signed OS, and IEEE 802.1X support. For networked commercial installations, this level of device identity protection helps meet modern cybersecurity compliance expectations.
Best For
- Retail and Service Spaces: The 110° wide-angle lens and 4K resolution cover customer areas, aisles, service counters, and entry points from a single ceiling mount, while AI object detection supports meaningful alert filtering.
- Offices, Schools, and Corridors: The compact turret-style dome mounts discreetly on ceilings or walls in high-traffic indoor spaces including reception areas, hallways, classrooms, and shared workspaces where coverage breadth matters more than optical zoom.
- Outdoor Entries and Covered Approaches: IP66 weather protection, IK08 impact resistance, and an operating range of -30°C to 50°C make this camera suited to covered outdoor entry points, building facades, and sheltered commercial approaches.
- Installations Requiring Cybersecurity Compliance: Axis Edge Vault with FIPS 140-3 Level 3 certification and signed OS support makes the M3128-LVE appropriate for organisations with strict device security or network hardening requirements.
Why Choose the AXIS M3128-LVE
The AXIS M3128-LVE separates itself from entry-level 8MP dome cameras through its combination of on-camera AI and enterprise-grade cybersecurity. While many cameras at this resolution rely on server-side motion detection, the M3128-LVE runs AXIS Object Analytics on a built-in deep learning processing unit, classifying humans and vehicles at the edge. This matters for installers and end users who want fewer irrelevant alerts and faster forensic review without adding VMS server load. The camera also includes Axis Edge Vault with FIPS 140-3 Level 3 certified key storage, which is rarely included at this price point and camera size. Add IP66 and IK08 ratings, OptimizedIR for after-hours indoor and outdoor coverage, a 5-year warranty, and a design built to be repainted to match the installation environment, and the M3128-LVE justifies its place in professional commercial projects. Available through Security Wholesalers, it suits integrators and end users who need verifiable analytics and hardware security in a compact dome format.
Buyer Decision Tips
Fixed Lens Consideration: The AXIS M3128-LVE uses a fixed 2.9mm lens with no optical zoom adjustment. The 110° wide-angle view is the only physical framing this camera provides. Digital pan, tilt, and zoom allow electronic inspection within the captured 4K image, but the physical angle cannot be changed after installation. Confirm the mounting position covers the required scene before installation. If the site requires a narrower field of view or optical zoom for distant subjects, a varifocal lens model will be more appropriate.
Frame Rate at 4K: At maximum 3840 x 2160 resolution, the M3128-LVE captures at up to 12 or 15 fps depending on region and stream configuration. This is sufficient for most retail, office, and commercial monitoring scenarios, but may not suit applications that require smooth high-frame-rate capture such as fast-moving production lines or high-speed traffic monitoring. For those requirements, a lower resolution stream at higher frame rate can be configured, or a different camera model may be more suitable.
Key Features & Technical Specifications
| Model |
AXIS M3128-LVE |
| Product Type |
AI-Powered Turret-Style Dome Network Camera |
| Resolution |
8MP / 4K – 3840 x 2160 |
| Maximum Frame Rate |
12/15 fps |
| Image Sensor |
1/2.8″ CMOS |
| Lens |
2.9mm fixed lens, F2.0 |
| Horizontal Field of View |
110° |
| Vertical Field of View |
60° |
| Minimum Illumination |
0.22 lux colour / 0.05 lux black and white |
| Wide Dynamic Range |
Yes |
| IR Technology |
OptimizedIR |
| IR Range |
Up to 20m or more depending on scene |
| Video Compression |
H.264, H.265, Axis Zipstream |
| Analytics |
AXIS Object Analytics (human and vehicle detection, classification, tracking, counting), AXIS Scene Metadata, AXIS Live Privacy Shield, AXIS Video Motion Detection |
| Deep Learning |
Built-in deep learning processing unit |
| Local Storage |
microSD card slot supported |
| Power |
Power over Ethernet, PoE Class 3 |
| IP Rating |
IP66 |
| Vandal / Impact Rating |
IK08 |
| Operating Temperature |
-30°C to 50°C |
| Cybersecurity |
Axis Edge Vault, FIPS 140-3 Level 3 certified secure key storage, secure boot, signed OS, HTTPS encryption, IEEE 802.1X |
| Available Colours |
Black or white, designed for repaint |
| Warranty |
5 years |
Ideal Use Cases
Retail Stores and Service Areas
The 110° wide-angle lens covers large floor areas, aisles, and checkout counters from ceiling mount positions, while AXIS Object Analytics tracks and counts people moving through the space, supporting both security monitoring and operational review.
Office Lobbies and Reception Areas
The compact turret-style dome installs discreetly on ceilings in visitor-facing spaces. The flat-faced design reduces light reflections in glass-heavy environments, and 4K resolution captures facial and clothing detail useful for access and incident review.
School Hallways and Education Facilities
Wide corridor coverage from a single ceiling-mounted camera, combined with AI human detection, helps school administrators monitor movement through hallways, stairwells, and covered outdoor entries without requiring dense camera layouts.
Building Entrances and Covered Outdoor Areas
IP66 weather protection, IK08 impact resistance, and an operating temperature range of -30°C to 50°C make the M3128-LVE suited to outdoor walls and soffits above building entries, car park pedestrian routes, and sheltered external walkways.
Cybersecurity-Sensitive Commercial Sites
Organisations in finance, government, healthcare, and critical infrastructure can deploy the M3128-LVE knowing Axis Edge Vault provides FIPS 140-3 Level 3 certified key storage, signed firmware, and secure boot at the device level.
Choosing the Right Model
- Choose this model if: You need 8MP 4K resolution with on-camera AI object analytics, a wide 110° field of view for general area monitoring, outdoor-rated durability with IK08 vandal resistance, and enterprise cybersecurity with Axis Edge Vault in a compact dome form factor.
- Choose a different model if: The site requires optical zoom to monitor a distant subject or a narrow entrance lane. The fixed 2.9mm lens cannot be adjusted, so a varifocal dome or turret camera would provide better framing flexibility for those scenarios. If the application also needs built-in audio, note that the M3128-LVE has no built-in microphone or speaker, so an external audio device or a camera with integrated audio support would be required.
FAQs
- What types of objects can AXIS Object Analytics detect on the M3128-LVE?
AXIS Object Analytics running on the M3128-LVE’s built-in deep learning processing unit can detect and classify humans and vehicles. It supports counting, tracking, and zone-based trigger scenarios. Because this processing happens on the camera itself, analytics results are available without requiring a dedicated analytics server or additional software licence.
- Does the AXIS M3128-LVE have built-in audio?
No. The M3128-LVE has no built-in microphone or speaker. If audio recording or voice communication is required at the installation point, a separate external audio device or a different camera model that includes integrated audio hardware would need to be specified.
- Is the M3128-LVE suitable for ceiling mounting indoors?
Yes. The turret-style dome profile is designed for ceiling and wall mounting in indoor commercial spaces. The flat-faced housing helps reduce IR reflections inside buildings, and the 110° wide-angle view covers broad zones from a single compact mounting point. It suits retail ceilings, corridor walls, office lobbies, and classroom mounts where a low-profile camera appearance is preferred.
- What is the maximum IR range of the AXIS M3128-LVE?
The built-in OptimizedIR supports coverage up to 20m or more depending on the scene. Actual range varies based on reflectivity of surfaces, ambient light levels, and scene content. For indoor corridors and entrances with walls and floors nearby, the effective IR range is typically consistent. Open outdoor areas with lower surface reflectivity may see variation from the stated range.
- What cybersecurity certifications does the M3128-LVE support?
The AXIS M3128-LVE includes Axis Edge Vault, which provides FIPS 140-3 Level 3 certified cryptographic key storage and operations. It also supports secure boot, signed operating system, HTTPS encryption, and IEEE 802.1X network authentication. These features support deployments in environments with formal network security requirements or device integrity policies.
- Can the AXIS M3128-LVE store footage locally without a recorder?
Yes. The camera includes a memory card slot that supports local microSD storage. This allows edge recording directly on the camera, which is useful for standalone deployments, as a backup recording layer alongside a network recorder, or in locations where network bandwidth is limited. The specific card capacity supported should be confirmed against Axis documentation for this model.
- Where can I purchase the AXIS M3128-LVE in Australia?
The AXIS M3128-LVE is part of the Security Wholesalers range and is available for both trade and project supply. Security Wholesalers stocks AXIS Communications products for integrators, installers, and commercial end users across Australia.
