Axis Q1805-LE replaced Q1785-LE Network Camera, HDTV 1080p, 80m IR, Zipstream, WDR, PoE, 4.3-137mm

$2,790.00

FREE DELIVERYWARRANTY GUARANTEED

✔ Dedicated 5★ Customer Care Team ✔ Fast & Responsive Tech Support

The AXIS Q1805-LE delivers a high-performance 2MP bullet camera solution designed for long-distance identification across perimeter, commercial, industrial, and critical infrastructure sites. Featuring HDTV 1080p imaging, 32x optical zoom, OptimizedIR up to 100m, and a 4.3-137mm varifocal lens, it provides strong detail at distance with flexible scene coverage. It also includes deep learning analytics, AXIS Object Analytics, Lightfinder 2.0, Forensic WDR, and Zipstream with H.264/H.265 support. Built with IP66/IP67 weather protection, IK10 body impact resistance, electronic image stabilisation, and PoE support, it is suited to demanding outdoor surveillance environments.

Key Features

2MP HDTV 1080p Imaging: Captures clear video for reliable monitoring and identification.
32x Optical Zoom: Supports long-distance surveillance while maintaining usable image detail.
OptimizedIR 100m: Provides infrared illumination for visibility in complete darkness.
Deep Learning Analytics: Enables intelligent object classification and edge-based analytics.
Zipstream Compression: Reduces bandwidth and storage requirements using H.264/H.265.
Outdoor-Rated Protection: IP66/IP67 and IK10 body ratings support harsh outdoor installations.

Additional Information

Datasheet-axis-q1805-le-bullet-camera

$2,790.00 inc GST +5 Year Warranty & Support

Description

Product SKU: Q1805-LE

Product Overview

Long-range outdoor identification across perimeter fence lines, industrial yards, and extended access roads is where the AXIS Q1805-LE is built to operate. This outdoor bullet camera combines a 4.3-137mm motorised varifocal lens with 32x optical zoom and HDTV 1080p resolution at up to 90 frames per second, giving installers a high-frame-rate imaging platform for locations where fixed-lens cameras cannot resolve the detail required. Equipped with built-in OptimizedIR reaching 100m, Lightfinder 2.0 for colour retention in near-darkness, and Forensic WDR for scenes with mixed or difficult lighting, the Q1805-LE maintains usable image quality across a wide range of outdoor conditions. It also integrates AXIS Object Analytics supported by an onboard deep learning processing unit, Zipstream compression in H.264 and H.265, electronic image stabilisation for exposed pole-mounted positions, and PoE-out for powering compatible accessories at the camera point. Rated IP66, IP67, and IK10 with an operating range from -40 degrees Celsius to 60 degrees Celsius, it serves as the current-generation replacement for AXIS Q1785-LE installations.

Key Capabilities

32x Optical Zoom Across a 4.3-137mm Varifocal Range

The motorised varifocal lens shifts from a 60-degree wide-angle view to a 2.3-degree telephoto at the far end, allowing this camera to be positioned well back from gates, perimeter lines, and road entries while still delivering identifiable detail. Remote zoom adjustment avoids the need to physically reposition the unit after installation.

OptimizedIR Illumination to 100m

Built-in OptimizedIR delivers black-and-white coverage in complete darkness across distances up to 100m. The illumination level adjusts automatically to match the current zoom position, reducing overexposure at closer range while sustaining usable detail further down a driveway, access road, or perimeter approach.

HDTV 1080p at up to 90 fps

With 1920 x 1080 resolution at up to 90 frames per second, the Q1805-LE captures smooth footage of vehicles and personnel at speed. The elevated frame rate is particularly valuable at transport corridors, controlled entry points, and industrial zones where motion clarity is needed for post-incident review.

AXIS Object Analytics with Deep Learning Onboard

A dedicated deep learning processing unit enables AXIS Object Analytics to classify objects including people and vehicles directly on the camera without relying on server-side processing. This reduces irrelevant event triggers across large outdoor sites and makes forensic search faster when reviewing incidents after the fact.

Electronic Image Stabilisation for Exposed Mounting

Pole-mounted and rooftop cameras are particularly vulnerable to vibration from wind and structural movement. Electronic image stabilisation actively compensates for this, keeping footage usable in exposed outdoor positions where camera shake would otherwise degrade video quality during adverse weather or high-traffic periods.

PoE with PoE-Out and Axis Edge Vault

Single-cable PoE Class 4 installation simplifies large-site deployment. PoE-out lets the camera power a compatible strobe, siren, or speaker at the same mounting point. Axis Edge Vault provides hardware-level cybersecurity including secure key storage, HTTPS encryption, and IEEE 802.1X network authentication for sites with network integrity requirements.

Best For

Perimeter and Fence Line Coverage: The 32x optical zoom and 100m OptimizedIR allow a single camera to cover extended boundary approaches and fence lines from one fixed mounting point, identifying activity at distances beyond the reach of standard outdoor cameras.
Industrial Yards and Logistics Sites: IP66, IP67, and IK10 body protection combined with an operating range down to -40 degrees Celsius make this camera suitable for freight yards, container storage areas, loading docks, and exposed manufacturing sites.
Vehicle Access Roads and Controlled Entry Points: Up to 90 fps at HDTV 1080p resolution, combined with the telephoto zoom range, supports clear capture of vehicle movement along driveways and access corridors from standoff distances that keep the camera clear of site traffic.
Critical Infrastructure Sites: Axis Edge Vault cybersecurity, IEEE 802.1X authentication, and AXIS Object Analytics make this camera well suited to utilities, water treatment facilities, transport hubs, and compounds where both outdoor durability and network security are required.
AXIS Q1785-LE Replacement Projects: Sites migrating away from the Q1785-LE can use the Q1805-LE as the current-generation equivalent, gaining updated analytics, Zipstream compression, PoE-out, and Axis Edge Vault within the same outdoor bullet form factor.

Why Choose the AXIS Q1805-LE

What separates the AXIS Q1805-LE from a standard outdoor bullet camera is the combination of 32x optical zoom, 100m OptimizedIR, HDTV 1080p at up to 90 fps, and onboard deep learning analytics in a single IK10-rated housing. A shorter-range fixed-lens camera cannot replicate targeted long-distance identification across a perimeter, access road, or industrial yard. The motorised varifocal lens is set once during commissioning and requires no manual repositioning, which matters for cameras installed at height or on exposed structures. Electronic image stabilisation directly addresses the vibration problems that pole-mounted bullet cameras face in windy or high-traffic environments. PoE-out reduces cabling runs when accessories need to be integrated at the camera position, and Axis Edge Vault meets the cybersecurity requirements increasingly expected on commercial and infrastructure sites. Available through Security Wholesalers, the Q1805-LE is a well-specified platform for professional installers who need long-range outdoor capability backed by current-generation analytics and network security.

Buyer Decision Tips

Zoom Range vs Broad-Scene Coverage: The Q1805-LE is optimised for targeted long-range monitoring rather than wide-area full-frame capture. At 4.3mm the horizontal field of view is approximately 60 degrees, suitable for general approach coverage. At 137mm it narrows to approximately 2.3 degrees, suited to pinpointing a gate, entry point, or road corridor at distance. If the requirement is broad-scene high-resolution capture across a wide area at a fixed zoom level, a higher-megapixel multi-sensor or wide-angle camera may deliver more practical full-frame detail for that scenario.

Plan Mounting Position Before Installation: Because the Q1805-LE uses a motorised varifocal lens, the zoom setting should be confirmed during commissioning based on the actual monitoring distance. Establishing the target standoff distance, mounting height, and intended coverage angle before the camera goes up avoids the need to revisit the installation. Verify the IR range requirement against the actual scene depth to confirm 100m OptimizedIR is sufficient for the site layout.

Key Features & Technical Specifications

Model	AXIS Q1805-LE
Product Type	Outdoor Bullet Camera
Replacement Reference	Current replacement option for AXIS Q1785-LE installations
Maximum Video Resolution	1920 x 1080 (HDTV 1080p)
Maximum Frame Rate	Up to 90 fps
Image Sensor	1/2.8″ CMOS
Lens Type	4.3-137mm motorised varifocal
Optical Zoom	32x
Aperture	F1.4-F4.0
Horizontal Field of View	60 degrees (wide) to 2.3 degrees (telephoto)
Vertical Field of View	39 degrees (wide) to 1.3 degrees (telephoto)
Minimum Illumination	0.06 lux colour / 0 lux with IR
IR Illumination	Built-in OptimizedIR up to 100m
Low-Light Technology	Lightfinder 2.0
Wide Dynamic Range	Forensic WDR
Image Stabilisation	Electronic Image Stabilisation
Video Compression	H.264, H.265, Axis Zipstream
Analytics	AXIS Object Analytics, video motion detection, active tampering alarm
Alarm I/O	2 inputs / 2 outputs
Local Storage	Memory card slot supported
Power	Power over Ethernet (PoE Class 4)
PoE-Out	Supports PoE-out for compatible accessories
Weather Protection	IP66, IP67
Impact Resistance	IK10 body, IK08 glass
Operating Temperature	-40 degrees Celsius to 60 degrees Celsius
Cybersecurity	Axis Edge Vault, HTTPS encryption, IEEE 802.1X

Ideal Use Cases

Perimeter Fence Lines and Boundary Approaches

The 32x optical zoom and 100m OptimizedIR allow a single Q1805-LE to identify activity along extended site boundaries from one fixed position. The camera covers both wide approach zones and narrow long-range targets through a single motorised lens rather than requiring multiple fixed-lens cameras across the same boundary.

Freight Yards and Logistics Sites

IP66, IP67, and IK10 body protection alongside a -40 to 60 degree Celsius operating range make this camera appropriate for freight yards, container storage areas, loading docks, and exposed outdoor logistics environments where dust, rain, and temperature variation are ongoing conditions.

Access Roads and Controlled Entry Corridors

Up to 90 fps at HDTV 1080p, combined with the telephoto zoom reach of 137mm, supports clear capture of vehicle movement along driveways and controlled entry points. The camera can be mounted well clear of site traffic while still covering the full entry approach with usable detail.

Critical Infrastructure and Utility Sites

Axis Edge Vault hardware-level cybersecurity, IEEE 802.1X network authentication, and AXIS Object Analytics edge processing suit this camera to utilities, water treatment infrastructure, transport hubs, and secure compounds where outdoor durability and network integrity requirements apply simultaneously.

Pole-Mounted and Exposed Outdoor Positions

Electronic image stabilisation directly addresses the vibration that affects pole-mounted cameras in windy or high-traffic locations. On exposed industrial structures, rooftops, and elevated mounts, this feature maintains consistent footage quality that mechanical fixes or heavy housings alone cannot always deliver.

Choosing the Right Model

Choose this model if: Your site requires long-range targeted identification at perimeter lines, access roads, industrial yards, or entry gates where 32x optical zoom and 100m OptimizedIR are operationally necessary and fixed-lens cameras cannot resolve the required detail at distance.
Choose this model if: You are replacing an existing AXIS Q1785-LE installation and need the current-generation equivalent with updated deep learning analytics, Zipstream compression, PoE-out, and Axis Edge Vault cybersecurity in the same outdoor bullet housing.
Choose a different model if: The requirement is broad-area high-resolution coverage at a fixed zoom level rather than long-range targeted identification. A higher-megapixel wide-angle or multi-sensor camera will typically deliver more usable full-frame detail for wide-scene monitoring without requiring zoom calibration.
Choose a different model if: The installation is indoors or in a sheltered low-impact environment where the outdoor IP66/IP67 and IK10 rating is unnecessary and a more compact camera form factor would be more practical for the space.

FAQs

Is the AXIS Q1805-LE a direct replacement for the AXIS Q1785-LE?
The Q1805-LE is the current replacement option for Q1785-LE installations. It retains the outdoor bullet camera format with 32x optical zoom and long-range IR while introducing AXIS Object Analytics with deep learning, Zipstream H.264/H.265 compression, Lightfinder 2.0, Forensic WDR, PoE-out, and Axis Edge Vault cybersecurity that were not part of the previous generation.
What does 32x optical zoom mean for a perimeter or industrial site installation?
It means the Q1805-LE can transition from a 60-degree wide view covering a broad area to a 2.3-degree telephoto view focused on a specific distant point such as a gate, road entry, or boundary line. This allows the camera to be mounted significantly further away from the monitored location while still capturing identifiable detail, which is useful where proximity mounting is not practical or safe.
How does the OptimizedIR illumination work at different zoom levels?
The built-in OptimizedIR adjusts its output automatically to match the current zoom position. At wider angles, the IR spread covers a broader area at reduced intensity to avoid overexposing subjects at close range. At telephoto settings, the beam narrows and concentrates to maintain coverage at longer distances. The maximum listed range is 100m in complete darkness, though actual performance varies with mounting height, scene reflectivity, and weather conditions.
What analytics are processed on the camera itself?
The Q1805-LE includes a dedicated deep learning processing unit that runs AXIS Object Analytics on the camera edge, enabling object detection and classification of people and vehicles without sending every stream to a server for analysis. It also supports video motion detection and active tampering alarm. This reduces server load and can improve the relevance of alerts on active outdoor sites.
Does the Q1805-LE need a separate power supply at the mounting point?
No. The camera is powered through a single Ethernet cable using Power over Ethernet at PoE Class 4. It also provides PoE-out, which allows a compatible accessory such as a strobe, siren, or speaker to draw power from the camera itself. This reduces the number of separate power cables required at the installation point, which is a practical benefit on large outdoor sites.
Is this camera rated for extreme outdoor temperatures?
Yes. The Q1805-LE operates from -40 degrees Celsius to 60 degrees Celsius, covering both cold climate sites such as southern Australian winters and hot exposed industrial locations. IP66 and IP67 weather ratings provide protection against driven rain, dust ingress, and temporary water immersion. The IK10 body rating adds resistance to physical impact at the housing level.
What cybersecurity features does the Q1805-LE include?
Axis Edge Vault provides hardware-level cybersecurity including a secure key storage element, HTTPS encryption, and support for IEEE 802.1X network authentication. These features are relevant for commercial and critical infrastructure sites where cameras must meet network security policies alongside their surveillance function. The Q1805-LE is part of the Security Wholesalers range, and pre-purchase specification support is available from the team for sites with specific network security requirements.

Additional Information

Datasheet-axis-q1805-le-bullet-camera
