Product SKU: M4308-PLE
Product Overview
Wide-area monitoring across a retail floor, school foyer, or outdoor building entrance typically demands multiple fixed cameras to cover all directions. The AXIS M4308-PLE addresses this with a single compact dome delivering 12MP panoramic coverage through a 1.3mm fixed stereographic lens with Sharpdome 360, providing a complete 360-degree overview from ceiling mount or a 180-degree view from wall mount. Featuring Axis Lightfinder with a minimum colour illumination of 0.19 lux, Forensic WDR, and OptimizedIR built-in IR, it maintains usable image quality across varied lighting from bright mixed-light foyers through to complete darkness outdoors. Equipped with a built-in deep learning processing unit, it runs AXIS Object Analytics on the camera without relying on server-side resources. It also integrates 4 built-in microphones with voice enhancer and noise suppression, digital roll for post-installation alignment, Axis Zipstream with H.264 and H.265 compression, and Axis Edge Vault hardware cybersecurity. Rated IP66 and IK10 and operating across -40 degrees Celsius to 50 degrees Celsius, the AXIS M4308-PLE suits professional indoor and outdoor panoramic deployments requiring audio capture, on-camera analytics, and hardware-level network security from a single mounting point.
Key Capabilities
Ceiling and Wall Coverage Modes
Ceiling mounting produces a complete 360-degree overview covering all directions simultaneously, while wall mounting produces a 180-degree view suited to building entries, corridors, and directional approaches. One camera handles monitoring tasks that would otherwise require several fixed-lens units at separate positions across the same space.
Stereographic Lens with Sharpdome 360
The 1.3mm stereographic lens prioritises resolution toward the outer edges of the panoramic image where standard fisheye optics typically sacrifice practical detail. Sharpdome 360 maintains sharpness across the full 2880 x 2880 pixel scene, making it possible to identify people and activity throughout the entire wide-angle frame rather than only near the centre.
On-Camera Deep Learning Analytics
A built-in deep learning processing unit runs AXIS Object Analytics directly on the camera for human and vehicle classification, removing the need for server-side processing resources. AXIS Fence Guard, Loitering Guard, Motion Guard, and Speed Monitor extend rule-based event configuration at the camera level, reducing irrelevant alert volume and supporting faster forensic search.
4 Built-In Microphones with Voice Enhancer
Four integrated microphones with voice enhancer and noise suppression capture audio across the full panoramic scene. This adds investigative context to incidents and interactions that video alone may not fully convey, making the camera particularly practical in retail environments, school common areas, reception spaces, and hospitality venues where ambient noise is a constant factor.
Lightfinder, Forensic WDR, and OptimizedIR
Axis Lightfinder maintains colour detail at 0.19 lux in near-dark conditions. Forensic WDR handles high-contrast mixed-light scenes without washing out bright zones or losing shadow detail. Built-in IR with OptimizedIR extends monitoring capability into complete darkness, covering the full range of real-world lighting conditions the camera is likely to encounter across indoor and outdoor locations.
Axis Edge Vault Cybersecurity and Outdoor Durability
Axis Edge Vault hardware-based security, signed OS, and secure boot protect the camera against firmware tampering and credential theft at the hardware level. IP66 weather resistance, IK10 vandal resistance, and operation across -40 degrees Celsius to 50 degrees Celsius support exposed outdoor mounting alongside regulated indoor environments where network device integrity is a compliance requirement.
Best For
- Open-Area Overview Monitoring: Ceiling-mounted 360-degree coverage suits retail shop floors, school common areas, building foyers, and large open spaces where activity in all directions must be captured from a single mounting point using the full 12MP panoramic image.
- Entrance and Corridor Surveillance: Wall-mounted 180-degree coverage suits building entries, reception areas, corridors, and external access points where movement along a defined approach needs to be observed comprehensively without installing multiple cameras.
- Sites Requiring Audio Context: The 4 built-in microphones with voice enhancer and noise suppression make the AXIS M4308-PLE practical wherever audio capture adds investigative or situational value alongside panoramic video, including retail counters, school spaces, and public-facing foyers.
- Installations Prioritising On-Camera Analytics: AXIS Object Analytics and AXIS Scene Metadata run on the camera using its built-in deep learning unit, making this model suited to sites where server processing overhead needs to be minimised and faster forensic search across panoramic footage is a priority.
- Outdoor Panoramic Coverage in Demanding Conditions: IP66 weather protection, IK10 vandal resistance, and the broad operating temperature range support deployment at covered walkways, commercial exteriors, and exposed access points where panoramic visibility must be maintained through weather exposure and physical impact risk.
Why Choose the AXIS M4308-PLE
What sets the AXIS M4308-PLE apart from standard panoramic cameras is the combination of a 12MP stereographic lens with Sharpdome 360, 4 built-in microphones with voice enhancer, and an on-camera deep learning processing unit handling AXIS Object Analytics, AXIS Fence Guard, Loitering Guard, and Speed Monitor without adding load to the recording server. Where a basic fisheye dome delivers distorted outer edges and no audio capture, the AXIS M4308-PLE maintains sharpness toward the limits of the panoramic frame and records audio context across the full scene simultaneously. Forensic WDR handles the mixed-light conditions common to foyers, retail floors, and building entries, while Lightfinder at 0.19 lux and OptimizedIR extend usable monitoring into very low light and complete darkness. Axis Edge Vault hardware-based cybersecurity with signed OS and secure boot addresses protection standards that entry-level network cameras do not meet. Available through Security Wholesalers, the AXIS M4308-PLE suits projects requiring a single compact dome to consolidate panoramic coverage, multi-channel audio, on-camera analytics, and outdoor durability from one installation point.
Buyer Decision Tips
Mounting Position Determines the Coverage Mode: The AXIS M4308-PLE delivers a full 360-degree overview only when ceiling mounted, with the lens facing straight down. Wall mounting repositions the lens to face outward and produces a 180-degree view suited to entrances, corridors, and directional approaches. Decide the mounting position before installation, and use the digital roll feature afterward to fine-tune image orientation without physically rotating the camera body.
No Optical Zoom on a Fixed Panoramic Lens: The 1.3mm stereographic lens is fixed and captures the full panoramic scene at all times. Digital PTZ allows operators to inspect areas of interest within the recorded image, but no optical magnification is available. If a specific distant subject needs to be monitored in close detail rather than as part of a broad overview, a fixed or varifocal lens camera aimed at that zone will produce better magnified results for that defined target.
Key Features & Technical Specifications
| Model |
AXIS M4308-PLE |
| Part Number |
02100-001 |
| Product Type |
Outdoor-Ready Panoramic Dome Network Camera |
| Image Sensor |
1/1.7″ CMOS |
| Resolution |
12MP, 2880 x 2880 maximum |
| Frame Rate |
25/30 fps |
| Lens |
1.3mm fixed stereographic lens |
| Field of View |
183° horizontal, 183° vertical |
| Coverage Modes |
360° overview (ceiling mount), 180° overview (wall mount) |
| Minimum Illumination |
0.19 lux colour, 0.04 lux black and white |
| Low-Light Technology |
Axis Lightfinder |
| Wide Dynamic Range |
Forensic WDR |
| IR Illumination |
Built-in IR with OptimizedIR |
| Compression |
H.264, H.265, Axis Zipstream |
| Analytics |
AXIS Object Analytics, AXIS Scene Metadata, AXIS Image Health Analytics, AXIS Speed Monitor, AXIS Video Motion Detection, AXIS Fence Guard, AXIS Loitering Guard, AXIS Motion Guard |
| Deep Learning |
Built-in deep learning processing unit |
| Built-In Microphones |
4 built-in microphones with voice enhancer and noise suppression |
| Digital PTZ and Digital Roll |
Yes |
| Local Storage |
Memory card slot supported |
| Power |
Power over Ethernet (PoE) |
| IP Rating |
IP66 |
| Vandal Rating |
IK10 (IR window IK09) |
| Operating Temperature |
-40 °C to 50 °C |
| Cybersecurity |
Axis Edge Vault, signed OS, secure boot |
| Sustainability |
PVC free |
Ideal Use Cases
Retail Shop Floors
A ceiling-mounted AXIS M4308-PLE covers aisles, queue lines, service counters, and entry points in a 360-degree overview from a single position. The 4 built-in microphones with voice enhancer capture audio context around customer interactions and incidents that video footage alone may not fully document for investigation or dispute resolution.
School Common Areas and Walkways
With 12MP panoramic resolution and on-camera deep learning classifying humans, this camera suits school foyers, covered external walkways, library spaces, and administration areas where broad coverage and classification-based alerting are both needed from a compact ceiling or wall-mount installation without placing processing demand on a central server.
Office Foyers and Lift Lobbies
The compact dome profile suits commercial interiors where camera aesthetics are a consideration alongside monitoring coverage. Digital roll corrects image orientation post-installation in lift lobbies, waiting areas, and reception spaces without requiring physical adjustment, and AXIS Object Analytics filters motion events in high foot-traffic environments to reduce irrelevant alerts.
Outdoor Building Entrances
IP66 weather resistance, IK10 vandal resistance, and built-in IR with OptimizedIR allow the AXIS M4308-PLE to cover external doorways, access-controlled entry points, and covered outdoor approaches where 180-degree panoramic visibility must be maintained through weather exposure, physical impact risk, and low-light or no-light conditions after dark.
Hospitality Lobbies and Public Concourses
Hotel lobbies, transit waiting areas, shopping centre concourses, and commercial public spaces benefit from the 360-degree overview and multi-microphone audio capture. Forensic WDR handles the mixed natural and artificial lighting typical of these environments, maintaining usable detail in both the brightest and darkest areas of the panoramic frame simultaneously.
Regulated and Cybersecurity-Sensitive Sites
Axis Edge Vault hardware security, signed OS, and secure boot make the AXIS M4308-PLE relevant to government facilities, healthcare environments, financial institutions, and other deployments where network camera cybersecurity and tamper resistance form part of the site compliance or procurement specification.
Choosing the Right Model
- Choose this model if: You need a single outdoor-rated dome camera to deliver 360-degree or 180-degree panoramic coverage with 12MP resolution, 4 built-in microphones with voice enhancer, on-camera deep learning analytics, and hardware-based cybersecurity from one compact mounting point.
- Choose a different model if: Your installation requires optical zoom to monitor a specific distant target in close detail rather than capturing a broad panoramic overview. A fixed or varifocal lens camera aimed at that target will produce better magnified detail for a defined zone than the fixed 1.3mm stereographic lens designed for full-scene panoramic coverage.
- Choose a different model if: The site relies on analogue or HD-over-coax cabling infrastructure. The AXIS M4308-PLE is a network camera powered by PoE and requires an IP-based recording system and compatible network infrastructure to operate.
FAQs
- What is the practical difference between ceiling and wall mounting on the AXIS M4308-PLE?
Ceiling mounting positions the 1.3mm stereographic lens facing straight down, producing a complete 360-degree overview that covers all directions simultaneously from one point. Wall mounting positions the lens to face outward, producing a 180-degree view suited to monitoring a building entry, corridor, or outdoor approach along a defined direction. The digital roll feature allows image orientation to be corrected post-installation without physically repositioning the camera body after it has been fitted and cabled.
- How does the stereographic lens improve on a standard fisheye design at 12MP?
A standard fisheye lens projects the panoramic image in a way that sacrifices practical resolution toward the outer edges of the frame. The stereographic lens in the AXIS M4308-PLE is specifically designed to prioritise sharpness toward those outer areas rather than concentrating detail at the centre. Sharpdome 360 further improves sharpness across the full 2880 x 2880 pixel scene, making subjects toward the limits of the panoramic frame more identifiable than they would be on a conventional fisheye camera of equivalent total resolution.
- Which analytics applications run directly on the AXIS M4308-PLE without server processing?
All listed analytics run on the camera using its built-in deep learning processing unit. These include AXIS Object Analytics for human and vehicle classification, AXIS Scene Metadata, AXIS Image Health Analytics, AXIS Speed Monitor, AXIS Video Motion Detection, AXIS Fence Guard, AXIS Loitering Guard, and AXIS Motion Guard. Rule-based event triggers and classification-based filtering are all handled at the camera level, reducing the processing load placed on the recording server or VMS in use at the site.
- How effectively do 4 microphones cover the wide area captured by a panoramic lens?
The multi-microphone configuration is designed to capture audio across the broad area covered by the panoramic lens rather than relying on a single directional microphone that favours one zone. Voice enhancer improves speech clarity within the recorded audio, and noise suppression reduces ambient background interference. This is particularly relevant in environments such as retail floors, school common areas, and public foyers where ambient noise levels would otherwise reduce the investigative value of the recorded audio alongside the panoramic video.
- What outdoor conditions is the AXIS M4308-PLE rated to handle?
The camera is rated IP66 for weather protection, IK10 for vandal resistance overall with the IR window rated IK09, and is specified to operate across -40 degrees Celsius to 50 degrees Celsius. Built-in IR with OptimizedIR supports monitoring in complete darkness outdoors. This combination suits covered building entrances, exposed commercial walkways, outdoor access-controlled entry points, and external areas where both weather resistance and physical impact resistance are required alongside panoramic imaging.
- What does Axis Edge Vault protect in the AXIS M4308-PLE, and which sites does this matter for?
Axis Edge Vault is a hardware-based secure element built into the camera that protects cryptographic keys, the device identity certificate, and signed firmware. Combined with a signed OS and secure boot, it prevents unauthorised firmware from executing on the device and protects against credential theft and hardware-level tampering. This level of camera cybersecurity is relevant to government facilities, healthcare environments, financial institutions, and any deployment where network device integrity is part of the site compliance or procurement specification. The AXIS M4308-PLE is part of the Security Wholesalers range for projects where these standards apply.
- How does Axis Zipstream manage storage requirements for continuous 12MP panoramic recording?
Axis Zipstream with H.264 and H.265 dynamically reduces the bitrate applied to low-detail and static areas of the panoramic footage while preserving full detail around motion and objects of interest. A continuous 12MP panoramic stream produces significantly more data than a standard fixed-lens camera, and Zipstream can substantially reduce storage and bandwidth consumption across a recording system without discarding the image detail required for forensic review, analytics processing, or event playback after an incident.
