Product SKU: M3128-LVE
Product Overview
For commercial sites that need sharp 4K detail and intelligent event detection in a compact, discreet housing, the AXIS M3128-LVE delivers an AI-powered turret-style dome camera built for both indoor and outdoor installation. Featuring 3840 x 2160 resolution from a 1/2.8″ CMOS sensor, a fixed 2.9mm lens with a 110° horizontal field of view, and built-in OptimizedIR up to 20m, it covers entrances, corridors, retail floors, and sheltered outdoor positions without drawing unnecessary attention. Equipped with a built-in deep learning processing unit and AXIS Object Analytics preinstalled, it detects, classifies, tracks, and counts humans and vehicles directly on the device. It also integrates Axis Edge Vault with FIPS 140-3 Level 3 certified secure key storage, IP66 weather protection, and IK08 impact resistance. With H.265 and Axis Zipstream compression, local microSD storage support, and a 5-year warranty, the M3128-LVE is well suited to retail, offices, schools, hospitality venues, and covered outdoor commercial access points.
Key Capabilities
8MP 4K Resolution
Captures up to 3840 x 2160 video from a 1/2.8″ CMOS sensor, delivering the image detail needed for identifying individuals, reading signage, and producing usable recorded evidence across retail floors, corridors, and building entrances.
Edge-Based AI Object Analytics
The built-in deep learning processing unit runs AXIS Object Analytics on the camera itself, detecting, classifying, tracking, and counting humans and vehicles without relying on server processing. This reduces irrelevant motion alerts and simplifies forensic searches in recorded footage.
Wide 110° Fixed Lens Coverage
The 2.9mm F2.0 lens provides a 110° horizontal and 60° vertical field of view, making it well suited to broad indoor scene coverage from a single ceiling or wall mounting point in corridors, lobby areas, shop floors, and classrooms.
OptimizedIR Night Visibility
Built-in OptimizedIR illumination extends visibility up to 20m in complete darkness, maintaining useful black-and-white footage at night without requiring external lighting. This supports round-the-clock coverage at entrances, service areas, and outdoor access points.
Axis Edge Vault Cybersecurity
Axis Edge Vault provides hardware-based cybersecurity with FIPS 140-3 Level 3 certified secure cryptographic key storage. Combined with secure boot, signed OS, HTTPS, and IEEE 802.1X support, it meets rigorous network security requirements for commercial surveillance deployments.
Best For
- Indoor Ceilings with Wide Coverage Needs: The 110° horizontal field of view and compact turret dome profile make the M3128-LVE effective for corridor ceilings, reception desks, classroom walls, and retail floors where a single camera must cover a broad area.
- Entrances and Mixed-Light Scenes: WDR handles high-contrast conditions near glass doors, sun-facing entries, and window-lined corridors, preserving useful detail in both bright and shaded areas of the same frame.
- Sites Requiring Intelligent Alert Filtering: AXIS Object Analytics at the edge separates human and vehicle activity from background motion, making the M3128-LVE suitable for locations that require meaningful event notifications rather than simple motion triggers.
- Outdoor Commercial Positions with Security Demands: IP66 weather protection, IK08 impact resistance, and an operating range of -30°C to 50°C make this camera practical for sheltered outdoor walls, covered walkways, and external building entrances in Australian commercial environments.
Why Choose the AXIS M3128-LVE
The AXIS M3128-LVE separates itself from basic 4K dome cameras through the combination of a built-in deep learning processing unit and AXIS Object Analytics running directly on the device. Where a standard 4K camera records everything and relies on the recorder or VMS to filter events, the M3128-LVE classifies humans and vehicles at the camera itself, reducing server load and improving the speed of recorded footage searches. The Axis Edge Vault platform, with FIPS 140-3 Level 3 certified secure key storage, secure boot, and signed OS, goes well beyond the cybersecurity provisions found on comparable fixed-lens dome cameras. The 5-year warranty and support for local microSD storage add practical value for long-term deployments. Available at Security Wholesalers, the M3128-LVE is a practical specification choice for retail, education, and commercial office projects where AI-filtered alerting, 4K detail, and hardware-level cybersecurity are all required from a single compact dome camera.
Buyer Decision Tips
Fixed Lens vs. Varifocal: The M3128-LVE uses a fixed 2.9mm lens with a 110° field of view and no optical zoom adjustment. This is well suited to general area monitoring from a close or mid-range ceiling mount, but is not the right choice for positions that require a narrower angle, a longer reach, or the ability to frame a specific zone precisely during installation. If the mounting position is further from the area of interest or if coverage needs to be tightly directed, a varifocal dome camera would provide more installation flexibility.
4K Storage and Bandwidth Planning: The M3128-LVE records at up to 3840 x 2160 at 12/15fps. At full 4K resolution across multiple channels, storage and bandwidth requirements increase significantly compared to 2MP or 4MP deployments. Axis Zipstream with H.265 reduces this substantially by lowering bitrate during low-activity periods, but recorders, network switches, and storage capacity should be sized for 4K streams before committing to a multi-camera deployment.
Key Features & Technical Specifications
| Model |
AXIS M3128-LVE |
| Product Type |
AI-Powered Turret-Style Dome Network Camera |
| Resolution |
8MP / 4K – 3840 x 2160 |
| Maximum Frame Rate |
12/15 fps |
| Image Sensor |
1/2.8″ CMOS |
| Lens |
Fixed 2.9mm, F2.0 |
| Horizontal Field of View |
110° |
| Vertical Field of View |
60° |
| Minimum Illumination |
0.22 lux colour / 0.05 lux black and white |
| Wide Dynamic Range |
Yes |
| IR Technology |
OptimizedIR, up to 20m (scene dependent) |
| Compression |
H.264, H.265, Axis Zipstream |
| Analytics |
AXIS Object Analytics (human and vehicle detection), AXIS Scene Metadata, AXIS Live Privacy Shield, AXIS Video Motion Detection |
| Deep Learning |
Built-in deep learning processing unit |
| Cybersecurity |
Axis Edge Vault, FIPS 140-3 Level 3 certified secure key storage, secure boot, signed OS, HTTPS, IEEE 802.1X |
| Power |
PoE Class 3 |
| Local Storage |
Memory card slot supported |
| Audio |
No built-in audio support |
| IP Rating |
IP66 |
| Vandal / Impact Rating |
IK08 |
| Operating Temperature |
-30°C to 50°C |
| Available Colours |
Black or white, designed for repaint |
| Warranty |
5-year warranty |
Ideal Use Cases
Retail Store Interiors
The 110° wide field of view and 8MP resolution allow a single camera to cover broad retail floor areas, service counters, and entry zones. AXIS Object Analytics supports detection of customer and staff movement without triggering constant motion-based alerts from product displays or environmental changes.
Office Corridors and Reception Areas
The compact turret dome profile and discreet black or white housing blend into office and commercial interiors. The wide coverage angle handles long corridor runs and open reception spaces from a single ceiling position, with 4K detail supporting identification at entry points.
School and Education Facilities
With IK08 impact resistance and a discreet form factor, the M3128-LVE suits classroom walls, hallways, administration areas, and covered outdoor entries at schools. OptimizedIR supports monitoring during after-hours periods when lighting is reduced or switched off.
Building Entrances and Glass Door Zones
WDR handles the contrast between bright outdoor light and darker interior spaces near glass entries, preserving legible detail across the full frame. This makes the M3128-LVE well suited to lobby entrances, foyers, and access control points where lighting conditions shift throughout the day.
Covered Outdoor Commercial Positions
IP66 weather protection and an operating range of -30°C to 50°C allow the M3128-LVE to be mounted under eaves, on covered walkways, and at sheltered outdoor entrances to commercial buildings. Axis Edge Vault cybersecurity ensures the device maintains secure operation in network-connected outdoor environments.
Choosing the Right Model
- Choose this model if: The installation requires 4K image detail, edge-based AI human and vehicle classification, hardware-level cybersecurity via Axis Edge Vault, and reliable day/night performance in a compact turret dome for indoor ceilings, corridors, wide entrances, or sheltered outdoor positions.
- Choose a different model if: The mounting position requires optical zoom or a narrower field of view to cover a longer distance or a specific zone precisely. A varifocal dome camera allows the lens angle to be adjusted during installation, making it more suitable for positions where the fixed 110° view of the M3128-LVE would capture too much surrounding area or fall short on reach.
- Choose a different model if: The site requires two-way audio communication. The M3128-LVE has no built-in audio support, so locations needing live voice capability at an entry point or service counter would require a camera with confirmed built-in microphone and speaker.
FAQs
- What makes the AXIS M3128-LVE different from a standard 4K dome camera?
The M3128-LVE includes a built-in deep learning processing unit and AXIS Object Analytics preinstalled, allowing the camera to detect and classify humans and vehicles at the edge without server-side processing. It also includes Axis Edge Vault with FIPS 140-3 Level 3 certified secure key storage, which goes well beyond the basic cybersecurity provisions found on most comparable fixed-lens dome cameras in this class.
- Can the AXIS M3128-LVE be mounted outdoors?
Yes. The M3128-LVE carries an IP66 weather protection rating and IK08 impact resistance, and operates across a temperature range of -30°C to 50°C. It is suitable for covered outdoor positions such as sheltered building entries, eave mounts, and outdoor corridors. For fully exposed positions with direct rain exposure, ensuring the mounting accessory also carries a suitable weather rating is recommended.
- What analytics does AXIS Object Analytics support on this camera?
AXIS Object Analytics runs on the built-in deep learning processing unit and supports detection, classification, tracking, and counting of humans and vehicles directly on the device. Additional analytics preinstalled include AXIS Scene Metadata, AXIS Live Privacy Shield, AXIS Video Motion Detection, and an active tampering alarm. These run at the edge without requiring a separate analytics server.
- Does the fixed 2.9mm lens limit where this camera can be installed?
The fixed 2.9mm lens delivers a 110° horizontal field of view, making it effective for close to mid-range general area coverage. It cannot be optically adjusted to suit longer distances or narrower angles. Positions requiring precise framing of a specific zone, a long corridor far from the camera, or a distant outdoor approach are better served by a varifocal model where the lens angle can be set during installation.
- What compression does the AXIS M3128-LVE support and how does it affect storage?
The camera supports H.264, H.265, and Axis Zipstream. Zipstream dynamically reduces bitrate during low-activity periods while retaining full detail when relevant events occur. At 4K resolution, this has a meaningful impact on storage and bandwidth requirements across multi-camera deployments. H.265 with Zipstream enabled provides the most efficient storage outcome for continuous 4K recording.
- Is the AXIS M3128-LVE available through Security Wholesalers?
Yes, the AXIS M3128-LVE is part of the Security Wholesalers range. It is available for commercial, integrator, and project purchasing alongside compatible Axis mounting accessories, recorders, and network switches. The camera carries a 5-year manufacturer warranty and supports standard Axis VMS and NVR integration through ONVIF and native Axis protocols.
Additional Information
Datasheet-axis-m3128-lve-dome-camera
