Product SKU: AXIS C1110-E
Product Overview
The AXIS C1110-E Network Cabinet Speaker is a stylish all-in-one network speaker designed for clear voice messages, background music, live announcements and event-triggered audio. It features Power over Ethernet for one-cable power and connectivity, a built-in 7W Class D amplifier, preconfigured digital signal processing, 96 dB maximum sound pressure level, 60 Hz–20 kHz frequency response, a 4-inch dynamic cone speaker and 1.25-inch dome tweeter. With two-way audio, echo cancellation, a built-in microphone for remote health testing, AXIS Audio Manager Edge, SIP support and open platform integration, it is ideal for schools, retail stores, offices, warehouses, public facilities, hospitality venues and semi-protected outdoor areas.
Why Choose the AXIS C1110-E Network Cabinet Speaker
The AXIS C1110-E is ideal for organisations that need a flexible speaker for both professional voice messaging and quality background music. Its all-in-one network design removes the need for separate amplifiers or dedicated audio cabling, while PoE keeps installation simple using one standard network cable. AXIS Audio Manager Edge comes built in, allowing users to manage zones, users, content, schedules, prioritised messages and health monitoring from a browser. With open integration support for VMS, VoIP, analytics and mass notification workflows, the speaker can support everyday communication, safety announcements, customer messaging, music and security event responses from one system.
Key Capabilities
Clear Voice and Rich Background Music
The AXIS C1110-E combines a 4-inch dynamic cone speaker, 1.25-inch dome tweeter and preconfigured DSP to deliver clear voice messages and rich background music. This makes it useful for public address, retail ambience, customer messaging, staff announcements and scheduled audio.
PoE Network Audio Installation
Power over Ethernet allows one network cable to provide both power and connectivity. This removes the need for separate audio cabling or external amplifier equipment, helping simplify installation on walls, ceilings and poles in suitable indoor or semi-protected outdoor locations.
Two-Way Audio with Echo Cancellation
The built-in microphone supports two-way audio with optional full-duplex echo cancellation, allowing authorised users to communicate through the speaker where required. This can support situational awareness, remote response, voice confirmation and communication workflows in connected Axis systems.
Remote Health Testing
The built-in microphone enables Auto Speaker Test and remote health monitoring, helping users confirm that the speaker is working without needing to visit the site. This is valuable for multi-speaker systems, safety messaging, scheduled announcements and public address reliability.
Built-In Audio Management
AXIS Audio Manager Edge is built in, supporting zone management, content management, scheduling, content prioritisation, health monitoring and user permissions. This makes it easy to manage audio locally or remotely through a standard browser without separate audio management hardware.
Key Features
-
All-in-One Network Speaker: The AXIS C1110-E combines speaker hardware, amplifier, DSP and audio management software in one unit. This reduces the need for separate amplifiers, audio servers or dedicated speaker cabling, making installation cleaner and easier to manage.
-
Power over Ethernet: PoE allows the speaker to receive power and data over one standard network cable. This simplifies installation, supports centralised network management and makes it easier to deploy audio across multiple areas using standard IT infrastructure.
-
Clear Voice Messaging: Preconfigured digital signal processing helps optimise speech clarity for live, scheduled and event-triggered announcements. This is useful for safety instructions, staff communication, customer announcements, public address messages and operational audio workflows.
-
Rich Background Music: With 60 Hz–20 kHz frequency response and a bass-reflex speaker design, the AXIS C1110-E provides a deeper sound impression suitable for background music. This makes it useful for retail, hospitality, reception, showroom and customer-facing environments.
-
Two-Way Audio: The built-in microphone enables two-way audio with echo cancellation, supporting real-time communication where required. This can help operators speak to people on site, confirm messages, respond to incidents or support interactive audio workflows.
-
Remote Health Monitoring: Auto Speaker Test uses the built-in microphone to verify speaker function remotely. This helps organisations maintain confidence that announcements and alerts will play correctly, reducing the need for manual on-site testing.
-
AXIS Audio Manager Edge Included: Built-in AXIS Audio Manager Edge supports audio zones, user management, scheduled content, live and prerecorded announcements, message priority and health monitoring. This gives users strong audio control without separate management hardware.
-
SIP and VoIP Integration: SIP support allows the speaker to integrate with compatible VoIP phone systems, PBX platforms and SIP endpoints. This makes it practical for live announcements, paging, callouts and communication workflows using existing IP telephony systems.
-
Open Platform Integration: The speaker supports open integration through the Axis platform, including VAPIX and ACAP. This allows integration with video management systems, analytics, mass notification systems and event-driven security workflows.
-
Flexible Mounting: The easy-click mounting bracket supports wall, ceiling and pole installation. The speaker can be installed horizontally or vertically, making it adaptable for retail spaces, corridors, warehouses, offices, hospitality areas and semi-protected outdoor placements.
Specifications Summary
| Feature |
Specification |
| Model |
AXIS C1110-E Network Cabinet Speaker |
| Product Type |
Network Cabinet Speaker / All-in-One IP Speaker |
| Primary Function |
Live announcements, prerecorded messages, scheduled audio, event-triggered messages and background music |
| Speaker Type |
Two-way bass-reflex cabinet speaker |
| Speaker Components |
4-inch dynamic cone speaker and 1.25-inch dome tweeter |
| Amplifier |
Built-in 7W Class D amplifier |
| Maximum Sound Pressure Level |
96 dB |
| Frequency Response |
60 Hz–20 kHz |
| Horizontal Speaker Coverage |
140° |
| Vertical Speaker Coverage |
90° |
| Digital Signal Processing |
Built-in and preconfigured DSP |
| Audio Streaming |
One-way and two-way audio, mono, with optional full-duplex echo cancellation |
| Built-In Microphone |
Yes, can be disabled |
| External Audio Input |
External microphone and line-in support |
| Built-In Microphone Frequency Range |
50 Hz–12 kHz |
| Remote Health Testing |
Auto Speaker Test using built-in microphone |
| Audio Management |
AXIS Audio Manager Edge built in |
| Zone Management |
Up to 200 speakers divided into 20 zones through AXIS Audio Manager Edge |
| Content Management |
Music, live announcements and prerecorded announcements |
| Scheduling |
Supported through AXIS Audio Manager Edge |
| Content Prioritisation |
Urgent messages can interrupt scheduled content |
| Multi-Site Management |
AXIS Audio Manager Center support |
| Advanced Audio Management |
AXIS Audio Manager Pro support, sold separately |
| Audio Codecs |
AAC LC, G.711 PCM, G.726 ADPCM, Axis µ-law, WAV, MP3 and Opus |
| SIP / VoIP Support |
SIP support for VoIP and PBX integration |
| Open Integration |
VAPIX, ACAP and one-click cloud connection support |
| Video Management Compatibility |
Compatible with AXIS Camera Station Edge, AXIS Camera Station Pro, AXIS Camera Station 5 and selected partner VMS platforms |
| Mass Notification Compatibility |
Singlewire InformaCast, Intrado Revolution, Lynx and Alertus support where configured |
| Network Connection |
Standard network connection with PoE for power and connectivity |
| Installation |
Wall, ceiling and pole mounting support using easy-click mounting bracket |
| Orientation |
Horizontal or vertical installation |
| Installation Environment |
Indoor and semi-protected outdoor installation, such as under eaves |
| Available Colours |
White and black variants |
| Typical Applications |
Public address, background music, business announcements, safety messages, event-triggered audio, intrusion deterrence and customer communication |
| Warranty |
5-year warranty |
Ideal Use Cases
- Retail Stores and Showrooms – Suitable for background music, customer announcements, promotional messages, closing notices, staff callouts and event-triggered deterrence messages.
- Schools and Education Sites – Useful for bells, scheduled announcements, safety messages, lockdown instructions, evacuation notices and zone-based communication across classrooms or common areas.
- Commercial Buildings and Offices – Practical for reception areas, lobbies, meeting spaces, corridors, staff areas and shared facilities requiring clear voice messages or background music.
- Warehouses and Industrial Facilities – Ideal for operational announcements, safety alerts, loading dock messages, event-triggered warnings and clear audio communication in larger indoor spaces.
- Hospitality and Public Facilities – Suitable for cafés, restaurants, waiting areas, public buildings and semi-protected outdoor locations where voice messages and music need to be managed centrally.
Understanding Network Cabinet Speaker Workflows
The AXIS C1110-E works as a complete IP speaker rather than a traditional passive speaker. It connects directly to the network using PoE, includes its own amplifier and DSP, and is managed through Axis audio software. This allows the speaker to play live announcements, scheduled messages, prerecorded clips, event-triggered warnings and background music. Because it includes a microphone, it can also support two-way audio and remote speaker health testing, helping users manage communication and reliability from anywhere.
| Audio Function |
What It Provides |
Best For |
| Live Announcements |
Real-time voice messages through the network speaker |
Public address, staff callouts, customer messages and urgent instructions |
| Scheduled and Prerecorded Audio |
Automated playback of messages, bells, music or reminders |
Schools, retail stores, commercial buildings, hospitality and routine communication |
| Two-Way Audio |
Communication through the speaker using the built-in microphone and echo cancellation |
Remote response, message confirmation, security workflows and interactive communication |
| Remote Health Testing |
Auto Speaker Test verifies speaker function using the built-in microphone |
Multi-speaker systems, safety alerts, public address reliability and reduced site visits |
Tip:
Use the AXIS C1110-E when a site needs a large cabinet-style network speaker for clear voice messaging, background music and managed audio zones. Confirm speaker placement, PoE power design, indoor or semi-protected outdoor exposure, audio zones, SIP requirements and management software before installation.
FAQs
- What is the AXIS C1110-E Network Cabinet Speaker used for?
The AXIS C1110-E is used for live announcements, prerecorded messages, scheduled audio, event-triggered voice messages and background music. It is suitable for retail stores, schools, offices, warehouses, public facilities, hospitality venues and other sites that need clear managed network audio.
- Does the AXIS C1110-E use PoE?
Yes, the AXIS C1110-E uses Power over Ethernet for power and network connectivity. This allows one standard network cable to power the speaker and connect it to the audio system, reducing the need for separate audio cabling, local power supplies or external amplifier equipment.
- Does the AXIS C1110-E support two-way audio?
Yes, the AXIS C1110-E supports two-way audio with optional full-duplex echo cancellation. Its built-in microphone allows authorised users to communicate through the speaker, support interactive workflows and gain better situational awareness when the system is configured for two-way communication.
- Can the AXIS C1110-E be remotely tested?
Yes, the built-in microphone enables Auto Speaker Test for remote health testing. This helps verify that the speaker is working without visiting the site, which is valuable for public address, safety messages, scheduled announcements and multi-speaker audio systems.
- What audio management software is included?
AXIS Audio Manager Edge is built in, allowing users to manage zones, content, schedules, user permissions, content priority and health monitoring. It can divide up to 200 speakers into 20 zones, making it suitable for structured local audio systems.
- Can the AXIS C1110-E be installed outdoors?
The AXIS C1110-E is suitable for indoor and semi-protected outdoor installations, such as under eaves. It should not be treated as a fully exposed outdoor speaker unless the installation conditions match Axis guidance and the speaker is protected from direct severe weather exposure.
Additional Information
Datasheet-axis-c1110-e-network-cabinet-speaker
