Product SKU: P5655-E
Product Overview
Covering a large outdoor site from a single camera position is where the AXIS P5655-E earns its specification. This outdoor PTZ network camera is built around a 32x optical zoom lens spanning 4.3 to 137.6mm, shifting between a 58.3-degree wide overview and a 2.4-degree telephoto position for close inspection of vehicles, pedestrians, or access points at a significant distance from the mount. Equipped with Lightfinder 2.0 for colour imaging down to 0.1 lux, Forensic WDR for high-contrast scenes, and Autotracking 2 for unmanned movement following, it maintains useful footage across variable conditions without relying on constant operator control. It also integrates Electronic Image Stabilisation, Focus Recall, H.264 and H.265 compression with Axis Zipstream, and a full complement of I/O connectivity. Built to IP66, NEMA 4X, and IK10 standards with an operating range of -30 degrees C to 50 degrees C, the AXIS P5655-E is suited to commercial, industrial, and public-space PTZ deployments across demanding Australian conditions.
Key Capabilities
32x Optical Zoom with 4.3-137.6mm Varifocal Lens
Optical zoom preserves image quality as the camera narrows its field of view, unlike digital zoom which degrades resolution. Moving from a 58.3-degree wide position to a 2.4-degree telephoto gives operators genuine long-range reach to inspect distant gates, vehicles, or personnel without losing the detail needed for post-event review.
Autotracking 2 for Autonomous Movement Detection
Autotracking 2 directs the PTZ to detect and follow moving subjects across the scene without manual operator input. For perimeter zones, open yards, and public areas where staffing is intermittent or overnight monitoring is unattended, this keeps the camera actively responding to movement rather than holding a static preset.
Lightfinder 2.0 and Forensic WDR
Lightfinder 2.0 delivers colour images at 0.1 lux, supporting useful detail in low-ambient outdoor scenes where entry-level cameras switch to monochrome. Forensic WDR addresses simultaneous bright and dark areas in the same frame, such as backlit vehicle entrances, mixed streetlighting, and shaded versus open zones within a single wide view.
Electronic Image Stabilisation and Focus Recall
At the telephoto end of a 32x zoom, even minor vibration from wind or industrial machinery becomes visible as blur. Electronic Image Stabilisation compensates for this on exposed pole and elevated mounts. Focus Recall returns each preset position to sharp focus quickly after repositioning, reducing the delay between moving the camera and obtaining a usable image.
H.264, H.265, and Axis Zipstream Compression
Zipstream dynamically lowers bitrate in low-activity areas of the frame while retaining full detail where forensic quality is needed. On multi-camera commercial systems where PTZ streams run continuously, this has a practical compounding effect on both storage volume and network bandwidth over extended recording periods.
IP66, NEMA 4X, IK10, and Cybersecurity Architecture
IP66 and NEMA 4X address dust ingress and water exposure including corrosive environments. IK10 adds resistance to physical impact at publicly accessible or industrial mounting locations. An operating range of -30 degrees C to 50 degrees C, signed OS, and secure boot form a protection profile suited to long-term professional network deployments in harsh outdoor conditions.
Best For
- Large Outdoor Sites Requiring Single-Point Coverage Across Multiple Zones: Pan, tilt, and 32x optical zoom allow one AXIS P5655-E to serve car parks, building approaches, access roads, and open yards from an elevated mount, reducing the number of fixed camera positions required across a large footprint.
- Perimeter and Fence Line Monitoring with Autotracking: Autotracking 2 follows movement along open boundaries without manual operator direction, making the camera relevant for large perimeter zones where continuous staffed monitoring is not practical after hours.
- Exposed or Vibration-Prone Mounting Positions: Electronic Image Stabilisation compensates for blur caused by wind load, nearby heavy machinery, or structural movement on industrial and elevated mounts, particularly at longer focal lengths where vibration is most visible.
- Sites with Low Ambient Light but Some External Illumination: Lightfinder 2.0 at 0.1 lux colour and 0.01 lux monochrome supports usable imaging in poorly lit conditions, suitable for sites with partial pole lighting, spill from buildings, or ambient street lighting where complete darkness does not occur.
- Multi-Camera Networked Systems Where Storage Is a Consideration: Zipstream with H.265 reduces per-stream storage and bandwidth requirements, which has a meaningful effect on recorder sizing and network load when multiple continuous PTZ feeds run alongside fixed camera streams on the same system.
Why Choose the AXIS P5655-E
The AXIS P5655-E addresses a specific gap that fixed-lens cameras and short-range varifocals cannot fill: long-range optical zoom combined with autonomous tracking, vibration compensation, and professional outdoor protection in a single unit. The 32x optical zoom from 4.3 to 137.6mm gives genuine reach to inspect vehicles and personnel at distances where standard cameras cannot resolve meaningful detail. Autotracking 2 reduces the need for constant operator control across large or unmanned sites. Focus Recall and Electronic Image Stabilisation tackle two practical PTZ limitations that affect footage quality in real-world installations: slow refocusing between presets and blur at long focal lengths on exposed mounts. Lightfinder 2.0 and Forensic WDR extend imaging capability across mixed and low-ambient outdoor lighting conditions. The IP66, NEMA 4X, and IK10 ratings, paired with an operating range extending to -30 degrees C, reflect the durability level expected from a professional outdoor PTZ. Available at Security Wholesalers, the AXIS P5655-E is a well-specified option for projects where wide-area coverage, autotracking, and long-range zoom are all required from the same device.
Buyer Decision Tips
Buyer Tip – No Built-In IR Illumination: The AXIS P5655-E does not include built-in infrared illumination. Lightfinder 2.0 performs well in low-ambient conditions but requires some available light to function. Sites with genuinely no light source after hours, such as unmanned perimeter zones, remote fence lines, or car parks without pole lighting, will require external supplementary illumination to be planned into the installation. Confirm ambient light levels at each intended deployment position before finalising this camera for complete-darkness monitoring scenarios.
Buyer Tip – PTZ Coverage Is Sequential, Not Simultaneous: The AXIS P5655-E can monitor a wide physical area but only in one direction at any given moment. For critical monitoring points that must be recorded continuously at the same time, such as multiple building entrances that all need uninterrupted footage, supplementing the PTZ with fixed cameras at those locations will deliver more reliable coverage than relying on the PTZ alone. Plan how the camera will be used operationally across a full day and night cycle before committing to it as the sole coverage solution for any fixed critical position.
Key Features & Technical Specifications
| Model |
AXIS P5655-E |
| Part Number |
01681-001 |
| Product Type |
Outdoor PTZ Network Camera |
| Maximum Video Resolution |
1920 x 1080 (HDTV 1080p) |
| Maximum Frame Rate |
Up to 50/60 fps |
| Image Sensor |
1/2.8″ CMOS |
| Lens |
4.3-137.6mm varifocal |
| Optical Zoom |
32x |
| Digital Zoom |
12x |
| Aperture |
F1.4-4.0 |
| Horizontal Field of View |
58.3 degrees (wide) to 2.4 degrees (telephoto) |
| Minimum Illumination |
0.1 lux colour / 0.01 lux black and white |
| Low-Light Technology |
Lightfinder 2.0 |
| Wide Dynamic Range |
Forensic WDR |
| Image Stabilisation |
Electronic Image Stabilisation |
| Focus Support |
Focus Recall |
| Autotracking |
Autotracking 2 |
| Compression |
H.264, H.265, Axis Zipstream |
| Built-In IR |
No |
| Power |
PoE+ and 24V AC/DC |
| Outdoor Rating |
IP66, NEMA 4X |
| Vandal Rating |
IK10 |
| Operating Temperature |
-30 degrees C to 50 degrees C |
| Cybersecurity |
Signed OS and secure boot |
| I/O Ports |
Supported |
| Scene Profiles |
Indoor, outdoor, forensic, and traffic profiles |
Ideal Use Cases
Car Parks and Vehicle Entry Points
32x optical zoom allows a single elevated camera to inspect vehicle detail, monitor pedestrian movement between bays, and direct attention to entry and exit lanes without needing fixed cameras at every position. PTZ control provides flexibility to redirect coverage as activity patterns change throughout the day.
Industrial Yards and Loading Dock Areas
IP66, NEMA 4X, and IK10 ratings support deployment in environments with dust, moisture, chemical exposure, and physical impact risk. Electronic Image Stabilisation addresses blur from nearby machinery and heavy vehicle movement, which becomes particularly visible at longer focal lengths on mounts near active loading and unloading operations.
Open Perimeter and Fence Line Monitoring
Autotracking 2 follows movement across open ground and along fence lines without requiring an operator to direct the PTZ manually. From an elevated corner position, the 32x optical zoom extends the effective inspection distance to cover large site boundaries where fixed cameras at fence intervals would otherwise be required.
Public Spaces, Plazas, and Transport Hubs
Forensic WDR and Lightfinder 2.0 handle the variable and rapidly changing lighting found in open pedestrian areas and transit drop-off zones. The traffic scene profile assists at camera positions near roadways, and IK10 provides resistance to impact at publicly accessible mounting heights where accidental or deliberate contact is more likely.
Multi-Zone Commercial Property Monitoring
A single AXIS P5655-E can serve building approaches, shared outdoor areas, and access roads across a commercial property using preset zones and Autotracking 2. Zipstream compression with H.265 keeps storage and bandwidth demands manageable across sites running several continuous streams alongside fixed camera feeds on the same recorder.
Choosing the Right Model
- Choose this model if: Your installation requires wide-area PTZ coverage with 32x optical zoom, Autotracking 2, Lightfinder 2.0, Forensic WDR, and vibration compensation across outdoor environments such as car parks, industrial yards, perimeter zones, or commercial properties where a single camera must serve multiple monitoring roles at varying distances.
- Choose a different model if: Your site has no ambient light source after hours and complete-darkness monitoring is a hard requirement, as the AXIS P5655-E does not include built-in IR. A PTZ camera with integrated IR illumination would be a more appropriate fit for that scenario. If simultaneous uninterrupted recording of several fixed critical points is the primary need, fixed cameras at those positions will provide more consistent continuous coverage than a PTZ operating sequentially between presets.
FAQs
- What does the 32x optical zoom on the AXIS P5655-E enable that a standard fixed camera cannot?
Optical zoom narrows the field of view while retaining resolution, unlike digital zoom which simply enlarges pixels. Moving from a 58.3-degree wide-area view to a 2.4-degree telephoto position means an operator can resolve detail on vehicles, people near access points, or movement along a distant fence line that would appear as indistinguishable shapes on a fixed wide-angle camera mounted at the same position.
- How does Autotracking 2 function and what configuration does it require?
Autotracking 2 uses onboard processing to detect movement within a defined zone and direct the PTZ to follow the subject. During commissioning, the installer configures detection areas, sensitivity thresholds, and the behaviour the camera adopts after tracking ends or a subject leaves the scene. Once set up, it operates independently without manual joystick input, which is particularly relevant for sites with intermittent staffing or overnight unattended monitoring requirements.
- Does the AXIS P5655-E require PoE+ or will a standard PoE switch work?
The AXIS P5655-E requires PoE+ (802.3at) for network-powered operation. The PTZ motor, pan and tilt drive, and processing load exceed the 15.4W ceiling of standard 802.3af PoE. If your switch only supports standard PoE, you will need either a PoE+ capable switch or a mid-span PoE+ injector at that port. A 24V AC/DC supply is also supported as an independent power option where a direct electrical connection is available.
- Why does the AXIS P5655-E include Electronic Image Stabilisation and when does it matter?
At 32x optical zoom, even small amounts of physical movement at the camera mount produce visible blur in the recorded image. Wind load on an elevated pole, vibration from nearby industrial machinery, or structural flex on a building parapet all contribute to this. Electronic Image Stabilisation compensates for that movement in real time, keeping footage usable at long focal lengths in mounting conditions where physical vibration cannot be eliminated through bracket selection alone.
- What is the purpose of the traffic scene profile on the AXIS P5655-E?
The traffic scene profile adjusts shutter and exposure settings to reduce motion blur on fast-moving vehicles passing through the frame. This is relevant for camera positions near roadways, entrance gates, or drive-through areas where vehicles at speed would otherwise appear blurred under standard scene settings. The forensic profile is a separate option that prioritises image settings for post-event review usability rather than real-time display quality.
- What cybersecurity protections are built into the AXIS P5655-E?
The camera includes a signed operating system and secure boot, which verify that the firmware has not been altered and that only authenticated software runs on the device at startup. These are network-level protections relevant to professional installations where cameras are integrated into managed enterprise or government networks. Axis also provides ongoing firmware updates through its standard support process to address security vulnerabilities identified after deployment.
- Where can the AXIS P5655-E be purchased in Australia?
The AXIS P5655-E is supplied by Security Wholesalers, which distributes Axis Communications products to security integrators and installers across Australia. Purchasing through an authorised supply channel supports access to the applicable manufacturer warranty and Axis support processes for network cameras supplied into the Australian market.
