Product SKU: AXIS-02330-001 P3267-LVE
Product Overview
Designed for integrators specifying professional outdoor dome cameras on commercial, institutional, and public-sector projects, the Axis P3267-LVE combines 5MP resolution with a 3-8mm varifocal lens, deep learning edge analytics, and a housing rated to both IP66 and IK10 in a single unit. Featuring Forensic WDR and Lightfinder technology, it maintains usable detail across the backlit entrances, transitional lighting conditions, and high-contrast outdoor scenes that push simpler domes into overexposed or underexposed footage. Equipped with built-in IR and OptimizedIR, the illumination beam automatically adjusts to match the current lens position, keeping night coverage consistent whether the lens is set wide at 3mm or narrowed to 8mm. It also incorporates Axis Zipstream compression, which intelligently reduces bandwidth and storage overhead on static background regions while preserving full detail on moving subjects and evidentiary content. This makes the P3267-LVE well suited to multi-camera enterprise deployments where per-camera storage costs accumulate across a site and edge intelligence is required without adding a dedicated analytics server.
Key Capabilities
Deep Learning Edge Analytics via Axis SoC
The Axis System-on-Chip processes deep learning analytics directly on the camera, enabling accurate event detection and metadata generation without a remote server. This reduces infrastructure complexity and keeps analytical response local to the point of capture, which is valuable across distributed multi-site deployments where centralised processing is impractical.
Forensic WDR for High-Contrast Outdoor Scenes
Forensic WDR captures simultaneous detail in bright highlights and deep shadows within the same frame. This is particularly relevant at glass-fronted building entrances, covered walkways, and outdoor positions where strong sunlight or artificial light creates contrast levels that cause standard sensors to clip either the bright or dark areas of the scene.
Lightfinder Low-Light Sensitivity
Lightfinder extends colour detail and image clarity into low-ambient conditions before IR illumination is engaged. This matters most during transitional lighting periods such as dusk, dawn, and poorly lit covered environments, where a camera without Lightfinder would lose colour accuracy well before switching to monochrome IR mode.
OptimizedIR Adaptive Night Illumination
Built-in IR with OptimizedIR automatically narrows or widens the illumination spread to match the varifocal lens position. This prevents foreground overexposure at close range on a wide setting and maintains useful IR reach at longer focal positions, eliminating the uneven illumination common on varifocal cameras with fixed-beam IR emitters.
Axis Zipstream Intelligent Compression
Zipstream analyses each frame and reduces bitrate selectively on static background regions while maintaining full resolution on moving subjects and areas carrying forensic value. Across a site with many cameras, the cumulative reduction in average bitrate translates to meaningful NVR storage savings without degrading footage that may be required for investigation.
IP66 and IK10 Outdoor Construction
IP66 weatherproofing protects against dust ingress and high-pressure water jets. The IK10 rating confirms the dome enclosure withstands a 20-joule impact under IEC 62262, making the P3267-LVE suitable for exposed public-facing positions mounted within reach where tampering or accidental physical contact is a realistic concern.
Best For
- Backlit Entry Points and Glass-Fronted Lobbies: Forensic WDR resolves the extreme contrast at commercial doorways, while the varifocal lens allows precise framing of the threshold zone and approaching foot traffic at the time of commissioning.
- Exposed Exterior Positions on Institutional Buildings: IK10 and IP66 ratings meet specified requirements for school perimeters, healthcare campuses, and government facilities where both weather exposure and physical interference are ongoing risks.
- Large Multi-Camera Enterprise Deployments: Zipstream reduces per-camera storage overhead across sites with many cameras, and on-device deep learning analytics reduces the processing demand placed on centralised VMS infrastructure.
- Projects Requiring Edge Intelligence Without a Dedicated Analytics Server: The Axis SoC runs deep learning analytics on the device itself, making the P3267-LVE practical for sites where adding and maintaining a separate analytics server is not operationally or financially viable.
Why Choose the Axis P3267-LVE
The P3267-LVE is built around a specific combination that a lower-cost outdoor dome cannot replicate. The genuine Axis System-on-Chip delivers deep learning analytics processed at the edge, Forensic WDR handles backlit contrast at the sensor level rather than through post-processing approximations, and Lightfinder preserves colour detail in low-ambient conditions before the camera switches to IR. The 3-8mm varifocal range gives installers meaningful framing control across different mounting heights and site geometries without stocking multiple fixed-lens models. OptimizedIR ties the illumination beam directly to the current lens position, which is a level of integration absent from standard outdoor domes using fixed IR emitters. Zipstream then reduces storage overhead intelligently, without applying blanket compression that degrades evidentiary frames. For integrators and end users sourcing cameras through Security Wholesalers, the P3267-LVE is a professional outdoor dome specification where imaging quality, edge intelligence, and long-term deployment efficiency are all confirmed, not marketing claims.
Buyer Decision Tips
Mounting Height and Varifocal Lens Setting: The 3-8mm range provides a wide field of view at the 3mm end and a narrower, more directed framing at 8mm. Before installation, calculate the mounting height against the width of the area you need to cover. A camera positioned at 3 metres covering a 4 to 5 metre entrance width will suit a mid-range focal position. For longer approaches or higher mounting positions, adjust toward 8mm during commissioning to maintain useful subject size in frame. Setting this correctly on day one avoids a return visit for re-framing.
VMS Compatibility for Analytics Access: The P3267-LVE processes deep learning analytics within the Axis ACAP ecosystem and generates metadata that feeds into compatible video management platforms. Deploying this camera on a recorder that supports only basic ONVIF video streaming will still capture 5MP footage, but the analytical output from the Axis SoC will not be accessible or actionable. Confirm your VMS or NVR supports Axis metadata and event integration before specifying this camera on analytics-dependent projects, as this determines whether the edge processing hardware delivers its full value.
Key Features & Technical Specifications
| Model |
Axis P3267-LVE |
| Part Number |
02330-001 |
| Resolution |
5 megapixel |
| Frame Rate |
Up to 30 fps |
| Lens Type |
Varifocal |
| Focal Length |
3-8mm |
| Housing Type |
Outdoor dome |
| IR Illumination |
Built-in with OptimizedIR |
| Wide Dynamic Range |
Forensic WDR |
| Low-Light Technology |
Lightfinder |
| Analytics |
Deep learning on the edge via Axis SoC |
| Analytics Platform |
Axis Camera Application Platform (ACAP) compatible |
| Compression |
Axis Zipstream technology |
| Weather Protection |
IP66 |
| Impact Protection |
IK10 |
| Cybersecurity |
Built-in cybersecurity features |
| Processing Platform |
Axis System-on-Chip (SoC) |
Ideal Use Cases
Commercial Building Entry Points
Forensic WDR manages the intense backlit contrast typical of glass-fronted lobbies and covered doorways, while the 3-8mm varifocal lens allows the installer to frame the exact doorway threshold and approaching pedestrian zone without swapping optics between different mounting positions.
School and Campus Perimeters
IK10 vandal resistance and IP66 weatherproofing make the P3267-LVE suited to exposed mounting positions on school buildings, covered walkways, and campus perimeter structures where both deliberate interference and ongoing weather exposure are standard operational conditions.
Government and Public Infrastructure
Built-in cybersecurity features address the data protection and network integrity requirements typical of public-sector specifications. The Axis SoC provides a trusted, auditable edge processing environment compatible with ACAP analytics applications applicable to government and critical infrastructure deployments.
Covered and Structured Car Parks
Lightfinder sensitivity and OptimizedIR night illumination keep the P3267-LVE effective across the variable, often dim conditions of covered car park environments. The varifocal lens adapts to different bay widths and ceiling heights across a single site without requiring multiple fixed-lens camera variants.
Large Enterprise and Institutional CCTV Systems
Zipstream reduces per-camera storage demand across sites with dozens of cameras, lowering NVR capacity requirements at scale. The on-device analytics capability also reduces the processing load placed on centralised infrastructure, making the P3267-LVE a practical choice for expanding or upgrading enterprise-scale systems.
Choosing the Right Model
- Choose this model if: You need a 5MP outdoor dome with a varifocal lens for flexible commissioning across varied mounting positions and scene geometries, IK10 and IP66 protection for exposed public-facing exterior installations, and deep learning analytics processed on the device without an external analytics server.
- Choose a different model if: Your project is entirely indoor with no weather or impact exposure requirements and analytics capability is not part of the brief. A fixed-lens indoor dome at a lower price point covers that scope without the additional cost of outdoor-rated construction and edge processing hardware.
- Choose a different model if: Your application requires active deterrence outputs such as a built-in audible alert or visible light strobe triggered by on-device detection. The P3267-LVE is focused on imaging quality, edge intelligence, and environmental durability rather than integrated on-device deterrence outputs.
FAQs
- What does IK10 mean in practical terms for an outdoor dome mounted within public reach?
IK10 is the highest classification under IEC 62262, confirming the dome enclosure can withstand an impact of 20 joules. For the P3267-LVE, this means the housing resists deliberate tampering attempts, accidental contact from maintenance equipment, and minor projectile impacts without the dome cracking or the lens shifting, which is directly relevant at positions mounted within arm’s reach on building exteriors.
- Can the varifocal lens be adjusted after the camera is mounted to the ceiling or wall soffit?
Yes. The 3-8mm varifocal lens is set during installation to achieve the correct field of view for that specific mounting position and coverage zone. This allows a single camera model to serve a narrow approach corridor at 8mm or a wide entrance area at 3mm. Adjustment requires physical access to the camera, so calculating the correct focal position before finalising the cable entry point saves unnecessary revisits after commissioning.
- Why does OptimizedIR matter specifically on a varifocal camera rather than a fixed-lens model?
On a fixed-lens camera, the IR beam spread can be matched to the single focal length at the factory. On a varifocal camera, the field of view changes depending on where the lens is set. Without automatic beam adjustment, a fixed IR emitter will overexpose close subjects at wide focal lengths and under-illuminate subjects at longer focal lengths. OptimizedIR synchronises the IR spread to the current lens position, so illumination remains correctly matched regardless of how the 3-8mm lens is configured during commissioning.
- Will the deep learning analytics work if the P3267-LVE is connected to a basic NVR or DVR?
The camera will still record 5MP video to any ONVIF-compatible recorder. However, the analytical output and metadata generated by the Axis SoC are only accessible and actionable through a VMS or NVR platform that supports Axis event and metadata integration within the ACAP ecosystem. On a basic recorder with no Axis integration, the edge analytics hardware is present but its output cannot be utilised. Confirm VMS compatibility before specifying this camera on analytics-dependent projects.
- How does Zipstream reduce storage without degrading footage used in investigations?
Zipstream analyses each frame and identifies regions of low informational value, such as static walls, floors, and sky areas, where bitrate can be reduced with no meaningful loss. On regions containing moving subjects, faces, vehicles, or other forensically relevant content, full resolution is maintained. The result is a lower average bitrate across the recording session without compressing the frames most likely to be reviewed during an incident investigation.
- Is the P3267-LVE suitable for surface mounting to a rendered or concrete wall without a separate back box?
The P3267-LVE is designed for direct surface mounting using the supplied hardware. Where conduit entry, specific wall construction types, or flush-mount aesthetics are required, compatible Axis mounting accessories are available separately from the camera itself. Review the installation guide and the Axis accessory catalogue to confirm the correct bracket or back box for each site condition before finalising the cable routing plan.
- Where can the Axis P3267-LVE be sourced in Australia and is a datasheet available for project documentation?
The Axis P3267-LVE (02330-001) is available through Security Wholesalers, with the product datasheet accessible directly from the product listing page. The datasheet includes full optical specifications, mounting dimensions, power draw, supported compression formats, and accessory compatibility information required for project design submissions and specification documentation.
