Axis Q6135-LE 2MP PTZ Camera, H.264/65, 32x Zoom, 50HZ, WDR, IP66, NEMA 4X & NEMA TS2 01958-006‍‌​​​‌‌‌‌‌‌​​‌‌​​​‍

Product SKU: Q6135-LE

Product Overview

Wide-area outdoor surveillance across unlit parks, ports, transit hubs, and large perimeters demands a camera that can both sweep a scene and resolve fine detail at distance without supplementary lighting. The Axis Q6135-LE is an outdoor PTZ dome camera built precisely for those conditions. Equipped with a 1/2.8-inch CMOS sensor delivering HDTV 1080p at up to 60 fps, it combines 32x optical zoom with Lightfinder 2.0 for colour imaging down to approximately 0.06 lux, and optimised IR illumination reaching up to around 250 metres for complete darkness operation. Sharpdome technology extends the usable tilt range to 20 degrees above the horizon without image degradation, while Autotracking 2 with click-to-track keeps the camera locked onto moving subjects automatically. Rated IP66, IP67, IK10, NEMA 4X, and NEMA TS2, with Arctic temperature control enabling operation from -50 degrees Celsius, the Q6135-LE is engineered for installation in environments where most PTZ cameras would fail.

Key Capabilities

Best For

• Large Unlit Outdoor Areas: Optimised IR reaching approximately 250 metres and Lightfinder 2.0 at 0.06 lux allow effective surveillance across parks, harbours, and open land without external lighting infrastructure.
• Perimeter and Critical Infrastructure Monitoring: Autotracking 2, 32x optical zoom, and Guard Suite fence guard analytics enable proactive detection and tracking of intruders along boundaries at substations, ports, and transport facilities.
• High-Detail Subject Identification at Distance: The 32x optical zoom and 60 fps capture rate allow operators to resolve vehicle plates, facial detail, and other identifying information from significant distances, even during fast movement.
• Extreme Climate Installations: Arctic temperature control rated to -50 degrees Celsius and wind resistance to 55 m/s make the Q6135-LE suitable for coastal, alpine, or desert environments where standard PTZ cameras cannot operate reliably.
• Public Space and Event Venue Coverage: 256 preset positions, guard tours, and tour recording allow operators to program comprehensive scene sweeps across stadiums, transit centres, and campuses, with Autotracking 2 taking over when motion is detected.

Why Choose the Axis Q6135-LE

The Q6135-LE addresses a specific gap in outdoor PTZ performance: the ability to operate effectively in complete darkness at long range without relying on external lighting or sacrificing the agility of a motorised PTZ. Where standard outdoor PTZ cameras typically offer IR ranges of 30 to 80 metres, the Q6135-LE extends to approximately 250 metres with optimised IR, while Lightfinder 2.0 retains usable colour footage down to 0.06 lux. The FIPS 140-2 Level 2 certified TPM and secure boot architecture go beyond what most commercial PTZ cameras offer, which matters on government, infrastructure, and critical site deployments with cybersecurity mandates. Sharpdome technology solves the distortion problem common to dome-based PTZ cameras when tilting above the horizon, retaining image quality in elevated mounting scenarios. Available at Security Wholesalers, the Q6135-LE suits deployments where a simpler fixed or budget PTZ camera would leave coverage gaps that cannot be compensated by adding more cameras.

Buyer Decision Tips

Key Features & Technical Specifications

Ideal Use Cases

Choosing the Right Model

• Choose this model if: You need outdoor PTZ coverage of large unlit areas with IR reach to approximately 250 metres, autotracking of moving subjects, and a hardened housing rated for extreme temperatures, coastal exposure, or wind-prone environments where standard PTZ units would not be suitable.
• Choose a different model if: Your site requires simultaneous multi-zone coverage without operator control, in which case fixed wide-angle or multi-sensor cameras will provide continuous coverage that a PTZ cannot match, since the Q6135-LE covers only one direction at any given time. A simpler fixed-lens camera is also more cost-effective where zoom and pan-tilt functionality are not required for the monitored area.

FAQs

1. What is the effective IR range of the Q6135-LE and does it need external lighting at night?
   The Q6135-LE uses optimised IR illumination that reaches approximately 250 metres, which is significantly further than most commercial PTZ cameras. Combined with Lightfinder 2.0 for colour imaging at approximately 0.06 lux, the camera can operate in near-dark and fully dark conditions without any external floodlighting, making it suited to unlit parks, harbours, and remote perimeter sites.
2. How does Sharpdome technology affect installation planning?
   Standard dome PTZ cameras experience image distortion when tilting above the horizontal plane, which limits their usefulness on elevated mounts or near building edges. Sharpdome technology on the Q6135-LE maintains image sharpness up to 20 degrees above the horizon, meaning the camera can be mounted higher without losing usable detail when looking toward the horizon or slightly upward.
3. What does FIPS 140-2 Level 2 certification mean for this camera?
   FIPS 140-2 Level 2 is a US federal cybersecurity standard for cryptographic modules. On the Q6135-LE, the TPM module meets this certification alongside secure boot and signed firmware. For deployments on government sites, critical infrastructure, or projects with formal cybersecurity compliance requirements, this certification provides documented assurance of hardware-level security against tampering and key extraction.
4. What power supply does the Q6135-LE require?
   The camera requires PoE+ (IEEE 802.3at, Class 4) or an AC power source. Standard PoE (802.3af) switches do not supply sufficient wattage and will not power the unit. Installers must confirm their network switch or PoE injector supports Class 4 PoE+ before installation. An AC power option is available where running high-power PoE to a remote mounting location is not practical.
5. Can the Q6135-LE operate in extreme cold or coastal environments?
   Yes. The Arctic temperature control feature enables camera startup at -50 degrees Celsius and stable operation across the full -50 to +50 degrees Celsius range. The NEMA 4X rating covers resistance to windblown dust and rain, and the wind resistance specification of 55 m/s makes the unit suitable for coastal and exposed pole-mount deployments where standard IP66-rated cameras would be at risk.
6. What analytics run on the camera itself rather than on an external server?
   AXIS Object Analytics runs on the ARTPEC-7 processor embedded in the Q6135-LE, providing on-device detection and classification of people and vehicles. Guard Suite applications including motion detection, loitering guard, fence guard, and object removal are also built in. This means analytics triggers and Autotracking 2 responses do not depend on a connected server, which improves response times and reduces bandwidth requirements. This is part of the Q6135-LE range available through Security Wholesalers.
7. How many simultaneous video streams can the Q6135-LE deliver?
   The camera supports up to 20 configurable video streams across H.265, H.264, and Motion JPEG formats, with Axis Zipstream reducing bandwidth and storage consumption while preserving detail in motion and high-contrast areas. Variable bitrate, average bitrate, maximum bitrate, and low-latency streaming modes are all available, giving system integrators flexibility in balancing storage capacity against image quality across different monitoring priorities.

Additional Information

• AXIS Q6135-LE Datasheet

{
